Ultra-wide swath synthetic aperture radar (SAR) systems are of great significance for applications such as terrain measurement and ocean monitoring. In conventional SAR systems, targets echo from the near-range and far-range of an observed swath mutually overlap, and the blind ranges are caused by those that the radar cannot receive while it is transmitting. Therefore, the swath of conventional SAR systems is limited due to their range ambiguity as well as the transmitted pulse blockage. With the development of waveform diversity, range ambiguity can be suppressed by radar waveform design with a low-range sidelobe without increasing the system’s complexity when compared to the scan-on-receive (SCORE) based on digital beamforming (DBF) technique. Additionally, by optimizing the pulse repetition interval (PRI) variation strategy, the negative impact of blind range on imaging can be reduced. Based on these technologies, this paper proposes a theoretical architecture to achieve an ultra-wide swath SAR imaging system via chaotic frequency modulation (FM) signals and a random pulse repetition interval variation strategy without increasing the antenna area. By transmitting time-variant chaotic-FM signals, the interference between targets in the near range and far range can be reduced by the corresponding match filters. Furthermore, random pulse repetition intervals increase the irregularity and aperiodicity of the blind ranges to further improve the imaging quality. Simulation results demonstrate that the proposed wide-swath SAR system has better performance compared to classical SAR systems. Full article

Digital array radar (DAR) can fully realize digitalization at both the transmitting and receiving ends. However, the development of freedom at the transmitting end is far from mature. So, the new concept of multi-dimensional waveform coding array has appeared, which can optimize the transmitting resources in space–time/frequency waveform or another dimension. Space–time coding array (STCA) is a typical kind of multi-dimensional waveform coding array, which can make full use of the high degree of freedom at the transmitting end. It realizes emission diversity by introducing a small time delay between different transmission array elements. In this paper, an optimization method for STCA, which combines the array spatial coding at the transmitting end and mismatched filter design at the receiving end, is proposed. This method aims to solve the sidelobe problems of STCA: the inherent resonance phenomenon and the resolution loss problem. The experimental verification and quantitative comparative analysis prove the effectiveness of the proposed method. The resolution is restored to the ideal level under the premise of maintaining the beam-scanning ability and ultra-low sidelobe, and the resonance phenomenon caused by spectrum discontinuity is eliminated simultaneously. Full article

