Search Results (8)

We report on asymmetrically shaped Fano resonances in Al_0.2Ga_0.8N/GaN-based quantum cascade structures. In order to observe this type of resonance in electro-luminescence, a spectrally narrow feature must interact with a broad, quasi-continuous emission. While the narrow waveform is provided by the GaN-based LO-phonon at 92 meV (13.5 µm, 741 cm⁻¹), the broad peak consists of overlapping inter-subband transitions between several higher-order excited states ranging from 80 to 300 meV and the ground state. Through the interference of these spectrally dissimilar peaks, a typical, asymmetric Fano line shape is generated. Full article

High-power quantum cascade lasers (QCLs) have a wide application prospect. In this paper, a high-power high-beam-quality device with a large ridge width is demonstrated. The effect of different ridge widths on mode loss was studied, and the results showed that the mode loss decreased as the ridge width increased. Furthermore, as the width of the ridge increased, the temperature of the active region rose. In the experiment, the wafers were grown by metal–organic chemical vapor deposition (MOCVD), and the ridge width of the device was controlled by wet etching. A laser with a ridge width of 15 µm and a length of 5 mm achieved an output of 2.2 W under 288 K continuous wave (CW) operation, with a maximum slow-axis divergence angle of 27.2° and a device wavelength of 5 μm. The research results of this article promote the industrial production of base transverse mode QCL. Full article

The introduction of strong-field ligands can enable luminescence in first-row transition-metal complexes. In this way, earth-abundant near-infrared emitters can be obtained using early 3d metals. A prime example is the molecular ruby [Cr(ddpd)₂]³⁺ (ddpd = N,N′-dimethyl-N,N′-dipyridin-2-ylpyridine-2,6-diamine) that can achieve high phosphorescence quantum yields at room temperature in aqueous solution. To understand these remarkable properties, here, we simulate its photodynamics in water using trajectory surface hopping on linear vibronic coupling potentials parametrized from multiconfigurational CASSCF/CASPT2 calculations. We find that after excitation to the second absorption band, a relaxation cascade through metal-centered states occurs. After an initial back-and-forth intersystem crossing with higher-lying doublet states, the complex relaxes through a manifold of quartet metal-centered states to the low-lying doublet metal-centered states which are responsible for the experimentally observed emission. These electronic processes are driven by an elongation of the Cr–ligand bond lengths as well as the twisting motion of the trans-coordinated pyridine units in the ddpd ligands. The low-lying doublet states are reached within 1–2 ps and are close in geometry to the doublet minima, thus explaining the high phosphorescence quantum yield of the molecular ruby [Cr(ddpd)₂]³⁺. Full article

In this work, we present and analyze a design of an absorber–waveguide system combining a highly sensitive waveguide array concept with a resonant selective absorber. The waveguide part is composed of an array of coupled strip waveguides and is therefore called a coupled strip array (CSA). The CSA is then coupled to the end of a slab Tamm plasmon (STP-) resonator, which is composed of a quasicrystal-like reflector formed by the patterning of a silicon slab and an interfacing tungsten slab. The concept describes an emitter–waveguide or waveguide–detector system featuring selective plasmon-enhanced resonant absorption or emission. These are crucial properties for corresponding optical on-chip integrated devices in context with evanescent field absorption sensing in fluids or gases, for example. Thus, the concept comprises a valuable and more cost-effective alternative to quantum cascade lasers. We designed the lateral dimensions of the STP resonator via a simple quasi-crystal approach and achieved strong narrowband resonances (emittance and Q-factors up to 85% and 88, respectively) for different silicon thicknesses and substrate materials (air and silicon oxide). Moreover, we analyze and discuss the sensitivity of the complete emitter–waveguide system in dependence on the slab thickness. This reveals the crucial correlation between the expected sensitivity assigned to the absorber–waveguide system and field confinement within the silicon. Full article

