This parameter study examines the impact of two distinct adhesion layers, chromium (Cr) and titanium (Ti), on the performance of CuO/Cu₂O-based chemoresistive gas sensors by varying the layer thickness. The sensing material utilised on a Si-SiO₂ sensor chip with Pt electrodes is an ultrathin CuO/Cu₂O film fabricated through thermal deposition of Cu and subsequent oxidation. The sensors were evaluated by measuring the change in electrical resistance against a range of target gases, including carbon monoxide (CO), carbon dioxide (CO₂) and a mixture of hydrocarbons (HC_Mix), in order to assess any potential cross-sensitivity issues. As the reactions occur at the surface, the surface was characterised by scanning electron microscopy (SEM) and the composition by grazing incidence X-Ray diffraction (GIXRD) measurement to gain further insight into the influence of the adhesion layer on the sensing performance. Full article

We report a systematic nanoscale investigation on the ultrathin Cr film growth process and properties. Polycrystalline metallic films were manufactured by magnetron sputtering on fused silica substrates. The film growth was observed in situ by broad-band optical monitoring (BBM) and plasma-emission spectroscopy (OES) methods. The ex situ characterization of the Cr films with thicknesses varying from 2.6 nm up to 57 nm were performed by both non-destructive and destructive techniques. Recently, we reported on a novel set of data for optical and electrical properties of sputtered chromium films. The optical and electrical properties of the films are known to be governed by their structure and microstructure, which were analyzed in detail in the present research. Moreover, the optical properties of the films were studied here in a significantly wider optical range and obtained using both in situ and ex situ measurements. Reliable in situ nanoscale characterization of metal films was shown to ensure an unfailing approach in obtaining ultrathin layers with desirable thickness and stable and well-determined optical constants and electrical conductivity. This is of high importance for various industries and novel upcoming applications. Full article

Brillouin light scattering (BLS) has been established as a standard technique to study thermally excited sound waves with frequencies up to ~100 GHz in transparent materials. In BLS experiments, one usually uses a Fabry–Pérot interferometer (FPI) as a spectrometer. The drastic improvement of the FPI contrast factor over 10¹⁰ by the development of the multipass type and the tandem multipass type FPIs opened a gateway to investigate low energy excitations (ħω ≤ 1 meV) in various research fields of condensed matter physics, including surface acoustic waves and spin waves from opaque surfaces. Over the last four decades, the BLS technique has been successfully applied to study collective spin waves (SWs) in various types of magnetic structures including thin films, ultrathin films, multilayers, superlattices, and artificially arranged dots and wires using high-contrast FPIs. Now, the BLS technique has been fully established as a unique and powerful technique not only for determination of the basic magnetic constants, including the gyromagnetic ratio, the magnetic anisotropy constants, the magnetization, the SW stiffness constant, and other features of various magnetic materials and structures, but also for investigations into coupling phenomena and surface and interface phenomena in artificial magnetic structures. BLS investigations on the Fe/Cr multilayers, which exhibit ferromagnetic-antiferromagnetic arrangements of the adjacent Fe layer’s magnetizations depending on the Cr layer’s thickness, played an important role to open the new field known as “spintronics” through the discovery of the giant magnetoresistance (GMR) effect. In this review, I briefly surveyed the historical development of SW studies using the BLS technique and theoretical background, and I concentrated our BLS SW studies performed at Tohoku University and Ishinomaki Senshu University over the last thirty five years. In addition to the ferromagnetic SW studies, the BLS technique can be also applied to investigations of high-frequency magnetization dynamics in superparamagnetic (SPM) nanogranular films in the frequency domain above 10 GHz. One can excite dipole-coupled SPM excitations under external magnetic fields and observe them via the BLS technique. The external field strength determines the SPM excitations’ frequencies. By performing a numerical analysis of the BLS spectrum as a function of the external magnetic field and temperature, one can investigate the high-frequency magnetization dynamics in the SPM state and determine the magnetization relaxation parameters. Full article

Chromium nitride thin films are known for their good mechanical properties. We present the characteristics of ultrathin chromium nitride films under 400 nm thickness deposited on silicon substrates by direct current and high-power impulse magnetron sputtering techniques. The methods of investigation of the CrN films were scanning electron microscopy, atomic force microscopy, and nanoindentation. Qualitative and quantitative analyses were performed using AFM and SEM images by fractal dimension, surface roughness and gray-level co-occurrence matrix methods. Our results show that using magnetron techniques, ultrathin CrN films with excellent mechanical properties were obtained, characterized by values of Young’s modulus between 140 GPa and 250 GPa for the samples obtained using high-power impulse magneton sputtering (HiPIMS) and between 240 GPa and 370 GPa for the samples obtained using direct current sputtering (DC). Stiffness measurements also reveal the excellent mechanical properties of the investigated samples, where the samples obtained using HiPIMS sputtering had stiffness values between 125 N/m and 132 N/m and the samples obtained using DC sputtering had stiffness values between 110 N/m and 119 N/m. Full article

