Plastic film mulching technology occupies a prominent position in China’s agricultural production and plays an important role in improving crop yields, which can increase farmers’ income and ensure national food security. As the current residual film recycling mechanism is incomplete, the accumulation of residual film in the soil has gradually increased, and the problem of residual film pollution has posed a serious threat to agricultural production and the natural environment. Ridge mulching cultivation is one of the main planting patterns for grain and oil crops, such as peanuts, potatoes, and maize, in China. In this paper, the planting patterns, mulching conditions, characteristics, and distribution of residual film of the typical ridge mulching crops, such as peanut and potato, were analyzed. The merits and demerits of various kinds of residual film recycling machines and the application status and operation quality of peanut and potato residual film recycling machines are summarized. Problems and suggestions for the mechanized recycling of residual film were raised. This study may provide ideas for the development of residual film mechanization recycling of ridge mulching crops. The aim of this study is to propose practical solutions by analyzing the current status and existing problems of mechanized residual film recovery in order to reduce residual film pollution, protect the environment, and achieve sustainable agricultural development. Full article

Plastic film mulching technology can effectively enhance crop yield and quality, and the use of mulch has been increasing in recent years; however, the problem of mulch residue is worsening due to the large amount of recycling work and slow natural degradation. In this study, a potato seedling killing and residual film recycling machine is designed to provide good working conditions for potato harvesters before harvesting in response to the problems of difficult separation of film tangles, the low net rate of recycling due to the mixing of residual film with soil, and the high soil content in residual film recycling operations in northwest China. The machine is based on the potato monoculture and double row planting mode in Gansu area. This paper puts forward the overall design scheme and carries out the theoretical analysis and parameter determination of the key components, such as the seedling killing device, the film surface cleaning device, the film unloading device, and so on. Using EDEM software to carry out the virtual simulation test and Design-Expert13 to analyze the test results, we determined the optimal working scheme for the machine, with a forward speed of 0.8 m/s, a film gap of 125 mm, and a spiral stirrer speed of 600 r/min. Based on a field test for verification, the test results show that the machine’s residual film recovery rate was 83.3%, the impurity rate was 3.8%, and the rate of injury to the potatoes was 1.4%. The machine meets the requirements of national and industry standards, and it can simultaneously realize straw crushing, film surface cleaning, residual film recycling, and hydraulic film unloading operations, with better operating results and while reaching the expected results. It can also provide a reference for the design and testing of a seeding and residual film recycling machine. Full article

The technology of plastic film mulching is widely applied in Xinjiang, but it also brings about serious issues of residual film pollution. Currently, the 1MSF-2.0 residual film recovery machine can effectively address the problem. However, it faces challenges such as high overall machine weight and noticeable frame vibrations, which affect the stability of the entire machine operation. The frame, as the installation foundation, needs to bear loads and impact. Therefore, the reliability of the frame is crucial for the stability of the entire machine. Improving the frame’s vibration is of great importance. In response to the significant vibration issues during the operation of the 1MSF-2.0 residual film recovery machine, this paper utilized Workbench 2020 R2 to establish a finite element model of the machine frame and conducted static analysis to obtain strength information, thereby initially understanding the optimization space of the frame. Building upon this, Mechanical was employed to solve the first 14 natural frequencies and mode shapes of the frame, and the accuracy of the theoretical analysis was verified through modal testing. After analyzing the frequency characteristics of external excitation forces, it was found that the fourth-order natural frequency of the frame fell within the frequency range of the excitation force of the shaft of the straw grinder, causing resonance in the frame and necessitating structural optimization. The optimal results indicated that the optimized frame increased in mass by 4.41%, reduced the maximum stress value by 2.56 MPa, and increased the fourth-order natural frequency to 22.7 Hz, avoiding the frequency range of the excitation force of the shaft of the straw grinder, thus improving the resonance issue. This paper provides a reference for optimizing the design of the frame of the residual film recovery machine. Full article

The extended duration of mulching in Xinjiang cotton fields leads to a significant decline in the tensile strength of plastic film. When recycling is in operation, the soil and the spring teeth of the machinery used can easily cause secondary damage and fracture the residual film. Establishing appropriate working parameters for recycling is essential to enhance the overall quality of collection efforts. By analyzing the motion process of a chain-tooth residual film pickup device, we identified key working parameters that significantly impact the efficiency of recycling. Employing the finite element method (FEM) and a coupled algorithm incorporating smooth particle hydrodynamics (SPH), we developed a coupled finite element model representing the interaction among spring teeth, soil, and residual film. Through simulation and analysis of the process of inserting the spring teeth into the soil to collect film, we derived the governing rules for residual film stress and deformation changes. Utilizing forward speed, rotational angular velocity, and angle of entry into the soil of the spring teeth as test factors and selecting the residual film stress and the residual film deformation as test indices, we conducted a multi-factor simulation test. We established a mathematical model correlating test factors with test indices, and the influence of each factor on the test index was analyzed. Subsequently, we optimized the working parameters of the spring teeth. The results indicated that the optimal working parameters are forward speed of 1111.11 mm/s, rotational angular velocity of 25 rad/s, and angle of entry into the soil of 30°. At these values, the average peak stress of residual film was 4.51 MPa and the height of residual film pickup was 84.48 mm. To validate the optimized the spring teeth impact on performance, field experiments were conducted with recovery rate and winding rate as test indices. The results demonstrated a 92.1% recovery rate and a 1.1% winding rate under the optimal combination of working parameters. The finite element model presented in this paper serves as a reference for designing and analyzing key components of residual film recycling machines. Full article

