Traditional pipe roof support design methods generally assume horizontal ground conditions and treat the pipe roof as a monolithic beam, thereby neglecting the differential stress distribution among individual steel pipes under unsymmetrical loading. To address this gap, this paper presents two main contributions: a low-carbon cement-based grouting material suitable for pipe roof reinforcement, and a new mechanical model that simultaneously accounts for biased pressure conditions and the inter-pipe micro-arch effect. First, the working performance of limestone calcined clay cement (LC³) grout was systematically tested at a water–cement ratio of 1:1, and the optimal mix ratio was determined. Grout–soil reinforcement tests on weathered granite show that, for grout-to-soil volume ratios between 0.2 and 0.8, the compressive strength of the reinforced material exceeds 10 MPa and the elastic modulus exceeds 600 MPa. Second, a mechanical model for the pipe roof was established based on the Pasternak two-parameter foundation theory, incorporating both biased pressure conditions and the inter-pipe micro-arch effect. The model predictions were compared with existing field monitoring data in the literature, showing consistent trends and good agreement in peak deflection values. Parametric analysis reveals that under horizontal ground conditions, the pipe roof response is symmetric, with the vault as the most critical area. As the bias angle increases, the maximum response shifts toward the higher side of the terrain, and the stress difference between pipes on both sides increases significantly. Theoretical analysis of the low-carbon grouting material shows that pipe roof deflection is moderately reduced compared to traditional grouting materials, but at the cost of increasing bending moment and shear force within the steel pipes. The proposed low-carbon grouting material and the validated mechanical model provide theoretical support for the design optimization of pipe roof support in shallow unsymmetrical loading tunnels. Full article

This study focuses on monitoring the deformation of the shallow unsymmetrical section of a super-large-span tunnel portal relying on the newly built Shimentangshan Tunnel, and through numerical simulations, the construction sequence and drift ratios were optimized to address challenges related to the stability of surrounding rock and structure. The findings indicate that employing the double-side drift method results in a maximum settlement value of 107.0 mm and a maximum convergence value of 108.8 mm, leading to larger deformations. Excavating the shallow buried side first followed by the deep buried side proves beneficial for deformation control of the support structure and effectively limits damage to the surrounding rock. A drift ratio of 0.3 ensures optimal support structure security and stability. Considering both structural deformation and surrounding rock damage, a ratio between 0.25 and 0.35 for the drifts is recommended. Taking into account construction efficiency and economic benefits, a construction plan for the shallow buried unsymmetrical section at the portal of super-large-span tunnels is proposed. Full article

In the construction process of tunnel inlet sections, the rock mass can sustain unsymmetrical pressure due to asymmetrical terrain on the two sides of the tunnel. The fact that the inlet sections are usually under shallow buried conditions with strongly weathered rock mass exacerbates the issue. This paper discusses optimization strategies of the initial support of a shallow buried tunnel based on the analytical results of asymmetrical loading characteristics. Numerical simulation is performed with particle flow code (PFC) using the Jianshanji tunnel project as an example. The simulation results show that the bench excavation has slightly less total deformation than the full-section excavation but the deformation range is wider, especially in the tunnel arch. Both lining support and slope reduction treatments can effectively improve rock deformation, with lining support demonstrating better performance in controlling deformation and adjusting stress distribution. Based on the simulation results, the bench excavation and lining support are used in the actual project, and the corresponding optimization control measures were adopted to address deformation issues, including crushed-stone backfilling for compression resistance, advanced grouting reinforcement, and grouting. The field data show that the tunnel stability is effectively improved by adopting the optimization schemes, which further validates the effectiveness of the proposed unsymmetrical control method. Full article

Based on practical engineering, considering the characteristics of unsymmetrical loading, shallow burying, and weak surrounding rock of the tunnel, MIDAS finite element software is adopted to analyze the influence effect and deformation characteristics of a temporary steel support when the tunnel is excavated by a two-step center diaphragm method (CDM). The simulation results are compared with the field monitoring results. It can be seen that: (1) Affected by the unsymmetrical loading, the settlement of the right spandrel of the tunnel is obvious. The existence of a temporary steel support reduces the settlement of the surrounding rock at the spandrel greatly, making the distribution of principal stress at the spandrel more reasonable. (2) The deformation of the temporary steel support at the upper bench undergoes four stages: convergence, expansion, convergence, and stabilization; and the deformation at the lower bench undergoes five stages: convergence, expansion, convergence, expansion, and stabilization. (3) There is an obvious “bench-type” phenomenon in the principal stress change of the temporary steel support. The analysis results provide a scientific basis and technical guidance for the construction optimization of unsymmetrical loading tunnels using the same support technology. Full article

We conducted a field test on Huitougou (HTG) Tunnel, which is a typical shallow-buried and unsymmetrically loaded tunnel. The on-site monitoring data indicated that the surrounding rock pressure and lining stress on both sides of the tunnel were indeed asymmetrical and that the pressure ratios (original unsymmetrical coefficient) of each corresponding monitoring point were different. According to the tunnel design principle, we proposed the unsymmetrical coefficient (UC) to characterize the asymmetrical degree of the tunnel, and verified and compared the UC of the field test and numerical simulation results. The effects of different factors on the UC such as the slope angle of the ground, the thickness of the overburden cover, the physical and mechanical properties of the surrounding rock, and the construction method were studied and analyzed. The research results reveal that the bias coefficient calculated by the numerical simulation was close to the monitoring results. The results of the factor analysis indicate that the slope angle, overburden thickness, and elastic modulus significantly affected the bias degree, while other factors had little effect. The concise and clear UC accurately described the unsymmetrical degree of any unsymmetrical-loaded tunnel and provided more accurate judgment regarding the safety of the tunnel design phase and construction phase. Full article
