Plow loosening machines are essential agricultural machinery in the agricultural production process. Improving the surface strengthening process and extending the working life of the plow teeth of the plow loosening machine are of great significance. In this paper, the preparation of Stellite6/Cu composite coating on the surface of 316L steel substrate intended for strengthening the plow teeth of a plow loosening machine using laser cladding technology was studied. The influence of different laser process parameters on the microstructure and properties of Stellite6/Cu composite coating was investigated. The composite coating powder was composed of Stellite6 powder with a different weight percent of copper. Microstructural analysis, phase composition, elemental distribution, microhardness, wear resistance, and corrosion resistance of the composite coatings on the plow teeth were analyzed using scanning electron microscopy (SEM), X-ray diffraction (XRD), microhardness testing, energy dispersive spectroscopy (EDS), friction and wear testing, and electrochemical workstation measurements. The results showed that (1) When the laser power was 1000 W, the average hardness of the prepared Stellite6/Cu composite layer achieved the highest hardness, approximately 1.36 times higher than the average hardness of the substrate, and the composite coating prepared exhibited the best wear resistance; (2) When the scanning speed was 800 mm/min, the composite coating exhibited the lowest average friction coefficient and the optimal corrosion resistance in a 3.5% wt.% NaCl solution with a self-corrosion current density of −7.55 µA/cm²; (3) When the copper content was 1 wt.%, the composite coating achieved the highest average hardness with 515.2 HV, the lowest average friction coefficient with 0.424, and the best corrosion resistance with a current density of −8.878 µA/cm². Full article

This paper investigates the effect of plasticity ball burnishing on characteristics of surface integrity, residual stress and hardness of laser direct energy deposited (DEDed) Stellite 21 alloys, with a focus on the burnishing directional effect on surface and microstructural deformation. The results demonstrated that the burnishing improved surface finish, reducing Sa and Sz by 24% and 47%, respectively. The burnishing flattened and modified the cellular/columnar grains at a depth of 50 µm, with the most notable changes observed on the cross-sectional plane normal to the burnishing direction. Compared to the ground surface, the burnishing introduced higher and deeper compressive stresses along normal to the burnishing/grinding direction (−1341 MPa and 61 µm) as compared to that along the burnishing direction (−449 MPa and 56 µm). Likewise, the burnishing increased the full width at half maximum (FWHM) in the same fashion by broadening XRD peaks along normal to the burnishing direction. Due to higher grain modification and dislocation density, the burnishing has improved microhardness at a depth of 320 µm by 26% along normal to the burnishing direction. These findings demonstrate that the plasticity ball burnishing has a directional effect on plastic deformation and can be considered a plausible technique for tailored surface integrity, residual stress and hardness, which potentially improve the service performance of DEDed Stellite 21 alloy components. Full article

This paper investigates the tribological behavior of Stellite 6 coatings produced with high-velocity oxygen fuel (HVOF), with an emphasis on the transition between severe and mild wear regimes and the glaze layer formation. The development of these coatings involved two spray parameters modifying the oxygen fuel ratio and three post-heat treatment conditions at temperatures ranging between 600 °C and 1150 °C. The coatings were tested under conditions varying the normal load, temperature, sliding distance, and testing temperatures (up to 300 °C). The results show that the coating obtained from the HVOF process exhibited a microstructure different from the conventional bulk Co-alloys, significantly impacting the wear performance. The coating post-processing was essentialto enhance wear resistance at elevated temperatures. Full article

Laser cladding is a modern surface treatment process used for the regeneration of damaged components and deposition of coatings for protection against corrosion and wear. Precise process control enables the production of claddings on small surfaces (<1 cm²). However, in some cases (e.g., cladding of turbine blades), there is a limited possibility of heat dissipation into the substrate material, which causes its rapid heating to several hundred degrees Celsius. This work’s objective is to determine the effect of the substrate temperature and laser cladding parameters of a Stellite 6 cobalt-based alloy on the Inconel 718 nickel-based alloy substrate on the geometry of a single cladding track, as well as its microstructure and hardness. Laser cladding with Stellite 6 powder was performed using an Yb:YAG TruDisk 1000 laser. The varied process parameters included the laser beam power density, cladding speed, and powder flow rate. The samples were preheated using a chamber furnace to a temperature ranging from 20 to 800 °C. The geometry of the single tracks produced by laser cladding and the substrate material dilution ratio were determined by measurements conducted on their cross-sections. Further microstructure investigations were performed by means of electron microscopy (SEM). Additionally, hardness measurements (HV0.3) were conducted on the cross-section of each cladded track. It was found that a higher substrate temperature causes melt pool widening and increases the melt depth, while the height of the single cladded track remains only slightly altered. These phenomena lead to the excessive dilution of the substrate material in the cladding (>35%) and result in a decrease in its hardness to the values characteristic of the Inconel 718 substrate (395 HV0.3). Full article

