Search Results (81)

Numerical simulation is a vital tool in the development of FeCrAl alloy cladding tubes, with its reliability closely tied to the predictive accuracy of the thermal deformation constitutive model used. In this study, hot compression tests on 0Cr23Al5 alloy were conducted using a Gleeble-3800 thermal compression testing machine (Dynamic Systems Inc., located in Albany, NY, USA), across a temperature range of 850–1050 °C and a strain rate range of 0.1–10 s⁻¹. Based on the data obtained, both the Arrhenius constitutive model and the artificial neural network (ANN) model were developed. The ANN model demonstrated significantly superior predictive accuracy, with an average absolute relative error (AARE) of only 0.70% and a root mean square error (RMSE) of 1.99 MPa, compared to the Arrhenius model (AARE of 4.30% and RMSE of 14.47 MPa). Further validation via the VUHARD user subroutine in ABAQUS revealed that the ANN model has good applicability and reliability in numerical simulations, with its predicted flow stress showing high consistency with the experimental data. The ANN model developed in this study can effectively predict the rheological stress of FeCrAl alloys during hot deformation. It provides methodological support for high-fidelity constitutive modeling of the flow stress of FeCrAl alloys and offers a reliable constitutive model for simulating the thermomechanical load response behavior of FeCrAl alloys. Full article

In this study, the hot deformation behavior of novel 0.17C-3.92Mn-1.02Si-0.53Al-0.22Mo-0.032Ti-0.069V steel during continuous compression was predicted using numerical simulation, providing a reference for optimizing the process. Medium-Mn steels have not been applied for forgings yet. Therefore, their industrial application requires detailed investigations on their hot deformability. Results of finite element (FEM) simulations will be used for further optimization of the press forging process. The material model parameters used in the FEM method were identified based on stress–strain curves registered during hot compression tests carried out using a Gleeble thermomechanical simulator. The numerical simulation and physical investigations were performed at temperatures of 900, 1000 and 1100 °C to reflect a range of temperatures occurring during press forging. The influence of strain rates of 0.05, 0.5 and 5 s⁻¹ on the flow behavior of steel was also investigated. Colored maps of the plastic strain distribution in a sample volume were obtained as a result of the numerical research. The maps allowed for the identification of differently strengthened zones as a result of varied plastic strain. Results of FEM analysis were experimentally validated by hardness measurements. A good correlation between the hardness and plastic deformation zones was obtained. An increase in the material hardness was identified in the zones characterized by the highest plastic strain. Full article

A modified carbide-free bainite (CFB) steel has been developed, building on existing alloys for compatibility with commercial continuous annealing lines (CALs), featuring a low austenitization temperature and short overaging time. The microstructural features of such candidate CFB sheets are compared with those of conventional CFB steel sheets that require higher reheating temperatures and longer overaging times. The effects of annealing parameters such as reheating temperatures and overaging temperatures on phase transformation kinetics and microstructure evolution are presented. The annealing process was simulated in a Gleeble thermomechanical processing simulator, and the microstructural characterization was carried out using XRD, SEM, and EBSD. Reconstruction of parent austenite grains from EBSD data did not reveal any variant selection, regardless of changes in the austenitization temperature, overaging temperature, or carbon content. It was observed that the V1–V2 variant pairing is the most common at the lower overaging temperature for reheating at 950 °C; however, this pairing decreases as the isothermal overaging temperature increases, with variant pairings involving low misorientation boundaries—such as V1–V4 and V1–V8—becoming more frequent. Steels with higher carbon content exhibit no significant changes in their variant pairing, regardless of variations in the austenitizing or isothermal temperatures. The XRD results show that the retained austenite fraction is reduced by increasing the isothermal transformation temperature. Full article

