The seismic design of underground or aboveground structures is commonly based on the free-field assumption, which neglects the interaction between underground structures–soil–aboveground structures (USSI). This simplification may lead to unsafe or overly conservative, cost-intensive designs. To address this limitation, a series of shaking table tests were conducted on a coupled USSI system, in which the underground component consisted of a subway station connected to tunnels through structural joints to investigate the “city effect” on-site seismic response, particularly under long-period horizontal seismic excitations. Five test configurations were developed, including combinations of one or two aboveground structures, with or without a subway station. These were compared to a free-field case to evaluate differences in dynamic characteristics, acceleration amplification factors (AMFs), frequency content, and response spectra. The results confirm that boundary effects were negligible in the experimental setup. Notably, long-period seismic inputs had a detrimental impact on the field response when structures were present, with the interaction effects significantly altering surface motion characteristics. The findings demonstrate that the presence of a subway station and/or aboveground structure alters the seismic response of the soil domain, with clear dependence on the input motion characteristics and relative structural positioning. Specifically, structural systems lead to de-amplification under high-frequency excitations, while under long-period inputs, they suppress short-period responses and amplify long-period components. These insights emphasize the need to account for USSI effects in seismic design and retrofitting strategies, particularly in urban environments, to achieve safer and more cost-effective solutions. Full article

The prevalence of pipe jacking projects that traverse beneath subway tunnels in urban environments is on the rise, and the construction of pipe jacking can have a considerable effect on the deformation and stress experienced by existing shield tunnel segments. This study aims to assess the impact of pipe jacking construction on the longitudinal deformation of these segments, specifically centering on the pipe jacking project that intersects with Metro Line 6 in Chengdu. Initially, seven monitoring sections were established on-site to evaluate the vertical and horizontal deformation characteristics of each section. Then, a numerical model was developed using FLAC3D software to simulate the pipe jacking construction in relation to the existing shield tunnel. This model is designed to further explore the effects of the geological strata and the relative spatial arrangement of the two structures on the deformation of the shield tunnel. The findings reveal that under same geological conditions, the effects arising from the vertical clearance between the pipe jacking and the shield tunnel are significant. Specifically, when the vertical clearance is reduced from 2.4 m (the diameter of the pipe) to 1.4 m, the maximum vertical deformation at the crown experiences a 14.40% increase, while the maximum differential settlement between the pipe rings escalates by 46.66%. It is advisable that the separation between the two during construction should not fall below the diameter of the pipe. This research could serve as a valuable reference for the safeguarding of existing shield tunnels in analogous projects. Full article

The construction of urban subway tunnels typically induces soil settlement within a specific radius of the surrounding area. However, the accuracy of current methods for predicting ground deformation curves corresponding to the excavation of double-track tunnels with small spacing remains insufficient. Most studies simplify this problem by modeling it as a two-dimensional plane problem; however, the actual ground deformation exhibits pronounced three-dimensional characteristics. Consequently, studying the ground settlement patterns caused by the construction of small-spacing double-track tunnels is crucial. This study is based on the Peck formula, used to calculate surface settlement caused by the excavation of single-track tunnels. By incorporating the maximum settlement offset e and the soil loss rate η(y), the soil displacement calculation formula is derived for small-spacing double-track tunnel excavation. The accuracy of the derived formula is then validated through a case study. The findings provide a theoretical reference for predicting surface settlement induced by the excavation of small-spacing double-track tunnels. Furthermore, the influence of different parameters on ground settlement patterns is explored. The results indicate that appropriately increasing the tunnel spacing, increasing burial depth, and adopting a sequential excavation method for the two tunnels help reduce ground settlement. Full article

Underground engineering construction in the karst regions of Southwestern China has become a focal point of China’s advancing regional urban development. However, construction activities interfere with the karst groundwater environment, which is characterized by irregular pore distributions and complex, variable flow patterns. This study establishes a numerical model of the karst water system traversed by Line 2 of the Guiyang Rail Transit in China. Incorporating hydrogeological conditions and tunnel engineering parameters, the model simulates the effects of tunnel construction on the karst groundwater system. The flow-field distribution of the karst groundwater system is altered at various stages of tunnel construction. During tunnel excavation, a drainage zone centered around the subway forms in the groundwater system, altering the groundwater flow field and causing fluctuations in the groundwater level. During the lining phase, the tunnel area gradually transforms into a waterproof zone. Although the groundwater level gradually recovers under rainfall recharge, the waterproofing effect of the tunnel drives the formation of a new groundwater flow field within the groundwater system, changing both the groundwater level and the original flow field. This work offers support for the coordinated development of underground engineering and environmental protection in karst areas, facilitating sustainable urbanization. Full article