This work investigates the effect of the addition of tungsten carbide (WC) particles as reinforcements to Ni (Inconel 625) versus Co (Stellite 6) alloys during deposition by laser cladding to form wear-resistant metal matrix composite (MMC) coatings. While the related literature often associates the presence of WC with the enhanced wear performance of MMC coatings, this work shows that such an effect is not universal as it may critically depend on the metallic matrix employed. Thus, to demonstrate whether the reinforcement and matrix act synergically in such a scenario or not, MMC coatings formed by Inconel 625 and Stellite 6, both with WC content ranging from 10% to 40%, were deposited under the same laser cladding setup on AISI 304 stainless steel substrates, being WC-free samples produced together for comparison basis. As expected, the hardness levels increased with more WC presence in both matrices, but the wear resistance was specifically evaluated by means of the metal wheel abrasion test (ASTM B611). The results revealed that the use of WC as a reinforcement indeed affects the matrix materials differently; for Stellite 6, the wear resistance increased with up to 20% of WC (in contrast to the hardness indication), whereas for Inconel 625, the wear resistance progressively decreased with more WC content. It was observed via scanning electron microscopy (SEM) that the WC particles within the Inconel 625 alloy tended to intensive cracking, being in this way more prone to detach from the matrix and hence representing a weakening factor for the effectiveness of the coatings produced. Thus, it is concluded that the addition of WC particles, as potential reinforcements for MMC coatings, is not always effective (synergic with the matrix) in providing wear resistance, hence, opposing the prevailing consensus. This outcome and its reasons will certainly help with insights into proper design of MMC coatings, starting with the importance of matrix material selection. Full article

To fulfill the harsh surface demand for key industrial components, metal matrix composite coatings (MMC) with hard ceramic particles located in the metallic matrix have attracted considerable attention in recent years. In this paper, WC/Stellite-6 composite coatings were fabricated via supersonic laser deposition (SLD). The effects of laser heating temperature, WC particle size and addition content on the deposition characteristics were systematically studied. The microstructures and mechanical properties of the as-prepared composite coatings were examined. The results demonstrated that increasing laser heating temperature can improve powder deposition efficiency for both coarse and fine WC-reinforced coatings. The peak coating height of fine WC-reinforced composite coating is 1157 μm, which is higher than that of coarse WC-reinforced composite coating (505.5 μm) deposited under the same laser heating temperature. The increase in laser heating temperature and WC addition content in original composite powder resulted in the increase in WC fraction in the composite coating, which can achieve a highest value of 55.9 vol.%. The SLD composite coating had comparable bonding strength (145.5 MPa) to that of laser cladded (LC) coating. The SLD specimen showed plastic fracture behavior, which was different from brittle fracture behavior for the LC sample. Full article

Friction surfacing (FS) is a solid-state process for depositing metallurgically bonded coatings for corrosion and wear protection. It is particularly attractive for depositing coatings in materials that are difficult to fusion deposit. Stellite 6 is one such material, which is widely used as a protective coating on steel structures to combat wear and corrosion. In the current study, Stellite 6 was successfully friction-surfaced on low carbon steel plates without using any preheating. The microstructures and wear behavior of Stellite 6 coatings produced using FS were comparatively investigated with those produced using the plasma transferred arc (PTA) process. The PTA coatings showed a cast microstructure consisting of γ-dendrites and an inter-dendritic carbide network. On the other hand, the FS coatings showed a wrought microstructure with dynamically recrystallized grains and fine, uniformly distributed carbide particles. The FS coatings also showed uniform composition across the coating thickness and were undiluted, while the PTA coatings showed significant dilution as well as strong local variations in chemistry. The FS coatings exhibited a 22% increase in hardness (550 HV) compared to the PTA coatings (450 HV). Pin-on-disc dry sliding wear tests showed that the FS coatings (1.205 mm³) were more wear resistant compared to the PTA coatings (6.005 mm³), highlighting their superior mechanical performance. This study uniquely demonstrates the feasibility of depositing Stellite 6 coatings using FS without the need for preheating or post-deposition heat treatments, while achieving superior microstructural refinement, hardness, and wear resistance compared to conventional PTA coatings. Full article