This study used the Gleeble 3800 thermomechanical simulator to examine the hot deformation characteristics of AISI 8822H steel. The main goal was to understand the alloy’s behaviour under various thermomechanical settings, emphasising temperature ranges between 1173 K and 1323 K and strain rates from 0.01 s⁻¹ to 10 s⁻¹. This study aimed to enhance the alloy’s manufacturing process by offering a thorough understanding of the material’s response to these conditions. Four various constitutive models—Arrhenius-type, Johnson–Cook, modified Johnson–Cook, and Trimble—were used in a comprehensive technique to forecast flow stress values in order to meet the study’s goals. The accuracy of each model in forecasting the behaviour of the material under the given circumstances was assessed. A thorough comparison investigation revealed that the Trimble model was the most accurate model allowing prediction of material behaviour, with the maximum correlation factor (R = 0.99) and at least average absolute relative error (1.7%). On the other hand, the Johnson–Cook model had the least correlation factor (R = 0.92) and the maximum average absolute relative error (32.2%), indicating that it was the least accurate because it could not account for all softening effects. Full article

Gleeble thermomechanical simulators are widely utilized tools for the investigation of high-temperature deformation behavior in materials. However, temperature gradients that develop within the specimen during Gleeble compression tests have the potential to result in non-uniform deformation, which may subsequently impact the accuracy of the measured mechanical properties. This study presents an experimental and numerical investigation of the temperature fields in 2017-T4 aluminum alloy specimens prior to Gleeble compression tests at temperatures ranging from $300 °\mathrm{C} \mathrm{to} 500 °\mathrm{C}$ utilizing uniform temperature distribution (ISO-T) tungsten carbide anvils. The use of multiple thermocouples, welded to both the specimen and anvils, offers valuable insights into the temperature gradients and their evolutions. A coupled thermal–electrical finite-element model was developed in Abaqus for the purpose of simulating the resistive heating process. A user amplitude subroutine (UAMP) is implemented to regulate the heating based on a proportional–integral–derivative (PID) algorithm that modulates the current density to follow the specified temperature profile. The numerical results demonstrate that the temperature gradients within the specimen at the end of the heating process, reaching a temperature of $400 °\mathrm{C}$, are minimal, with values below $1.9 °\mathrm{C}$. This is in accordance with the experimental observations. The addition of graphite foils between the specimen and anvils has been shown to effectively reduce the gradients. The use of the measured anvil temperature as a boundary condition, rather than a constant value of $20 °\mathrm{C}$, has been demonstrated to improve the agreement between the simulated and experimental cooling curves. The modeling approach provides a framework for quantifying temperature gradients in Gleeble compression specimens and for assessing their impact on the measured constitutive response of materials at elevated temperatures. Full article

In recent years, there has been a lack of information in the literature regarding the extrusion and connection of closed profiles from oxygen-free copper in bridge dies. Available studies contain information on the processes of extrusion and connection of profiles from aluminium alloys and various types of steel. However, there is a lack of detailed data on the values of technological parameters for which copper is joined in the extrusion process. Therefore, one of the goals of this work is to fill the gap in the literature regarding the extrusion of oxygen-free copper in bridge dies. In this work, the authors determined the thermo-mechanical conditions at which oxygen-free copper will be joined. This paper describes the effects of charge temperature and hydrostatic pressure in the weld zone of a bridge die on copper bonding in the fabrication of tubular profiles. Physical tests of the welding process under the conditions of upsetting a material consisting of two parts were carried out using the Gleeble 3800 metallurgical process simulator with the PocketJaw module in the standard configuration for SICO (strain-induced crack opening) tests. For the numerical simulations, the commercial computer programme FORGE^®NxT 2.1. using the finite element method (FEM) was used. Based on the analysis of the test results obtained, it was found that complete material bonding during the extrusion process could be achieved for a charge temperature higher than 600 °C and a hydrostatic pressure of 45–65 MPa. Full article