Recent developments in mid-infrared (MIR) spectroscopic ellipsometry enabled by quantum cascade lasers (QCLs) have resulted in a drastic improvement in signal-to-noise ratio compared to conventional thermal emitter based instrumentation. Thus, it was possible to reduce the acquisition time for high-resolution broadband ellipsometric spectra from multiple hours to less than 1 s. This opens up new possibilities for real-time in-situ ellipsometry in polymer processing. To highlight these evolving capabilities, we demonstrate the benefits of a QCL based MIR ellipsometer by investigating single and multilayered polymer films. The molecular structure and reorientation of a $2.5$$\mathsf{\mu }\mathrm{m}$ thin biaxially oriented polyethylene terephthalate film is monitored during a stretching process lasting $24.5$ s to illustrate the perspective of ellipsometric measurements in dynamic processes. In addition, a polyethylene/ethylene vinyl alcohol/polyethylene multilayer film is investigated at a continuously varying angle of incidence (0${}^{\circ }$– 50${}^{\circ }$) in $17.2$ s, highlighting an unprecedented sample throughput for the technique of varying angle spectroscopic ellipsometry in the MIR spectral range. The obtained results underline the superior spectral and temporal resolution of QCL ellipsometry and qualify this technique as a suitable method for advanced in-situ monitoring in polymer processing. Full article

Active nanoplasmonics have recently led to the emergence of many promising applications. One of them is the spaser (surface plasmons amplification by stimulated emission of radiation) that has been shown to generate coherent and intense fields of selected surface plasmon modes that are strongly localized in the nanoscale. We propose a novel nanospaser composed of a metal nanoparticles-graphene nanodisks hybrid plasmonic system as its resonator and a quantum dots cascade stack as its gain medium. We derive the plasmonic fields induced by pulsed excitation through the use of the effective medium theory. Based on the density matrix approach and by solving the Lindblad quantum master equation, we analyze the ultrafast dynamics of the spaser associated with coherent amplified plasmonic fields. The intensity of the plasmonic field is significantly affected by the width of the metallic contact and the time duration of the laser pulse used to launch the surface plasmons. The proposed nanospaser shows an extremely low spasing threshold and operates in the mid-infrared region that has received much attention due to its wide biomedical, chemical and telecommunication applications. Full article

n-type doped Ge quantum wells with SiGe barriers represent a promising heterostructure system for the development of radiation emitters in the terahertz range such as electrically pumped quantum cascade lasers and optically pumped quantum fountain lasers. The nonpolar lattice of Ge and SiGe provides electron–phonon scattering rates that are one order of magnitude lower than polar GaAs. We have developed a self-consistent numerical energy-balance model based on a rate equation approach which includes inelastic and elastic inter- and intra-subband scattering events and takes into account a realistic two-dimensional electron gas distribution in all the subband states of the Ge/SiGe quantum wells by considering subband-dependent electronic temperatures and chemical potentials. This full-subband model is compared here to the standard discrete-energy-level model, in which the material parameters are limited to few input values (scattering rates and radiative cross sections). To provide an experimental case study, we have epitaxially grown samples consisting of two asymmetric coupled quantum wells forming a three-level system, which we optically pump with a free electron laser. The benchmark quantity selected for model testing purposes is the saturation intensity at the 1→3 intersubband transition. The numerical quantum model prediction is in reasonable agreement with the experiments and therefore outperforms the discrete-energy-level analytical model, of which the prediction of the saturation intensity is off by a factor 3. Full article

In an effort to overcome current limitations to electrical tuning of quantum cascade lasers, a strategy is proposed which combines heterogeneous quantum cascade laser gain engineering with sampled grating architectures. This approach seeks to not only widen the accessible spectral range for an individual emitter, but also compensate for functional non-uniformity of reflectivity and gain lineshapes. A trial laser with a dual wavelength core is presented which exhibits electroluminescence over a 750 cm⁻¹ range and discrete single mode laser emission over a 700 cm⁻¹ range. Electrical tuning over 180 cm⁻¹ is demonstrated with a simple sampled grating design. A path forward to even wider tuning is also described using more sophisticated gain and grating design principles. Full article