The effectiveness of a machining process can be determined by analysing the quality of the generated surface and the rate of tool wear. Stellite is highly challenging to machine, which is why it is primarily processed through grinding methods. This study concentrates on the impact of cutting parameters and tool wear (VB_b, KB_b) on the created surface roughness surface (Rt, Ra, Rz) during the orthogonal cutting of Stellite 6, which is overlaid on a steel surface, C45, prepared by means of HP/HVOF (JP-5000). The results indicate that the dominant influence on the change in the total roughness profile height value (Rt) is the mutual interaction of cutting speed and depth of cut at 16% (p < 0.000). The greatest impact on the change in the mean arithmetic deviation of the roughness profile (Ra) value is the interaction of cutting speed, tool front angle, and depth of cut with a 15% share (p < 0.000), as well as on the change in the Rz value (15%) and tool wear VB_b (25%). This investigation lays the groundwork for potentially substituting the processing of flat surfaces with hardened layers created by thermal spraying (such as Stellite 6) with grinding or methods that offer greater efficiency from both economic and technological perspectives. Full article

Coating welding with cobalt alloys on pipelines is crucial for the offshore industry due to its exceptional resistance to corrosion and wear. In this paper, two welding conditions with different currents were proposed to observe the behavior of the dissimilar joint. The microstructure, mechanical properties, and dilution of a dissimilar material consisting of AISI 4130 steel substrate coated with Stellite 6 alloy were analyzed. Firstly, samples were metallographically prepared for the evaluation of the weld bead and the coating phases using SEM, EDS, and XRD analyses. Then, microstructural characterization was performed qualitatively using confocal microscopy and quantitatively to determine the phase fraction volumes in the dendritic and interdendritic regions, as well as the resulting dilution. Results revealed that varying welding conditions did not significantly affect the hardness of the coatings, which remained within the alloy standard of 36-45 HRC, with microhardness varying by 3%–5% from one condition to another and phase fraction volume showing a variation of 5.6% between welding conditions. On the other hand, experimental results indicated a clear effect of welding current variation on dilution values, with 4.6% for condition 1 and 16.7% for condition 2, allowing for direct proportional relationships to be established, i.e., higher deposition current results in greater dilution. Full article

To address the issue of cracking in aluminum extrusion dies during operation, this study employs laser cladding technology to modify the surface of these dies. This modification aims to enhance their hardness and friction resistance. Laser cladding technology was utilized to coat the surface of H13 steel with Stellite 12, a cobalt-based alloy, at varying laser power levels. The surface formation quality, microstructural organization, phase composition, microhardness, and wear resistance of the coatings were investigated using optical microscopy, scanning electron microscopy, energy-dispersive spectroscopy, X-ray diffraction (XRD), microhardness testing, and confocal microscopy. The results indicated that as the laser power increased, the surface formation quality of the coating gradually improved, while the dilution rate of the coating increased. Changes in the phase composition and microstructure were not significant, and both microhardness and wear resistance initially increased before decreasing. Optimal process parameters for achieving good surface formation quality, high microhardness, and strong wear resistance were found to be a laser output power of 2200 W, scanning speed of 10 mm/s, feeding rate of 1.2 r/min, and overlap rate of 40%. The results indicate that the coating applied to the surface of H13 steel using Stellite 12 enhances the performance of aluminum extrusion dies. Full article

Crack-free Stellite-6 alloy was fabricated using the laser powder bed fusion technique equipped with a heating module as the first attempt. Single tracks were printed with a build plate heated to 400 °C to identify the processing window. Based on the melt pool dimensions, two combinations (sample A: 300 W/750 mm/s and sample B: 275 W/1000 mm/s) were identified to print the cubes. The as-printed microstructure comprised FCC-Co dendrites with M₇C₃ in the interdendritic region. W-rich M₆C particles were found in the overlapping regions between the melt pools, matching the Scheil simulations. However, gas pores were observed due to the higher nitrogen and oxygen content of the feedstock requiring hot isostatic pressing (HIP) at 1250 °C and 150 MPa for 2 h. Sample A was partially recrystallized with slightly coarsened M₇C₃, while sample B underwent complete recrystallization followed by grain growth along with higher coarsening of the M₇C₃ after HIP. The varying recrystallization behavior can be attributed to the difference in residual stresses and grain aspect ratio in the as-built condition dictated by laser power and scanning speed. The microhardness after HIP was slightly higher than its wrought counterpart, indicating no severe impact of post-processing on the properties of Stellite-6 alloy. Full article

