This paper presents a circularly polarized (CP) antenna based on crossed dipoles with bandpass-type filtering radiation response. The antenna employs a pair of crossed dipole arms as radiators, which are printed on the upper and lower planes of the substrate. To achieve bandpass filtering effects, radiation nulls are introduced on both sides of the passband. By vertically extending the ends of the four dipole arms, a ring-shaped current is formed between adjacent dipoles, generating the upper-band radiation null. Additionally, four parasitic patches are introduced parallel to the ends of the crossed dipole arms, creating another upper-band radiation null, further enhancing the frequency selectivity at the band edges and broadening the axial ratio (AR) bandwidth. Moreover, a square-ring slot is etched on the ground plane to introduce a lower-band radiation null, ultimately achieving a good bandpass filtering response. The proposed wideband CP filtering dipole antenna is implemented and tested. The antenna has a compact size of 0.49${\lambda }_0\times$ 0.49${\lambda }_0\times$ 0.16${\lambda }_0$ (where ${\lambda }_0$ denotes the wavelength corresponding to the lowest operating frequency). The measured results show that the proposed antenna has an impedance bandwidth of 75% (1.65–3.66 GHz) and an overlapping AR bandwidth of 46.9% (2.25–3.63 GHz). Without additional filtering circuits, the antenna exhibits a stable gain of approximately 7 dB and three radiation nulls, with suppression levels of 20 dB in both the lower and upper stopbands, achieving good bandpass filtering performance. Full article

The Internet of Things (IoT) is one of the pivotal technologies driving the digital transformation of industry, business, and personal life. Along with new opportunities, the exponential growth of IoT devices also brings environmental challenges, driven by the increasing accumulation of e-waste. This paper introduces a novel, compact, cubic-shaped rectenna with a 3D-printed composite substrate featuring five identical patches. The design aims to integrate RF energy harvesting technology with eco-friendly materials, enabling its application in powering next-generation sustainable IoT systems. Due to its symmetrical design, each patch antenna achieves a bandwidth of 130 MHz within the frequency range of 2.4 GHz to 2.57 GHz, with a maximum efficiency of 60.5% and an excellent isolation of below −25 dB between adjacent patch antennas. Furthermore, measurements of the rectifier circuit indicate a maximum conversion efficiency of 33%, which is comparable to that of other rectennas made on 3D-printed substrates. The proposed visually unobtrusive design not only enhances compactness but also allows the proposed rectenna to harvest RF energy from nearly all directions. Full article

In this paper, we design a frequency reconfigurable antenna for terahertz communication. The antenna is based on a Yagi design, with the main radiating elements being a pair of dipole antennas printed on the top and bottom of a dielectric substrate, respectively. The director and reflector elements give the antenna end-fire characteristics. The ends of the two arms of the dipole are constructed by staggered metal and graphene parasitic patches. By utilizing the effect of gate voltage on the conductivity of graphene, the equivalent length of the dipole antenna arms are altered and thereby adjust the antenna’s operating frequency. The proposed reconfigurable hybrid Yagi–Uda antenna can operate in five frequency bands separately at a peak gain of 4.53 dB. This reconfigurable antenna can meet the diverse requirements of the system without changing its structure and can reduce the size and cost while improving the performance. Full article

This article presents a printed antenna, designed with a fractal-shaped patch with fish-tail structured outer edges, a tapered feedline, and a rectangular notch-based defected partial ground structure (DPGS). The presented design has been printed on a FR-4 substrate, which has a dielectric constant of 4.4 and a loss tangent of 0.035. The overall dimension of the proposed antenna is 24 × 40 × 1.6 mm³. The proposed fractal antenna achieved dual broad-band functionality by maintaining the compact size of the radiator. The designed fractal radiator can operate at three distinct resonant frequencies (3.22, 7.64, and 9.41 GHz), covering two distinct frequency bands, extending from 2.5 to 4.2 GHz and 7 to 9.8 GHz. A thorough parametric analysis has been carried out using CST Studio suite 2019 licensed version to achieve better performance in terms of S₁₁ (dB), radiation efficiency, and gain over the operating frequency range. The operating bands fall within the S, C, and X bands to support sub-6GHz 5G and Radar applications at the microwave frequency range. Full article

