Optimal Reactive Power Dispatch (ORPD) is a power system optimization tool that modifies system control variables such as bus voltage and transformer tap settings, and it compensates devices’ Volt Ampere Reactive (VAR) output. It is used to decrease real power loss, enhance the voltage profile, and promote stability. Furthermore, several issues have been faced in electricity markets, such as price volatility, transmission line congestion, and an increase in the cost of electricity during peak hours. Programs such as demand response (DR) provide system operators with more control over how small customers participate in lowering peak-hour energy prices and demand. This paper presents an extensive study on ORPD methodologies and DR programs for lowering voltage deviation, limiting cost, and minimizing power losses to create effective and economical operations systems. The main objectives of this work are to minimize costs and losses in the system and reduce voltage variation. The Grasshopper Optimization Algorithm (GOA) and Dragonfly Algorithm (DA) have been implemented successfully to solve this problem. The proposed technique has been evaluated by using the IEEE-30 bus system. The results obtained by the implementation of demand response systems show a considerable reduction in costs and load demands that benefit consumers through DR considerations. The results obtained from the GOA and DA are compared with those generated by other researchers and published in the literature to ascertain the algorithm’s efficiency. Full article

Power system stability is of paramount importance in the context of energy sustainability. The reliable and efficient operation of power systems is crucial for supporting modern societies, economies, and the growing demand for electricity while minimizing environmental impact and increasing sustainability. Due to the insufficient effect of power system stabilizers (PSSs) on damping the inter-area mode oscillations, Flexible AC Transmission System (FACTS) devices are utilized for damping this mode and stabilizing power systems. In the present study, a novel optimization framework considering different and variable weight coefficients based on eigenvalue locations is presented, and the parameters of PSS and variable impedance devices, including static Volt-Ampere Reactive (VAR) compensator (SVC) and Thyristor-Controlled Series Compensator (TCSC) (comprising amplifying gain factor and time constants of phase-compensating blocks), are optimized in a coordinated manner using the proposed optimization framework built based on genetic algorithm (GA). Moreover, in the suggested optimization framework, the locations of FACTS devices and control signals are considered optimization parameters. Numerical results for the IEEE 69-bus power system demonstrated an effective improvement in the damping of inter-area modes utilizing the offered approach. Full article

In this manuscript, we propose a single-phase UPC (universal power compensator) system to extensively tackle power quality issues (voltage and current) with an equal VAR (volt-ampere reactive) sharing approach between the series and shunt APF (active power filter) of a UPC system. The equal VAR sharing feature facilitates the series and shunt APF inverters to be of an equal rating. An SRF (synchronous reference frame)-based direct PA (power angle) calculation technique is implemented to realize equal VAR sharing between the APFs of the UPC. This PA estimation utilizes d and q axis current parameters derived for the reference signal generation of the shunt APF. An SRF-based method is highly useful for power estimations in distorted supply voltage conditions compared with other conventional methods, i.e., the PQ method. It comprises a reduced complexity and estimations with an easiness to retain two APF inverters of equal rating. A rigorous simulation analysis is performed with MATLAB/SIMULINK and a real-time digital simulator (OPAL-RT) for addressing different power quality-disturbing elements such as current harmonics, voltage harmonics, voltage sag/swell and load VAR demand with the proposed method. Full article

Typically, the main control on alternating current (AC) power systems is performed by the scheduling of rotary machines of synchronous generators and static machines of on-load tap changer (OLTC) transformers and volt-ampere reactive (VAR) sources. Large machines of synchronous generators can be managed by utilizing terminal voltage control when synchronized in parallel to the power system. These machines are typically terminal voltage regulated. In addition, substation on-load tap changer (OLTC) transformers improve system voltage management by controlling variable turn ratios that are adjusted in different levels known as taps along either the primary or secondary winding. Moreover, volt-ampere reactive (VAR) sources of static VAR compensators (SVCs), which are automated impedance devices connected to the AC power network, are designed for voltage regulation and system stabilization. In this paper, scheduling of these machines is coordinated for optimal power system operation (OPSO) using a recent algorithm of social network search optimizer (SNSO). The OPSO is performed by achieving many optimization targets of cost of fuel, power losses, and polluting emissions. The SNS is a recent optimizer that is inspired from users in social networks throughout the different moods of users such as imitation, conversation, disputation, and innovation mood. The SNSO is developed for handling the OPSO problem and applied on an IEEE standardized 57-bus power system and real Egyptian power system of the West Delta area. The developed SNSO is used in various assessments and quantitative analyses with various contemporary techniques. The simulated findings prove the developed SNSO’s solution accuracy and resilience when compared to other relevant techniques in the literature. Full article

