The rescaling of rainfall requires measurements of rainfall rates over many dimensions. This paper develops one approach using 10 m vertical spatial observations of the Doppler spectra of falling rain every 10 s over intervals varying from 15 up to 41 min in two different locations and in two different years using two different micro-rain radars (MRR). The transformation of the temporal domain into spatial observations uses the Taylor “frozen” turbulence hypothesis to estimate an average advection speed over an entire observation interval. Thus, when no other advection estimates are possible, this paper offers a new approach for estimating the appropriate frozen turbulence advection speed by minimizing power spectral differences between the ensemble of purely spatial radial power spectra observed at all times in the vertical and those using the ensemble of temporal spectra at all heights to yield statistically reliable scaling relations. Thus, it is likely that MRR and other vertically pointing Doppler radars may often help to obviate the need for expensive and immobile large networks of instruments in order to determine such scaling relations but not the need of those radars for surveillance. Full article

A realistic approach for gathering high-resolution observations of the rainfall rate, R, in the vertical plane is to use data from vertically pointing Doppler radars. After accounting for the vertical air velocity and attenuation, it is possible to determine the fine, spatially resolved drop size spectra and to calculate R for further statistical analyses. The first such results in a vertical plane are reported here. Specifically, we present results using MRR-Pro Doppler radar observations at resolutions of ten meters in height over the lowest 1.28 km, as well as ten seconds in time, over four sets of observations using two different radars at different locations. Both the correlation functions and power spectra are useful for translating observations and numerical model outputs of R from one scale down to other scales that may be more appropriate for particular applications, such as flood warnings and soil erosion, for example. However, it was found in all cases that, while locally applicable radial power spectra could be calculated, because of statistical heterogeneity most of the power spectra lost all generality, and proper correlation functions could not be computed in general except for one 17-min interval. Nevertheless, these results are still useful since they can be combined to develop catalogs of power spectra over different meteorological conditions and in different climatological settings and locations. Furthermore, even with the limitations of these data, this approach is being used to gain a deeper understanding of rainfall to be reported in a forthcoming paper. Full article

Studies of snow virga precipitation are rare. In this study, we investigated data from a vertically pointing Doppler Micro Rain Radar (MRR) in Bern, Switzerland, from 2008 to 2013 for snow virga precipitation events. The MRR data were reprocessed using the radar data processing algorithm of Garcia-Benardi et al., which allows the reliable determination of the snow virga precipitation rate. We focus on a long-lasting snow virga event from 17 March 2013, supported by atmospheric reanalysis data and atmospheric back trajectories. The snow virga was associated with a wind shear carrying moist air and snow precipitation in the upper air layers and dry air in the lower air layers. The lowest altitudes reached by the precipitation varied between 300 m and 1500 m above the ground over the course of the event. The duration of the snow virga was 22 h. In disagreement with the MRR observations, ERA5 reanalysis indicated drizzle at the ground over a time segment of 4 h during the snow virga event. Full article

It is important to understand the statistical–physical structure of the rain in the vertical so that observations aloft can be translated meaningfully into what will occur at the surface. In order to achieve this understanding, it is necessary to gather high temporal and spatial resolution observations of rain in the vertical. This can be achieved by translating radar Doppler spectra into drop size distributions. A long-standing difficulty in using such measurements, however, is the problem of vertical air motion, which can shift the Doppler spectra and therefore significantly alter the deduced drop size distributions and integrated variables. In this work, we overcome this difficulty by requiring that the measured radar reflectivity and the calculated rainfall rates satisfy fundamental physical theory. As a consequence, the mean vertical airspeed can be estimated and removed. Application of this new approach is demonstrated using vertically pointing Doppler radar observations in weak convection. It is shown that the new approach produces what appear to be better estimates of the rainfall rates as well as estimates of the temporal and spatial regionally coherent updraft and downdrafts occurring in the precipitation. The technique is readily applicable to other radars, especially those operating at non-attenuating frequencies. Full article

