Search Results (19)

Search Parameters:
Keywords = sump pump

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
20 pages, 5191 KiB
Article
Development of a Small-Working-Volume Plunger Hydraulic Pump with Improved Performance Characteristics
by Alexey N. Beskopylny, Denis Medvedev, Vyacheslav Grishchenko and Evgeniy Ivliev
Actuators 2025, 14(1), 34; https://doi.org/10.3390/act14010034 - 16 Jan 2025
Cited by 1 | Viewed by 1856
Abstract
Current trends in the development of technology are linked inextricably to the increasing level of automation in technological processes and production systems. In this regard, the development of systems for supplying working fluids with adjustable pumps that have high performance characteristics, an increased [...] Read more.
Current trends in the development of technology are linked inextricably to the increasing level of automation in technological processes and production systems. In this regard, the development of systems for supplying working fluids with adjustable pumps that have high performance characteristics, an increased service life and low operating costs is an important scientific and technical task. A primary challenge in the development of such systems lies in achieving low fluid flow rates while maintaining stable operating characteristics. This challenge stems from the fact that currently available controlled hydraulic pumps exhibit either a high cost or suboptimal life and efficiency parameters. This work focuses on the development of a plunger hydraulic pump with a small working volume. A mathematical model has been developed to investigate the characteristics, optimize the design of this pump and further expand the size range of such pumps. The solution was implemented on a computer using the dynamic modelling environment MATLAB/Simulink. In order to verify the mathematical model’s adequacy, a plunger pump prototype was built and integrated with a test bench featuring a measurement system. The test results showed higher pump efficiency and a significant reduction in hydraulic losses. An analysis of the obtained data shows that the pump is characterized by increased efficiency due to optimal flow distribution and reduced internal leakage, which makes it promising for use in hydraulic systems requiring improved operating characteristics. The developed pump has more rational characteristics compared to existing alternatives for use in water supply systems for induction superheaters. The experimental external characteristics of the developed pump are 10% higher than the external characteristics of the ULKA EX5 pump selected as an analogue, and the pressure characteristics are 65% higher. It offers production costs that are several times lower compared to existing cam-type plunger or diaphragm pumps with oil sumps and precision valve mechanisms. Additionally, it has significantly better operating characteristics and a longer service life compared to vibrating plunger pumps. Full article
(This article belongs to the Section Control Systems)
Show Figures

Figure 1

26 pages, 14879 KiB
Article
The Vortex Characteristics and Anti-Vortex Mechanism in a Lateral Agricultural Irrigation Pump Station with a Symmetrical Inlet-Distributed Method
by Zeyu Huang, Can Luo, Yajun Wang, Haojie Liang, Li Cheng, Kangzhu Jing, Rui Zhu and Bowen Zhang
Agriculture 2024, 14(12), 2170; https://doi.org/10.3390/agriculture14122170 - 28 Nov 2024
Viewed by 863
Abstract
Symmetric lateral inlet pumping stations are commonly utilized for water lifting in agricultural multi-crop irrigation districts, but they often share non-ideal flow patterns, which can easily cause pump vibration and sediment deposition. In this paper, a symmetrical lateral pumping station in an irrigation [...] Read more.
Symmetric lateral inlet pumping stations are commonly utilized for water lifting in agricultural multi-crop irrigation districts, but they often share non-ideal flow patterns, which can easily cause pump vibration and sediment deposition. In this paper, a symmetrical lateral pumping station in an irrigation district is taken as the research object, and CFD (Computational Fluid Dynamics) technology is used to study it. The model test used a model scale ratio of λL = 1:18. Results: By comparing the CFD data and test data, the average relative error for the left station is found to be 3.213%, while that for the right station is 5.107%, indicating that the numerical simulation method is reliable. Six different rectification measures are proposed, the cross sectional flow pattern of the pumping station is observed, and the longitudinal profile of axial velocity distribution in the sump is analyzed. The velocity-weighted average angle and hydraulic loss of each case study are also analyzed. The flow operates smoothly in case study 7. The vortex in the approach channel disappears when the columns and bottom sill are finally installed. Compared to the original case study, the velocity-weighted average angle at the 5# station in case study 7 increased by 14%, and it increased by 13.9% at station #9. The flow became more stable, and hydraulic losses were minimized. The simulated hydraulic loss in case study 7 decreased by 14.2%. These findings can serve as a reference for similar pump station projects. Full article
(This article belongs to the Section Agricultural Water Management)
Show Figures