Depletion of fossil fuel deposits is the main current issue related to the world’s power generation. Renewable energy sources integrated with energy efficiency represent an effective solution. The electrification of end-use coupled with renewable power generation integration is considered as an important tool to achieve these tasks. However, the current electric power system does not currently have the suitable features to allow this change. Therefore, in the future, it has to allow two-way direction power flows, communication, and automated controls to fully manage the system and customers. The resulting system is defined as the smart grid. This article analyses the smart grid state of play within China, the US, and the EU, assessing the completion state of each smart grid technology and integrated asset. The analysis related to these countries presented here shows that the smart grid overall state of play in China, the US, and the EU are equal to 18%, 15%, and 13%, respectively, unveiling the need related to further efforts and investments in these countries for the full smart grid development. Full article

Power systems may encounter disturbances during operation as a result of switching of various components, etc. Such perturbations include transformer tap-changing action, load variations, and line outages due to various types of faults of which an earth fault is the most common. Stability analysis of a transmission system is necessary for us to determine the stability state of the system so that appropriate control measures can be implemented to guarantee system stability. This article presents the use of eigenvalue obtained from the system-linearized eigenvectors to analyze the stability state of the system. The choice of the eigenvalue principle is based on the strength of accuracy of the method to determine the actual state of the system providing adequate data for easy solution to the problem. The node admittance parameters computed from the line parameters is applied to the eigenvalue–eigenvector model to determine the system stability state. The state of the eigenvalue is used as an input to a control system, which utilized static volt-ampere reactive (VAR) compensators (SVC) to automatically stabilize the non-stable buses in the transmission network. The 6 × 6 nodal admittance matrix is formed and fed to the developed eigenvalue–eigenvector model via MATLAB in order to compute the right and left eigenvectors and the diagonal or eigenvalue of the network under steady-state and contingency condition. After this, the system stability state is determined, and necessary control actions by the SVC are implemented to guarantee system security. The developed model was tested on the 6 bus Eastern Grid Nigerian Transmission Network and validated using a 41 bus network of the same country. The compensated model showed considerable efficiency in improving the transient stability state of the transmission networks in terms of ease of operation, seamless integration into existing control system, and efficient utilization of SVS to compensate for reactive power imbalances. The results from the step response graph of the compensated model shows performance accuracy as the system regained stability in less than 0.5 s, which is a significant improvement over the uncompensated model. Full article

This paper describes a methodology and specifics for technical studies on fault-induced delayed voltage recovery (FIDVR) mitigation to ensure power system reliability. Optimal locations of the dynamic volts-ampere-reactive (VAR) sources are determined for addressing the FIDVR issues in the voltage stability analysis and assessment methodology. We propose a voltage stability analysis method for planning dynamic VAR sources for bettering electric power transmission systems under contingency conditions. A time-domain dynamic simulation is performed to assess short-term voltage stability. While conducting dynamic simulations, sensitivity analysis is performed to assess the need for dynamic VAR sources. This study focuses on a reactive power compensation strategy to determine system voltage recovery performance by optimal flexible alternating current transmission system (FACTS) placement in a metropolitan region. The objective of this study is to determine the optimal installation of dynamic VAR sources while satisfying the requirements of voltage stability margin and transient voltage dip under a set of criteria. New insights are presented on the effect of FACTS controls on the reactive power compensation, which supports voltage recovery. The main features of the proposed method are (i) the development based on a load model for FIDVR, (ii) the use of sensitivity analysis of the network to the variations of the IM load, (iii) the establishment of the control function and compensation strategy to maintain the voltage of system within criteria limits, and (iv) the use of the sensitivity analysis based on branch parameterization for unsolvable cases. Case studies on the Korean power system validated the performance of the proposed strategy, showing that it effectively installed FACTS under contingency scenarios. Full article

Distribution networks (DNWs) are facing numerous challenges, notably growing load demands, environmental concerns, operational constraints and expansion limitations with the current infrastructure. These challenges serve as a motivation factor for various distribution network planning (DP) strategies, such as timely addressing load growth aiming at prominent objectives such as reliability, power quality, economic viability, system stability and deferring costly reinforcements. The continuous transformation of passive to active distribution networks (ADN) needs to consider choices, primarily distributed generation (DG), network topology change, installation of new protection devices and key enablers as planning options in addition to traditional grid reinforcements. Since modern DP (MDP) in deregulated market environments includes multiple stakeholders, primarily owners, regulators, operators and consumers, one solution fit for all planning scenarios may not satisfy all these stakeholders. Hence, this paper presents a review of several planning techniques (PTs) based on mult-objective optimizations (MOOs) in DNWs, aiming at better trade-off solutions among conflicting objectives and satisfying multiple stakeholders. The PTs in the paper spread across four distinct planning classifications including DG units as an alternative to costly reinforcements, capacitors and power electronic devices for ensuring power quality aspects, grid reinforcements, expansions, and upgrades as a separate category and network topology alteration and reconfiguration as a viable planning option. Several research works associated with multi-objective planning techniques (MOPT) have been reviewed with relevant models, methods and achieved objectives, abiding with system constraints. The paper also provides a composite review of current research accounts and interdependence of associated components in the respective classifications. The potential future planning areas, aiming at the multi-objective-based frameworks, are also presented in this paper. Full article