Super-wideband (SWB) antennas have emerged as a promising technology for next-generation wireless communication systems due to their ability to transmit and receive signals across a wide frequency spectrum. A half-elliptical-shaped patch antenna for a super-wideband antenna is proposed in this paper. The proposed antenna was composed of a half-elliptical-shaped patch with a microstrip feedline and a partial ground plane with a triangular inset and a bent edge ground plane. This proposed antenna was designed using Taconic TLY-5 with a dielectric permittivity of 2.2 and a total dimension of 200 × 220 × 1.57 mm³. The proposed antenna demonstrates a bandwidth of 23 GHz (from 0.5 GHz to 23.5 GHz) with a bandwidth ratio of 47:1. Full article

The paper presents a novel small-footprint varactor diode-based reconfigurable reflectarray (RRA) design and investigates its power reflection efficiency theoretically and experimentally in a real-life indoor environment. The surface is designed to operate at 865.5 MHz and is intended for simultaneous use with other wireless power transfer (WPT) efficiency-improving techniques that have been recently reported in the literature. To the best of the authors’ knowledge, no RRA intended to improve the performance of antenna-based WPT systems operating in the sub-GHz range has been designed and studied both theoretically and experimentally so far. The proposed RRA is a two-layer structure. The top layer contains electronically tunable phase shifters for the local phase control of an incoming electromagnetic wave, while the other one is fully covered by metal to reduce the phase shifter size and RRA’s backscattering. Each phase shifter is a pair of diode-loaded 8-shaped metallic patches. Extensive numerical studies are conducted to ascertain a suitable set of RRA unit cell parameters that ensure both adequate phase agility and reflection uniformity for a given varactor parameter. The RRA design parameter finding procedure followed in this paper comprises several steps. First, the phase and amplitude responses of a virtual infinite double periodic RRA are computed using full-wave solver Ansys HFSS. Once the design parameters are found for a given set of physical constraints, the phase curve of the corresponding finite array is retrieved to estimate the side lobe level due to the finiteness of the RRA aperture. Then, a diode reactance combination is found for several different RRA reflection angles, and the corresponding RRA radiation pattern is computed. The numerical results show that the side lobe level and the deviation of the peak reflected power angles from the desired ones are more sensitive to the reflection coefficient magnitude uniformity than to the phase agility. Furthermore, it is found that for scanning angles less than 50°, satisfactory reflection efficiency can be achieved by using the classical reactance profile synthesis approach employing the generalized geometrical optics (GGO) approximation, which is in accord with the findings of other studies. Additionally, for large reflection angles, an alternative synthesis approach relying on the Floquet mode amplitude optimization is utilized to verify the maximum achievable efficiency of the proposed RRA at large angles. A prototype consisting of 36 elements is fabricated and measured to verify the proposed reflectarray design experimentally. The initial diode voltage combination is found by applying the GGO-based phase profile synthesis method to the experimentally obtained phase curve. Then, the voltage combination is optimized in real time based on power measurement. Finally, the radiation pattern of the prototype is acquired using a pair of identical 4-director printed Yagi antennas with a gain of 9.17 dBi and compared with the simulated. The calculated results are consistent with the measured ones. However, some discrepancies attributed to the adverse effects of biasing lines are observed. Full article

In this paper, we present the design of a millimeter-wave 1 × 4 linear MIMO array antenna that operates across multiple resonance frequency bands: 26.28–27.36 GHz, 27.94–28.62 GHz, 32.33–33.08 GHz, and 37.59–39.47 GHz, for mm-wave wearable biomedical telemetry application. The antenna is printed on a flexible substrate with dimensions of 11.0 × 44.0 mm². Each MIMO antenna element features a modified slot-loaded triangular patch, incorporating ‘cross’-shaped slots in the ground plane to improve impedance matching. The MIMO antenna demonstrates peak gains of 6.12, 8.06, 5.58, and 8.58 dBi at the four resonance frequencies, along with a total radiation efficiency exceeding 75%. The proposed antenna demonstrates excellent diversity metrics, with an ECC < 0.02, DG > 9.97 dB, and CCL below 0.31 bits/sec/Hz, indicating high performance for mm-wave applications. To verify its properties under flexible conditions, a bending analysis was conducted, showing stable S-parameter results with deformation radii of 40 mm (Rx) and 25 mm (Ry). SAR values for the MIMO antenna are calculated at 28.0/38.0 GHz. The average SAR values for 1 gm/10 gm of tissues at 28.0 GHz are found to be 0.0125/0.0079 W/Kg, whereas, at 38.0 GHz, average SAR values are 0.0189/0.0094 W/Kg, respectively. Additionally, to demonstrate the telemetry range of biomedical applications, a link budget analysis at both 28.0 GHz and 38.0 GHz frequencies indicated strong signal strength of 33.69 dB up to 70 m. The fabricated linear MIMO antenna effectively covers the mm-wave 5G spectrum and is suitable for wearable and biomedical applications due to its flexible characteristics. Full article

