An efficient solution strategy based on fluid network modeling, computational fluid dynamics (CFD) and discrete particle modeling (DPM) is presented in order to predict and improve air quality, specifically regarding breathing aerosol concentration, in a person-occupied mechanically ventilated room. The efficiency of the proposed workflow is evaluated for the specific case of a lecture hall. It is found that the actual vent system is imbalanced and inefficient in managing the aerosol concentration within the room. Despite a high volumetric exchange rate, aerosol residence times and local aerosol concentrations remain high over an extended period of time, without additional efforts to alter air flow circulation throughout the room. The proposed strategy illustrates how such changes can be efficiently implemented in the basic 1D/3D co-simulation workflow. Analysis of the lecture hall and vent system shows that the execution time for the overall process workflow can be optimized by the following: (1) CAD geometry generation of the room via 3D laser scanning, (2) mesh generation based on the anticipated air discharge behavior from the vent system and (3) by employing HPC resources. Additional simplifications such as the decoupling of vent air flow and room aerodynamics, as observed for the investigated test case, one-way coupling between air flow and aerosol dispersion at low aerosol concentrations and the successive solution of flow field equations can further reduce the problem’s complexity and processing times. Full article

Accidental crankcase explosions in marine diesel engines are presumably caused by the inflammation of lubricating oil in air followed by flame propagation and pressure buildup. This manuscript deals with the numerical simulation of internal unvented and vented crankcase explosions of lubricating oil mist using the 3D CFD approach for two-phase turbulent reactive flow with finite-rate turbulent/molecular mixing and chemistry. The lubricating oil mist was treated as either monodispersed with a droplet size of 60 μm or polydispersed with a trimodal droplet size distribution (10 $\mathsf{\mu }$m (10 wt%), 250 $\mathsf{\mu }$m (10 wt%), and 500 $\mathsf{\mu }$m (80 wt%)). The mist was partly pre-evaporated with pre-evaporation degrees of 60%, 70%, and 80%. As an example, a typical low-speed two-stroke six-cylinder marine diesel engine was considered. Four possible accidental ignition sites were considered in different linked segments of the crankcase, namely the leakage of hot blow-by gases through the faulty stuffing box, a hot spot on the crankpin bearing, electrostatic discharge in the open space at the A-frame, and a hot spot on the main bearing. Calculations show that the most important parameter affecting the dynamics of crankcase explosion is the pre-evaporation degree of the oil mist, whereas the oil droplet size distribution plays a minor role. The most severe unvented explosion was caused by the hot spot ignition of the oil mist on the main bearing and flame breaking through the windows connecting the crankcase segments. The predicted maximum rate of pressure rise in the crankcase attained 0.6–0.7 bar/s, whereas the apparent turbulent burning velocity attained 7–8 m/s. The rate of heat release attained a value of 13 MW. Explosion venting caused the rate of pressure rise to decrease and become negative. However, vent opening does not lead to an immediate pressure drop in the crankcase: the pressure keeps growing for a certain time and attains a maximum value that can be a factor of 2 higher than the vent opening pressure. Full article

The heat dissipation characteristics of the lithium-ion battery pack will have an effect on the overall performance of electric vehicles. To investigate the effects of the structural cooling system parameters on the heat dissipation properties, the electrochemical thermal coupling model of the lithium-ion power battery has been established, and the discharge experiment of the single battery has been designed. The voltage and temperature curves with time are similar to those obtained from the numerical model at various discharge rates, and the experimental results are relatively accurate. Based on this model, the height, angle, and number of different air inlets and outlets are designed, and the heat dissipation characteristics of different structural parameters are analyzed. The results show that the maximum temperature decreases by 3.9 K when the angle increases from 0° to 6°, the average temperature decreases by 2 K and the maximum temperature difference decreases by 2.9 K when the height increases from 12 mm to 16 mm, and the more the number of air inlets and outlets there are, the better the heat dissipation effect is. Therefore, the air vent of the battery cooling system has an important impact on the heat dissipation characteristics of the battery, which should be fully considered in the design. Full article