In this study, 48 hot-rolling processing conditions were designed to investigate the influences of thermomechanical processing parameters on the recrystallization behavior and texture development. The hot-rolling experiments were conducted using the thermomechanical simulator Gleeble 3800 at temperatures of 275, 300, and 350 °C with strain rates of 5 and 90 ${\mathrm{s}}^{-1}$ up to 60 and 85% reduction. The microstructure and texture analysis were measured by using the EBSD technique on a large area. Experimental results show that the Cube component maintains a volume fraction between 10% and 20%, below the 40% recrystallization fraction, but the volume fraction of Cube significantly increases between 20% and 50% above the 40% recrystallization fraction. However, the fractions of Rotated Cube (RC) and Goss components remain below 10%. Full article

The flow behaviour of AA2060 Al alloy under warm/hot deformation conditions is complicated because of its dependency on strain rates ($\dot{\epsilon }$), strain ($\epsilon$), and deformation modes. Thus, it is crucial to reveal and predict the flow behaviours of this alloy at a wide range of temperatures ($T)$ and $\dot{\epsilon }$ using different constitutive models. Firstly, the isothermal tensile tests were carried out via a Gleeble-3800 thermomechanical simulator at a $T$ range of 100, 200, 300, 400, and 500 °C and $\dot{\epsilon }$ range of 0.01, 0.1, 1, and 10 s⁻¹ to reveal the warm/hot flow behaviours of AA2060 alloy sheet. Consequently, three phenomenological-based constitutive models (L-MJC, S1-MJC, S2-MJC) and a modified Zerilli–Armstrong (MZA) model representing physically based constitutive models were developed to precisely predict the flow behaviour of AA2060 alloy sheet under a wide range of $T$ and $\dot{\epsilon }$. The predictability of the developed constitutive models was assessed and compared using various statistical parameters, including the correlation coefficient (R), average absolute relative error (AARE), and root mean square error (RMSE). By comparing the results determined from these models and those obtained from experimentations, and confirmed by R, AARE, and RMSE values, it is concluded that the predicted stresses determined from the S2-MJC model align closely with the experimental stresses, demonstrating a remarkable fit compared to the S1-MJC, L-MJC, and MZA models. This is because of the linking impact between softening, the strain rate, and strain hardening in the S2-MJC model. It is widely known that the dislocation process is affected by softening and strain rates. This is attributed to the interactions that occurred between $\epsilon$ and $\dot{\epsilon }$ from one side and between $\epsilon$, $\dot{\epsilon }$, and $T$ from the other side using an extensive set of constants correlating the constitutive components of dynamic recovery and softening mechanisms. Full article

Exploring the mechanism of the α-ferrite precipitation process on high-temperature properties plays an important guiding role in avoiding slab cracks and effectively regulating quality. In this work, in situ observation of the α-ferrite sustained precipitation behavior for peritectic steel during the austenitic phase transition process has been investigated using high-temperature confocal scanning laser microscopy. Meanwhile, the high-temperature evolution of the phase fractions during the phase transition process was quantitatively analyzed based on the high-temperature expansion experiment using the peak separation method. Furthermore, the high-temperature properties variations of the casting slab during the α-ferrite sustained precipitation process were investigated with the Gleeble thermomechanical simulator. The results show that the film-like ferrite precipitated along the austenite grain boundaries at the initial stage of phase transition, then needle-like ferrite initiates rapid precipitation on film-like ferrite when the average thickness reaches 15~20 μm. Hot ductility reached a minimum at the ferrite phase fraction f_α = 10~15%, while high-temperature properties returned to a higher level after f_α > 40~45%. The appearance of a considerable amount of needle-like ferrite and grain refinement effectively improves the high-temperature properties with the α-ferrite precipitation process advances. Full article