With the rapid development of urban rail transit, the intensity and impact range of train-induced vibrations are increasing. Investigating the transmission characteristics and attenuation patterns of these vibrations in track structures aids in understanding train-induced environmental vibrations. This study conducted rail impact experiments on a long sleeper integrated slab of a straight section of a subway tunnel. The hammer struck the rail at various positions, and acceleration sensors recorded the responses of the rail, slab, and tunnel. In order to determine the impact force, the vertical wheel–rail force and the vibration response of track structures were measured. Then, the Lance-LC1304B force hammer was selected for the experiment, and the hammer impact force reached 30 kN, the magnitude of which reached the measured wheel–rail force size for the line. Based on the results of the impact tests, the vibration attenuation characteristics of the track structure were analyzed. Accordingly, reference values for the truncation time and truncation distance in the vehicle–track coupled dynamics model’s moving window were provided. By comparing the results of the hammering experiment with the train-induced vibration results, the main excitation frequencies during train operation were determined. These findings provide valuable insights for the development of rail transit systems. Full article

During shield tunnel construction, waste mud is a significant source of urban construction waste. However, the disposal of waste mud has always been a challenge in engineering. Addressing the challenge of harmlessly disposing of, or repurposing, mud cakes formed after pressure filtration of shield mud remains a pressing issue for many cities. To address the challenge of shield mud disposal and explore the utilization technology of this resource, this study focuses on shield mud obtained from the Shenzhen subway tunnel. Calcined shield mud powder (CSMP) was prepared by activating its potential pozzolanic properties through a calcination process. Compressive strength tests revealed that, while CSMP exhibits some pozzolanic activity, its performance is limited. When 30% of the cement is replaced, the mortar’s maximum strength activity index (SAI) is only 82.6%, which makes it unsuitable as a supplementary cementitious material for concrete applications. At the same time, CSMP was also evaluated as a partial replacement for fly ash in the formulation of synchronous grouting materials, with performance metrics including fluidity, bleeding rate, hardening rate, setting time, and compressive strength systematically tested. The experimental results showed that, while CSMP reduces the fluidity of grouting, it significantly improves volumetric stability, shortens setting time, and enhances mechanical performance. Compared to the fly ash used in the study, CSMP exhibited better pozzolanic reactivity, promoting the formation of C-S-H and C-A-S-H phases, optimizing the pore structure, and increasing the density and overall performance of the grouting material. When the substitution rate is below 60%, the performance of grouting meets standard requirements, indicating the strong feasibility of utilizing CSMP to replace fly ash in synchronous grouting materials. Full article

Tunneling in loose soil and urban areas presents numerous challenges. One effective solution is the use of Earth Pressure Balance Shields (EPBSs). Maintaining the correct balance of pressure at the tunnel face is critical, as applying too little pressure can cause a collapse, while excessive pressure may result in a blow-out. Therefore, a key aspect of using EPBSs in urban environments is determining the optimal pressure required to stabilize the tunnel face, taking into account the existing soil in the excavation chamber and controlling the screw conveyor’s rotation rate. This study focuses on a section of the second line of the Tabriz subway to evaluate the minimum pressure needed for tunnel face stability using empirical, analytical, and numerical approaches. The analytical methods involve evaluating the limit equilibrium of forces and considering soil buckling due to overburden, while the numerical methods employ 3D finite element analysis. Additionally, a sensitivity analysis of the parameters affecting the required pressure was conducted and compared across the three approaches. The results revealed that the formation of a pressure arch mitigates the full impact of overburden pressure on the tunnel face. For soil cohesion values below 20 kPa, the numerical results aligned well with the empirical and analytical findings. For a tunnel depth of 22.5 m and a water table 2 m below the surface, the estimated minimum pressure ranged from 150 to 180 kPa. Moreover, the analytical methods were deemed more suitable for determining the required support pressure at the tunnel face. These methods considered wedge and semi-circular mechanisms as the most probable failure modes. Also, for cohesive ground, the pressure from the finite element analysis was found to be almost always equal to or greater than the values obtained with the analytical solutions. Full article