The present study examines the possibility of thermal comfort optimisation inside an office room where, due to historical heritage, it is possible to modify neither the energetic characteristic of the envelope nor the position of the inlet air vents. The distribution of global and local thermal comfort indices is evaluated in both heating and cooling conditions by establishing a computational fluid dynamics (CFD) model validated against experimental data. The obtained results demonstrate a striking asymmetry of the air velocity and temperature distribution due to the low energy efficiency of the building. In heating mode, the predicted mean vote ($PMV$) values were improved if the discharged air from the fan coil was at its maximal velocity. However, at the same time, the vertical air temperature gradient increased by around 0.5 ${}^{°}$C in each working station. In the cooling condition, in the absence of the solar radiation, the minimal air-flow rate satisfied the acceptable range of the draught rate ($DR$), whereas in the presence of a solar load, it could not meet the required cooling load in all positions, leading to higher floor temperature. The findings of this study allow for identifying and rearranging the optimal position of working stations in terms of thermal comfort. Full article

A model is presented which allows steady-state pressure profiles in high-rise wastewater drainage networks to be related to intake air flowrates and discharge water flowrates. This model is developed using data taken from academic literature, and is based on experimental observations which suggest that a vertical annular downflow develops over distance such that the pressure gradient in the wet stack may be expressed as the sum of junction components and developed flow components. The model is used to analyse a simplified ‘medium rise’ primary vented system of height 40 m, hosting two inflow junctions, crossvents and Air Admittance Valves (AAVs). The model illustrates how the air supply configuration affects the airflow rates within the stack and the vents, and how the configuration affects the steady-state hydraulic pressure profile. The model offers the possibility of an alternative approach to the design of high-rise wastewater drainage networks, compared to existing design codes. These codes generally do not explain the role that the air admitted into the network has upon its performance. Full article

Dam safety requirements have become stronger in recent years, highlighting, among other issues, the need to increase the discharge capacity of existing spillways and the protection of embankment dams against potential overtopping, which are particularly threatened by the hydrological consequences of climate change. The current economic situation requires solutions that ensure the safety of these infrastructures at an affordable cost. Wedge-shaped blocks (WSBs) are one of these solutions. A more detailed understanding of the performance of WSBs was the objective of this work and, based on this, the evolution of WSB design. An extensive empirical test program was performed, registering hydrodynamic pressures on the block faces and leakage through the joints between blocks and their air vents. A new WSB (named ACUÑA) with a different design of air vents was tested in comparison to Armorwedge™, which was used as a reference case. Moreover, the hydraulic behavior of the WSB was analyzed according to the saturation state of the granular drainage layer. The ACUÑA unit was designed with air vents in the upper part of the riser where the registered negative pressures were higher. Negative pressures were also measured at the base of the block when the granular drainage layer was not fully saturated. Finally, the beneficial effect of sealing some of the joints between blocks was quantified. Full article

The dispersion of vapour of liquefied natural gas (LNG) is generally assumed to be from a liquid spill on the ground in hazard and risk analysis. However, this cold vapour could be discharged at height through cold venting. While there is similarity to the situation where a heavier-than-air gas, e.g., CO₂, is discharged through tall vent stacks, LNG vapour is cold and induces phase change of ambient moisture leading to changes in the thermodynamics as the vapour disperses. A recent unplanned cold venting of LNG vapour event due to failure of a pilot, provided valuable data for further analysis. This event was studied using CFD under steady-state conditions and incorporating the effect of thermodynamics due to phase change of atmospheric moisture. As the vast majority of processing plants do not reside on flat planes, the effect of surrounding topography was also investigated. This case study highlighted that integral dispersion model was not applicable as key assumptions used to derive the models were violated and suggested guidance and methodologies appropriate for modelling cold vent and flame out situations for elevated vents. Full article

In this study, electroencephalogram (EEG), photo-plethysmography (PPG), and surface temperature measurements of subjects were taken while performing a driving simulation when the cabin and vent discharge air temperature in summer were changed from discomfort to comfort conditions. Additionally, subjective questionnaires were used to analyze the subject’s thermal comfort under the various driving environments. As a result, the surface temperatures of the forehead, left hand, right hand, and abdomen of the subject during driving were reduced by 2, 0.97, 2.18, and 5.86 °C, respectively, by operating a 12.5 °C vent cooling function at a cabin temperature of 35 °C. As a comprehensive analysis of the subjective survey, PPG, and EEG results, total power (TP), the standard deviation of N-N interval (SDNN), and the root mean square of successive differences (RMSSD) of subjects increased and stress index decreased at cabin and vent discharge air temperatures of 30–27.5 °C and 16.5–18.5 °C, respectively. Furthermore, the relative sensory motor rhythm (SMR) wave and concentration index (CI) of the frontal lobe tended to increase under the same temperature conditions. Accordingly, it was confirmed that these temperature conditions provided a pleasant driving environment for the driver and increased concentration on driving. Full article