Figure 1

17 pages, 42401 KiB
Article
Numerical Modeling of Two-Phase Flow inside a Wet Flue Gas Absorber Sump
by Nejc Vovk and Jure Ravnik
Energies 2023, 16(24), 8123; https://doi.org/10.3390/en16248123 - 18 Dec 2023
Cited by 1 | Viewed by 1493
Abstract
A numerical model of a flue gas scrubber sump is developed with the aim of enabling optimization of the design of the sump in order to reduce energy consumption. In this model, the multiphase flow of the continuous phase, i.e., water, and the [...] Read more.
A numerical model of a flue gas scrubber sump is developed with the aim of enabling optimization of the design of the sump in order to reduce energy consumption. In this model, the multiphase flow of the continuous phase, i.e., water, and the dispersed phase, i.e., air bubbles, is considered. The air that is blown in front of the agitators, as well as the influence of the flow field of the agitators on the distribution of the dispersed phase and the recirculation pumps as outlet, is modeled. The bubble Sauter mean diameter is modeled using the population balance model. The model is used to analyze operating parameters such as the bubble retention time, the average air volume fraction, bubble Sauter mean diameter, the local distribution of the bubble size and the amount of air escaping from the pump outlets at two operating points. The purpose of the model is to simulate the two-phase flow in the sump of the flue gas scrubber using air dispersion technology with a combination of spargers and agitators, which, when optimized, reduces energy consumption by 33%. The results show that the homogeneity of air is lower in the bottom part of the absorber sump and that the amount of air escaping through recirculation pipes equals 1.2% of the total air blown into the absorber sump. The escaping air consists mainly of bubbles smaller than 6 mm. Additional operating point results show that halving the magnitude of the linear momentum source lowers the air retention, as well as the average homogeneity of the dispersed air. Full article
(This article belongs to the Topic Fluid Mechanics)
Show Figures

Figure 1

24 pages, 19356 KiB
Article
Flow Characteristics and Anti-Vortex in a Pump Station with Laterally Asymmetric Inflow
by Can Luo, Yufan He, Yinan Shang, Xiao Cong, Chao Ding, Li Cheng and Shuaihao Lei
Processes 2022, 10(11), 2398; https://doi.org/10.3390/pr10112398 - 14 Nov 2022
Cited by 13 | Viewed by 2628
Abstract
In a laterally asymmetric intake pumping station, the flow direction in the forebay is not consistent with flow in the intake channel. Thus, the adverse flow patterns, such as bias flow, large-scale vortex and asymmetric flow occur frequently in the forebay and sump. [...] Read more.
In a laterally asymmetric intake pumping station, the flow direction in the forebay is not consistent with flow in the intake channel. Thus, the adverse flow patterns, such as bias flow, large-scale vortex and asymmetric flow occur frequently in the forebay and sump. Based on the Reynolds-averaged Navier-Stokes (RANS) equation and the RNG k-ε turbulence model, a recent flow pattern in a laterally asymmetric intake pumping station was numerically simulated and analyzed, and effective vortex elimination measures were proposed. For the original scheme, seriously biased flow combined with large-scale vortices were observed in the forebay and several vortices occurred in the sump. To suppress the clash inflow in the south and north intake channel, the “straight diversion pier + curved wing wall” and “straight diversion pier + curved wing wall + V-shaped diversion pier” were installed separately. The” symmetrical 川-shaped diversion pier” and “symmetrical 川-shaped diversion pier + circular column” was utilized to eliminate the bias flow and large-scale vortices in the forebay. Finally, the “three- sectional diversion pier”, “three- sectional diversion pier + triangle column” and “three- sectional diversion pier + triangle column + straight back baffle” was applied to decrease the vortex and asymmetric flow near the suction pipe of the sump. By attaching the rectification measure schemes in the intake channel and the forebay, the bias flow and large-scale vortex in the forebay were suppressed to varying degrees. The schemes significantly reduced the recirculation coefficient and greatly reduced the recirculation volume. By utilizing the vortex elimination measures in the sump, the vortex and asymmetric flow basically disappeared, the velocity distribution tended to become more uniform, and the flow rate distinction of each pump was smaller. The outcome can be used to provide a reference and basis for the improvement of flow pattern in similar laterally asymmetric intake pump stations. Full article
Show Figures

