In this study, a tubular spot-welded grating sensor composed of a stainless-steel tube fixed to a substrate surface by welding is developed, and the tube is filled with high-performance epoxy resin components after the grating sensor is passed through it. A smart steel strand cable is created by spot welding steel strands using portable spot-welding equipment. This method generates a small current during spot welding, with a voltage of only 3 V to 5 V, and does not damage the internal structure of the steel strand. An equation related to the temperature, tension force, and wavelength fluctuation is presented in this article. A method with a transverse temperature coordinate and a longitudinal wavelength coordinate is used. A formula for the standard temperature calibration of the force values and a procedure for temperature adjustment of the force values are presented. The correlation coefficient between the stress on the steel strand and the wavelength of the tubular spot-welded grating sensor is as high as 0.999 according to static tensile testing, demonstrating good repeatability. The temperature adjustment coefficient for varying temperatures is 0.0264 nm/°C, and the test error is essentially limited to 3.0% F.S. When subjected to a 120 h relaxation test, the steel strand with the tubular spot-welded grating sensor exhibits a relaxation rate of 4.44%. The force value obtained after the relaxation test is 1.2% off from the standard load. A tubular spot-welded grating sensor is welded onto a steel strand within a cable sealing cylinder to create an extruded anchor epoxy-coated steel strand cable. The measured cable force is compared with the standard load. The maximum error is 0.5% F.S. The discrepancy between the measured cable force and the acceleration sensor value is 1.5% in one instance involving an arch bridge employing six smart suspension cables to detect cable forces onsite. The findings provide theoretical and engineering references for smart cables and demonstrate the high accuracy, dependability, and fixation performance of the tubular spot-welded grating sensor smart cable. Full article

According to current regulations, welding is strictly prohibited for prestressed and tension cables. In response, this article proposes the use of a portable spot-welding machine to spot weld steel strands. This method generates a small current during spot welding, with a voltage of only 3 V to 5 V, and does not damage the internal structure of the steel strand. To effectively monitor cable tension in cable-supported structures, a novel approach utilizing a chip-based, encapsulated spot-welded strain sensor was investigated. The strain sensing capability, temperature sensitivity, stress relaxation, and static load responses were investigated on the proposed smart steel strand cables with spot-welded strain sensors. The theoretical analyses and finite element simulations revealed that the strain transfer efficiency of the spot-welded strain sensor exceeded 96%. The experimental results demonstrated that the load-strain relationship of the smart steel strand cable had a fitting degree greater than 0.999, and the tension errors obtained under different loads were within 1.26%. The tension full capacity errors measured at different temperatures were generally within 1.0%. The relaxation rate of the smart steel strand cable after 120 h was 3.78% and reduced the sensor accuracy error by 3.97%. Thus, the proposed strain sensor equipped with a smart steel strand cable is suitable for use in long-term tension monitoring. Full article

Prestressed steel strands in prestressed structures offset or reduce the tensile stress caused by external loads, making them the primary load-bearing components. Great concerns have been raised about prestress monitoring due to the growing use of structural health monitoring (SHM). Piezoceramic (PZT) active sensing methods are commonly used in this field. However, there appears to be a problem of “energy saturation” in the utilization of piezoceramic active sensing methods. In this study, a smart anchor washer with semi-cylinders was developed to alleviate the saturation problem. An intelligent monitoring system is formed by combining the upper and lower annular cylinders with two piezoelectric patches. The piezoelectric patch on the upper annular cylinder is used as an actuator to emit signals through the contact interface of the smart anchor washer, which are then received by the piezoelectric patch on the lower annular cylinder. Based on wavelet packet decomposition, we investigate the correlation between the energy of the received signal and the applied tension force. Finally, a prestressing force index is developed for monitoring prestressing force using Shannon entropy. It is found that the index decreases with the increase in tension. The proposed design and index are also sensitive to early monitoring of prestressing force and can be used to monitor the entire prestressing process of steel strands. Full article

This study proposes a cost-effective prestress monitoring method for post-tensioned reinforced concrete (RC) beams using a smart strand. Firstly, the concept of a piezoelectric-based smart strand and its implementation for prestress force monitoring are developed. The smart strand is prepared by embedding inexpensive and high-sensitivity electromechanical impedance (EMI) sensors in a steel strand. Next, the feasibility of the proposed method is experimentally verified for prestress force monitoring of a simple supported post-tensioned RC beam. A smart strand prototype is fabricated and embedded into a 6.4 m RC beam which is then prestressed with different levels. For each prestress level, the EMI responses of the smart tendon are measured and the EMI features are extracted for prestress force monitoring. The results showed that the EMI signals of the smart strand showed strong resonant peaks that varied sensitively to the prestress level of the beam. The prestress change in the prestressed RC beam was successfully estimated by using linear regression models of the EMI features. Full article

Unlike conventional steel strands, the smart strand supports strain-measuring function and adopts different materials for its core wire and helical wires. This study intends to analytically derive the nonlinear stress-strain model of this strand made of two materials. The effect of the bending moment and torsional moment of the helical wires on the overall load within the range of geometric shapes shown by actually used strands is verified to be negligible and is thus ignored in order to simplify the analytical model. Moreover, the slight difference between the actual and analytic behaviors, which only appears in the slope varying part in the case of bilinear behavior, such as that of steel, is also ignored. The proposed constitutive model of the smart strand obtained by introducing the experimental stress-strain relation between the carbon fiber reinforced polymer core wire and the helical steel wires is in good agreement with the experimental data. The previous analytical models are applicable only to strands made of a unique linear material, whereas the model proposed in this study is also applicable to strands in which the core wire and the helical wires are made of two different materials, exhibiting nonlinear behavior. Full article

For the safety of prestressed structures, prestress loss is a critical issue that will increase with structural damage, so it is necessary to investigate prestress loss of prestressed structures under different damage scenarios. Unfortunately, to date, no qualified techniques are available due to difficulty for sensors to survive in harsh construction environments of long service life and large span. In this paper, a novel smart steel strand based on the Brillouin optical time domain analysis (BOTDA) sensing technique was designed and manufactured, and then series of tests were used to characterize properties of the smart steel strands. Based on prestress loss principle analysis of damaged structures, laboratory tests of two similar beams with different damages were used to verify the concept of full-scale prestress loss monitoring of damaged reinforced concrete (RC) beams by using the smart steel strands. The prestress losses obtained from the Brillouin sensors are compared with that from conventional sensors, which provided the evolution law of prestress losses of damaged RC beams. The monitoring results from the proposed smart strand can reveal both spatial distribution and time history of prestress losses of damaged RC beams. Full article