We attempt to solve the current problems of high impurity content and the poor reliability of chain harrow type residual film recovery machines when picking up residual film. This study makes a device for picking up residual film with a hook-and-tooth chain rail. First, we conducted an analysis of the trajectory of the tip movement of the hooked teeth in the designed picking device, with the condition that the residual mulch does not miss the picking, and the force conditions of the residual mulch in the conveying process and the collection process are presented. Secondly, to determine the optimal working parameters of the picking device, a three-factor, three-level response surface optimization test was conducted with the machine forward speed, hook tooth entry depth, and chain harrow input speed as the test factors and the residual film picking rate and the impurity rate of residual film as the test indexes. In addition, a response surface regression model was developed to analyze the effects of the selected factors on the picking device. When the forward speed of the machine was 1.62 m/s, the hook tooth entry depth was 38.51 mm, and the input speed of the chain harrow was 241.42 rpm, the pickup rate and the impurity rate of the residual film were 88.27% and 9.96%, respectively. Finally, the simulation test was carried out under optimal working conditions, with the maximum force of the hook teeth being 60.7 N, the maximum deformation being 31.42 mm, and the maximum stress being 215.33 Mpa. This study can be used as a guide to further improve the design of the residual film recovery machine. Full article

Aiming at the problem of high impurity rate in the recycled residual film, combined with the existing installation (4JMLE-210 agricultural residual film recycling machine), the removal mechanism of light impurities on the film surface was analyzed. The statics and kinematics analysis of light impurity particles in different spatial positions were carried out to determine the conditions for the movement of impurity particles. By analyzing critical conditions, such as ideal collision and throwing capacity, the structural dimensions of the straight pipe section and its outlet section were determined. Using Origin 2018 software, the movement track of the impurity particles left from the upper and lower limit positions and the ideal curve of the throwing arc were plotted, and the trapezoidal section was determined at the outlet of the throwing arc section. Finally, trial-produce prototype, and a field test was carried out on the performance of the machine by selecting the impurity rate in the recovered residual film as the test index. The results showed that when the forward speed of the machine and the rotating speed of the cutter roll were in the range of 5.4–5.8 km/h and 1440–1460 r·min⁻¹, the light impurity rate and working efficiency could keep a good balance. The light impurity rate in the recovered residual film was between 10.9% and 31.4%, and the average light impurity rate was around 18.7%, which met the design and application requirements. Full article

When the film is under no stress, it does not show any stiffness or capability to withstand loads. Therefore, with the help of ANSYS motion, the author applied pre-stress, controlled point coordinates and the equation of equivalent stress surface and used form-finding conditions to explore the equilibrium state of the films in different depths. The author established curve fitting equations and designed a new membrane-removing mulch film recovery machine. The author also analyzed key components and separately established regression equations between recovery rate, damage rate, release rate and the working angle of film picking mechanism, as well as the regression equation between the depth of picking mechanism into the soil and the working angle of clamping conveyor. Then the author conducted the variance analysis on these regression equations. By using Design Expert 8.0.6 to optimize the solution, when the working angle of the pick-up mechanism is 27.31°, the depth of the pick-up mechanism is 73.0 mm. The working angle of the clamping and conveying device is 38.33°, the recovery rate is 93.9% and the damage rate is 89.3%. The test result shows that when parameters are set as above values, the recovery rate of residual film is 92.5%, the release rate is 87.6% and the error values of damage rate and release rate are both lower than 1.5%, which have verified the feasibility of the optimization solution. The experimental result can work as a reference for the optimum working parameters of the new membrane-removing mulch film recovery machine. Full article

With the rapid development of planting techniques using plastic film mulching, the content of residual plastic film in soil increases year by year, which pollutes the soil and water, endangers the growth of crops and reduces the quality and yield of agricultural products. Therefore, in order to solve the problem that plastic film with a thickness of 0.008 mm, commonly used in China, is difficult to recycle, this study designed the residue film recycling machine based on the existing research results. After harvesting cotton in Xinjiang, the working performance of the residue film recovery machine of plough layer was measured. Through theoretical optimization and field experiments, the effects of conveyor speed, distance between elastic teeth and type of elastic teeth on residual film recovery were studied. The relationship between the parameters of the residual film recovery machine and the recovery effect of the residual film was analyzed. When the rotational speed and inclination angle of the conveying and separating device were 74 rpm, 35° and 120 rpm, 45°, respectively, under the condition that the distance between C-shaped elastic teeth was 59 mm, the recovery and separation rate of residual plastic film were 88.12% and 83.27%, respectively. Based on the study results, it is recommended to accelerate the development of naturally degradable agricultural plastic film or to popularize and apply thickened film. Relevant local standards and policies have been formulated to address the problem of residual film pollution, and a governance system has been established for the benefit of the government, scientific research institutions, enterprises and farmers. This study provides a reference for mechanized recovery of residual plastic film in soil and treatment of soil pollution. Full article