Figure 1

16 pages, 5719 KiB
Article
Study on the Hydraulic and Energy Loss Characteristics of the Agricultural Pumping Station Caused by Hydraulic Structures
by Weixuan Jiao, Zhishuang Li, Li Cheng, Yuqi Wang and Bowen Zhang
Agriculture 2022, 12(11), 1770; https://doi.org/10.3390/agriculture12111770 - 25 Oct 2022
Cited by 2 | Viewed by 2377
Abstract
The pumping station is an important part of the agricultural irrigation and drainage system. The sump is one of the common water inlet types of agricultural pumping stations. In the sump, to facilitate the installation and maintenance of equipment, some hydraulic structures, such [...] Read more.
The pumping station is an important part of the agricultural irrigation and drainage system. The sump is one of the common water inlet types of agricultural pumping stations. In the sump, to facilitate the installation and maintenance of equipment, some hydraulic structures, such as pump beams, maintenance platforms and chest walls, are added to the sump. At present, the impact of hydraulic structures in the sump on the hydraulic performance of the pump device is not clear, so this paper focused on the impact of hydraulic structures on the hydraulic characteristics and entropy generation characteristics of the pump device by using numerical simulation methods. The results showed that the installation of hydraulic structures in the sump has the greatest impact on the efficiency of the pump device. The efficiency coefficient increased after adding a pump beam in the sump and decreased by about 2% after adding a maintenance platform and a water retaining chest wall. Results also showed that the installation of hydraulic structures in the sump will lead to uneven distribution of entropy generation in the sump, especially in the vicinity of the hydraulic structures. The installation of the maintenance platform and chest wall will lead to the increase of the total entropy generation in the sump, which also means that the hydraulic loss in the sump will increase accordingly. Hence, in addition to the pump beam, other structures should be avoided in the sump. Full article
(This article belongs to the Special Issue Advances in Agricultural Engineering Technologies and Application)
Show Figures

Figure 1

17 pages, 8250 KiB
Article
Numerical and Experimental Research on Rectification Measures for a Contraction Diversion Pier in a Pumping Station
by Wentao Xu, Li Cheng, Kailian Du, Lei Yu, Yi Ge and Jiali Zhang
J. Mar. Sci. Eng. 2022, 10(10), 1437; https://doi.org/10.3390/jmse10101437 - 5 Oct 2022
Cited by 15 | Viewed by 1991
Abstract
In order to improve the flow state of a forebay, a contraction diversion pier is discovered, the geometric parameters of which affect the improvement of the flow state. In this paper, the standard k-ε model in the computational fluid dynamics (CFD) [...] Read more.
In order to improve the flow state of a forebay, a contraction diversion pier is discovered, the geometric parameters of which affect the improvement of the flow state. In this paper, the standard k-ε model in the computational fluid dynamics (CFD) numerical simulation method is used to research the flow state improvement of the forebay with a contraction diversion pier. In our research, the single factor method is used to analyze the influence of different geometric parameters. Then, the optimal geometric parameters of the contraction diversion pier are given. Results show that the contraction diversion pier can be used to concentrate the water flow. In the area where reflux is formed, the contraction diversion guides water flow along the diversion pier wall. In particular, when the retractable diversion pier is located in the middle of a reflux zone, the water backflow is effectively reduced, the flow state is improved, and the inlet condition of the pump is optimized. By comparing the cross-sectional streamlines, the velocity contour, the normal velocity uniformity of the longitudinal section, and the normal weighted mean angle, the optimal geometric parameters of the contraction diversion pier are obtained as follows: the distance from the contraction pier to the inlet sump is 0.1 L, the contraction angle is 20°, and the length of pier is 0.3 L. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

