The use of both structural steel and reinforced concrete is common in civil and military infrastructure projects. Anchorage plays a crucial role in these systems, serving as the key element that connects structural components and secures attachments within complex composite structures. This research focuses on evaluating the performance of steel–concrete column connections under the combined effects of lateral loading and fire exposure. Additionally, the study investigates the use of carbon fiber-reinforced polymers (CFRP) for strengthening and repairing these connections. The research methodology combines experimental testing and finite-element modeling to achieve its objectives. First, experimental investigation was carried out to test two groups of steel-reinforced concrete column specimens, each group made of three specimens. The first group specimens were designed based on special moment frame (SMF) detailing, and the other group specimens were designed based on intermediate moment frame (IMF) detailing. These two types of design were selected based on seismic demands, with SMFs offering high ductility and resilience for severe earthquakes and IMFs providing a cost-effective solution for moderate seismic zones, both benefiting from ongoing innovations in connection detailing and design approaches. Then, finite-element analysis was conducted to model the test specimens. High-fidelity finite-element modeling was conducted using ANSYS program, which included three-dimensional coupled thermal-stress analyses for the six tested specimens and incorporated nonlinear temperature-dependent materials characteristics of each component and the interfaces. Both the experimental and numerical results of this study show that fire has a more noticeable effect on displacement compared to the peak capacities of both types of specimens. Fire exposure results in a larger reduction in the initial residual lateral stiffness of the SMF specimens when compared to IMF specimens. While the effect of CFRP wraps on initial residual lateral stiffness was consistent for all specimens, it caused more improvement for the IMF specimen in terms of post-fire ductility when compared to SMF specimens. This exploratory study confirms the need for further research on the effect of fire on the concrete–steel anchorage zones. Full article

Determining the impact of pulse-type earthquake characteristics on the vulnerability of base-isolated buildings under non-pounding conditions has yielded conflicting results in previous studies. Moreover, this issue has received less attention for pounding conditions, especially floor-to-floor pounding. Therefore, this study aims to investigate the correlation between pulse-type earthquake characteristics and the seismic response of buildings under both pounding and non-pounding conditions. In the first stage, three base-isolated buildings and one fixed-base building are analyzed separately under 40 pulse-type earthquakes using the nonlinear time history method. Three scenarios are then considered to account for pounding with adjacent buildings. In the first pounding scenario, a base-isolated building with an intermediate moment frame (IMF) is placed between two fixed-base buildings. The second scenario involves changing the base-isolated building’s superstructure system to a special moment frame (SMF). Finally, the third scenario increases the base isolation period (T_b) of the base-isolated building used in scenario two. The correlation between earthquake characteristics and the seismic response of buildings is assessed by linear regression and the Pearson correlation coefficient. The results demonstrate that peak ground acceleration (PGA) has a strong correlation with the seismic response of buildings under pounding conditions, while peak ground velocity (PGV) shows a stronger correlation under non-pounding conditions. However, predicting building vulnerability with a single pulse-type earthquake characteristic remains unreliable unless a large number of ground motions are considered. Otherwise, it is crucial to consider the correlation of all earthquake characteristics with seismic responses. Full article

The present study analyzes the behavior of connections with flange-web welded plates using the finite element method in tubular columns filled with concrete, and beam, type I. An analytical study of the structural dynamic behavior of a Special Moment Frame (SMF) was carried out, in 5 levels, with HEB structural profiles, for IPE-type columns and beams, according to the requirements established by the AISC-360-16, ANSI-341 standards, and the Ecuadorian standard NEC-2015. The design process of the special frame structure was validated with the help of specialized software. Subsequently, the structural profiles were replaced following the actual construction situation in Ecuador. 3D models of the structural system and the elements of metallic connections were obtained for evaluation through the analysis of finite elements. These models were subjected to virtual tests according to the AISC 341-16 protocols and FEMA 350 standards. The evaluation of the connections showed that they did not meet the flexural strength criterion at 0.04 rad, but they exceeded $80\%$ of the plastic moment at $0.02$ rad. Thus, flange-web welded plate connections can be valid for intermediate moment frames (IMF) in areas with moderate seismicity. In addition, it was observed that the columns filled with concrete optimize the structural elements in terms of dimensions; but do not contribute significantly to soldered connections due to the later development of plastic ball joints. Full article