This paper describes a methodology for processing spectral raw data from Micro Rain Radar (MRR), a K-band vertically pointing Doppler radar designed to observe precipitation profiles. The objective is to provide a set of radar integral parameters and derived variables, including a precipitation type classification. The methodology first includes an improved noise level determination, peak signal detection and Doppler dealiasing, allowing us to consider the upward movements of precipitation particles. A second step computes for each of the height bin radar moments, such as equivalent reflectivity (Z_e), average Doppler vertical speed (W), spectral width (σ), the skewness and kurtosis. A third step performs a precipitation type classification for each bin height, considering snow, drizzle, rain, hail, and mixed (rain and snow or graupel). For liquid precipitation types, additional variables are computed, such as liquid water content (LWC), rain rate (RR), or gamma distribution parameters, such as the liquid water content normalized intercept (N_w) or the mean mass-weighted raindrop diameter (D_m) to classify stratiform or convective rainfall regimes. The methodology is applied to data recorded at the Eastern Pyrenees mountains (NE Spain), first with a detailed case study where results are compared with different instruments and, finally, with a 32-day analysis where the hydrometeor classification is compared with co-located Parsivel disdrometer precipitation-type present weather observations. The hydrometeor classification is evaluated with contingency table scores, including Probability of Detection (POD), False Alarm Rate (FAR), and Odds Ratio Skill Score (ORSS). The results indicate a very good capacity of Method3 to distinguish rainfall and snow (PODs equal or greater than 0.97), satisfactory results for mixed and drizzle (PODs of 0.79 and 0.69) and acceptable for a reduced number of hail cases (0.55), with relatively low rate of false alarms and good skill compared to random chance in all cases (FAR < 0.30, ORSS > 0.70). The methodology is available as a Python language program called RaProM at the public github repository. Full article

The cloud measurements for two years from the vertical pointing Ka-band cloud radar at Boseong in Korea are used to analyze detailed cloud properties. The reflectivity of the cloud radar is calibrated with other vertical pointing radars compared with the two disdrometers. A simple threshold-based quality control method is applied to eliminate non-meteorological echoes (insects and noise) in conjunction with despeckling along the radial direction. Clouds are classified into five types: high (HC), middle (MC), low (LC) for non-precipitating clouds, and deep (RainDP) and shallow (RainSH) for precipitating clouds. The average cloud frequency was about 35.9% with the maximum frequency of 50% in June for the total two-year sampling period. The RainDP occurred most frequently (11.8%), followed by HC (9.3%), MC (7.4%), RainSH (4.4%), and LC (2.9%) out of the average occurrence of the total 35.9%. HC and RainDP were frequently observed in summer and autumn, while RainSH, LC, and MC were dominant in the winter due to the dominant cloud development by the air-sea interaction during the cold air outbreak. The HC showed a significant seasonal variation of the maximum height and the rapid growth in the layer above 7 km (about −15 °C) in summer and autumn. This rapid growth appears in HC, MC, LC, and RainDP and is linked with rapid increases in Doppler velocity and mass flux. Thus, this growth is originated from the dominant riming processes in addition to depositional growth and is supported by an updraft in the layer between 6 and 8 km. MC showed a single frequency peak around 6 km with rapid growth above and strong evaporation below. The Doppler velocity of MC rapidly increases above 8 km and is nearly constant below this height due to strong evaporation except in the summer. LC had a similar trend of reflectivity (rapid growth in the HC region and strong evaporation in the lower region) lacking high frequency in the MC region. Unlike LC, the RainDP had continuous growth toward the ground in the entire layer with rapid growth in the HC and MC regions. In addition, two modes (cloud and precipitation) appear on the ground in spring and fall with the vertical continuity of the high frequency in the precipitation mode. The precipitation growth was most efficient in RainSH in summer with a reflectivity gradient of about 20 dBZ km⁻¹ and frequent updrafts larger than 1 m s⁻¹ and was smaller in the MC and HC regions. Full article