12 pages, 5650 KiB
Article
A Study Comparing the Subsurface Vortex Characteristics in Pump Sumps
by Sangyoon Kim, Changgu Kim, Byungha Kim, Hyunjun Jang, Incheol Kim and Young-Ho Lee
Energies 2022, 15(14), 5049; https://doi.org/10.3390/en15145049 - 11 Jul 2022
Cited by 4 | Viewed by 2239
Abstract
The vortex generated around the suction region of the pump sump causes problems such as damage to the pump, increased maintenance costs, and failure to supply coolant smoothly. Therefore, analyzing vortices is essential in pump sump design. However, the CFD analysis alone is [...] Read more.
The vortex generated around the suction region of the pump sump causes problems such as damage to the pump, increased maintenance costs, and failure to supply coolant smoothly. Therefore, analyzing vortices is essential in pump sump design. However, the CFD analysis alone is insufficient in pump sumps vortex analysis since the reliability of the results is doubtful in scaled model tests. This study conducted the model test to validate a suitable CFD simulation method by identifying the Type 2 vortex among the three types of subsurface vortices. The dye test and PIV technology were used to visualize the Type 2 subsurface vortices, whereas the PIV vorticity results were then compared to the CFD results. The average vorticity of 60.2 (1/s) was identified as the reference level of Type 2 subsurface vortices formation by mapping the dye test results with the PIV vorticity results. Furthermore, the average vorticities of 84.63 (1/s) and 85.15 (1/s) were recorded in the presence of Type 2 subsurface vortices in PIV and CFD, respectively, and these values can be applied to the designing of pump sumps. Full article
Show Figures

Figure 1

25 pages, 14707 KiB
Article
Corrosion Behaviour of Nodular Cast Iron Used for Rotor Manufacturing in Different Wastewaters
by Carmen Nejneru, Diana-Petronela Burduhos-Nergis, Mihai Axinte, Manuela Cristina Perju and Costica Bejinariu
Coatings 2022, 12(7), 911; https://doi.org/10.3390/coatings12070911 - 28 Jun 2022
Cited by 6 | Viewed by 2946
Abstract
Submersible drainage sump pumps work in a highly corrosive environment, forming films with corrosive reaction products on the surface. Pump rotors are high-demand parts, so they are made of quality materials with good wear and corrosion resistance properties such as nodular graphite cast [...] Read more.
Submersible drainage sump pumps work in a highly corrosive environment, forming films with corrosive reaction products on the surface. Pump rotors are high-demand parts, so they are made of quality materials with good wear and corrosion resistance properties such as nodular graphite cast iron. This paper analyses the corrosion behaviour of cast iron used in the manufacture of rotors in three types of wastewaters, with variable pH. Nodular graphite cast iron samples were immersed in wastewater for 30, 60, and 90 days and tested by linear polarisation and electrochemical impedance spectroscopy (EIS). Also, the layers of reaction products formed on the surface of the material were analysed by SEM and EDS. The results showed that nodular cast-iron immersed in wastewater with acidic pH showed intense corrosion, the oxide layer formed on its surface is unstable. Also, the final structure of the product layer is that of a tri-layer with cations and anions absorbed from the corrosion media: the double-electric layer directly connected to the metal surface, an internal layer consisting of ferrous compounds and ferric compounds that control the diffusion of oxygen, an outer layer, and a compact crust of ferric compounds. The change in the pH of the wastewater has a major influence on the corrosion rate of the cast iron, which increases from 356.4 µm/year in DWW-1 (6.5 pH) to 1440 µm/year in DWW-2 (3 pH) and 1743 µm/year DWWW-3 (11 pH) respectively. As can be seen, the experimental study covers the problem of the corrosion behaviour of the pump rotor in various types of wastewaters this aspect is particularly important for the good use of wastewater pumps and to predict possible deviations for the operation of the equipment within the treatment plants. Full article
Show Figures

