Search Results (29)

To address the inherent limitations of easy oxidation and unstable electrical properties in two-dimensional MXene-based flexible sensors, this study developed a MXene/GO/rGO (reduced graphene oxide) textile-based flexible sensor using a lamination method and in situ steam reduction technology. The sensor was constructed on a high-elasticity knitted polyester fabric, with MXene as the primary conductive layer, graphene oxide (GO) as the adhesive layer, and reduced graphene oxide (rGO) as the protective encapsulation surface layer. The tensile strain-sensing and electrothermal properties of the resulting e-textile were systematically characterized. The MXene/GO/rGO textile demonstrated outstanding electrical and mechanical performance, achieving a conductivity of 39.7 S·m⁻¹, a gauge factors ranging from –3 to –1.6, and a controllable electrothermal heating range from 43 °C to 85 °C under currents of 0.02–0.05 A. Experimental results demonstrated that under applied currents of 0.02, 0.03, 0.04, and 0.05 A, the fabric reached temperatures of 43, 56, 73, and 85 °C, respectively, and remained constant over extended periods. In terms of strain sensing, the sensor exhibited a short response time (65 ms), high discriminability for different strain levels and stretching rates, and a consistent relative resistance change (ΔR/R0) under various stretching speeds (0.5, 1, 2, 4, and 6 mm/s). Compared with sensors based on a single conductive material, the MXene/GO/rGO polyester fabric sensor shows superior electrothermal and strain-sensing performance, indicating promising potential for applications in intelligent wearable textiles such as medical thermal therapy, sports monitoring, and health management. Full article

Real-time sweat pH monitoring offers a non-invasive window into metabolic status, disease progression, and wound healing. However, current wearable pH sensors struggle to balance high electrochemical sensitivity with mechanical compliance. Here we report a stretchable fiber-integrated pH electrode based on a polyaniline-phytic acid-polyvinyl alcohol (PANI-PA-PVA) hydrogel, which combines mechanical elasticity with enhanced electrochemical performance for continuous sweat sensing. Freeze–thaw crosslinking of the hydrogel forms a porous interpenetrating network, facilitating rapid proton transport and stable coupling with dry-spun elastic gold fibers. This wearable device exhibits an ultra-Nernstian sensitivity of 68.8 mV pH⁻¹, ultra-fast equilibrium (<10 s within the sweat-relevant acidic window), long-term drift of 0.0925 mV h⁻¹, and high mechanical tolerance (gel stretch recovery up to 165%). The sensor maintains consistent pH responses under bending and tensile strains, yielding sweat pH measurements at the skin surface during running that closely match commercial pH meters (sweat pH range measured in test subjects: 4.2–5.0). We further demonstrate real-time wireless readouts by integrating elastic gold and Ag/AgCl fibers into a three-electrode textile structure. This PANI-PA-PVA hydrogel strategy provides a scalable material platform for robust, high-performance wearable ion sensing and skin diagnostics. Full article

This paper presents a study on the repeatability of washing effects on two antenna-based sensors for breathing monitoring. One sensor is an embroidered meander antenna-based sensor integrated into a T-shirt, and the other is a loop antenna integrated into a belt. Both sensors were subjected to five washing cycles, and their performance was assessed after each wash. The embroidered meander antenna was specifically compared before and after washing to monitor a male volunteer’s different breathing patterns, that is, eupnea, apnea, hypopnea, and hyperpnea. Stretching tests were also conducted to evaluate the impact of mechanical deformation on sensor behavior. The results highlight the changes in sensor performance across multiple washes and stretching conditions, offering insights into the durability and reliability of these embroidered and loop antennas for practical applications in wearable health monitoring. The findings emphasize the importance of considering both washing and mechanical stress in the design of robust antenna-based sensors. Full article

This study evaluates the mapping accuracy between textile stretch sensor data and surface electromyography (sEMG) signals using Multilayer Perceptron (MLP), Convolutional Neural Network (CNN), and Residual Network (ResNet) models. Data from the forearm, biceps brachii, and triceps brachii were analyzed using Root Mean Square Error (RMSE) and R² as performance metrics. ResNet achieved the lowest RMSE (e.g., 0.1285 for biceps brachii) and highest R² (0.8372), outperforming CNN (RMSE: 0.1455; R²: 0.7639) and MLP (RMSE: 0.1789; R²: 0.6722). The residual learning framework of ResNet effectively handles nonlinear patterns and noise, enabling more accurate predictions even for low-variability datasets like the triceps brachii. CNN showed moderate improvement over MLP by learning temporal features but struggled with low-variability datasets. MLP, as the baseline model, demonstrated the highest RMSE and lowest R², highlighting its limitations in capturing complex relationships. These results suggest the potential reliability of ResNet for mapping textile stretch sensor data to sEMG signals, showing promising performance within the scope of this study. Future research could explore broader applications across different sensor configurations and activities to further validate these findings. Full article