The present work analyses the natural ventilation of a multi-span greenhouse with one roof vent and two side vents by means of sonic anemometry. Opening the roof vent to windward, one side vent to leeward, and the other side vents to windward (this last vent obstructed by another greenhouse), causes opposing thermal G_T (m³ s⁻¹) and wind effects G_w (m³ s⁻¹), as outside air entering the greenhouse through the roof vent circulates downward, contrary to natural convection due to the thermal effect. In our case, the ventilation rate R_M (h⁻¹) in a naturally ventilated greenhouse fits a second order polynomial with wind velocity u_o (R_M = 0.37 u_o² + 0.03 u_o + 0.75; R² = 0.99). The opposing wind and thermal effects mean that ventilation models based on Bernoulli’s equation must be modified in order to add or subtract their effects accordingly—Model 1, in which the flow is driven by the sum of two independent pressure fields $G_{M1}=\sqrt{\left|G_T^2\pm G_w^2\right|}$ , or Model 2, in which the flow is driven by the sum of two independent fluxes $G_{M2}=\left|G_T\pm G_w\right|$ . A linear relationship has been obtained, which allows us to estimate the discharge coefficient of the side vents (C_dVS) and roof vent (C_dWR) as a function of u_o [C_dVS = 0.028 u_o + 0.028 (R² = 0.92); C_dWR = 0.036 u_o + 0.040 (R² = 0.96)]. The wind effect coefficient C_w was determined by applying models M1 and M2 proved not to remain constant for the different experiments, but varied according to the ratio u_o/∆T_io^0.5 or δ [C_wM1 = exp(−2.693 + 1.160/δ) (R² = 0.94); C_wM2 = exp(−2.128 + 1.264/δ) (R² = 0.98)]. Full article

The present work studies the effect of three insect-proof screens with different geometrical and aerodynamic characteristics on the air velocity and temperature inside a Mediterranean multi-span greenhouse with three roof vents and without crops, divided into two independent sectors. First, the insect-proof screens were characterised geometrically by analysing digital images and testing in a low velocity wind tunnel. The wind tunnel tests gave screen discharge coefficient values of C_d,φ of 0.207 for screen 1 (10 × 20 threads·cm⁻²; porosity φ = 35.0%), 0.151 for screen 2 (13 × 30 threads·cm⁻²; φ = 26.3%) and 0.325 for screen 3 (10 × 20 threads·cm⁻²; porosity φ = 36.0%), at an air velocity of 0.25 m·s⁻¹. Secondly, when screens were installed in the greenhouse, we observed a statistical proportionality between the discharge coefficient at the openings and the air velocity u_i measured in the centre of the greenhouse, u_i = 0.856 C_d + 0.062 (R² = 0.68 and p-value = 0.012). The inside-outside temperature difference ΔT_io diminishes when the inside velocity increases following the statistically significant relationship ΔT_io = (−135.85 + 57.88/u_i)^0.5 (R² = 0.85 and p-value = 0.0011). Different thread diameters and tension affects the screen thickness, and means that similar porosities may well be associated with very different aerodynamic characteristics. Screens must be characterised by a theoretical function C_d,φ = [(2eμ/K_pρ)·(1/u_s) + (2eY/K_p^0.5)]^−0.5 that relates the discharge coefficient of the screen C_d,φ with the air velocity u_s. This relationship depends on the three parameters that define the aerodynamic behaviour of porous medium: permeability K_p, inertial factor Y and screen thickness e (and on air temperature that determine its density ρ and viscosity μ). However, for a determined temperature of air, the pressure drop-velocity relationship can be characterised only with two parameters: ΔP = au_s² + bu_s. Full article

An adaptive neuro-fuzzy inference system (ANFIS) was developed using the subtractive clustering technique to study the air demand in low-level outlet works. The ANFIS model was employed to calculate vent air discharge in different gate openings for an embankment dam. A hybrid learning algorithm obtained from combining back-propagation and least square estimate was adopted to identify linear and non-linear parameters in the ANFIS model. Empirical relationships based on the experimental information obtained from physical models were applied to 108 experimental data points to obtain more reliable evaluations. The feed-forward Levenberg-Marquardt neural network (LMNN) and multiple linear regression (MLR) models were also built using the same data to compare model performances with each other. The results indicated that the fuzzy rule-based model performed better than the LMNN and MLR models, in terms of the simulation performance criteria established, as the root mean square error, the Nash–Sutcliffe efficiency, the correlation coefficient and the Bias. Full article
