The China Seismo-Electromagnetic Satellite (CSES-01) is the first satellite of the space-based observational platform for the earthquake (EQ) monitoring system in China. It aims to monitor the ionospheric disturbances related to EQ activities by acquiring global electromagnetic fields, ionospheric plasma, energy particles, etc., opening a new path for innovative explorations of EQ prediction. This study analyzed 47 shallow strong EQ cases (Ms ≥ 7 and depth ≤ 100 km) recorded by CSES-01 from its launch in February 2018 to February 2023. The results show that: (1) For the majority (90%) of shallow strong EQs, at least one payload onboard CSES-01 recorded discernible abnormal signals before the mainshocks, and for over 65% of EQs, two or three payloads simultaneously recorded ionospheric disturbances; (2) the majority of anomalies recorded by different payloads onboard CSES-01 predominantly manifest within one week before or on the mainshock day, or occasionally about 11–15 days or 20–25 days before the mainshock; (3) typically, the abnormal signal detected by CSES-01 does not directly appear overhead the epicenter, but rather hundreds of kilometers away from the epicenter, and more preferably toward the equatorward direction; (4) the anomaly recognition rate of each payload differs, with the highest rate reaching more than 70% for the Electric Field Detector (EFD), Search-Coil Magnetometer (SCM), and Langmuir Probe (LAP); (5) for the different parameters analyzed in this study, the plasma density from LAP, and electromagnetic field in the ULF band recorded by EFD and SCM, and energetic electrons from the High-Energy Particle Package (HEPP) show a relatively high occurrence of abnormal phenomena during the EQ time. Although CSES-01 has recorded prominent ionospheric anomalies for a significant portion of EQ cases, it is still challenging to accurately extract and confirm the real seismic precursor signals by relying solely on a single satellite. The combination of seismology, electromagnetism, geodesy, geochemistry, and other multidisciplinary means is needed in the future’s exploration to get infinitely closer to addressing the global challenge of EQ prediction. Full article

The vertical component magnetic field signal in the ground–airborne frequency domain electromagnetic (GAFDEM) method is detected by the air coil sensor, which is parallel to the ground. Unfortunately, the air coil sensor has low sensitivity in the low-frequency band, making it challenging to detect effective low-frequency signals and causing low accuracy and large error for interpreted deep apparent resistivity in actual detection. This work develops an optimized weight magnetic core coil sensor for GAFDEM. The cupped flux concentrator is used in the sensor to reduce the weight of the sensor while maintaining the magnetic gathering capacity of the core coil. The winding of the core coil is optimized to resemble the shape of a rugby ball, taking full advantage of the magnetic gathering capacity at the core center. Laboratory and field experiment results show that the developed optimized weight magnetic core coil sensor for the GAFDEM method is highly sensitive in the low-frequency band. Therefore, the detection results at depth are more accurate compared with those obtained using existing air coil sensors. Full article

In this paper, a new analytical method to achieve the maximum signal-to-noise ratio (SNR) of a micro search coil magnetometer (µSCM) is presented. A planar spiral inductor was utilized to miniaturize conventional bulky search coil magnetometers. First, dimensional analysis was applied to identify three dimensionless parameters for the µSCM’s key performance indices (sensitivity (S_e), noise, and SNR). The effect of the parameters on the µSCM’s performance was carefully investigated, and a novel 4D nomogram was developed. Furthermore, an SNR analysis considering noise sources of a low-noise amplifier was performed. By combining the results from the nomogram and the effect of the noise sources from the amplifier circuit, optimum values for the dimensionless parameters were calculated. According to the calculation results, the dominant noise source varied with an increase in the track width ratio to the outer diameter. Seven different samples were fabricated by a single-mask lithography process. The sensitivity of 1612 mV/mT was demonstrated at a 50 Hz input magnetic field, which was better than the previous µSCM (S_e = 6.5 mV/mT) by more than 2 orders of magnitude. Finally, one of the fabricated µSCMs was employed to measure the online power consumption of a personal computer while different types of software were running. Full article

As important observational platforms for the Smart Ocean concept, autonomous underwater vehicles (AUVs) that perform long-term observation in fleets are beneficial because they provide large-scale sampling data with a sufficient spatiotemporal resolution. Therefore, a large number of low-cost micro AUVs with docking capability for power recharge and data transmission are essential. This study designed a low-cost electromagnetic docking guidance (EMDG) system for micro AUVs. The EMDG system is composed of a transmitter coil located on the dock and a three-axial search coil magnetometer acting as a receiver. The search coil magnetometer was optimized for small sizes while maintaining sufficient sensitivity. The signal conditioning and processing subsystem was designed to calculate the deflection angle (β) for docking guidance. Underwater docking tests showed that the system can detect the electromagnetic signal and successfully guide AUV docking. The AUV can still perform docking in extreme positions, which cannot be realized through normal optical or acoustic guidance. This study is the first to focus on the EM guidance system for low-cost micro AUVs. The search coil sensor in the AUV is inexpensive and compact so that the system can be equipped on a wide range of AUVs. Full article
