Theoretically, the topological charge l in the vortex can be any integer or fraction, thus the vortex carrying different topological charges can form an infinitely orthogonal orbital angular momentum state space, which can provide new dimensional resources for optical communication. However, high-capacity optical communication requires low delay, thus real-time detection of the OAM is significant for communication. Metasurfaces have the characteristics of low loss, ultra-thin, easy integration, and flexible phase controls, which provide a meaningful way to realize integrated OAM generation and detection. Here, an optimized streamlined metasurface (OSM) is presented, which can detect high-order vortex beams in a single, simple, and rapid manner by photon momentum transformation (PMT). Since different vortices are converted into focusing modes with distinct azimuthal coordinates on a transverse plane through PMT, a single measurement can determine OAMs in an ample mode space. In addition, the OSM can detect more and higher order OAMs compared with a discrete metasurface (DM) at the same size, due to its better wavefront sampling capabilities. With the merits of an ultra-compact device size, simple optical structure, and outstanding vortex recognition ability, our approach may underpin the development of integrated optics and quantum systems. Full article

Offering real-time precise point positioning (PPP) services for global and large areas based on global navigation satellite systems (GNSS) has drawn more and more attention from institutions and companies. A precise and reliable satellite orbit is a core premise for multi-GNSS real-time services, especially for the GPS and GLONASS, which are undergoing modernization, whereas the Galileo, BDS and QZSS have just fulfilled the construction stage. In this contribution, a real-time precise orbit determination (POD) strategy for the five operational constellations based on the hourly updated ultrarapid orbit prediction method is presented. After combination of 72 h arc through three adjacent 24 h arc normal equations, the predicted orbits are finally generated (hourly updated). The POD results indicate that the mean one-dimensional (1-D) root mean square (RMS) values compared with the Deutsches GeoForschungsZentrum (GFZ) final multi-GNSS orbits are approximately 3.7 cm, 10.2 cm, 5.8 cm, 5.7 cm, 4.1 cm and 25.1 cm for GPS, BDS IGSOs, BDS MEOs, GLONASS, Galileo and QZSS NONE GEOs, respectively. The mean 1-D RMS values of the hourly updated ultrarapid orbit boundary overlapping comparison are approximately 1.6 cm, 6.9 cm, 3.2 cm, 2.7 cm, 1.8 cm and 22.2 cm for GPS, BDS IGSOs, BDS MEOs, GLONASS, Galileo and QZSS NONE GEOs, respectively. The satellite laser ranging (SLR) validation illuminates that the mean RMS values are approximately 4.53 cm and 4.73 cm for the four MEOs of BDS-3 and four BDS-2 satellites, respectively. Full article

Global Navigation Satellite System (GNSS) ultra-rapid orbit is critical for geoscience and real-time engineering applications. To improve the computational efficiency and the accuracy of predicted orbit, a parallel approach for multi-GNSS ultra-rapid orbit determination is proposed based on Message Passing Interface (MPI)/Open Multi Processing (OpenMP). This approach, compared with earlier efficient methods, can improve the efficiency of multi-GNSS ultra-rapid orbit solution without changing the original observation data and retaining the continuity and consistency of the original parameters to be estimated. To obtain high efficiency, three steps are involved in the approach. First and foremost, the normal equation construction is optimized in parallel based on MPI. Second, equivalent reduction of the estimated parameters is optimized using OpenMP parallel method. Third, multithreading is used for parallel orbit extrapolation. Thus, GNSS ultra-rapid orbit determination is comprehensively optimized in parallel, and the computation efficiency is greatly improved. Based on the data from MGEX and IGS stations, experiments are carried out to analyze the performance of the proposed approach in computational efficiency, accuracy and stability. The results show that the approach greatly improves the efficiency of satellite orbit determination. It can realize 1-h update frequency for the multi-GNSS ultra-rapid orbit determination using 88 stations with four-system observations. The accuracy of the GPS, GLONASS, Galileo and BDS ultra-rapid orbit with 1-h update frequency using the parallel approach is approximately 33.4%,31.4%,40.1% and 32.8% higher than that of the original orbit, respectively. The root mean squares (RMS) of GPS, GLONASS, Galileo and BDS predicted orbit are about 3.2 cm, 5.1 cm, 5.6 cm and 11.8 cm. Moreover, the orbit provided by the proposed method has a better stability. The precision loss of all parallel optimization can be negligible and the original correlation between the parameters is fully preserved. Full article