This paper introduces an application of the dandelion optimization (DO) algorithm in antenna arrays. This is the first time that the DO algorithm has been used for optimizing antenna arrays. For antenna array optimization, sidelobe level (SLL) and deep nulls are key technical indicators. A lower SLL can improve the signal-to-noise ratio and reduce the impact of clutter signals outside the main beam. Deep nulls need to be aligned with the direction of interference to eliminate the influence of interference sources. The combination of the two can effectively improve the anti-interference ability of the entire system. Therefore, antenna arrays with ultra-low sidelobes and ultra-deep nulls are currently hot in the field of antenna array design and are also some of the key technologies needed to achieve modern high-performance radar systems. As a new type of evolutionary algorithm inspired by nature, the DO algorithm is inspired by the wind propagation behavior of dandelions in nature. This algorithm iteratively updates the population from three stages of ascent, descent, and landing, ultimately finding the optimal position. It has good optimization ability in solving complex problems such as those involving nonlinearity, discreteness, and non-convexity, and the antenna array pattern synthesis optimization problem belongs to multivariate nonlinear problems. Therefore, the DO algorithm can be effectively applied in the field of antenna array optimization. In this work, we use the following method to obtain an optimized pattern of a linear array with the lowest sidelobe level (SLL), null placement in particular directions, and a lower notch in particular directions: by controlling the antenna array’s element spacing and leaving the phase unchanged to optimize the current amplitudes and by controlling the excitation current and phase fixation of the antenna array and changing the element spacing. In the first and second examples, different algorithms are used to reduce the SLL of the antenna. In the first example, the DO algorithm reduces the SLL to −33.37 dB, which is 2.67 dB, 2.67 dB, 3.77 dB, 2.74 dB, and 2.52 dB lower than five other algorithms. In the second example, the SLL optimized by the DO algorithm is −42.56 dB, which is 5.04 dB and 1.48 dB lower than two other algorithms. In both examples, the DO algorithm reduces the SLL lower than other algorithms when the main lobe of the antenna is not significantly widened. Examples 3, 4, and 5 use the DO algorithm to optimize the amplitude of the current, generating deep nulls and deep notches in specific directions. In Example 3, the DO algorithm obtains a depth of nulls equal to −187.6 dB, which is 66.7 dB and 44.3 dB lower than that of the flower pollination algorithm (FPA) and the chaotic colony predation algorithm (CCPA), respectively. In Example 4, the deep null obtained by the DO algorithm is as low as −98.69 dB, which is 6.67 dB lower than the deep null obtained by the grey wolf optimization (GWO) algorithm. In Example 5, the deep notch obtained by the DO algorithm is as low as −63.1 dB, which is 6.4 dB and 1.9 dB lower than the spider monkey optimization (SMO) algorithm and the grasshopper optimization algorithm (GOA), respectively. The data prove that the DO algorithm produces deeper nulls and notches than other algorithms. The last two examples involve reducing sidelobe levels and generating deep nulls by optimizing the spacing between elements. In Example 5, the SLL obtained using the DO algorithm is −22.8766 dB, which is 0.1998 dB lower than the lowest SLL of −22.6768 dB among other algorithms. In Example 6, the SLL obtained using the DO algorithm is −20.1012 dB, and the null depth is −125.1 dB, which is 1.592 dB lower than the SLL obtained by the cat swarm optimization (CSO) algorithm and 19.1 dB lower than the deep null obtained by the GWO algorithm, respectively. In summary, the results of six simulation experiments indicate that the DO algorithm has better optimization ability in linear array optimization than other evolutionary algorithms. Full article

This article aims to improve the synthesis efficiency and radiation performance of large ultra-wideband (UWB) rotationally symmetric sparse circular planar arrays by using a modified differential evolution algorithm (MDEA). In the proposed MDEA, we adopt a new encoding mechanism in which an individual represents an element position expressed in polar coordinates. Importantly, such an encoding mechanism can facilitate the multiplication calculation for the array factor in the individual being updated while making it easier to meet the given minimum element spacing constraint. Moreover, to cater to the new encoding mechanism, some low-dimensional evolution operators are introduced to avoid the prematurity. In particular, the UWB rotationally symmetric sparse planar array synthesis problem is transformed into the sidelobe suppression problem of the array pattern at the highest frequency under the given array aperture, and the minimum spacing constraints is used to guarantee enough space to place physical UWB antenna elements. Two synthesis examples of UWB sparse planar arrays based on rotationally symmetric structures are presented. The results show that the peak sidelobe level (PSL) obtained by the proposed MDEA is significantly lower than the results obtained by some existing algorithms in an acceptable CPU time, which proves the effectiveness and superiority of the proposed MDEA. Full article

Ultra-wideband (UWB) nonlinear frequency modulation (NLFM) waveforms have the advantages of low sidelobes and high resolution. By extending the frequency domain wideband synthesis method to the NLFM waveform, the synthetic bandwidth will be limited, and the grating lobe will grow as the number of subpulses increases at a fixed synthetic bandwidth. Aiming for the highly periodic grating lobes caused by equally spaced splicing and small subpulse time-bandwidth products (TxBW), a multisubpulse UWB NLFM waveform synthesis method is proposed in this paper. Random frequency hopping and spectral correction are utilized to disperse the energy of periodic grating lobes and optimize the matched filter of the subpulse, thereby reducing notches and Fresnel ripples in the synthesized spectrum. The results of the hardware-in-the-loop simulation experiment show that the peak sidelobe ratio (PSLR) and the integral sidelobe ratio (ISLR) of the NLFM synthetic wideband waveform (SWW) obtained by 50 subpulses with a bandwidth of 36 MHz are improved by 4.8 dBs and 4.5 dBs, respectively, when compared to the frequency domain wideband synthesis method, and that the grating lobe is suppressed by an average of 10.6 dBs. It also performs well in terms of point target resolution, and it has potential for 2D radar super-resolution imaging. Full article