Figure 1

27 pages, 10803 KiB
Article
Experimental and Numerical Study on Vortical Structures and Their Dynamics in a Pump Sump
by Václav Uruba, Pavel Procházka, Milan Sedlář, Martin Komárek and Daniel Duda
Water 2022, 14(13), 2039; https://doi.org/10.3390/w14132039 - 25 Jun 2022
Cited by 4 | Viewed by 2249
Abstract
Research on water flow in a pump inlet sump is presented. The main effort has been devoted to the study of the vortical structures’ appearance and their behavior. The study was conducted in a dedicated model of the pump sump consisting of a [...] Read more.
Research on water flow in a pump inlet sump is presented. The main effort has been devoted to the study of the vortical structures’ appearance and their behavior. The study was conducted in a dedicated model of the pump sump consisting of a rectangular tank 1272 × 542 × 550 mm3 with a vertical bellmouth inlet 240 mm in diameter and a close-circuit water loop. Both Computational Fluid Dynamics (CFD) and experimental research methods have been applied. The advanced unsteady approach has been used for mathematical modeling to capture the flow-field dynamics. For experiments, the time-resolved Particle Image Velocimetry (PIV) method has been utilized. The mathematical modeling has been validated against the obtained experimental data; the main vortex core circulation is captured within 3%, while the overall flow topology is validated qualitatively. Three types of vortical structures have been detected: surface vortices, wall-attached vortices and bottom vortex. The most intense and stable is the bottom vortex; the surface and wall-attached vortices are found to be of random nature, both in their appearance and topology; they appear intermittently in time with various topologies. The dominant bottom vortex is relatively steady with weak, low-frequency dynamics; typical frequencies are up to 1 Hz. The origin of the vorticity of all large vortical structures is identified in the pump propeller rotation. Full article
(This article belongs to the Topic Hydroelectric Power)
Show Figures

Figure 1

18 pages, 13305 KiB
Article
Hydraulic Optimization of Closed Transformation of Open Sump for the Water Treatment Pumping Station
by Xuanda Cheng and Xin Chen
Processes 2022, 10(4), 644; https://doi.org/10.3390/pr10040644 - 25 Mar 2022
Viewed by 2386
Abstract
Taking the closed modification of an open sump of a water treatment pump station as the research background, the hydraulic design criteria for the closed modification of the sump are put forward by combining numerical simulation, model test. Based on CFD technology, a [...] Read more.
Taking the closed modification of an open sump of a water treatment pump station as the research background, the hydraulic design criteria for the closed modification of the sump are put forward by combining numerical simulation, model test. Based on CFD technology, a water pumping station including closed sump, bellmouth, impeller, guide vane, elbow and outlet sump is simulated, and the hydraulic performance of the schemes under different parameters is analyzed and compared. The top floor clearance, width, back wall distance, and floor clearance of the sump are optimized hydraulically, and the hydraulic design criteria of the closed sump are obtained. The results show that when the recommended optimization parameters of the closed sump in this study are that the top floor height HD is 0.9 DL, the width B is 3.0 DL, the back wall distance T is from 0.4 DL, and the floor clearance C is 0.75 DL, the internal flow pattern and hydraulic of the closed sump is better. (DL is the diameter of bellmouth of water pumping station). The model test was set up to compare the hydraulic performance of the pumping station between CFD and the test. The results showed that the CFD data is in good agreement with the experimental data. Full article
(This article belongs to the Special Issue Design and Optimization Method of Pumps)
Show Figures

Figure 1

17 pages, 9410 KiB
Article
Numerical Simulation and Analysis of the Flow Characteristics of the Roof-Attached Vortex (RAV) in a Closed Pump Sump
by Bowen Zhang, Li Cheng, Minghu Zhu, Weixuan Jiao and Di Zhang
Machines 2022, 10(3), 209; https://doi.org/10.3390/machines10030209 - 15 Mar 2022
Cited by 8 | Viewed by 2995
Abstract
Unsteady numerical simulation and visual experiment are used to reveal the formation mechanism of the roof-attached vortex (RAV) on the roof of the closed sump of a pumping station. The results show that RAVs mainly occur between the pump device and the rear [...] Read more.
Unsteady numerical simulation and visual experiment are used to reveal the formation mechanism of the roof-attached vortex (RAV) on the roof of the closed sump of a pumping station. The results show that RAVs mainly occur between the pump device and the rear wall of the closed sump. In the 10th period of impeller rotation, there are 2 RAVs at the roof. V1 (Vortex 1 in numerical simulation) is located directly behind the water pump unit, and V2 (Vortex 2 in numerical simulation) is close to the right wall. Significantly, the vorticity intensity at the V1 vortex core increases with the rotation of the impeller. Vtest1 (Vortex 1 in test) and Vtest2 (Vortex 2 in test) are two RAVs observed in the experiment, which are highly consistent with the unsteady numerical simulation V1 and V2. Comparing the vorticity intensity of the roof, rear wall, and sidewall, it can be seen that the maximum vorticity intensity on the roof is more significant than that on the rear wall and both sides of the wall. The roof is more likely to induce vortex. When the RAVs on the roof occur, the pressure in the middle of the bell mouth is lower than that on the sidewall, and the velocity is higher. At 2/5 T, the blade is in the low-pressure zone. The velocity distribution uniformity and velocity weighted average angle at the bell mouth also decreased. The RAVs enter the pump after being generated, which is the most harmful to the safe and stable operation of the pump. The study can provide theoretical guidance for the optimal design of the closed sump. Full article
(This article belongs to the Section Electromechanical Energy Conversion Systems)
Show Figures

