Ultra-Bend-Resistant 4-Core Simplex Cable Used for Short-Reach Dense Spatial Division Multiplexing Optical Transmission
by Zelin Zhang, Yu Qin, Jie Zhu, Caoyuan Wang, Xinli Jiang, Yichun Shen and Limin Xiao
Micromachines 2024, 15(1), 108; https://doi.org/10.3390/mi15010108 - 7 Jan 2024
Viewed by 2658
Abstract
We optimized and fabricated an ultra-bend-resistant 4-core simplex cable (SXC) employing 4-core multicore fiber (MCF) suitable for short-reach dense spatial division multiplexing (DSDM) optical transmission in the O-band. The characteristics of transmission loss, macro-bending and cross-talk (XT) between adjacent cores after cabling were [...] Read more.
We optimized and fabricated an ultra-bend-resistant 4-core simplex cable (SXC) employing 4-core multicore fiber (MCF) suitable for short-reach dense spatial division multiplexing (DSDM) optical transmission in the O-band. The characteristics of transmission loss, macro-bending and cross-talk (XT) between adjacent cores after cabling were firstly clarified. By introducing the trapezoid index and optimizing the cabling process, the maximum values of added XT of 1.17 dB/km due to 10 loops with a bending radius of 6 mm imposed over the 4-core SXC and a macro-bending loss of 0.37 dB/10 turns were, respectively, achieved.P Then, the optical transmission with low bit error rate (BER) was presented using a 100GBASE-LR4 transceiver over the 1.2 km long 4-core SXC. The excellent bending resistance of the 4-core SXC may pave the way for a reduction in space pressure and increase in access density on short-reach optical interconnect (OI) based on DSDM. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

13 pages, 5941 KB
Article
Reduction of Crosstalk Errors in a Surface Encoder Having a Long Z-Directional Measuring Range
by Yifan Hong, Ryo Sato, Yuki Shimizu, Hiraku Matsukuma, Hiroki Shimizu and Wei Gao
Sensors 2022, 22(23), 9563; https://doi.org/10.3390/s22239563 - 6 Dec 2022
Cited by 9 | Viewed by 2766
Abstract
A modified two-axis surface encoder is proposed to separately measure both the in-plane displacement and the Z-directional out-of-plane displacement with minor crosstalk errors. The surface encoder is composed of a scale grating and a small-sized sensor head. In the modified surface encoder, [...] Read more.
A modified two-axis surface encoder is proposed to separately measure both the in-plane displacement and the Z-directional out-of-plane displacement with minor crosstalk errors. The surface encoder is composed of a scale grating and a small-sized sensor head. In the modified surface encoder, the measurement laser beam from the sensor head is designed to be projected onto the scale grating at a right angle. For measurement of the X- and Y-directional in-plane scale displacement, the positive and negative first-order diffracted beams from the scale grating are superimposed on each other in the sensor head, producing interference signals. On the other hand, the Z-directional out-of-plane scale displacement is measured based on the principle of a Michelson-type interferometer. To avoid the influence of reflection from the middle area of the transparent grating, which causes periodic crosstalk errors in the previous research, a specially fabricated transparent grating with a hole in the middle is employed in the newly designed optical system. A prototype sensor head is constructed, and basic performances of the modified surface encoder are tested by experiments. Full article
(This article belongs to the Special Issue Feature Papers in Optical Sensors 2022)
Show Figures