The microstructure and mechanical properties of a low-alloy medium carbon steel (Fe-0.5C-0.9Mn-1Cr-0.16V, in wt.%) were investigated after rapid tempering and compared with a conventionally tempered counterpart. The conventional thermal cycle was performed in a laboratory-scale box furnace while rapid heat treatments were carried out using the Gleeble 3800 thermomechanical simulator machine. In the rapid heat treatments, the heating rate was 50 °C/s for austenitizing and 60 °C/s for the tempering process, with a cooling rate of 60 °C/s for both treatments. Austenitization was performed at 900 °C for 3 s and tempering was conducted at 300 °C and 500 °C for 2 s. For conventional routes, the heating rate for both austenitization and tempering was 5 °C/s. Likewise, the austenitization was carried out at 900 °C for 45 min and tempering was carried out at 300 °C and 500 °C for 30 min. The results revealed that rapid tempering resulted in a significantly increased impact toughness compared to conventional tempering, while maintaining a consistent high strength level. The quenched samples showed the highest hardness and tensile strength but obtained the lowest toughness values. The optimum combination of strength and toughness was achieved with the sample rapidly tempered at 300 °C, resulting in a tensile strength of 2050 MPa and impact energy of 14 J for sub-sized CVN samples. These desirable mechanical properties were achieved throughout the tempered martensitic microstructure with a minor fraction of pearlitic strings. Full article

The “electron wind effect” has long been cited as a potential catalyst of solid-state transformations in metals, particularly when high current densities are involved. However, the literature exploring similar effects at lower current densities, such as those occurring during Gleeble thermomechanical simulation, remains scarce. The present work compares recrystallization activity in cold-rolled low-carbon steel during heat treatment by conventional furnace versus direct resistance heating (Gleeble). Multiple levels of cold work, annealing durations, and soak temperatures were examined, allowing for an in-depth comparison of recrystallization rates and activation energies between samples subjected to identical time–temperature profiles in the furnace and Gleeble. In addition to the expected increase in recrystallization behavior with the increases in temperature and cold-reduction levels, the use of the Gleeble system as the heating method resulted in faster initial microstructural transformation than a conventional furnace. The variability in recrystallized fractions persisted until the microstructures had saturated to their nearly fully recrystallized levels, at which point the microhardness and electron backscatter diffraction (EBSD) revealed convergence to equivalent behavior irrespective of the heating method. Analysis of the recrystallization kinetics by fitting to a JMAK relationship reflected the increased transformation activity during Gleeble treatment, with the value of the kinetic exponent also indicating greater grain growth activity at higher temperature. Full article

Measuring the mechanical properties of weld Heat Affected Zone (HAZ) remains one of the main challenges in the failure analysis of spot-welded components. Due to the small size of the HAZ and variation in the temperature history, different peak temperatures and cooling rates impose a range of phase transformations across the resistance spot weld. Among the HAZ sub-regions, the sub-critical HAZ (SCHAZ), which experiences temperatures below A_C1 (350–650 °C), usually shows a reduction in the hardness in most of the modern AHSS grades due to the martensite tempering phenomenon. SCHAZ softening may lead to strain localization during loading. Therefore, it is important to characterize the local properties of the SCHAZ region to accurately predict RSW failure. However, it is not feasible to extract standard mechanical test specimens out of the SCHAZ of the spot-welded structure due to its small size. In this work, the SCHAZ of the spot weld for two AHSS, 3G-980 and PHS-1500, was simulated using a Gleeble^® (Dynamic Systems Inc., 323 NY-355, Poestenkill, NY 12140, USA) 3500 thermo-mechanical simulator. An in-situ high-speed IR thermal camera was used to measure the entire temperature field during the Gleeble heat-treatment process, which allowed for the visualization of the temperature distribution in the gauge area. The temperature and hardness data were fit to a Hollomon-Jaffe (HJ) model, which enables hardness prediction in the SCHAZ at any given temperature and time. Using the HJ model, a heat treatment schedule for each material was chosen to produce samples with hardness and microstructure matching the SCHAZ within actual spot weld coupons. Tensile specimens were machined from the coupons heat treated using simulated heat treatment schedules, and mechanical testing was performed. The results showed that the 3G-980 SCHAZ has a slight increase in yield strength and tensile strength, compared to the base metal, due to the formation of fine carbides within the microstructure. In contrast, the SCHAZ of PHS-1500 showed a significant reduction in the yield and tensile strength with yield point elongation behavior due to the reduction of the martensite phase and an increase in carbide formation due to the tempering process. Full article