Figure 1

14 pages, 22018 KiB
Article
Study on the Vortex in a Pump Sump and Its Influence on the Pump Unit
by Xijie Song, Chao Liu and Zhengwei Wang
J. Mar. Sci. Eng. 2022, 10(1), 103; https://doi.org/10.3390/jmse10010103 - 13 Jan 2022
Cited by 6 | Viewed by 3034
Abstract
The vortex in a pump sump is a negative problem for the pump unit, which can lead to the decline of pump performance. Focusing on the internal pressure characteristics of the floor-attached vortex (FAV) and its influence on the pump unit, the FAV [...] Read more.
The vortex in a pump sump is a negative problem for the pump unit, which can lead to the decline of pump performance. Focusing on the internal pressure characteristics of the floor-attached vortex (FAV) and its influence on the pump unit, the FAV was analyzed adopting the previously verified numerical simulation method and experiment. The results show that the pressure in the vortex core gradually decreases with time, drops to a negative pressure at the development stage, and then reaches the lowest pressure during the continuance stage. When the negative pressure of the vortex tube is around the vaporization pressure of the continuance stage, it can cause a local cavitation at the impeller inlet. The evolution of the FAV is accompanied by a change of pressure gradient in the vortex core which is discussed in detail. This research provides theoretical guidance for a better understanding of the vortex characteristics and the optimal design for the pump. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

21 pages, 94250 KiB
Article
Numerical Investigation of the Performance of a Submersible Pump: Prediction of Recirculation, Vortex Formation, and Swirl Resulting from Off-Design Operating Conditions
by Virgel M. Arocena, Binoe E. Abuan, Joseph Gerard T. Reyes, Paul L. Rodgers and Louis Angelo M. Danao
Energies 2021, 14(16), 5082; https://doi.org/10.3390/en14165082 - 18 Aug 2021
Cited by 13 | Viewed by 3083
Abstract
Like any other turbomachinery, it is essential that the hydraulic behavior and performance of mixed-flow pumps are evaluated way in advance prior to manufacturing. Pump performance relies heavily on the proper design of the intake structure. Intake structures should be accurately designed in [...] Read more.
Like any other turbomachinery, it is essential that the hydraulic behavior and performance of mixed-flow pumps are evaluated way in advance prior to manufacturing. Pump performance relies heavily on the proper design of the intake structure. Intake structures should be accurately designed in order to minimize and avoid unnecessary swirl and vortex formations. Ensuring the optimum performance condition as well as predicting how a particular intake structure affects the efficiency of the pump often requires either physical model studies or theoretical evaluations. Unfortunately, physical models are costly, time-consuming, and site-specific. Conversely, design and performance predictions using a theoretical approach merely gives performance values or parameters, which are usually unable to determine the root cause of poor pump performance. This study evaluates the viability of using Computational Fluid Dynamics (CFD) as an alternative tool for pump designers and engineers in evaluating pump performance. A procedure for conducting CFD simulations to verify pump characteristics such as head, efficiency, and flow as an aid for preliminary pump design is presented. Afterwards, a multiphase simulation using the VOF approach is applied to compare the fluid dynamics between four different pump intake structures. A full-sized CFD model of the pump sump complete with the pump’s active components was used for the intake structure analysis in order to avoid scaling issues encountered during the reduced-scale physical model test. The results provided a clear illustration of the hydraulic phenomena and characteristic curves of the pump. A performance drop in terms of reduction in TDH was predicted across the various intake structure designs. The CFD simulation of intake structure provided a clear insight on the varying degree of swirl, flow circulation, and effect on pump efficiency between all four cases. Full article
(This article belongs to the Special Issue Mathematical Modelling of Energy Systems and Fluid Machinery 2022)
Show Figures