The RadAlp experiment aims at developing advanced methods for rain and snow estimation using weather radar remote sensing techniques in high mountain regions for improved water resource assessment and hydrological risk mitigation. A unique observation system has been deployed in the French Alps, Grenoble region. It is composed of a Météo-France operated X-band MOUC radar (volumetric, Doppler and polarimetric) on top of the Mt Moucherotte (1920 m ASL), the X-band XPORT research radar (volumetric, Doppler, polarimetric), a K-band micro rain radar (MRR, Doppler, vertically pointing) and in situ sensors (rain gauges, disdrometers), latter three operated on the Grenoble campus (220 m ASL). Based on the observation that the precipitation phase changes at/below the elevation of mountain-top MOUC radar for more than 60% of the significant events, an algorithm for ML identification has been developed using valley-based radar systems: it uses the quasi vertical profiles of XPORT polarimetric measurements (horizontal and vertical reflectivity, differential reflectivity, cross-polar correlation coefficient) and the MRR vertical profiles of apparent falling velocity spectra. The algorithm produces time series of the altitudes and values of peaks and inflection points of the different radar observables. A literature review allows us to link the micro-physical processes at play during the melting process with the available polarimetric and Doppler signatures, e.g., (i) regarding the altitude differences between the peaks of reflectivity, cross-polar correlation coefficient and differential reflectivity, as well as (ii) regarding the co-variation of the profiles of Doppler velocity spectra and cross-polar correlation coefficient. A statistical analysis of the ML based on 42 rain events (98 h of XPORT data) is then proposed. Among other results, this study indicates that (i) the mean value of the ML width in Grenoble is 610 m with a standard deviation of 160 m; (ii) the mean altitude difference between the horizontal reflectivity and the ${\rho }_{HV}$ peaks is 90 m and the mean altitude difference between the ${\rho }_{HV}$ and Zdr peaks is 30 m; (iii) even for the limited rainrate range in the dataset (0–8.5 mm h ${}^{-1}$ ), the “intensity effect” is clear on the reflectivity profile and the ML width, as well as on polarimetric variables such as ${\rho }_{HV}$ peak value and the Zdr enhancement in the upper part of the profile. On the contrary, the study of both the “density effect” and the influence of the $0°\mathrm{C}$ isotherm altitude did not yield significant results with the considered dataset; (iv) a principal component analysis on one hand shows the richness of the dataset since the first 2 PCs explain only 50% of the total variance and on the other hand the added-value of the polarimetric variables since they rank high in a ranking of the total variance explained by individual variables. Full article

Millimeter wave cloud radar (MMCR) is one of the primary instruments employed to observe cloud–precipitation. With appropriate data processing, measurements of the Doppler spectra, spectral moments, and retrievals can be used to study the physical processes of cloud–precipitation. This study mainly analyzed the vertical structures and microphysical characteristics of different kinds of convective cloud–precipitation in South China during the pre-flood season using a vertical pointing Ka-band MMCR. Four kinds of convection, namely, multi-cell, isolated-cell, convective–stratiform mixed, and warm-cell convection, are discussed herein. The results show that the multi-cell and convective–stratiform mixed convections had similar vertical structures, and experienced nearly the same microphysical processes in terms of particle phase change, particle size distribution, hydrometeor growth, and breaking. A forward pattern was proposed to specifically characterize the vertical structure and provide radar spectra models reflecting the different microphysical and dynamic features and variations in different parts of the cloud body. Vertical air motion played key roles in the microphysical processes of the isolated- and warm-cell convections, and deeply affected the ground rainfall properties. Stronger, thicker, and slanted updrafts caused heavier showers with stronger rain rates and groups of larger raindrops. The microphysical parameters for the warm-cell cloud–precipitation were retrieved from the radar data and further compared with the ground-measured results from a disdrometer. The comparisons indicated that the radar retrievals were basically reliable; however, the radar signal weakening caused biases to some extent, especially for the particle number concentration. Note that the differences in sensitivity and detectable height of the two instruments also contributed to the compared deviation. Full article