With the development of the global navigation satellite system(GNSS), the hourly ultra-rapid products of GNSS are attracting more attention due to their low latency and high accuracy. A new strategy and method was applied by the Shanghai Astronomical Observatory (SHAO) Analysis Center (AC) of the international GNSS Monitoring and Assessment Service (iGMAS) for generating 6-hourly and 1-hourly GNSS products, which mainly include the American Global Positioning System (GPS), the Russian Global’naya Navigatsionnaya Sputnikova Sistema (GLONASS), the European Union’s Galileo, and the Chinese BeiDou navigation satellite system (BDS). The 6-hourly and 1-hourly GNSS orbit and clock ultra-rapid products included a 24-h observation session which is determined by 24-h observation data from global tracking stations, and a 24-h prediction session which is predicted from the observation session. The accuracy of the 1-hourly orbit product improved about 1%, 31%, 13%, 11%, 23%, and 9% for the observation session and 18%, 43%, 45%, 34%, 53%, and 15% for the prediction session of GPS, GLONASS, Galileo, BDS Medium Earth Orbit (MEO), Inclined Geosynchronous Orbit (IGSO), and GEO orbit, when compared with reference products with high accuracy from the International GNSS service (IGS).The precision of the 1-hourly clock products can also be seen better than the 6-hourly clock products. The accuracy and precision of the 6-hourly and 1-hourly orbit and clock verify the availability and reliability of the hourly ultra-rapid products, which can be used for real-time or near-real-time applications, and show encouraging prospects. Full article

Errors in ultra-rapid UT1-UTC primarily affect the overall rotation of spatial datum expressed by GNSS (Global Navigation Satellite System) satellite ultra-rapid orbit. In terms of existing errors of traditional strategy, e.g., piecewise linear functions, for ultra-rapid UT1-UTC determination, and the requirement to improve the accuracy and consistency of ultra-rapid UT1-UTC, the potential to improve the performance of ultra-rapid UT1-UTC determination based on an LS (Least Square) + AR (Autoregressive) combination model is explored. In this contribution, based on the LS+AR combination model and by making joint post-processing/rapid UT1-UTC observation data, we propose a new strategy for ultra-rapid UT1-UTC determination. The performance of the new strategy is subsequently evaluated using data provided by IGS (International GNSS Services), iGMAS (international GNSS Monitoring and Assessment System), and IERS (International Earth Rotation and Reference Systems Service). Compared to the traditional strategy, the numerical results over more than 1 month show that the new strategy improved ultra-rapid UT1-UTC determination by 29–43%. The new strategy can provide a reference for GNSS data processing to improve the performance of ultra-rapid products. Full article

The Global Navigation Satellite System (GNSS) ultra-rapid precise orbits are crucial for global and wide-area real-time high-precision applications. The solar radiation pressure (SRP) model is an important factor in precise orbit determination. The real-time orbit determination is generally less accurate than the post-processed one and may amplify the instability and mismodeling of SRP models. Also, the impact of different SRP models on multi-GNSS real-time predicted orbits demands investigations. We analyzed the impact of the ECOM 1 and ECOM 2 models on multi-GNSS ultra-rapid orbit determination in terms of ambiguity resolution performance, real-time predicted orbit overlap precision, and satellite laser ranging (SLR) validation. The multi-GNSS observed orbital arc and predicted orbital arcs of 1, 3, 6, and 24 h are compared. The simulated real-time experiment shows that for GLONASS and Galileo ultra-rapid orbits, compared to ECOM 1, ECOM 2 increased the ambiguity fixing rate to 89.3% and 83.1%, respectively, and improves the predicted orbit accuracy by 9.2% and 27.7%, respectively. For GPS ultra-rapid orbits, ECOM 2 obtains a similar ambiguity fixing rate as ECOM 1 but slightly better orbit overlap precision. For BDS GEO ultra-rapid orbits, ECOM 2 obtains better overlap precision and SLR residuals, while for BDS IGSO and MEO ultra-rapid orbits, ECOM 1 obtains better orbit overlap precision and SLR residuals. Full article