Figure 1

13 pages, 4778 KiB
Article
Free Discharge of Subsurface Drainage Effluent: An Alternate Design of the Surface Drain System in Pakistan
by Muhammad Ali Imran, Jinlan Xu, Muhammad Sultan, Redmond R. Shamshiri, Naveed Ahmed, Qaiser Javed, Hafiz Muhammad Asfahan, Yasir Latif, Muhammad Usman and Riaz Ahmad
Sustainability 2021, 13(7), 4080; https://doi.org/10.3390/su13074080 - 6 Apr 2021
Cited by 6 | Viewed by 4486
Abstract
In Pakistan, many subsurface (SS) drainage projects were launched by the Salinity Control and Reclamation Project (SCARP) to deal with twin problems (waterlogging and salinity). In some cases, sump pumps were installed for the disposal of SS effluent into surface drainage channels. Presently, [...] Read more.
In Pakistan, many subsurface (SS) drainage projects were launched by the Salinity Control and Reclamation Project (SCARP) to deal with twin problems (waterlogging and salinity). In some cases, sump pumps were installed for the disposal of SS effluent into surface drainage channels. Presently, sump pumps have become dysfunctional due to social and financial constraints. This study evaluates the alternate design of the Paharang drainage system that could permit the discharge of the SS drainage system in the response of gravity. The proposed design was completed after many successive trials in terms of lowering the bed level and decreasing the channel bed slope. Interconnected MS-Excel worksheets were developed to design the L-section and X-section. Design continuity of the drainage system was achieved by ensuring the bed and water levels of the receiving drain were lower than the outfalling drain. The drain cross-section was set within the present row with a few changes on the service roadside. The channel side slope was taken as 1:1.5 and the spoil bank inner and outer slopes were kept as 1:2 for the entire design. The earthwork was calculated in terms of excavation for lowering the bed level and increasing the drain section to place the excavated materials in a specific manner. The study showed that modification in the design of the Paharang drainage system is technically admissible and allows for the continuous discharge of SS drainage effluent from the area. Full article
Show Figures

Figure 1

15 pages, 30512 KiB
Article
The Influence of Geometric Parameters of Pump Installation on the Hydraulic Performance of a Prefabricated Pumping Station
by Bowen Zhang, Li Cheng, Chunlei Xu and Mo Wang
Energies 2021, 14(4), 1039; https://doi.org/10.3390/en14041039 - 16 Feb 2021
Cited by 7 | Viewed by 2772
Abstract
A prefabricated pumping station is a new type of pumping station that plays an important role in the construction of sponge cities in developing countries. It solves the problem of urban water-logging and makes great contributions to the sustainable development of water resources. [...] Read more.
A prefabricated pumping station is a new type of pumping station that plays an important role in the construction of sponge cities in developing countries. It solves the problem of urban water-logging and makes great contributions to the sustainable development of water resources. In order to research the influence of different installation positions of pumps on the internal hydraulic performance of a prefabricated pumping station, based on ANSYS software, the computational fluid dynamics (CFD) numerical simulation method was used to analyze the internal flow state of the prefabricated pump station. In this research, the optimal geometric parameters of pump installation in a prefabricated pumping station are given. The results show that when the distance between the connecting line of two pumps and the center of the sump is L = 0.2 R, the distance between the two pumps is S = 0.6 R, and the suspension height of the two pumps is H = 0.6 D, the internal flow pattern of the prefabricated pump station is better. (R is the cross-sectional radius of the sump and D is the diameter of the nozzle of the pump horn.) These research results have certain guiding significance for improvement of the hydraulic performance and operation efficiency of prefabricated pump stations. They also provide a theoretical basis for parameter selection for prefabricated pumping stations. Full article
Show Figures

Figure 1
