Envelope modeling is an efficient way to obtain the large-signal amplitude and phase dynamics of fast-varying sinusoidal signals required for, e.g., resonant frequency tracking or energy transfer rate regulation in power converters. In addition, the method eliminates fast-varying parameters from the model so that the simulation time and memory requirements are reduced. This paper reveals the envelope-modeling process of a capacitor-powered resonant inverter feeding a time-varying series RLC load, often employed in pulsed-power applications. Such an arrangement is nontrivial since the system does not reach a steady state within a single pulse duration. Furthermore, model order reduction is carried out without performing linearization due to large variations in the expected operation point. As a result, a reduced-order nonlinear envelope model is derived and validated by simulations. Both the proposed modeling method and the derived model aim to simplify the challenging task of feedback controller design. Full article

The manuscript presents an innovative approach for the engineering design of resonant DC/AC converters used as sources of high-frequency electricity for a variety of needs: industrial and domestic applications, wireless power transmission, high-performance lighting, and more. The methodology is based on the generalized consideration of electromagnetic processes in a series resonant RLC circuit fed by a square-wave voltage source. Due to the symmetry in the form of the current in the AC circuit of the DC/AC converter, it is possible to generalize all their possible operating modes. This was realized by applying the quasi-boundary method to the analysis of resonant DC/AC converters with and without reverse diodes operating in soft and hard switching modes. On this basis, the transfer functions of the devices, which give the relationship between their output and input voltages, are defined and analytically determined. Additionally considered are cases of resonant DC/AC converters with complex output circuits, which are applied to match the load needs and the capabilities of the power electronic device. In this sense, the basic dependencies for designing the main types of resonant DC/AC converters using series and parallel load compensation are given. The effectiveness of the proposed methods is demonstrated through several examples, and their verification and validation is achieved with simulations and prototypes. The proposed innovative design approach is applicable not only in power electronics education, but also in the design and prototyping of a whole class of power electronic devices. The unification of design methodologies formalizes and algorithmizes the design process, which is an important step for its automation and for applying various optimization procedures to achieve certain goals. Full article

This paper presents a unified approach to the analysis of DC/AC converters based on an equivalent representation of their AC circuit as a series RLC circuit. The resonant DC/AC converter with reverse diodes was chosen as the basis of the examination, and the obtained ratios for this device were used to derive the main ratios describing the operation of the other types of DC/AC converters—voltage source inverters (VSI) and current source inverters (CSI). Based on the commonality of electromagnetic processes in power circuits, the expressions for the current through the inductance and the voltage of the capacitor are found in a compact form with their initial phases. The base ratios found through the analysis are normalized to the control frequency, thereby summarizing all possible operating modes. In this way, electromagnetic processes in a whole class of power electronic devices are described from general positions, which is convenient from a methodical point of view with a view to improving power electronics education. The proposed analysis approach is also applicable to three-phase DC/AC inverters, taking into account the specifics related to the presence of three phases and, accordingly, their mutual influence in the formation of the output currents and voltages. On the other hand, the basic ratios determined through the application of the unified analysis approach are also useful with a view to creating engineering design methodologies, in which the values of all circuit elements are determined with comparatively simplified calculation procedures. Full article

Currently, the design of resonant power converters has only been developed while operating in the steady state, while the design operating in the transient stage has not been considered nor reported. This paper is interested in testing the performance of the resonant circuits operating in the transient stage and finding applications where benefits can be obtained from this form of operation. One application in which it is possible to obtain benefits from designing resonant circuits in the transient state is in the area of frequency multiplication. Usually, to achieve frequency multiplication, it is necessary to resort to complex methods and special devices that increase the complexity of the design and the total cost of the circuit. This paper evaluates the performance of a series RLC resonant circuit operating in the transient stage and with an underdamped response acting as a frequency multiplier, where the oscillation frequency of the current in the resonant tank is “n” number of times the switching frequency of the square voltage source at the input with a duty cycle of D = 50%. To validate the analysis, a circuit was designed to deliver an output power of 30 watts to a resistive load, where the switching frequency of the square voltage source at the input was 500 kHz. Since a multiplier value “n” equal to fifteen was chosen, the current in the resonant tank reached an oscillation frequency of 7.5 MHz. The design methodology was validated by simulations in SPICE, complying with the established design parameters. Full article

A sub-synchronous oscillation (SSO) suppression strategy of attaching virtual resistance controllers to the rotor-side converter (RSC) of the doubly-fed induction generator (DFIG) is proposed in this study to suppress sub-synchronous oscillation (SSO) caused by series compensation and grid connection of DFIG. A DFIG-based frequency domain impedance model considering RSC control under small signal perturbations is developed in a three-phase stationary coordinate system. Subsequently, the factors and mechanisms of SSO in the system with different phase sequences are analyzed in combination with the equivalent RLC resonant circuit of a DFIG-based series-compensated grid-connected system (SCGCS). SSO occurs when RSC and rotor winding generate a large equivalent negative resistance at the SSO frequency, resulting in a negative total system resistance. Additionally, the influences of series compensation degree (SCD) of line and inner loop parameters (ILPs) of RSC related to the total impedance of the system on the SSO characteristics are analyzed to optimize the parameters and improve the system stability. Based on the causes of SSO, virtual resistance controllers are attached to RSC to provide positive resistance to the system and to offset the equivalent negative resistance of RSC and rotor winding at the SSO frequency, thereby avoiding SSO of the system. Finally, time-domain simulations using power system computer aided design/electromagnetic transients including dc (PSCAD/EMTDC) show that the SSO of the system is effectively suppressed. Full article

This manuscript proposes a new unified approach for the analysis of voltage source inverters that summarizes and unifies the operating modes of a whole class of inverters powered by a voltage source: resonant, aperiodic and voltage source inverters. The study was performed on a full-bridge circuit of a series RLC inverter with reverse diodes, operating in aperiodic mode. Based on the community of processes in the power circuits, the expressions for the current through the load and the voltage of the capacitor in condensed form with their initial phases are determined. These basic ratios are presented in a normalized form according to the control frequency, thus summarizing the operation of the inverters with a control frequency below and above the quasi-resonant. A methodology for designing a voltage source inverter was developed, considered as a special case of a series RLC inverter with inverse diodes when operating in aperiodic mode and super-quasi-resonant frequency. The reliability of the obtained results was verified by comparison with the use of the classical methodology for design and computer simulations. The presented approach is useful from a methodological point of view, as it allows us, with a unified approach and through general mathematical expressions, to describe and study the processes in a significant part of DC/AC converters. Full article

In domestic induction heating applications, cookware can be considered an equivalent load in a series resistor–inductor–capacitor resonant converter. Therefore, the electrical parameters of an equivalent circuit change according to the cookware material, size and the cookware position on the heating coil. This study proposes an online estimation method for detecting the cookware status, determining the material and estimating the equivalent heating resistance of cookware on an induction heating cooker (IHC) for power control. The proposed method could turn off the circuit in abnormal situations such as low equivalent heating coverage rate or non-ferromagnetic cookware and adjust the power in normal situations. In the method, a half-bridge series resonant converter (HBSRC) generates two test patterns with three resonant voltage pulses to detect cookware every 10 ms, only the current feedback information is needed to avoid the calculation loads and times necessary for complex signal operations in software. To verify the proposed method, a digital signal processor based HBSRC with 1000 W was constructed. The maximum errors between the estimated and measured resistance and inductance were 7.14% and 2.91%, respectively. Moreover, power control in emulated user operation reveal that the proposed method and control system can effectively estimate load online to detect cookware status and determine whether to turn off or vary the heating power for an IHC. Full article