This paper presents a compact wideband circularly polarized cross-dipole antenna with a low-pass filter response. It consists of two pairs of folded cross-dipole arms printed separately on both sides of the top substrate, and the two dipole arms on the same surface are connected by an annular phase-shifting delay line to generate circular polarization. A bent metal square ring and four small metal square rings around the cross-dipoles are employed to introduce new resonant frequencies, effectively extending the impedance and axial-ratio bandwidth. Four square patches printed on the middle substrate are connected to the ground plane by the vertical metal plates in order to reduce the antenna height. Thus, a compact wideband circularly polarized antenna is realized. In addition, a transmission zero can be introduced at the upper frequency stopband by the bent metal square rings, without using extra filter circuits. For verification, the proposed model is implemented and tested. The overall size of the model is $90\mathrm{mm}\times 90\mathrm{mm}\times 33\mathrm{mm}$ ($0.37{\lambda }_0\times 0.37{\lambda }_0\times 0.14{\lambda }_0$; ${\lambda }_0$ denotes the center operating frequency). The measured impedance bandwidth and 3 dB axial-ratio (AR) bandwidth are 53.3% and 41%, respectively. An upper-band radiation suppression level greater than 15 dB is realized, indicating a good low-pass filter response. Full article

In this paper, an eight-port antenna array is presented for 5G handheld terminals to support multiple-input multiple-output (MIMO) operations. The reported design involves three layers: the top contains eight circular microstrip feed elements; the middle is a low-cost FR-4 substrate, and the bottom layer is a ground plane with four etched octagonal slots. Each resonating element is fed by 50-ohm sub-miniature connectors. To mitigate the detrimental effects of mutual coupling of ports and enhance overall isolation between the adjacent microstrip-fed circular patch elements, a neutralization line is strategically implemented between the feed lines of the antenna array. The design configuration involves two elements at each vertex of the printed circuit board (PCB). The overall dimensions of the PCB are 150 × 75 mm². Each slot and its corresponding radiating elements exhibit linear dual polarization and diverse radiation patterns. The proposed antenna design achieves the required operating bandwidth of more than 1000 MHz spanning from 3 to 4.2 GHz, effectively covering all the upper C-band frequency range of 3.3 GHz to 4.2 GHz allocated for 5G n77 and n78 frequency range 1 (FR1). Required port isolation and lower envelop correlation coefficient (ECC) are achieved for the band of interest. The proposed design gives a peak gain of up to 4 dB for the said band. In addition to these results, degradation in the performance of the antenna array is also investigated during different operating modes of the handheld device. Measured results from the fabricated unit cell and whole array also have a good match with simulated results. On the whole, the proposed antenna possesses the potential to be used in 5G and the open radio access network (ORAN) compliant handheld devices. Full article

Recently, the community has seen a rise in interest and development regarding holographic antennas. The planar hologram is made of subwavelength metal patches printed on a grounded dielectric board, constituting flat metasurfaces. When a known reference wave is launched, the hologram produces a pencil beam towards a prescribed direction. Most earlier works on such antennas have considered only a single beam. For the few later ones that studied multiple beams, they were achieved either by having each beam taken care of by a distinct frequency or by partitioning the hologram, thereby depriving each beam of the directivity it could have had it not shared the holographic aperture with other beams. There have been recent studies related to the use of tensor surface impedance concepts for the synthesis of holograms which have attained control over the polarizations and intensities of the beams. However, this approach is complicated, tedious, and time-consuming. In this paper, we present a method for designing a planar holographic leaky-wave multi-beam metasurface antenna, of which each simultaneous beam radiating at the same frequency towards any designated direction has a tailorable amplitude, phase, and polarization, all without hologram partitioning. Most importantly, this antenna is exempted from the need for the cumbersome technique of tensor impedance. Such features of beam configurability are useful in selective multiple-target applications that require differential gain and polarization control among the various beams. Only a single source is needed, which is another benefit. In addition, effective methods to mitigate sidelobes are also proposed here. Designs by simulations according to the method are herein validated with measurements performed on fabricated prototypes. Full article