AlCoCrFeNiTi_0.5 high-entropy alloy (HEA) shows excellent properties in hardness and corrosion resistance. AlCoCrFeNiTi_0.5 HEA was prepared using a non-consumable vacuum arc furnace. Hot-deformation behavior of AlCoCrFeNiTi_0.5 HEA was explored under 1073–1373 K with a strain rate between 0.001 and 1 s⁻¹ using a Gleeble-3800 thermomechanical simulator. The constitutive equation was established using the Arrhenius model, and the deformation activation energy and material constant were obtained. The processing map of HEA within 0.3–0.6 deformation was drawn according to dynamic material model (DMM). The results show that the hot-deformation process of HEA is dominated by work hardening combined with dynamic recovery, and dynamic recrystallization. The flow stress of HEA is significantly affected by deformation temperature and strain rate. The constitutive equation was constructed and verified, and the correlation coefficient of R² = 0.9873 indicated that the constitutive equation can be used to accurately predict the flow stress of HEA. The processing map of HEA shows that the optimal hot-working process parameters are in the range of temperature 1150–1300 K and strain rate 0.002–0.05 s⁻¹. This work will provide theoretical guidance for the hot-processing of HEA, which effectively promotes the application of the HEA in industry. Full article

This study presents a novel and thorough approach to comprehending and simulating the DRX process while hot compressing steel. To achieve this goal, we studied the high-temperature deformation behavior of a medium-carbon steel through hot compression testing on a Gleeble-3800 thermomechanical simulator over a broad range of strains, strain rates, and temperatures. We also employed an artificial neural network (ANN) to model the thermo-visco-plastic behavior with a flow law. The precision of quantifying the DRX volume fraction is dependent on critical conditions, which are essential for both analytical model evaluation and numerical implementation in finite element software. This study proposes a second ANN, serving as a universal approximator, to fit the data required for DRX critical condition calculations, whereas the Johnson–Mehl–Avrami–Kohnogorov (JMAK) model served as an analytical tool to estimate the DRX volume fraction, which underwent validation through experimental measurements. A numerical implementation of the JMAK model was conducted in ABAQUS software and compared against experimental data by means of microstructure analysis. The comparison revealed a strong correlation between the simulation and experiment. The study investigated the impact of temperature, strain, and strain rate on DRX evolution. The findings showed that DRX increases with rising temperature and strain but decreases with increasing strain rate. Full article

Since flow stress is an important parameter in the processing and application of metallic materials, it is necessary to trace the flow stress during austenite deformation. Thermal compression deformation of austenite in a high-strength bainitic steel was conducted using a Gleeble-3500 thermo-mechanical simulator, within the deformation temperature range of 400 °C~900 °C. By analyzing the stress–strain curves and strain-hardening exponent, the effects of strain hardening and dynamic recovery on the dislocation density of the material during the thermal processing were considered in the present work. Based on the general form of the Kocks–Mecking–Estrin (KME) model, the effects of deformation temperature and strain on the key parameters of the model were clarified. Differing from other work which commonly terms m (strain rate sensitivity exponent) and k₂ (dimensionless parameters for dynamic recovery) as constants, the current models consider the quantitative relationship between key parameters and deformation temperature and strain. The results show that m is an exponential function related to temperature and strain, which decreases with the increase in strain. Meanwhile, k₂ is a temperature-dependent polynomial function that increases as the deformation temperature increases. Finally, a modified constitutive KME model was proposed to predict the austenitic plastic stress with strain. Using established m-ε and k₂-T models, the predicted curves are in good agreement with the experimental measurements. Full article