The focus of this research is to examine the feasibility of using laser texturing as a method for surface preparation prior to thermal spraying. The experimental part includes the thermal spraying of a Stellite 6 coating by High Velocity Oxygen Fuel (HVOF) technology on laser-textured substrates. The thermal spraying of this coating was deposited both on conventional substrate material (low carbon steel) and on substrates that had been previously heat treated (nitrided steel). The properties of the coatings were analysed using scanning electron microscopy (SEM), optical microscopy (OM) and Raman spectroscopy. Adhesion was assessed through a tensile adhesion test. The results showed the usability of laser texturing in the case of carbon steel, which was comparable or even better than traditional grit blasting. For nitrided steel, the problem remains with the hardness and brittleness of the nitrided layer, which allows for the propagation of brittle cracks near the interface and thus reduces the adhesion strength. Full article

In this work, the influence of powder reuse up to three times on directed energy deposition (DED) with laser processing has been studied. The work was carried out on two different gas atomized powders: a cobalt-based alloy type Stellite^® 21, and a super duplex stainless steel type UNS S32750. One of the main findings is the influence of oxygen content of the reused powder particles on the final quality and densification of the deposited material and the powder catch efficiency of the laser deposition process. There is a direct relationship between a higher surface oxidation of the particles and the presence of oxygen content in the particles and in the as-built materials, as well as oxides, balance of phases (in the case of the super duplex alloy), pores and defects at the micro level in the laser-deposited material, as well as a decrease in the amount of material that actually melts, reducing powder catch efficiency (more than 12% in the worst case scenario) and the initial bead geometry (height and width) that was obtained for the same process parameters when the virgin powder was used (without oxidation and with original morphology of the powder particles). This causes some melting faults, oxides and formation of undesired oxide compounds in the microstructure, and un-balance of phases particularly in the super duplex stainless steel material, reducing the amount of ferrite from 50.1% to 37.4%, affecting in turn material soundness and its mechanical properties, particularly the hardness. However, the Stellite^® 21 alloy type can be reused up to three times, while the super duplex can be reused only once without any major influence of the particles’ surface oxidation on the deposited material quality and hardness. Full article

The article presents research results on the possibility of shaping the structure and properties of Co-Cr-W-C-Ti alloys (type Stellite 6) using laser cladding technology. Cobalt-based alloys are used in several industries because they are characterized by high erosion, abrasion, and corrosion resistance, retaining these properties at high temperatures. To further increase erosion resistance, it seems appropriate to reinforce material by in situ synthesis of hard phases. Among the transition metal carbides (TMCs), titanium carbide is one of the hardest and can have a positive effect on the extension of the lifetime of components made from cobalt-based alloys. In this article, concentration of C, W, and Ti due to the possibility of in situ synthesis of titanium carbides was subjected to detailed analysis. The provided research includes macrostructure and microstructure analysis, X-ray diffraction (XRD), microhardness, and penetrant tests. It was found that the optimal concentrations of Ti and C in the Co-Cr-W-C alloy allow the formation of titanium carbides, which significantly improves erosion resistance for low impact angles. Depending on the concentrations of titanium, carbon, and tungsten in the molten metal pool, it is possible to shape the alloy structure by influencing to morphology and size of the reinforcing phase in the form of the complex carbide (Ti,W)C. Full article

Laser cladding technology is an effective surface modification technique. In order to prepare coating with excellent properties on the surface of the cold heading die punch, stellite-6 cladding coating with different proportions of Y₂O₃ was prepared on the surface of W6Mo5Cr4V2 high-speed steel using laser cladding technology in this paper. The effects of different Y₂O₃ contents on the macroscopic morphology, microstructure, phase analysis, microhardness, and tribological properties of the stellite-6 coatings were investigated. It was determined that the optimal Y₂O₃ content for the stellite-6 powder was 2%. The results showed that the coating with 2%Y₂O₃ had the least number of pores and cracks and exhibited good surface flatness when joined. The microstructure became finer and denser, composed mainly of branch, cellular, equiaxed, and columnar grains. The coating consisted mainly of γ-Co, Fe-Cr, and Co₃Fe₇ strengthening phases, indicating good metallurgical bonding between the coating and the substrate. The average microhardness reached 539 HV when 2%Y₂O₃ was added, a 15.2% increase compared with the unmodified multilayer coating. The friction coefficient of the clad layer was 0.356, a 21.8% improvement over the unmodified stellite-6 coating. The average worn area of the cross-section was 3398.35 μm², a reduction of approximately 27.8% compared with the unmodified stellite-6 clad layer. The wear surface primarily exhibited abrasive wear, with fewer cavities and a smoother surface. Full article
