Recently, precast slab tracks have been used widely in railway applications, especially in conventional urban railway lines. These types of tracks are rapidly constructed and limit interruptions to train operation. However, the problems of dynamic stability when the trains run on the discontinuous type of tracks must be seriously considered. This paper focuses on analyzing the train-track interaction in two types of tracks under the dynamic load by using the numerical analysis program (APATSI) to evaluate the structural response as well as the running safety to precisely understand the load transfer efficiency of precast slab track systems. Full article

In Korea, a precast floating track with anti-vibration isolators was recently developed to reduce the vibration and noise in urban railway stations, without disrupting train operations. This precast floating slab track is a newly developed structure and differs from existing conventional slab tracks. In this study, a Finite Element Method program (MIDAS CIVIL 2019) was used to analyze the load-carrying ability of structures under the train axle loads. After finishing the design, to understand more precisely about load transfer efficiency of this type of track, an assembly test (two load cases) was conducted with three precast panels (with rail 60 K mounted on) and compared with Finite Element Analysis results. The final results satisfied the test standards in Korea, which confirms that the precast floating track has an acceptable safety factor and structural behavior. Full article

The surface crack of ballastless track slab can seriously reduce the serviceability and durability of high-speed railway (HSR). Aiming at accurately and efficiently detecting the slab cracks, this research proposes an infrared thermography (IRT)-based method for the surface crack, which is the most serious and common crack type in track slab. A three dimensional finite element (FE) model of IRT detection of concrete slab with surface cracks is established. The relation between the width of detectable cracks and the ambient temperature can be thereby obtained by inputting the measured thermodynamic parameters in the model. Parametric study shows that with ambient temperature higher than 15 °C, cracks with a width of no less than 0.2 mm can be well detected. Scale model test and field test are conducted, IRT method can effectively locate the slab surface cracks with width as small as 0.14 mm when ambient temperature is no less than 20 °C. Full article

This study focuses on evaluating the field performance of a newly developed eco-friendly precast concrete slab track structure for railway/subway systems in Seoul, South Korea. Although Ballasted railway track structures are one of the most common track structures in the railway industry, they have some drawbacks including higher maintenance cost, un-uniform supports, and a high level of noise and vibration. However, a ballastless (slab-based) track structure system requires less maintenance and uniform support conditions, as well as several ballastless structure systems developed for high-speed trains. The Seoul Metro subway in South Korea has developed a ballastless reinforced concrete (RC) slab railway system using a type of conventional concrete. This study presents a ballastless precast concrete slab using a newly developed eco-friendly concrete, which can significantly improve structural performances and the manufacturability of a railway track structure system. This study evaluates the field performance of the eco-friendly concrete slab system deployed in one of the existing tunnel sections of the Seoul Metro subway system. A total of 10 m long slab sections including a 5 m long eco-friendly “ballasted track to slab track (B2S)” panels section and a 5 m long conventional B2S panels section are installed and monitored side by side. Field tests are performed to measure the level of noise, vibration, dynamic wheel load, rail displacement, and rail stress. The field measurements from the eco-friendly B2S section are compared to those of the conventional reinforced concrete slab track systems. The results show that the performance of the new B2S system using the eco-friendly concrete is comparable and/or superior to the conventional system. Full article
