Due to the continuous increase in data traffic, it is becoming imperative to develop communication systems capable of meeting the throughput requirements. Monolithic Opto-Electronic Integrated Circuits (OEICs) are ideal candidates to meet these demands. With that in mind, we propose a compact and computationally efficient model for Uni-Traveling Carrier Photodiodes (UTC-PDs) which are a key component of OEICs because of their high bandwidth and RF output power. The developed compact model is compatible with existing SPICE design software, enabling the design of beyond 5G and terahertz (THz) communication circuits and systems. By introducing detailed physical equations describing, in particular, the dark current, the intrinsic series resistance, and the junction capacitance, the model accurately captures the physical characteristics of the UTC-PD. The model parameter extraction follows a scalable extraction methodology derived from that of the bipolar and CMOS technologies. A detailed description of the de-embedding process is presented. Excellent agreement between the compact model and measurements has been achieved, showing model versatility across various technologies and scalability over several geometries. Full article

This review paper reports the prerequisites of a monolithic integrated terahertz (THz) technology capable of meeting the network capacity requirements of beyond-5G wireless communications system (WCS). Keeping in mind that the terahertz signal generation for the beyond-5G networks relies on the technology power loss management, we propose a single computationally efficient software design tool featuring cutting-edge optical devices and high speed III–V electronics for the design of optoelectronic integrated circuits (OEICs) monolithically integrated on a single Indium-Phosphide (InP) die. Through the implementation of accurate and SPICE (Simulation Program with Integrated Circuit Emphasis)-compatible compact models of uni-traveling carrier photodiodes (UTC-PDs) and InP double heterojunction bipolar transistors (DHBTs), we demonstrated that the next generation of THz technologies for beyond-5G networks requires (i) a multi-physical understanding of their operation described through electrical, photonic and thermal equations, (ii) dedicated test structures for characterization in the frequency range higher than 110 GHz, (iii) a dedicated parameter extraction procedure, along with (iv) a circuit reliability assessment methodology. Developed on the research and development activities achieved in the past two decades, we detailed each part of the multiphysics design optimization approach while ensuring technology power loss management through a holistic procedure compatible with existing software tools and design flow for the timely and cost-effective achievement of THz OEICs. Full article

Frequency multipliers and mixers based on Schottky barrier diodes (SBDs) are widely used in terahertz (THz) imaging applications. However, they still face obstacles, such as poor performance consistency caused by discrete flip-chip diodes, as well as low efficiency and large receiving noise temperature. It is very hard to meet the requirement of multiple channels in THz imaging array. In order to solve this problem, 12-μm-thick gallium arsenide (GaAs) monolithic integrated technology was adopted. In the process, the diode chip shared the same GaAs substrate with the transmission line, and the diode’s pads were seamlessly connected to the transmission line without using silver glue. A three-dimensional (3D) electromagnetic (EM) model of the diode chip was established in Ansys High Frequency Structure Simulator (HFSS) to accurately characterize the parasitic parameters. Based on the model, by quantitatively analyzing the influence of the surface channel width and the diode anode junction area on the best efficiency, the final parameters and dimensions of the diode were further optimized and determined. Finally, three 0.34 THz triplers and subharmonic mixers (SHMs) were manufactured, assembled, and measured for demonstration, all of which comprised a waveguide housing, a GaAs circuit integrated with diodes, and other external connectors. Experimental results show that all the triplers and SHMs had great performance consistency. Typically, when the input power was 100 mW, the output power of the THz tripler was greater than 1 mW in the frequency range of 324 GHz to 352 GHz, and a peak efficiency of 6.8% was achieved at 338 GHz. The THz SHM exhibited quite a low double sideband (DSB) noise temperature of 900~1500 K and a DSB conversion loss of 6.9~9 dB over the frequency range of 325~352 GHz. It is indicated that the GaAs monolithic integrated process, diodes modeling, and circuits simulation method in this paper provide an effective way to design THz frequency multiplier and mixer circuits. Full article