The predicted navigation satellite clock offsets are crucial to support real-time global navigation satellite system (GNSS) precise positioning applications, especially for those applications difficult to access the real-time data stream, such as the low earth orbit (LEO) autonomous precise orbit determination. Currently, the clock prediction for the Chinese BeiDou system is still challenging to meet the precise positioning requirement. The onboard clocks of BeiDou satellites are provided by different manufacturers, and the clocks’ switch events are more frequent. Considering the satellite-specified and temporal variation of the BeiDou clocks characteristics, we intend to use an adaptive model for BeiDou clock prediction. During clock prediction, we identify different models for BeiDou clocks’ characteristics, and then address the optimal model with a cross-validation procedure. The model achieving the minimum variance in the cross-validation procedure is used for the final clock prediction. We compared the prediction results of our method with two well-recognized BeiDou ultra-rapid clock products, named GBU-P and ISU-P, respectively. The comparison results indicate that the adaptive model achieves about 1-ns precision for 3-h prediction, which corresponds to 47.3% and 32.1% precision improvement compared to the GBU-P and ISU-P products, respectively. The efficiency of the predicted clocks is further validated with the precise point positioning (PPP) data processing. The results indicate that the static PPP solution precision is improved by 21.6%–30.0% compared to the current predicted clock product. The precision improvement in kinematic PPP is even more significant, which reaches 46.7%–53.9% with respect to these GBU-P and ISU-P products. Therefore, the proposed adaptive model is a practical and an efficient way to improve the BeiDou clock prediction. Full article

The accuracy of ultra-rapid orbits is a key parameter for the performance of GNSS (Global Navigation Satellite System) real-time or near real-time precise positioning applications. The quality of the current BeiDou demonstration system (BDS) ultra-rapid orbits is lower than that of GPS, especially for the new generational BDS-3 satellites due to the fact that the availability of the number of ground tracking stations is limited, the geographic distribution of these stations is poor, and the data processing strategies adopted are not optimal. In this study, improved data processing strategies for the generation of ultra-rapid orbits of BDS-2/BDS-3 satellites are investigated. This includes both observed and predicted parts of the orbit. First, the predicted clock offsets are taken as constraints in the estimation process to reduce the number of the unknown parameters and improve the accuracy of the parameter estimates of the orbit. To obtain more accurate predicted clock offsets for the BDS’ orbit determination, a denoising method (also called the Tikhonov regularization algorithm), inter-satellite correlation, and the partial least squares method are all incorporated into the clock offsets prediction model. Then, the Akaike information criterion (AIC) is used to determine the arc length in the estimation models by taking the optimal arc length in the estimation of the initial orbit states into consideration. Finally, a number of experiments were conducted to evaluate the performance of the ultra-rapid orbits resulting from the proposed methods. Results showed that: (1) Compared with traditional models, the accuracy improvement of the predicted clock offsets from the proposed methods were 40.5% and 26.1% for BDS-2 and BDS-3, respectively; (2) the observed part of the orbits can be improved 9.2% and 5.0% for BDS-2 and BDS-3, respectively, by using the predicted clock offsets as constraints; (3) the accuracy of the predicted part of the orbits showed a high correlation with the AIC value, and the accuracy of the predicted orbits could be improved up to 82.2%. These results suggest that the approaches proposed in this study can significantly enhance the accuracy of the ultra-rapid orbits of BDS-2/BDS-3 satellites. Full article