The rapid developments in conductive polymers with flexible electronics over the past years have generated noteworthy attention among researchers and entrepreneurs. Conductive polymers have the distinctive capacity to conduct electricity while still maintaining the lightweight, flexible, and versatile characteristics of polymers. They are crucial for the creation of flexible electronics or gadgets that can stretch, bend, and adapt to different surfaces have sparked momentous interest in electronics, energy storage, sensors, smart textiles, and biomedical applications. This review article offers a comprehensive overview of recent advancements in conductive polymers over the last 15 years, including a bibliometric analysis. The properties of conductive polymers are summarized. Additionally, the fabrication processes of conductive polymer-based materials are discussed, including vacuum filtering, hydrothermal synthesis, spray coating, electrospinning, in situ polymerization, and electrochemical polymerization. The techniques have been presented along with their advantages and limitations. The multifunctional applications of conductive polymers are also discussed, including their roles in energy storage and conversion (e.g., supercapacitors, lithium-ion batteries (LIBs), and sodium-ion batteries (SIBs)), as well as in organic light-emitting diodes (OLEDs), organic solar cells (OSCs), conductive textiles, healthcare monitoring, and sensors. Future scope and associated challenges have also been mentioned for further development in this field. Full article

In this study, we explore how the strategic positioning of conductive yarns influences the performance of plated knit strain sensors fabricated using commercial knitting machines with both conductive and non-conductive yarns. Our study reveals that sensors with conductive yarns located at the rear, referred to as ‘purl plated sensors’, exhibit superior performance in comparison to those with conductive yarns at the front, or ‘knit plated sensors’. Specifically, purl plated sensors demonstrate a higher sensitivity, evidenced by a gauge factor ranging from 3 to 18, and a minimized strain delay, indicated by a 1% strain in their electromechanical response. To elucidate the mechanisms behind these observations, we developed an equivalent circuit model. This model examines the role of contact resistance within varying yarn configurations on the sensors’ sensitivity, highlighting the critical influence of contact resistance in conductive yarns subjected to wale-wise stretching on sensor responsiveness. Furthermore, our findings illustrate that the purl plated sensors benefit from the vertical movement of non-conductive yarns, which promotes enhanced contact between adjacent conductive yarns, thereby improving both the stability and sensitivity of the sensors. The practicality of these sensors is confirmed through bending cycle tests with an in situ monitoring system, showcasing the purl plated sensors’ exceptional reproducibility, with a standard deviation of 0.015 across 1000 cycles, and their superior sensitivity, making them ideal for wearable devices designed for real-time joint movement monitoring. This research highlights the critical importance of conductive yarn placement in sensor efficacy, providing valuable guidance for crafting advanced textile-based strain sensors. Full article

The integration of textile-based flexible sensors and electronic devices has accelerated the development of wearable textiles for posture monitoring. The complexity of the processes required to create a complete monitoring product is currently reflected in three main areas. The first is the sensor production process, which is complex. Second, the integration of the sensor into the garment requires gluing or stitching. Finally, the production of the base garment requires cutting and sewing. These processes deteriorate the user experience and hinder the commercial mass production of wearable textiles. In this paper, we knitted a one-piece seamless knitted vest (OSKV) utilizing the one-piece seamless knitting technique and positioned an embedded needle sensing zone (EHSZ) with good textile properties and electrical performance for monitoring human shoulder activity. The EHSZ was knitted together with the OSKV, eliminating the need for an integration process. The EHSZ exhibited good sensitivity (GF = 2.23), low hysteresis (0.29 s), a large stretch range (200%), and excellent stability (over 300 cycles), satisfying the requirement to capture a wide range of deformation signals caused by human shoulder movements. The OSKV described the common vest process structure without the stitching process. Furthermore, OSKV fulfilled the demand for seamless and trace-free monitoring while effortlessly and aesthetically satisfying the knitting efficiency of commercial garments. Full article