Conventional radars commonly use a linear frequency-modulated (LFM) waveform as the transmitted signal. The LFM radar is a simple system, but its impulse-response function produces a −13.25 dB sidelobe, which in turn can make the detection of weak targets difficult by drowning out adjacent weak target information with the sidelobe of a strong target. To overcome this challenge, this paper presents a modeling and optimization method for non-linear frequency-modulated (NLFM) waveforms. Firstly, the time-frequency relationship model of the NLFM signal was combined by using the Legendre polynomial. Next, the signal was optimized by using a bio-inspired method, known as the Firefly algorithm. Finally, the numerical results show that the advantages of the proposed NLFM waveform include high resolution and high sensitivity, as well as ultra-low sidelobes without the loss of the signal-to-noise ratio (SNR). To the authors’ knowledge, this is the first study to use NLFM signals for target-velocity improvement measurements. Importantly, the results show that mitigating the sidelobe of the radar waveform can significantly improve the accuracy of the velocity measurements. Full article

In this paper, in order to reduce the probability of the radar waveform intercepted by the passive detection system, the time-bandwidth product of the radar waveform is increased, and the detection probability of the radar waveform to the target is improved. This paper tackles the holographic RF stealth radar and proposes a joint coding waveform based on the linear frequency modulation (LFM) waveform. Joint coding uses complementary codes to perform phase-coding, and combines the codewords optimized by genetic algorithm in order to perform discrete frequency-coding waveform. The joint coding waveform model is theoretically analyzed, and the ambiguity function, pulse compression and target detection probability of the joint coding waveform are obtained by numerical simulation. In addition, the complexity of the algorithm and the low probability of intercept (LPI) characteristic of the joint coding waveform are analyzed. The results show that the joint coding waveform has an approximate “pushpin” ambiguity function, ultra-low sidelobe characteristics, better RF stealth and target detection performance. Finally, it has good application prospects in the current battlefield environment. Full article

The miniaturized high-gain antenna is required in portable, ultra-wideband radar systems. However, the miniaturization, ultra-wideband and high gain often restrict each other in the antenna design. In this paper, a dual-polarized, double-slot, antipodal tapered slot antenna with a double-layer, dual-loop structure and novel slot edges is presented. The proposed magnetic dual-loop structure has the capacity to reduce the low cut-off frequency of the double-slot tapered slot antenna by weakening the resonance and coupling. In addition, the high gain, low sidelobe level (SLL), and low cross-polarization level are achieved in the boresight direction. A novel gradient slot profile is designed to improve the low-frequency directivity of the tapered slot antenna without affecting the matching. To feed the antenna elements, a kind of wideband, balun-divider structure is designed. The dual-polarized antenna is combined by two orthogonal elements in a cross configuration without galvanic contact or influence to performance. The measured results show that the impedance bandwidth of the proposed antenna is 0.6~4 GHz, and the maximum gain is 11 dBi. The isolation between the two antenna ports is better than 32 dB, and the cross-polarization discrimination (XPD) is better than 20 dB. Full article

Simultaneous fully polarimetric radar uses orthogonal polarization channels to transmit a pair of signals, both of which must have good auto- and cross-correlation characteristics. In this paper, the design of sequences with good correlation properties and Doppler tolerance is investigated. New cyclic algorithms, namely, Cyclic Algorithm-Gradient I (CAGI) and Cyclic Algorithm-Gradient II (CAGII) are proposed to solve the optimization problem. Meanwhile, the sequences designed in this paper have ultra-low auto- and cross-correlation side-lobes in a specified lag interval. Numerical experiments are conducted to demonstrate and validate the superiority of the proposed cyclic algorithms, especially for the measurement of moving targets. Full article