Abnormal information of satellite orbits inevitably appears in the broadcast ephemeris. Failure to obtain unhealthy information on GPS satellite orbits in precise orbit determination (POD) degrades GPS service performance. At present, the reliable unhealthy information published by the Center for Orbit Determination in Europe (CODE) is usually used, but it has at least one-day latency, and the current level of unhealthy information cannot fully meet the requirements of rapid and real-time geodetic applications, especially for non-IGS (International global navigation satellite systems (GNSS) Service) analysis centers and BeiDou navigation satellite system (BDS) users. Furthermore, the unhealthy orbit information detected by the traditional method, which is based on the synchronized pseudo-range residuals and regional observation network, cannot meet the requirement of setting separate sub-arcs in POD. In view of these problems, we propose a three-step method for determining unhealthy time periods of GPS satellite orbit in broadcast ephemeris during POD to provide reliable unhealthy information in near-real time. This method is a single-epoch solution, and it can detect unhealthy time periods in each sampling of observation in theory. It was subsequently used to detect unhealthy time periods for satellites G09 and G01 based on the 111 globally distributed tracking stations in the IGS. The performance of the new method was evaluated using cross-validation. Based on the test results, it detected an orbital leap for G09 in the broadcast ephemeris from 09:59:42 to 14:00:42 on 25 August 2017. Compared to the traditional method, the unhealthy start time using the three-step method was in better agreement with the information provided by CODE’s satellite crux files. G01 did not appear to have an orbital leap on the specified date, but it was misjudged by the traditional method. Furthermore, compared to the traditional method, the three-step method can perform unhealthy time period detection for a satellite all day long. In addition, precise orbit determination for unhealthy satellites is realized successfully with the unhealthy orbit arc information identified in this study. Compared to the CODE orbit, the root mean square and standard deviation of the new method for G09 are less than 2 cm, and the three-step method shows an improvement in accuracy compared with the traditional method. From the above results, it can be seen that this study can provide a feasible approach to meet the real-time unhealthy time period detection requirements of a satellite orbit in a broadcast ephemeris during POD. Furthermore, compared to waiting for updates of CODE’s satellite crux files or for accumulating delayed observation data, it has the potential to provide additional information in the process of generating ultra-rapid/real-time orbits. Full article

The geostationary earth orbit (GEO) and inclined geosynchronous orbit (IGSO) satellites of the Beidou navigation satellite system are maneuvered frequently. The broadcast ephemeris can be interrupted for several hours after the maneuver. The orbit-only signal-in-space ranging errors (SISREs) of broadcast ephemerides available after the interruption are over two times larger than the errors during normal periods. To shorten the interruption period and improve the ephemeris accuracy, we propose a two-step orbit recovery strategy based on a piecewise linear thrust model. The turning points of the thrust model are firstly determined by comparison of the kinematic orbit with an integrated orbit free from maneuver; afterward, precise orbit determination (POD) is conducted for the maneuvered satellite by estimating satellite orbital and thrust parameters simultaneously. The observations from the IGS Multi-Global Navigation Satellite System (GNSS) Experiment (MGEX) network and ultra-rapid products of the German Research Center for Geosciences (GFZ) are used for orbit determination of maneuvered satellites from Sep to Nov 2017. The results show that for the rapidly recovered ephemerides, the average orbit-only SISREs are 1.15 and 1.0 m 1 h after maneuvering for GEO and IGSO respectively, which is comparable to the accuracy of Beidou broadcast ephemerides in normal cases. Full article

The predicted parts of ultra-rapid orbits are important for (near) real-time Global Navigation Satellite System (GNSS) precise applications; and there is little research on GPS/GLONASS/BDS/Galileo/QZSS five-system ultra-rapid precise orbit determination; based on the one-step method and double-difference observation model. However; the successful development of a software platform for solving five-system ultra-rapid orbits is the basis of determining and analyzing these orbits. Besides this; the different observation models and processing strategies facilitate to validate the reliability of the various ultra-rapid orbits. In this contribution; this paper derives the double-difference observation model of five-system ultra-rapid precise orbit determination; based on a one-step method; and embeds this method and model into Bernese v5.2; thereby forming a new prototype software platform. For validation purposes; 31 days of real tracking data; collected from 130 globally-distributed International GNSS Service (IGS) multi-GNSS Experiment (MGEX) stations; are used to determine a five-system ultra-rapid precise orbit. The performance of the software platform is evaluated by analysis of the orbit discontinuities at day boundaries and by comparing the consistency with the MGEX orbits from the Deutsches GeoForschungsZentrum (GFZ); between the results of this new prototype software platform and the ultra-rapid orbit provided by the International GNSS Monitoring and Assessment System (iGMAS) analysis center (AC) at the Institute of Geodesy and Geophysics (IGG). The test results show that the average standard deviations of orbit discontinuities in the three-dimension direction are 0.022; 0.031; 0.139; 0.064; 0.028; and 0.465 m for GPS; GLONASS; BDS Inclined Geosynchronous Orbit (IGSO); BDS Mid-Earth Orbit (MEO); Galileo; and QZSS satellites; respectively. In addition; the preliminary results of the new prototype software platform show that the consistency of this platform has been significantly improved compared to the software package of the IGGAC. Full article