The corrosion resistance of stainless steel is attributed to the extraordinary protectiveness of the ultrathin native passive film (~3 nanometers) on alloy surface. This protectiveness, independent of alloying, can possibly be further increased by modifying the native film to resist corrosion in harsh conditions. However, the modification based on the film itself is extremely difficult due to its rapid, self-limiting growth. Here we present a strategy by using low-temperature plasma processing so as to follow the growth kinetics of the native film. The native oxide film is restarted and can uniformly grow up to ~15 nanometers in a self-limiting manner. High-resolution TEM found that the film exhibited a well-defined, chemical-ordering layered structure. The following corrosion tests revealed that the anodic current density of the alloy decreased by two orders of magnitude in 0.6 M NaCl solution with a remarkable increase of pitting potential. This enhancement is also observed in Fe-Cr alloys with Cr contents above ~10.5 wt.%. The superior protectiveness of the alloy is thus attributed to the continuous and thickened high-quality ultrathin Cr₂O₃ layer in the restarted film. Full article

Ultra-thin metallic films are widely applied in optics and microelectronics. However, their properties differ significantly from the bulk material and depend on the substrate material. The nucleation, film growth, and layer properties of atomic layer deposited (ALD) iridium thin films are evaluated on silicon wafers, BK7, fused silica, SiO₂, TiO₂, Ta₂O₅, Al₂O₃, HfO₂, Ru, Cr, Mo, and graphite to understand the influence of various substrate materials. This comprehensive study was carried out using scanning electron and atomic force microscopy, X-ray reflectivity and diffraction, four-point probe resistivity and contact angle measurements, tape tests, and Auger electron spectroscopy. Within few ALD cycles, iridium islands occur on all substrates. Nevertheless, their size, shape, and distribution depend on the substrate. Ultra-thin (almost) closed Ir layers grow on a Ta₂O₅ seed layer after 100 cycles corresponding to about 5 nm film thickness. In contrast, the growth on Al₂O₃ and HfO₂ is strongly inhibited. The iridium growth on silicon wafers is overall linear. On BK7, fused silica, SiO₂, TiO₂, Ta₂O₅, Ru, Cr, and graphite, three different growth regimes are distinguishable. The surface free energy of the substrates correlates with their iridium nucleation delay. Our work, therefore, demonstrates that substrates can significantly tailor the properties of ultra-thin films. Full article

Solar selective absorbers have significant applications in various photothermal conversion systems. In this work, a global optimization method based on genetic algorithm was developed by directly optimizing the solar photothermal conversion efficiency of a nano-chromium (Cr) film-based solar selective absorber aiming to work at the specified working temperature and solar concentration. In consideration of the semi-transparent metal absorption layer employed in multilayered solar selective absorbers, the optical constants of ultrathin Cr film were measured by spectroscopic ellipsometer and introduced into the optimization process. The ultrathin Cr film-based solar selective absorber was successfully designed and fabricated by the magnetron sputtering method for the working temperature at 600 K and a solar concentration of 1 Sun. The measured reflectance spectra of the sample show a good agreement with the numerical simulations based on measured optical constants of ultrathin Cr film. In comparison, the simulated results by using the optical constants of bulk Cr film or literature data exhibit a large discrepancy with the experimental results. It demonstrates the significance of considering the actual optical constants for the semi-transparent metal absorption layer in the design of nano-metal film-based solar selective absorber. Full article

In this study, we propose and fabricate a perfect absorber on a planar substrate using alternate silicon dioxide and ultrathin metallic lossy chromium (Cr) films. Furthermore, we transfer the absorber to a curved substrate via an optimization design of symmetric structures. The absorber exhibits a highly efficient absorption and large incident-angular tolerance characteristics in the whole visible region. We investigate each layer contribution to the absorption theoretically, and find that ultrathin (~5 nm) lossy Cr films play a dominant absorptive role. Using the effective interface method, we calculate the phase difference on the lossy Cr front surface. It is close to the destructive interference condition, from which we clarify why the proposed structures can produce a highly efficient absorption. Full article

Although Vanadium dioxide (VO₂) has a potential application value for smart energy efficient windows because of its unique phase transition characteristic, there are still many obstacles that need to be overcome. One challenge is to reduce its high transition temperature (ζ_c = 68 °C) to near room temperature without causing its phase transition performance degradation. In this paper, a novel method was employed that covered a 3 nm ultra-thin heavy Cr-doped VO₂ layer on the pure VO₂ films. Compared with the as-grown pure VO₂, obviously, phase transition temperature decreasing from 59.5 °C to 48.0 °C was observed. Different from previous doping techniques, almost no phase transition performance weakening occurred. Based on the microstructure and electrical parameters measurement results, the mechanism of ζ_c reducing was discussed. The upper ultra-thin heavy Cr-doped layer may act as the induced role of phase transition. With temperature increasing, carrier concentration increased from the upper heavy Cr-doped layer to the bottom pure VO₂ layer by diffusion, and induced the carrier concentration reach to phase transition critical value from top to bottom gradually. The present method is not only a simpler technique, but also avoids expensive alloy targets. Full article
