Accurately measuring river flow is not only crucial for hydrologists monitoring hydrological processes but also important for all professionals involved in hydrological research. The ultrahigh frequency (UHF) band enables the surface flow velocity measurement at a deeper effective water depth, so it is less susceptible to the influence of wind drift. However, in curved river channels, the spatial variation in surface velocity is caused by the uneven erosion of the water flow, and this variation is influenced by both air shear stress and the curvature of the river. To mitigate the impact of water level on cross-sectional flow velocity estimation and address the nonlinear relationship between cross-sectional area and water level, this paper proposes a model that is independent of river water level. The nonlinear relationship between cross-sectional area and water level is calculated using a Taylor series expansion. The model was validated using experimental data collected from the Xiantao section of the Han River in Hubei, China, from March to July 2018. The data were discussed separately for high-flow and low-flow periods and were divided into training and validation sets in an 8:2 ratio. Compared to the previous method, our improved method reduces the Root Mean Square Error (RMSE) and Mean Absolute Percentage Error (MAPE) by approximately 2%. In the estimation of flow during the dry season, the improved method achieved a correlation coefficient of 0.9523, representing an increase of 0.1243 compared to the original method. The RMSE was 23.0383, and the MAPE was 0.0232, showing reductions of 23.144 and 0.0241, respectively, compared to the original method. In the estimation of discharge during the wet season, the improved method achieved a correlation coefficient of 0.9908, an increase of 0.0575 compared to the original method. The RMSE was 65.4929, and the MAPE was 0.0391, reflecting reductions of 75.1271 and 0.0338, respectively, compared to the original method. This advancement further enhances the application of UHF radar for discharge measurement in meandering rivers. Full article

Geosynchronous spaceborne–airborne (GEO-SA) ultra-high-frequency ultra-wideband bistatic synthetic aperture radar (UHF UWB BiSAR) provides high-precision images for marine and polar environments, which are pivotal in glacier monitoring and sea ice thickness measurement for polar ocean mapping and navigation. Contrasting with traditional high-frequency BiSAR, it faces unique challenges, such as the considerable spatial variability, significant range–azimuth coupling, and vast volumes of echo data, which impede high-resolution image reconstruction. This paper presents an improved bistatic nonlinear chirp scaling (NLCS) algorithm for imaging oceanic scenes with GEO-SA UHF UWB BiSAR. This methodology extends the two-dimensional (2-D) spectrum up to the sixth order via the method of series reversion (MSR) to meet accuracy demands and then employs an elliptical model to elucidate the alterations in the azimuth frequency modulation (FM) rate mismatch. Initially, the imaging geometry and signal model are introduced, and then a separation of bistatic slant ranges based on the configuration is proposed. In addition, during range processing, after eliminating linear range cell migration (RCM), the derivation process for the sixth-order 2-D spectrum is detailed and an improved filter is applied to correct the high-order RCM. Finally, during azimuth processing, the causes of the FM rate mismatch are analyzed, a cubic perturbation function derived from the elliptical model is used for FM rate equalization, and a unified sixth-order filter is applied to complete the azimuth compression. Experimental results with point targets and natural oceanic scenes validate the outstanding efficacy of the proposed NLCS algorithm, particularly in imaging quality enhancements for GEO-SA UHF UWB BiSAR. Full article

Inland shipping is of great significance in economic development, and ship surveillance and classification are of great importance for ship management and dispatch. For river ship detection, ultrahigh-frequency (UHF) radar is an effective equipment owing to its wide coverage and easy deployment. The extension in range, Doppler, and azimuth and target recognition are two main problems in UHF ship detection. Clustering is a necessary step to get the center of an extended target. However, it is difficult to distinguish between different target echoes when they overlap each other in range, Doppler, and azimuth and so far practical methods for extended target recognition with UHF radar have been rarely discussed. In this study, a two-stage target classification method is proposed for UHF radar ship detection. In the first stage, grid-based gradient descent (GBGD) clustering is proposed to distinguish targets with three-dimensional (3D) information. Then in the second stage, the inverse synthetic aperture radar (ISAR) imaging algorithm is employed to differentiate ships of different types. The simulation results show that the proposed method achieves a 20% higher clustering accuracy than other methods when the targets have close 3D information. The feasibility of ISAR imaging for target classification using UHF radar is also validated via simulation. Some experimental results are also given to show the effectiveness of the proposed method. Full article

