Search Results (11)

This paper presents a design, model, and comparative analysis of two internal MEMS vibrating ring gyroscopes for harsh environmental conditions. The proposed design investigates the symmetric structure of the vibrating ring gyroscopes that operate at the identical shape of wine glass mode resonance frequencies for both driving and sensing purposes. This approach improves the gyroscope’s sensitivity and precision in rotational motion. The analysis starts with an investigation of the dynamic behaviour of the vibrating ring gyroscope with the detailed derivation of motion equations. The design geometry, meshing technology, and simulation results were comprehensively evaluated on two internal vibrating ring gyroscopes. The two designs are distinguished by their support spring configurations and internal ring structures. Design I consists of eight semicircular support springs and Design II consists of sixteen semicircular support springs. These designs were modelled and analyzed using finite element analysis (FEA) in Ansys 2023 R1 software. This paper further evaluates static and dynamic performance, emphasizing mode matching and temperature stability. The results reveal that Design II, with additional support springs, offers better mode matching, higher resonance frequencies, and better thermal stability compared to Design I. Additionally, electrostatic, modal, and harmonic analyses highlight the gyroscope’s behaviour under varying DC voltages and environmental conditions. Furthermore, this study investigates the impact of temperature fluctuations on performance, demonstrating the robustness of the designs within a temperature range from −100 °C to 100 °C. These research findings suggest that the internal vibrating ring gyroscopes are highly suitable for harsh conditions such as high temperature and space applications. Full article

This paper presents the development of an analytical model of an internal vibrating ring gyroscope in a Microelectromechanical System (MEMS). The internal ring structure consists of eight semicircular beams that are attached to the externally placed anchors. This research work analyzes the vibrating ring gyroscope’s in-plane displacement behavior and the resulting elliptical vibrational modes. The elliptical vibrational modes appear as pairs with the same resonance frequency due to the symmetric structure of the design. The analysis commences by conceptualizing the ring as a geometric structure with a circular shape possessing specific dimensions such as thickness, height, and radius. We construct a linear model that characterizes the vibrational dynamics of the internal vibrating ring. The analysis develops a comprehensive mathematical formulation for the radial and tangential displacements in local polar coordinates by considering the inextensional displacement of the ring structure. By utilizing the derived motion equations, we highlight the underlying relationships driving the vibrational characteristics of the MEMS’ vibrating ring gyroscope. These dynamic vibrational relationships are essential in enabling the vibrating ring gyroscope’s future utilization in accurate navigation and motion sensing technologies. Full article

This research presents a comparative analysis of the two important design methodologies involved in developing microelectromechanical system (MEMS) vibrating ring gyroscopes, namely, internal and external ring gyroscopes. Internal ring gyroscopes are constructed with the outside placement of support pillars connected with the semicircular beams that are attached to the vibrating ring structure. The design importance of this particular setting effectively isolates the vibrating ring structure from any external mechanical vibrations, significantly improving the gyroscope’s performance. The internal ring structure provides exceptional precession and reliability, making this design an ideal candidate for harsh conditions, as they can sustain substantial amounts of unwanted and external vibrations without degrading the performance of the gyroscope. On the other hand, external ring gyroscopes include the placement of the support pillars within the vibrating ring structure. This particular design setting is quite convenient in terms of fabrication and provides higher gyroscopic sensitivity. However, this design may lead to coupling of the vibrational modes and potentially compromise the performance of the gyroscope. This research discusses and compares the findings of a modal analysis of the two distinguished design approaches for the MEMS vibrating ring gyroscopes. Full article

Microelectromechanical system (MEMS) inertial sensors are integral components in a variety of smart electronic devices, most notably MEMS vibrating gyroscopes, which are rotational inertial sensors. The applications of MEMS vibrating gyroscopes range from household appliances to GPS and even to military applications. However, the stability and reliability of these MEMS inertial sensors in space applications still pose challenges. In this research study, we introduce a simple design for a vibrating ring gyroscope with eight semicircular support springs connected to outside-placed anchors. The symmetric design structure with semicircular support springs provides higher sensitivity while minimizing mode mismatch. The design and modelling analysis of the vibrating ring gyroscope was conducted using Ansys 2023 R1. The proposed vibrating ring gyroscope has a ring radius of 1000 µm, a 210 µm radius for the semicircular support springs, a ring and support spring thicknesses of 10 µm, and an area of 80 × 80 µm² for the outside-placed anchors. The vibrating ring gyroscope operates at two identical elliptical-shape resonant modes, one for driving resonance frequency and the other for sensing resonance frequency. Both simulated resonance frequencies were measured at 48.78 kHz and 48.80 kHz. The modelled result achieved a mode mismatch of 0.02 kHz, which can be easily rectified with tuning electrodes. Full article