Currently, subway and underground engineering projects are vital for alleviating urban congestion and enhancing citizens’ quality of life. Among these, excavation engineering for foundation pits involves the most accidents in geotechnical engineering. Although there are various construction methods, most face issues such as a large footprint, high investments, resource waste, and low mechanization. Addressing these, this paper focuses on a subway foundation pit project in Guangzhou using mechanical shaft sinking technology. Using intelligent cloud monitoring, we analyzed the stress–strain patterns of the cutting edge and segments. The results showed significant improvements in construction efficiency, cost reduction, safety, and resource conservation. Based on this work, this paper makes the following conclusions: (1) The mechanical shaft sinking method offers advantages such as small footprint, high mechanization, minimal environmental impact, and cost-effectiveness. The achievements include a 22.22% reduction in construction time, a 20.27% decrease in investment, and lower worker risk. (2) Monitoring confirmed that all cutting edge and segment values remained safe, demonstrating the method’s feasibility and rationality. (3) Analyzing shaft monitoring data and field uncertainties, this study proposes recommendations for future work, including precise segment lowering control and introducing high-precision total stations and GPS technology to mitigate tunneling and assembly inaccuracies. The research validates the mechanical shaft sinking scheme’s scientific and logical nature, ensuring safety and contributing to technological advancements. It offers practical insights, implementable suggestions, and significant economic benefits, reducing project investment by RMB 41,235,600. This sets a benchmark for subway excavation projects in South China and beyond, providing reliable reference values. Furthermore, the findings provide valuable insights and guidance for industry peers, enhancing overall efficiency and sustainable development in subway construction. Full article

Soft marine soil exhibits unique mechanical properties that can lead to significant deformation and instability in the surrounding rock of urban subway tunnels. This presents a critical challenge for tunnel engineering researchers and designers. This thesis investigates the stability characteristics of surrounding rock in marine soft soil tunnels under cyclic loading conditions. Focusing on the shield tunnel segment between Left Fortress Station and Taiziwan Station of Shenzhen Urban Rail Transit Line 12, a discrete–continuous coupled numerical analysis method is employed to examine the deformation characteristics of the surrounding rock. This analysis takes into account the effects of dynamic loads resulting from train operations on the arch bottom’s surrounding rock. The findings indicate that damage to the surrounding rock occurs gradually, with the marine soft soil layer, particularly at higher water content, being prone to substantial plastic deformation. Additionally, under the influence of train vibration loads, the degree of vertical fluctuation in the internal marine soft soil diminishes with increasing depth from the bottom of the tunnel arch. This coupled numerical analysis approach offers valuable insights and methodologies for assessing the structural safety of tunnel projects throughout their operational periods. Full article

This paper presents a particular tunneling method, the new Austrian tunneling method (NATM), which plays an important role in reducing subsidence of the surface and damage to structures in urban areas. It has a wide range of applications in shallow tunneling projects all over the world. In this study, numerical modeling of the third-line Metro tunnel in Tehran, which is designed and stabilized by the NATM, is under discussion. The foregoing tunnel is excavated manually with a one-meter advancing step. In this project, the constructors use a lattice girder and spray concrete with 31 cm thickness as the initial lining. A suitable numerical software for this modeling is PLAXIS 3D Tunnel, which allows high-resolution finite element modeling (FEM) of the studied object. The performance of this method is investigated and compared with that of other NATMs. The numerical modeling yielded a value of 30.01 mm for earth subsidence in the most damaged area of the settlement, which was confirmed with a dramatically low difference by earth surface monitoring. Moreover, this tunnel was drilled and excavated using various methods, among which the least settlement was obtained by the proposed method. The results are promising, and they indicate that tunneling with this method should continue to be used to expand the subway line in the city. Full article

In view of the safety of the construction of the long foundation pit of the new upper span to the existing subway under urban complex environment conditions, combined with the construction of the intersection section of the first line of the existing subway across the north–south Expressway in Shenyang, the mechanical properties during construction were studied by means of numerical simulation and on-site monitoring. The results showed that the general deformation characteristic of the existing metro tunnel was “uplift first, then restrain”. The local deformation characteristic was an unloading rebound in the cross region, and a compression deformation occurs outside the cross region. The index could be controlled in the range of the control value of the existing line protection by adopting the measures consisting of an uplift pile + capping beam balance, reinforcing the surrounding soil, the excavation of the foundation pit in sections, and the comprehensive construction. Full article