A global design method for a terahertz monolithic integrated frequency multiplier is proposed. Compared with a traditional independent design, the method in this paper adopts overall optimization and combines the device with the circuit design. The advantage is that it provides a customized design for frequency multipliers according to specifications. On the basis of the gallium arsenide process of the Institute of Microelectronics, Chinese Academy of Sciences, two types of Schottky diodes have been developed to meet the needs of different designs. On the one hand, a Schottky diode with a 3 μm junction’s diameter was used in the design of the 200 GHz balanced doubler and, on the other hand, a diode with a 5 μm diameter was used in the 215 GHz unbalanced tripler. The measured results indicated that the output power of the doubler was more than 250 μW at 180~218 GHz, and the maximum was 950 μW at 198 GHz when driven with 12.3 mW, whereas that of the tripler was above 5 mW at 210~218 GHz and the maximum exceeded 10 mW. Such frequency multiplier sources could be widely used in terahertz imaging, radiometers, and so on. Full article

We present thickness measurements with millimeter and terahertz waves using frequency-modulated continuous-wave (FMCW) sensors. In contrast to terahertz time-domain spectroscopy (TDS), our FMCW systems provide a higher penetration depth and measurement rates of several kilohertz at frequency modulation bandwidths of up to 175 GHz. In order to resolve thicknesses below the Rayleigh resolution limit given by the modulation bandwidth, we employed a model-based signal processing technique. Within this contribution, we analyzed the influence of multiple reflections adapting a modified transfer matrix method. Based on a brute force optimization, we processed the models and compared them with the measured signal in parallel on a graphics processing unit, which allows fast calculations in less than 1 s. TDS measurements were used for the validation of our results on industrial samples. Finally, we present results obtained with reduced frequency modulation bandwidths, opening the window to future miniaturization based on monolithic microwave integrated circuit (MMIC) radar units. Full article

This paper reviews the state of emerging transistor technologies capable of terahertz amplification, as well as the state of transistor modeling as required in terahertz electronic circuit research. Commercial terahertz radar sensors of today are being built using bulky and expensive technologies such as Schottky diode detectors and lasers, as well as using some emerging detection methods. Meanwhile, a considerable amount of research effort has recently been invested in process development and modeling of transistor technologies capable of amplifying in the terahertz band. Indium phosphide (InP) transistors have been able to reach maximum oscillation frequency (f_max) values of over 1 THz for around a decade already, while silicon-germanium bipolar complementary metal-oxide semiconductor (BiCMOS) compatible heterojunction bipolar transistors have only recently crossed the f_max = 0.7 THz mark. While it seems that the InP technology could be the ultimate terahertz technology, according to the f_max and related metrics, the BiCMOS technology has the added advantage of lower cost and supporting a wider set of integrated component types. BiCMOS can thus be seen as an enabling factor for re-engineering of complete terahertz radar systems, for the first time fabricated as miniaturized monolithic integrated circuits. Rapid commercial deployment of monolithic terahertz radar chips, furthermore, depends on the accuracy of transistor modeling at these frequencies. Considerations such as fabrication and modeling of passives and antennas, as well as packaging of complete systems, are closely related to the two main contributions of this paper and are also reviewed here. Finally, this paper probes active terahertz circuits that have already been reported and that have the potential to be deployed in a re-engineered terahertz radar sensor system and attempts to predict future directions in re-engineering of monolithic radar sensors. Full article

A waveguide-to-microstrip transition is an essential component for packaging integrated circuits (ICs) in rectangular waveguides, especially at millimeter-wave and terahertz (THz) frequencies. At THz frequencies, the on-chip transitions, which are monolithically integrated in ICs are preferred to off-chip transitions, as the former can eliminate the wire-bonding process, which can cause severe impedance mismatch and additional insertion loss of the transitions. Therefore, on-chip transitions can allow the production of low cost and repeatable THz modules. However, on-chip transitions show limited performance in insertion loss and bandwidth, more seriously, this is an in-band resonance issue. These problems are mainly caused by the substrate used in the THz ICs, such as an indium phosphide (InP), which exhibits a high dielectric constant, high dielectric loss, and high thickness, compared with the size of THz waveguides. In this work, we propose a broadband THz on-chip transition using a dipole antenna with an integrated balun in the InP substrate. The transition is designed using three-dimensional electromagnetic (EM) simulations based on the equivalent circuit model. We show that in-band resonances can be induced within the InP substrate and also prove that backside vias can effectively eliminate these resonances. Measurement of the fabricated on-chip transition in 250 nm InP heterojunction bipolar transistor (HBT) technology, shows wideband impedance match and low insertion loss at H-band frequencies (220–320 GHz), without in-band resonances, due to the properly placed backside vias. Full article