Microelectromechanical system (MEMS) vibrating gyroscope design considerations are always intriguing due to their microscale mechanical, electrical, and material behavior. MEMS vibrating ring gyroscopes have become important inertial sensors in inertial measurement units (IMU) for navigation and sensing applications. The design of a MEMS vibrating ring gyroscope incorporates an oscillating ring structure as a proof mass, reflecting unique design challenges and possibilities. This paper presents a comprehensive design analysis of the MEMS vibrating ring gyroscope from the mechanical, electrical, and damping perspectives. The mechanical design of the MEMS vibrating ring gyroscope investigates the various frame designs of the vibrating ring structure, as well as the various beam structures, including rectangular and semicircular beam structures, which are analyzed using mathematical models and finite element analysis (FEA) simulations that provide an in-depth analysis of the stiffness and deflection of the vibrating structures. The electrical designs of the MEMS vibrating ring gyroscope are analyzed using various electrode configurations, electrostatic actuation, and capacitive detection mechanisms. The design analysis of various forms of damping, including viscous, structural, thermoelastic, and anchor damping, is discussed. The variety of design structures is investigated for MEMS vibrating ring gyroscopes’ mechanical, electrical, and damping performance. Full article

This paper presents design and characterisation of a new compact metasurface based linear polarisation converter for terahertz applications. The metasurface unit cell with periodicity of 0.292${\lambda }_0$ consists of an asymmetrically oriented planar double semicircular goblet-shaped resonators. It is printed on a polydimethylsiloxane (PDMS) dielectric substrate backed by a gold layer that acts as a ground plane. This metasurface structure exhibits a broadband cross-polarisation conversion in the frequency range of 0.72–0.99 THz with a polarisation conversion ratio (PCR) > 95% and angular stability > ${\mathrm{40}}^{\circ }$ for both TE and TM modes. However, the PCR for the single band is >99% at resonant frequencies of 0.755 and 0.94 THz, while the optimised design shows 100% PCR over a BW of 95 GHz. Furthermore, slight modification and optimisation of the broadband design results in quad-ring and slotted DSGRs that produce dual and triple broadband polarisation conversion, respectively. The quad-ring DSGR performs polarisation conversion for frequency range of 0.70–1.08 and 1.61–1.76 THz while the slotted DSGR shows the triple broadband cross-conversion for frequency range of 0.67–0.85, 1.04–1.11, and 1.62–1.76 THz with PCR > 95%. This design is simple, easy to modify to implement single and multi broadband polarisation conversion with high PCR at terahertz regime. In addition to that, it is easy to fabricate and integrate with other components like multiple-input multiple-output terahertz antennas for mutual coupling reduction. Full article

Manipulation of multichannel vector beams (VBs) with metasurfaces is an important topic and holds potential applications in information technology. In this paper, we propose a novel metasurface for the generation of dual VBs, which is composed of orthogonal slit pairs arranged on multiple groups of combined semicircular rings (CSRs). A group of CSRs include a right-shifted set and a left-shifted set of semicircular rings, and each set of semicircular rings has two halves of circles with different radii, sharing the same shifted center. Under the illumination of linearly polarized light, the two shifted sets of semicircular rings generate the two VBs at the shifted center positions on the observation plane. The slit units of each set are designed with independent rotation order and initial orientation angle. By adjusting the linear polarization of illumination, both two VBs with their orders and polarization states are independently controlled simultaneously. The principle and design are demonstrated by the finite-difference time domain (FDTD) simulation. The work is of significance for miniatured devices of VB generators and for related applications. Full article