Figure 1

20 pages, 1380 KB
Article
Investigation of Regression Methods for Reduction of Errors Caused by Bending of FSR-Based Pressure Sensing Systems Used for Prosthetic Applications
by Chakaveh Ahmadizadeh and Carlo Menon
Sensors 2019, 19(24), 5519; https://doi.org/10.3390/s19245519 - 13 Dec 2019
Cited by 12 | Viewed by 4936
Abstract
The pressure map at the interface of a prosthetic socket and a residual limb contains information that can be used in various prosthetic applications including prosthetic control and prosthetic fitting. The interface pressure is often obtained using force sensitive resistors (FSRs). However, as [...] Read more.
The pressure map at the interface of a prosthetic socket and a residual limb contains information that can be used in various prosthetic applications including prosthetic control and prosthetic fitting. The interface pressure is often obtained using force sensitive resistors (FSRs). However, as reported by multiple studies, accuracies of the FSR-based pressure sensing systems decrease when sensors are bent to be positioned on a limb. This study proposes the use of regression-based methods for sensor calibration to address this problem. A sensor matrix was placed in a pressure chamber as the pressure was increased and decreased in a cyclic manner. Sensors’ responses were assessed when the matrix was placed on a flat surface or on one of five curved surfaces with various curvatures. Three regression algorithms, namely linear regression (LR), general regression neural network (GRNN), and random forest (RF), were assessed. GRNN was selected due to its performance. Various error compensation methods using GRNN were investigated and compared to improve instability of sensors’ responses. All methods showed improvements in results compared to the baseline. Developing a different model for each of the curvatures yielded the best results. This study proved the feasibility of using regression-based error compensation methods to improve the accuracy of mapping sensor readings to pressure values. This can improve the overall accuracy of FSR-based sensory systems used in prosthetic applications. Full article
(This article belongs to the Special Issue Smart Sensors for Healthcare and Medical Applications)
Show Figures

Figure 1

14 pages, 4149 KB
Article
Decoupled Six-Axis Force–Moment Sensor with a Novel Strain Gauge Arrangement and Error Reduction Techniques
by Getnet Ayele Kebede, Anton Royanto Ahmad, Shao-Chun Lee and Chyi-Yeu Lin
Sensors 2019, 19(13), 3012; https://doi.org/10.3390/s19133012 - 8 Jul 2019
Cited by 45 | Viewed by 7415
Abstract
In this study, a novel strain gauge arrangement and error reduction techniques were proposed to minimize crosstalk reading and simultaneously increase sensitivity on a decoupled six-axis force–moment (F/M) sensor. The calibration process that comprises the least squares method and error reduction techniques was [...] Read more.
In this study, a novel strain gauge arrangement and error reduction techniques were proposed to minimize crosstalk reading and simultaneously increase sensitivity on a decoupled six-axis force–moment (F/M) sensor. The calibration process that comprises the least squares method and error reduction techniques was implemented to obtain a robust decoupling matrix. A decoupling matrix is very crucial for minimizing error and crosstalk. A novel strain gauge arrangement that comprised double parallel strain gauges in the decoupled six-axis force–moment sensor was implemented to obtain high sensitivity. The experimental results revealed that the maximum calibration error, F/M sensor measurement error, and crosstalk readings were reduced to 3.91%, 1.78%, and 4.78%, respectively. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

12 pages, 2353 KB
Article
Circular Array of Magnetic Sensors for Current Measurement: Analysis for Error Caused by Position of Conductor
by Hao Yu, Zheng Qian, Huayi Liu and Jiaqi Qu
Sensors 2018, 18(2), 578; https://doi.org/10.3390/s18020578 - 14 Feb 2018
Cited by 33 | Viewed by 7174
Abstract
This paper analyzes the measurement error, caused by the position of the current-carrying conductor, of a circular array of magnetic sensors for current measurement. The circular array of magnetic sensors is an effective approach for AC or DC non-contact measurement, as it is [...] Read more.
This paper analyzes the measurement error, caused by the position of the current-carrying conductor, of a circular array of magnetic sensors for current measurement. The circular array of magnetic sensors is an effective approach for AC or DC non-contact measurement, as it is low-cost, light-weight, has a large linear range, wide bandwidth, and low noise. Especially, it has been claimed that such structure has excellent reduction ability for errors caused by the position of the current-carrying conductor, crosstalk current interference, shape of the conduction cross-section, and the Earth’s magnetic field. However, the positions of the current-carrying conductor—including un-centeredness and un-perpendicularity—have not been analyzed in detail until now. In this paper, for the purpose of having minimum measurement error, a theoretical analysis has been proposed based on vector inner and exterior product. In the presented mathematical model of relative error, the un-center offset distance, the un-perpendicular angle, the radius of the circle, and the number of magnetic sensors are expressed in one equation. The comparison of the relative error caused by the position of the current-carrying conductor between four and eight sensors is conducted. Tunnel magnetoresistance (TMR) sensors are used in the experimental prototype to verify the mathematical model. The analysis results can be the reference to design the details of the circular array of magnetic sensors for current measurement in practical situations. Full article
(This article belongs to the Special Issue Magnetic Sensors)
Show Figures

Graphical abstract