People whose jobs involve repetitive motions of the wrist and forearm can suffer from lateral epicondylitis, which is a significant burden on both the individual and the employer due to treatment costs, reduced productivity, and work absenteeism. This paper describes an ergonomic intervention to reduce lateral epicondylitis in the workstation of a textile logistics center. The intervention includes workplace-based exercise programs, evaluation of risk factors, and movement correction. An injury- and subject-specific score was calculated from the motion captured with wearable inertial sensors at the workplace to evaluate the risk factors of 93 workers. Then, a new working movement was adapted to the workplace, which limited the observed risk factors and took into account the subject-specific physical abilities. The movement was taught to the workers during personalized sessions. The risk factors of 27 workers were evaluated again after the intervention to validate the effectiveness of the movement correction. In addition, active warm-up and stretching programs were introduced as part of the workday to promote muscle endurance and improve resistance to repetitive stress. The present strategy offered good results at low cost, without any physical modification of the workplace and without any detriment to productivity. Full article

With the start of the intelligent age, textiles are no longer limited to safety protection, warmth, and aesthetic purposes. They have become intelligent textiles, which combine functionality, intelligence, and information technology to adapt to the era and enrich our lives, such as wearable textiles and energy harvesting electronics. However, the limited stretchable smart textiles and complex fabrication methods have largely hindered their development. Here, a mass-manufactured 3D stitching double weave fabric-based elastic triboelectric nanogenerator (3DWE-TENG) is developed. Based on its stable electrical output performances and rapid response to external tensile strain, it can be used for energy harvesting and self-powered sensing simultaneously through both the lining layer and the exterior layer. With an advanced 3D structural design and using the improved woven method, 3DWE-TENG can be stretched to 300% and achieves a stable mechanical structure, breathability, and excellent flexibility. Furthermore, it also has low costs, wearable comfortability, and high fabricating efficiency due to the mature woven technique and the common yarns used in the fabric. This work provides more opportunities for stretchable power sources and self-powered sensors with applications in wearable electronics. Full article

With the triboelectric nanogenerator developing in recent years, it has gradually become a promising alternative to fossil energy and batteries. Its rapid advancements also promote the combination of triboelectric nanogenerators and textiles. However, the limited stretchability of fabric-based triboelectric nanogenerators hindered their development in wearable electronic devices. Here, in combination with the polyamide (PA) conductive yarn, polyester multifilament, and polyurethane yarn, a highly stretchable woven fabric-based triboelectric nanogenerator (SWF-TENG) with the three elementary weaves is developed. Different from the normal woven fabric without elasticity, the loom tension of the elastic warp yarn is much larger than non-elastic warp yarn in the weaving process, which results in the high elasticity of the woven fabric coming from the loom. Based on the unique and creative woven method, SWF-TENGs are qualified with excellent stretchability (up to 300%), flexibility, comfortability, and excellent mechanical stability. It also exhibits good sensitivity and fast responsibility to the external tensile strain, which can be used as a bend–stretch sensor to detect and identify human gait. Its collected power under pressure mode is capable of lighting up 34 light-emitting diodes (LEDs) by only hand-tapping the fabric. SWF-TENG can be mass-manufactured by using the weaving machine, which decreases fabricating costs and accelerates industrialization. Based on these merits, this work provides a promising direction toward stretchable fabric-based TENGs with wide applications in wearable electronics, including energy harvesting and self-powered sensing. Full article

The aim of this paper is to present novel highly sensitive and stretchable strain sensors using data analysis to report on human live parameters using the Arduino embedded system as a proof of concept in developing new and innovative solutions for health care. The article introduces the solution of textile sensor origination with electrical resistance measurement using the mobile Arduino microcontroller in the designed/elaborated textile printed sensor. The textile sensor was developed by the screen printing technique based on the water dispersion of carbon nanotubes during printing composition. By stretching and squeezing the T-shirt during breathing, the electrical resistances of the printed sensor were changed. The measured resistance corresponded to the number of breaths of the person wearing the T-shirt. The microcontroller calculated the number of breaths as a number of electrical resistance peaks, which then led to monitoring human live parameters. Full article

Smart textile sensors have been gaining popularity as alternative methods for the continuous monitoring of human motion. Multiple methods of fabrication for these textile sensors have been proposed, but the simpler ones include stitching or embroidering the conductive thread onto an elastic fabric to create a strain sensor. Although multiple studies have demonstrated the efficacy of textile sensors using the stitching technique, there is almost little to no information regarding the fabrication of textile strain sensors using the embroidery method. In this paper, a design guide for the fabrication of an embroidered resistive textile strain sensor is presented. All of the required design steps are explained, as well as the different embroidery design parameters and their optimal values. Finally, three embroidered textile strain sensors were created using these design steps. These sensors are based on the principle of superposition and were fabricated using a stainless-steel conductive thread embroidered onto a polyester–rubber elastic knit structure. The three sensors demonstrated an average gauge factor of $1.88\pm 0.51$ over a 26% working range, low hysteresis ($8.54\pm 2.66\%$), and good repeatability after being pre-stretched over a certain number of stretching cycles. Full article