Ceramic materials have properties such as: high hardness; high ratio between mechanical resistance/density, wear and corrosion resistance; high stability to the action of corrosive agents; and relatively low price. However, the use of technical ceramics has a rather limited area, determined essentially by its tribo-mechanical behavior. The machine parts may fail and not fulfill their functional role due to some limit factors. This paper is based on the behavior of aluminum ceramics in terms of stress and strain in the contact area, and the tribological behavior of these materials. A mathematical concept, including multi-objective optimization based on the cuckoo search algorithm of breaking ceramic materials in which there are defects in the form of internal cracks, has been developed. A defect criterion has been formulated to allow the evaluation of the propagation of the semicircular crack which shapes the places where there are natural defects in the ceramic mass. The model highlighted is the contact between two curved surfaces, specific to the ball–ring contact in the bearings. It has highlighted tensions stress and the stress factors, taking into account the coefficient of conformity and the influence of the friction effects. The experimental study of the mechanical stress state in the contact areas was carried out with the ceramic friction couple ball-bearing ring (Al₂O₃—99.7% with the addition of SiO₂, Fe₂O and MgO). A large number of experimental tests were performed. The results of this research work are useful for mechanical designers to identify the crack effect on mechanical parts’ lifetime and to improve reliability. Full article

In order to study the influence of texture on the wear and lubrication performance of the surface of the tools, three kinds of textures with unidirectional convergence morphology were processed on the surface of the samples, and each texture was designed with different area occupancy ratios. Simulation analysis shows that, owing to the reflow and convection effect of liquid in the texture, the lubricating film flowing through the textured surface has a high hydrodynamic pressure value, and the semicircular ring texture is the most prominent. By comparing the friction coefficient, when the area occupancy ratio of texture on the surface is 10%, the surface of the samples with different morphology has the lowest coefficient of friction; the friction coefficient of the semicircular ring textured surface is especially very low. Surface textures reduce the direct contact area between the friction pairs, and generate dynamic pressure lubrication and secondary lubrication, so that the surface friction coefficient of the samples is obviously reduced. The surfaces of the non-textured samples have abrasive wear and contact fatigue wear, and the surfaces of the textured samples have adhesive wear, abrasive wear, and cavitation. Full article

In this paper, a circular polarizer comprising dual semicircular split-rings (DSSRs) is presented. By placing it above an elliptical radiator that radiates linearly polarized (LP) waves, dual-layer patch antennas capable of radiating right-hand (RH) or left-hand (LH) circularly polarized (CP) waves are achieved in terms of the different offset direction of the bottom splits of the DSSRs. Because of both the capacitive coupling to the radiator and the degenerate modes existing in the excited DSSRs, the DSSRs collaboratively result in a circularly polarized radiation, successfully converting incident LP waves into CP ones. Simulated results show that the impedance, axial ratio (AR), and gain frequency response of both proposed CP antennas are identical, with a simulated 3-dB AR bandwidth of 72 MHz covering 2.402–2.474 GHz and a gain enhanced by 3.9 dB. The proposed antennas were fabricated and measured, revealing an operational bandwidth of 65 MHz (2.345–2.41 GHz) and a peak gain up to 9 dBi. Moreover, a low profile of 0.063λ₀ is maintained. The proposed CP antennas could be as a candidate for wireless target detection applications in terms of their identical frequency response property. Full article

We present a compact ultra-wideband (UWB) antenna integrated with sharp notches with a detailed analysis of the mutual coupling of the multiple notch resonators. By utilizing complementary split ring resonators (CSRR) on the radiating semi-circular patch, we achieve the sharp notch-filtering of various bands within the UWB band without increasing the antenna size. The notched frequency bands include WiMAX, INSAT, and lower and upper WLAN. In order to estimate the frequency shifts of the notch due to the coupling of the nearby CSRRs, an analysis of the coupling among the multiple notch resonators is carried out and we construct the lumped-circuit equivalent model. The time domain analysis of the proposed antenna is performed to show its validity on the UWB application. The measured frequency response of the input port corresponds quite well with the calculations and simulations. The radiation pattern of the implemented quad-notched UWB antenna is nearly omnidirectional in the passband. Full article