Tunnels for subways and railways are a vital part of urban transportation systems, where shield tunneling using assembled segmental linings is the predominant construction approach. With increasing operation time and varying geological conditions, shield tunnels usually develop defects that compromise both structural integrity and operational safety. One common issue is the separation of segment joints that may cause water/mud penetration and corrosion. Existing inspection strategies can only detect openings after their occurrence, which cannot provide early warnings for predictive maintenance. To address this issue, this work proposes a multi-point seam contact pressure monitoring method for joint opening identification. It first derived the theoretical correlation between contact pressure distribution and segment opening; then, a finite element model was established to explore the stress and deformation responses under combined axial and bending loads. Finally, multi-point piezoelectric film sensors were implemented on a scaled segment model to validate the theoretical and numerical analyses. Results indicate that the multi-point monitoring method can effectively identify opening amounts at the segment joints with an average error of 8.8%, confirming the method’s feasibility. These findings support the use of this monitoring technique for early detection and assessment of joint openings in shield tunnels. Full article

The construction of group foundation pits near subway stations often leads to environmental pollution, thereby causing certain damage to urban ecology. By optimizing the excavation sequence of group foundation pits, the adverse effects on surrounding underground structures and soil during excavation can be effectively mitigated, contributing to the sustainable development of cities. Taking a group foundation pit project in Changzhou as an example, this study utilized the finite element software PLAXIS 3D to simulate various working conditions under different excavation sequences, comparing the deformation of the subway station, shield tunnel, and surrounding soil. The results show that, influenced by the excavation of group foundation pits, the difference between maximum deformation and minimum deformation of shield tunnel is 25.85%, and the difference between the maximum deformation and minimum deformation of the subway envelope is 19.44%. The subway envelope is least affected by the change in excavation sequence. Both the displacement of the subway station and the surrounding soil exhibit a significant “cumulative effect”, with displacement changes closely related to the distance from the pit to the station and the ground, as well as the amount of soil unloaded in each excavation. Therefore, it is advisable to adhere to the principle of “far before near, shallow before deep, small before large” during excavation, which facilitates the coordinated development of urban infrastructure construction and the urban ecological environment, providing valuable reference and guidance for the sustainable development of cities. Full article

Although the rapid expansion of urban rail transit offers convenience to citizens, the issue of subway vibration cannot be overlooked. This study investigates the spatial distribution characteristics of vibration in the Fayuan Temple historic and cultural reserve. It involves using a V001 magnetoelectric acceleration sensor capable of monitoring low amplitudes with a sensitivity of 0.298 V/(m/s²), a measuring range of up to 20 m/s², and a frequency range span from 0.5 to 100 Hz for in situ testing, analyzing the law of vibration propagation in this area, evaluating the impact on buildings, and determining the vibration reduction scheme. The reserve is divided into three zones based on the vertical vibration level measured during the in situ test as follows: severely excessive, generally excessive, and non-excessive vibration. Furthermore, the research develops a dynamic coupling model of vehicle–track–tunnel–stratum–structure to verify the damping effect of the wire spring floating plate track and periodic pile row. It compares the characteristics of three vibration reduction schemes, namely, internal vibration reduction reconstruction, periodic pile row, and anti-vibration reinforcement or reconstruction of buildings, proposing a comprehensive solution. Considering the construction conditions, difficulty, cost, and other factors, a periodic pile row is recommended as the primary treatment measure. If necessary, anti-vibration reinforcement or reconstruction of buildings can serve as supplemental measures. Full article

The safety of the geotechnical environment around subways is vitally important for their sustainability. Ground settlement is a very common threat to the safe operation of subways and is related to subway traffic vibrations. Taking Nanjing subway line 10 as an example, field tests, discrete element simulations, and a grey relational analysis are carried out to study the deformation mechanism of the underlying sandy soil induced by vibrations. The results show that the vibration load of Nanjing subway Line 10 is mainly concentrated in the vertical direction. The particles’ coordination number below the subway increases under the vibration load, while the coordination number on the side of the tunnel decreases, which may cause a shear dilatancy effect. Among the five microscopic indexes, the local porosity and the coordination number are closely related to the deformation. Although the deformation of the underlying sandy soil is quite small under the subway traffic load, it will accumulate under frequent loading and then lead to urban engineering geological disasters. Full article
