The integration of Building Information Modeling (BIM) and 3D Geographic Information System (3D GIS) models provides high-precision spatial data for digital twin watersheds. To tackle the challenges of large data volumes and rendering latency in integrated models, this study proposes a three-step framework that uses Industry Foundation Classes (IFCs) as the base model and Open Scene Graph Binary (OSGB) as the target model: (1) geometric optimization through an angular weighting (AW)-controlled Quadric Error Metrics (QEM) algorithm; (2) Level of Detail (LOD) hierarchical mapping to establish associations between the IFC and OSGB models, and redesign scene paging logic; (3) coordinate registration by converting the IFC model’s local coordinate system to the global coordinate system and achieving spatial alignment via the seven-parameter method. Applied to the Santun River Basin digital twin project, experiments with 10 water gate models show that the AW-QEM algorithm reduces average loading time by 15% compared to traditional QEM, while maintaining 97% geometric accuracy, demonstrating the method’s efficiency in balancing precision and rendering performance. Full article

To enhance the intelligence and digital management level of radio telescopes and ensure the safe and stable operation of antennas, this paper proposes a real-time state evaluation method for the antenna structure of radio telescopes based on digital twin (DT) technology. Firstly, based on the five-dimensional model of DT, a digital twin system (DTs) framework for radio telescopes is designed. Secondly, the quadric error metrics (QEM) mesh-simplification algorithm and mesh-reconstruction technology are employed to obtain a lightweight twin model of the antenna. Furthermore, a random forest (RF) regression surrogate model is established using finite element point cloud data samples. The K-nearest neighbor (KNN) algorithm and radial basis function (RBF) interpolation algorithm are utilized to construct the virtual–physical mapping model of the antenna, enabling rapid prediction and evaluation of the antenna structure state. Finally, a DT for real-time antenna structure state evaluation is developed using the Unity3D engine, with an experimental prototype of a reflector antenna as the object. Experimental results show that the average prediction accuracy of the physical field surrogate model of the system is 0.98, and the average computation time is 0.4 s. The system meets the precision and computational efficiency requirements for the real-time and accurate evaluation of the antenna structure state. Full article

With the rapid advancement of computer graphics and three-dimensional modeling technology, the processing and optimization of three-dimensional (3D) models have become contentious research topics. In the context of mobile devices or web applications, situations may arise where it becomes necessary to load a 3D model with a substantial memory footprint in real-time or dynamically adjust the level of detail of a model based on the scene’s proximity. In such cases, it is imperative to optimize the original model to ensure smoothness and responsiveness. Due to the simplicity of their algorithm, quadric error metrics (QEMs) can deliver excellent results in simplifying 3D models while maintaining high efficiency. Therefore, QEM is widely employed in engineering applications within the realm of computer graphics development. Moreover, in the pursuit of enhanced quality and efficiency, numerous scholars have improved it based on QEM algorithms. This study aims to provide a systematic review and summary of the principles and applications of current research on QEM algorithms. First, we conducted a bibliometric analysis of 128 studies in related fields spanning from 1998 to 2022 using CiteSpace. This allowed us to sort QEM algorithms and gain insights into their development status and emerging trends. Second, we delve into the fundamental principles and optimizations of the QEM algorithms to provide a deeper understanding of their implementation process. Following that, we explore the advantages and limitations of the QEM algorithms in practical applications and analyze their potential in various domains, including virtual reality and game development. Finally, this study outlines future research directions, which encompass the development of more efficient error metric calculation methods, the exploration of adaptive simplification strategies, and the investigation of potential synergies with deep learning technologies. Current research primarily centers on enhancing QEM algorithms by incorporating additional geometric constraints to better differentiate between flat and irregular areas. This enables a more accurate determination of the areas that should be prioritized for folding. Nevertheless, it is important to note that these improvements may come at the cost of reduced computational efficiency. Therefore, future research directions could involve exploring parallel computing techniques and utilizing GPUs to enhance computational efficiency. Full article

In the design and operation scenarios driven by Digital Twins, large computer-aided design (CAD) models of production line equipment can limit the real-time performance and fidelity of the interaction between digital and physical entities. Digital CAD models often consist of combined parts with characteristics of discrete folded corner planes. CAD models simplified to a lower resolution by current mainstream mesh simplification algorithms might suffer from significant feature loss and mesh breakage, and the interfaces between the different parts cannot be well identified and simplified. A lightweight approach for common CAD assembly models of Digital Twins is proposed. Based on quadric error metrics, constraints of discrete folded corner plane characteristics of Digital Twin CAD models are added. The triangular regularity in the neighborhood of the contraction target vertices is used as the penalty function, and edge contraction is performed based on the cost. Finally, a segmentation algorithm is employed to identify and remove the interfaces between the two CAD assembly models. The proposed approach is verified through common stereoscopic warehouse, robot base, and shelf models. In addition, a scenario of a smart phone production line is applied. The experimental results indicate that the geometric error of the simplified mesh is reduced, the frame rate is improved, and the integrity of the geometric features and triangular facets is effectively preserved. Full article

Triangulated irregular networks (TINs) are widely used in terrain visualization due to their accuracy and efficiency. However, the conventional algorithm for multi-scale terrain rendering, based on TIN, has many problems, such as data redundancy and discontinuities in scale transition. To solve these issues, a method based on a detail-increment model for the construction of a continuous-scale hierarchical terrain model is proposed. First, using the algorithm of edge collapse, based on a quadric error metric (QEM), a complex terrain base model is processed to a most simplified model version. Edge collapse records at different scales are stored as compressed incremental information in order to make the rendering as simple as possible. Then, the detail-increment hierarchical terrain model is built using the incremental information and the most simplified model version. Finally, the square root of the mean minimum quadric error (MMQE), calculated by the points at each scale, is considered the smallest visible object (SVO) threshold that allows for the scale transition with the required scale or the visual range. A point cloud from Yanzhi island is converted into a hierarchical TIN model to verify the effectiveness of the proposed method. The results show that the method has low data redundancy, and no error existed in the topology. It can therefore meet the basic requirements of hierarchical visualization. Full article