During the Northridge earthquake, extensive brittle failures on the weld zones of the beam bottom flanges in the rigidity connection of steel special moment frames (SMFs) were detected. One of the primary reasons is the high-tensile strain demand created at the beam bottom flange zones due to positive bending. The weak panel zone of the I-section column exhibits more shear deformation, which promotes and accelerates the brittle fracture of the beam bottom flange weld zones. A box-strengthened panel zone can minimize the shear deformation of the panel zone of the I-section column, which may also reduce the inter-story displacement of steel SMFs and enhance their seismic behavior. In order to investigate this fact, in this research we carried out a model test of a steel frame with a box-strengthened panel zone to examine SMFs’ seismic performance and inter-story displacement, as well as testing the contribution of panel zone shear deformation to inter-story drift. Numerical methods were then used to investigate the influence of the axial compression ratio and beam-to-column linear stiffness ratio on the effect of shear deformation on the box-strengthened panel zone. Design recommendations are given based on the research results. Full article

The performance-based seismic design pretends to take care of the lives of the occupants and reduce the cost of damage caused by earthquakes. Several ways of estimating damage and economic losses have been developed, but most of them lack objectivity and have great dispersion in the results. In the last decade, the advancement of technology has allowed the appearance of new methodologies, such as the one developed by the Pacific Earthquake Engineering Research Center (PEER methodology). However, the information regarding application and scope is scarce. In the present investigation, the economic seismic performance for a steel building was determined by applying the PEER methodology with different levels of seismic intensity. A multi-family residential model of special moment frames (SMF) was used, and the structure was designed by means of modal analysis. Spectral, incremental dynamic non-linear analysis was performed where the structural response was determined, with the help of the PACT software. The seismic performance, expressed as the repair costs, repair times, deaths, and injuries, was defined. The results obtained indicate that buildings designed with traditional structural standards can be demolished after the action of an earthquake because the repair costs exceed 40% of the replacement cost. Rare and very rare seismic events can cause the total suspension of the service and a considerable number of deaths and injuries. Full article

The intermodular connection between modules plays a vital role in the overall performance of modular structures. The separation between a column and connection is possible due to the absence of links (welding or bolting) since limited space is available between modules. This study proposed a self-locking joint to be used in a modular steel structure, connecting columns with a connection without need of extra space between modules. The behavior of the proposed connection subjected to monotonic load was evaluated using a finite element approach using ABAQUS software. The influencing factors contributed to the behavior of the self-locking connection and columns observed using a parametric study. The parametric study was conducted by varying beam thickness, bolt pretension force and friction coefficient µ. Results indicate that the proposed connection can be classified as a semirigid connection according to Eurocode 3 and special moment frame (SMF) as recommended by AISC. Full article

Near-field (NF) earthquakes have drawn considerable attention from earthquake and structural engineers. In the field of earthquake engineering, numerous studies have identified the devastating nature of such earthquakes, and examined the characteristics related to the response of engineering structures to these types of earthquakes. Herein, special steel moment frames (SMFs) of three-, five-, and eight-story buildings have been examined via a nonlinear time history analysis in OpenSees software. The behavioral seismic differences of these frames have been evaluated in two states: (1) under the simultaneous excitation of the horizontal and vertical constituents of near-field earthquakes that have Fling-steps in their records; and (2) under simultaneous excitation of the horizontal and vertical constituents of far-field (FF) earthquakes. In addition, during modeling, the effects of panel zones have been considered. Considering that the simultaneous effects of the horizontal and vertical constituents of near-field earthquakes were subjected to a fling-step resulting in an increased inter-story drift ratio, the horizontal displacement of stories, an axial force of columns, created the moment in columns, base shearing of the structure, and velocity and acceleration of the stories. Full article