For ultra-rapid orbits provided by the Global Navigation Satellite System (GNSS), the key parameters, accuracy and timeliness, must be taken into consideration in real-time and near real-time applications. However, insufficient observations in later epochs appear to generate low accuracy in observed orbits, for which a correlation between the Dilution of Precision (DOP) of the orbit parameters and their accuracy is found. To correct the observed GNSS ultra-rapid orbit, a correction method based on the DOP values is proposed by building the function models between DOP values and the orbit accuracy. With 10-day orbit determination experiments, the results show that the observed ultra-rapid-orbit errors, generated by insufficient observations, can be corrected by 12–22% for the last three hours of the observed orbits. Moreover, considering the timeliness constraints in ultra-rapid-orbit determination, a DOP amplification factor is defined to weight the contribution of each tracking station and optimize the station distribution in the orbit determination procedure. Finally, six schemes are designed to verify the method and strategy in determining the ultra-rapid orbit based on one-month observations. The orbit accuracy is found to decrease by 1.27–6.34 cm with increasing amplification factor from 5–20%. Thus, the observed ultra-orbit correction method proposed is ideal when considering accuracy and timeliness in ultra-rapid orbit determination. Full article

Currently, ultra-rapid orbits play an important role in the high-speed development of global navigation satellite system (GNSS) real-time applications. This contribution focuses on the impact of the fitting arc length of observed orbits and solar radiation pressure (SRP) on the orbit prediction performance for GPS, GLONASS, Galileo and BeiDou. One full year’s precise ephemerides during 2015 were used as fitted observed orbits and then as references to be compared with predicted orbits, together with known earth rotation parameters. The full nine-parameter Empirical Center for Orbit Determination in Europe (CODE) Orbit Model (ECOM) and its reduced version were chosen in our study. The arc lengths of observed fitted orbits that showed the smallest weighted root mean squares (WRMSs) and medians of the orbit differences after a Helmert transformation fell between 40 and 45 h for GPS and GLONASS and between 42 and 48 h for Galileo, while the WRMS values and medians become flat after a 42 h arc length for BeiDou. The stability of the Helmert transformation and SRP parameters also confirmed the similar optimal arc lengths. The range around 42–45 h is suggested to be the optimal arc length interval of the fitted observed orbits for the multi-GNSS joint solution of ultra-rapid orbits. Full article

High precision real-time orbit of navigation satellites are usually predicted based on batch estimation solutions, which is highly dependent on the accuracy of the dynamic model. However, for the BDS satellites, the accuracy and reliability of the predicted orbit usually decrease due to the inaccurate dynamic model or orbit maneuvers. To improve this situation, the sequential estimation Square Root Information Filtering (SRIF) was applied to determine the real-time BDS orbits. In the filter algorithm, usually a long period is required for the orbit to converge to the final accuracy, due to lake of accurate initial state. This paper focuses on the impact of the initial state with different a priori Standard Deviation (STD) on the BDS orbit convergence performance in both normal and abnormal periods. For the normal period, the Ultra-Rapid (UR) orbit products and the Broadcast Ephemerides (BRDC) used as initial orbits are discussed respectively. For the abnormal period, orbit maneuver is analyzed. Experimental results show that a proper a priori STD of initial state can significantly accelerate the orbit convergence, while a loose a priori STD takes more than 10 h to converge in the radial direction for the BDS GEO/IGSO/MEO satellites. When the UR orbit product is used as the initial orbit, the orbit of the IGSO/MEO satellites can converge to decimeter-level immediately. When the BRDC product is used, the accuracy of meter-level can be obtained for the IGSO/MEO immediately, and converge to decimeter-level in about 6 h. For the period after the orbit maneuver, the real-time orbit accuracy can reach meter-level in about 6 h after the first group of broadcast ephemerides is received. Full article