In this article, a 1 × 4 wideband, dual-polarized patch antenna array fed by a novel, differentially fed structure is proposed. The differentially fed structure of the antenna was realized by a parallel line structure that was printed on a PCB and connected with the inner and outer conductors of a coaxial cable. This method elaborately solved the problem of the narrow bandwidth of conventional microstrip differential feeding. By using a relatively thick air substrate (thickness = 0.19 λ₀), stacked patches, a coupling feeding structure, and a differential feeding structure with the novel design, the element of the patch antenna array introduced below operated from 0.415 GHz to 0.707 GHz (achieving the 52.0% bandwidth) with a VSWR < 2.0, yielding a high port isolation less than −28 dB. For the array, an active VSWR less than 2.0 was also obtained with a port isolation of less than −25 dB, ranging from 0.405 GHz to 0.696 GHz. In the desired bandwidth, the array had an azimuth 3 dB beamwidth of about 19° for both horizontal polarization and vertical polarization. The antenna array also had good performance in scanning (stable gain and 3 dB beamwidth) and circular polarization (a 3 dB axial ratio bandwidth better than 54.5%). Full article

A passive wireless high-temperature sensor for far-field applications was developed for stable temperature sensing up to 1000 °C. The goal is to leverage the properties of electroceramic materials, including adequate electrical conductivity, high-temperature resilience, and chemical stability in harsh environments. Initial sensors were fabricated using Ag for operation to 600 °C to achieve a baseline understanding of temperature sensing principles using patch antenna designs. Fabrication then followed with higher temperature sensors made from (In, Sn) O₂ (ITO) for evaluation up to 1000 °C. A patch antenna was modeled in ANSYS HFSS to operate in a high-frequency region (2.5–3.5 GHz) within a 50 × 50 mm² confined geometric area using characteristic material properties. The sensor was fabricated on Al₂O₃ using screen printing methods and then sintered at 700 °C for Ag and 1200 °C for ITO in an ambient atmosphere. Sensors were evaluated at 600 °C for Ag and 1000 °C for ITO and analyzed at set interrogating distances up to 0.75 m using ultra-wideband slot antennas to collect scattering parameters. The sensitivity (average change in resonant frequency with respect to temperature) from 50 to 1000 °C was between 22 and 62 kHz/°C which decreased as interrogating distances reached 0.75 m. Full article

In this paper, we propose a stacked dual-patch antenna with 3D printed thick quasi-air substrates and a cavity wall for wideband applications. To achieve the theoretical maximum bandwidth of the patch antenna, the quality factor of the system needs to be minimized. To achieve this, the area of the conductive radiator should be enlarged, while the permittivity of the substrate within the patch must be reduced close to 1. To realize a patch antenna with this maximum bandwidth, the stacked dual-patch configuration is employed to obtain an extended conductive radiator area. In addition, square-pipe resin frames manufactured using a 3D printing method are applied to the proposed antenna to implement a quasi-air substrate structure that has a low permittivity value close to 1. The proposed stacked dual-patch antenna with a quasi-air substrate has a broad bandwidth of 20.7%. The results demonstrate that by using the proposed antenna structure, broadband characteristics close to the fundamental bandwidth limit of the patch antenna can be achieved. Full article

This paper presents the manufacturing of a patch antenna using an advanced 3D printing technology called lights-out digital additive manufacturing (LDM). This 3D LDM printing technology is mainly used for printing circuit boards (PCBs); however, it has also been used to print a patch antenna from conductive (CI) and dielectric ink (DI). This 3D LDM-printed antenna was compared with antennas on different dielectric substrates (Arlon 25N and FR4). The obtained results are compared and analyzed in this paper. Full article

The design of the aperture-fed annular ring (AFAR) microstrip antenna is presented. This proposed design will ease the fabrication and usability of the 3D-printed and solderless 2D materials. This antenna consists of three layers: the patch, the slot within the ground plane as the power transfer medium, and the microstrip line as the feeding. The parameters of the proposed design are investigated using the finite element method FEM to achieve the 50 Ω impedance with the maximum front-to-back ratio of the radiation pattern. This study was performed based on four steps, each investigating one parameter at a time. These parameters were evaluated based on an initial design and prototype. The optimized design of 3D AFAR attained S₁₁ around 17 dB with a front-to-back ratio of more than 30 dB and a gain of around 3.3 dBi. This design eases the process of using a manufacturing process that involves 3D-printed and 2D metallic materials for antenna applications. Full article