The advancement of smart textiles has led to significant interest in developing wearable textile sensors (WTS) and offering new modalities to sense vital signs and activity monitoring in daily life settings. For this, textile fabrication methods such as knitting, weaving, embroidery, and braiding offer promising pathways toward unobtrusive and seamless sensing for WTS applications. Specifically, the knitted sensor has a unique intermeshing loop structure which is currently used to monitor repetitive body movements such as breathing (microscale motion) and walking (macroscale motion). However, the practical sensing application of knit structure demands a comprehensive study of knit structures as a sensor. In this work, we present a detailed performance evaluation of six knitted sensors and sensing variation caused by design, sensor size, stretching percentages % (10, 15, 20, 25), cyclic stretching (1000), and external factors such as sweat (salt-fog test). We also present regulated respiration (inhale–exhale) testing data from 15 healthy human participants; the testing protocol includes three respiration rates; slow (10 breaths/min), normal (15 breaths/min), and fast (30 breaths/min). The test carried out with statistical analysis includes the breathing time and breathing rate variability. These testing results offer an empirically derived guideline for future WTS research, present aggregated information to understand the sensor behavior when it experiences a different range of motion, and highlight the constraints of the silver-based conductive yarn when exposed to the real environment. Full article

Wearable technology has been getting more attention for monitoring vital signs in various medical fields, particularly in breathing monitoring. To monitor respiratory patterns, there is a current set of challenges related to the lack of user comfort, reliability, and rigidity of the systems, as well as challenges related to processing data. Therefore, the need to develop user-friendly and reliable wireless approaches to address these problems is required. In this paper, a novel, full, compact textile breathing sensor is investigated. Specifically, an embroidered meander dipole antenna sensor integrated into an e-textile T-shirt with a Bluetooth transmitter for real-time breathing monitoring was developed and tested. The proposed antenna-based sensor is designed to transmit data over wireless communication networks at 2.4 GHz and is made of a silver-coated nylon thread. The sensing mechanism of the proposed system is based on the detection of a received signal strength indicator (RSSI) transmitted wirelessly by the antenna-based sensor, which is found to be sensitive to stretch. The respiratory system is placed on the middle of the human chest; the area of the proposed system is 4.5 × 0.48 cm², with 2.36 × 3.17 cm² covered by the transmitter module. The respiratory signal is extracted from the variation of the RSSI signal emitted at 2.4 GHz from the detuned embroidered antenna-based sensor embedded into a commercial T-shirt and detected using a laptop. The experimental results demonstrated that breathing signals can be acquired wirelessly by the RSSI via Bluetooth. The RSSI range change was from −80 dBm to −72 dBm, −88 dBm to −79 dBm and −85 dBm to −80 dBm during inspiration and expiration for normal breathing, speaking and movement, respectively. We tested the feasibility assessment for breathing monitoring and we demonstrated experimentally that the standard wireless networks, which measure the RSSI signal via standard Bluetooth protocol, can be used to detect human respiratory status and patterns in real time. Full article

The development of wearable electronic devices has greatly stimulated the research interest of textile-based strain sensors, which can effectively combine functionality with wearability. In this work, the fabrication of highly stretchable and compressible strain sensors from weft-knitted spacer fabric was reported. Carbon nanotubes and polypyrrole were deposited on the surface of fabric via an in situ polymerization approach to reduce the electrical resistance. The as-fabricated WSP-CNT-PPy strain sensor exhibits high electrical conductivity and stable strain-sensing performance under different stretching deformations. The WSP-CNT-PPy strain sensor can be stretched up to 450% and compressed to 60% with a pressure of less than 50 KPa, which can be attributed to the unique loop and interval filament structures. The distinguishing response efficiency of WSP-CNT-PPy can effectively detect faint and strenuous body movements. In addition, the electrochemical behavior of WSP-CNT-PPy was also characterized to study the comprehensive properties. The electro-heating performance was also evaluated for feasible Joule heater applications. This work demonstrates the practicability of WSP-CNT-PPy strain sensor fabric for real-time monitoring in promising wearable garments. Full article