The Doppler spectra of sea echoes, which contain abundant information on floating scatterers, are important for exploring the characteristics of sea clutter. Using sea clutter data at low grazing angles observed by a coherent ultra-high frequency (UHF) radar located on Lingshan Island in the Yellow Sea, China, this study conducted detailed research on the characteristics of Doppler spectra with multiple ocean parameters, including grazing angle, significant wave height (SWH), and wave directions. The effect of sea echoes with different local normalized intensities on short-time Doppler spectra was further studied. The results indicate that with increasing sea states, the bimodal behavior of Doppler spectra, an evident phenomenon of Bragg scattering, gradually weakens. The frequency shifts of the mean spectra increased linearly with increasing SWH and wind speed, decreased linearly with increasing grazing angle, and decreased with the cosine value of the relative wave direction angles. In comparison, frequency shifts of the short-time spectra increased with increasing sea states and local echo intensities but fluctuated around a fixed value after reaching a certain extent. For spectral widths, the grazing angle is a significant influencing factor, with its broadening trend evident with a decrease in the grazing angle, whereas other ocean parameters, such as wave direction and wind direction, have no apparent influence. Considering the major contributions of the parameters, semi-empirical models for the mean spectral frequency shifts, mean spectral widths and short-time spectral frequency shifts were proposed. By verifying the measured data and predicted results, the models exhibited good prediction accuracy and applicability. The proposed inferences and models are helpful for understanding low grazing angle UHF-band sea clutter characteristics and improving target detection algorithms in offshore areas. These findings supplement previous studies on sea clutter Doppler spectra. Full article

Effectiveness verification of weapon equipment and the selection of stealth material are inseparable from target radar cross-section (RCS) measurement. For RCS characteristic analysis of sea surface small targets, a fishing vessel was measured using a shore-based ultra-high-frequency (UHF) band radar. In this article, a full program of RCS measurement and characteristic analysis is presented, and three strategies are adopted to guarantee its high precision. For this, a scheme was designed for RCS dynamic measurement, along with the construction of a two-stage median filter to improve target positioning precision, and an RCS estimation procedure with sea clutter removal is elaborated upon, which increases RCS accuracy. Note that the test range satisfies the far-field criterion, and the multipath effect is modified by external calibration in our data. The measurement results reveal that the RCS level of the sea surface small target is sensitive to the aspect angle and wave height at a low grazing angle, but the RCS fluctuation characteristic is not. Therefore, the aspect angle and wave condition must be considered for sea surface small target detection, classification, or identification. Full article

This work presents an enhanced autonomous airborne Synthetic Aperture Radar (SAR) imaging system able to provide full 3D radar images from the subsurface. The proposed prototype and methodology allow the safe detection of both metallic and non-metallic buried targets even in difficult-to-access scenarios without interacting with the ground. Thus, they are particularly suitable for detecting dangerous targets, such as landmines and Improvised Explosive Devices (IEDs). The prototype is mainly composed by an Ultra-Wide-Band (UWB) radar module working from Ultra-High-Frequency (UHF) band and a high accuracy dual-band Real Time Kinematic (RTK) positioning system mounted on board an Unmanned Aerial Vehicle (UAV). The UAV autonomously flies over the region of interest, gathering radar measurements. These measurements are accurately geo-referred so as to enable their coherent combination to obtain a well-focused SAR image. Improvements in the processing chain are also presented in order to deal with some issues associated to UAV-based measurements (such as non-uniform acquisition grids) as well as to enhance the resolution and the signal to clutter ratio of the image. Both the prototype and the methodology were validated with measurements, showing their capability to provide high-resolution 3D SAR images. Full article

This paper describes a multichannel super-heterodyne signal analyzer, called the Spectrum Analysis Solution (SAS), which performs multi-purpose spectrum sensing to support spectrally adaptive and cognitive radar applications. The SAS operates from ultrahigh frequency (UHF) to the S-band and features a wideband channel with eight narrowband channels. The wideband channel acts as a monitoring channel that can be used to tune the instantaneous band of the narrowband channels to areas of interest in the spectrum. The data collected from the SAS has been utilized to develop spectrum sensing algorithms for the budding field of spectrum sharing (SS) radar. Bandwidth (BW), average total power, percent occupancy (PO), signal-to-interference-plus-noise ratio (SINR), and power spectral entropy (PSE) have been examined as metrics for the characterization of the spectrum. These metrics are utilized to determine a contiguous optimal sub-band (OSB) for a SS radar transmission in a given spectrum for different modalities. Three OSB algorithms are presented and evaluated: the spectrum sensing multi objective (SS-MO), the spectrum sensing with brute force PSE (SS-BFE), and the spectrum sensing multi-objective with brute force PSE (SS-MO-BFE). Full article
