Search Results (36)

Power-Line Communication (PLC) allows data transmission through existing power lines, thus avoiding the expensive deployment of ad hoc network infrastructures. However, power line networks remain vastly unattended, which allows tampering by malicious actors. In fact, an attacker can easily inject a malicious signal (jamming) with the aim of disrupting ongoing communications. In this paper, we propose a new solution to detect jamming attacks before they significantly affect the quality of the communication link, thus allowing the detection of a jammer (geographically) far away from a receiver. We consider two scenarios as a function of the receiver’s ability to know in advance the impact of the jammer on the received signal. In the first scenario (jamming-aware), we leverage a classifier based on a Convolutional Neural Network, which has been trained on both jammed and non-jammed signals. In the second scenario (jamming-unaware), we consider a one-class classifier based on autoencoders, allowing us to address the challenge of jamming detection as a classical anomaly detection problem. Our proposed solution can detect jamming attacks on PLC networks with an accuracy greater than 99% even when the jammer is 68 m away from the receiver while requiring training only on traffic acquired during the regular operation of the target PLC network. Full article

The transformation of low-voltage distribution grids toward decentralized, user-centric models has increased the need for advanced metering infrastructures capable of ensuring both visibility and control. This paper presents a self-diagnostic advanced metering solution based on power-line communication deployed in a segment of the Spanish distribution network. The proposed infrastructure leverages the existing power network as a shared-media communication channel, reducing capital expenditures while enhancing system observability. A methodology is introduced for integrating smart metering data with topological and operational analytics to improve network monitoring and energy management. This study details the proposed metering infrastructure, highlighting its role in enhancing distribution network resilience through asynchronous energy measurements, event-driven analytics, and dynamic grid management strategies. The self-diagnostic module enables the detection of non-technical losses, identification of congested areas, and monitoring of network assets. Furthermore, this paper discusses the regulatory and technological challenges associated with scaling metering solutions, particularly in the context of increasing distributed energy resource penetration and evolving European Union regulatory frameworks. The findings demonstrate that a well-integrated advanced metering infrastructure system significantly improves distribution network efficiency, enabling proactive congestion detection and advanced load management techniques. However, this study also emphasizes the limitations of PLC in high-noise environments and proposes enhancements such as hybrid communication approaches to improve reliability and real-time performance. The insights provided contribute to the ongoing evolution of metering infrastructure technologies, offering a path toward more efficient and resource-optimized smart grids. Full article

Latin squares are an essential tool in the construction of combinatorial designs. Optimal solutions for problems such as scheduling problems and permutation arrays for powerline communication rely on the ability to construct sets of mutually orthogonal Latin squares (MOLS) that are as large as possible. Although constructions of suitable sets are known, they are scattered among a wide variety of sources, and can be both difficult to understand and contain errors. We describe our experience implementing the largest known sets of MOLS of order n, for n up to 500. We give a source for each construction, provide additional hints for the difficult cases, and correct some errors along the way. We also give constructions for new sets of MOLS of order n, where n is 486, 567, 622, 635, 754, 756, 764, 766, 774, 778, 802, 810, 822, 826, 894, 906, 916, 920 or 936. Full article

This paper presents a dual-purpose LED driver system that functions as both a lighting source and a Visible Light Communication (VLC) transmitter integrated with a Powerline Communication (PLC) network under the PRIME G3 standard. The system decodes PLC messages from the powerline grid and transmits the information via LED light to an optical receiver under a binary phase shift keying (BPSK) modulation. The load design targets a light flux of 800 lumens, suitable for LED light bulb applications up to 10 watts, ensuring practicality and energy efficiency. The Universal Asynchronous Receiver-Transmitter (UART) module enables communication between the PLC and VLC systems, allowing for an LED driver with dynamic control and real-time operation. Key signal processing stages are commented and developed, including a hybrid buck converter with modulation capabilities and a nonlinear optical receiver to regenerate the BPSK reference signal for VLC. Results show a successful prototype working under a laboratory environment. Experimental validation shows successful transmission of bit streams from the PLC grid to the VLC setup. A design guideline is presented in order to dictate the design of the electronic devices involved in the experiment. Finally, this research highlights the feasibility of integrating PLC and VLC technologies, offering an efficient and cost-effective solution for data transmission over existing infrastructure. Full article

Broadband powerline communication is a technology developed mainly with consumer applications and bulk data transmission in mind. Typical use cases include file download, streaming, or last-mile internet access for residential buildings. Applications gaining momentum are smart metering and grid automation, where response time requirements are relatively moderate compared to industrial (real-time) control. This work investigates to which extent G.hn technology, with existing, commercial off-the-shelf components, can be used for real-time control applications. Maximum packet rate and latency statistics are investigated for different G.hn profiles and MAC algorithms. An elevator control system serves as an example application to define the latency and throughput requirements. The results show that G.hn is a feasible technology candidate for industrial IoT-type applications if certain boundary conditions can be ensured. Full article

Power line communication (PLC) is a technology that exploits existing electrical transmission and distribution networks as guiding structures for electromagnetic signal propagation. This facilitates low-rate data transmission for signaling and control operations. As the demand in terms of data rate has greatly increased in the last years, the attention paid to broadband PLC (BPLC) has also greatly increased. This concept also extended to railways as broadband traction power line communication (BTPLC), aiming to offer railway operators an alternative data network in areas where other technologies are lacking. However, BTPLC implementation faces challenges due to varying operating scenarios like urban, rural, and galleries. Hence, ensuring coverage and service continuity demands the suitable characterization of the communication channel. In this regard, the scientific literature, which is an indicator of the body of knowledge related to BTPLC systems, is definitely poor if compared to that addressed to BPLC systems installed on the electrical transmission and distribution network. The relative papers dealing with BTPLC systems and focusing on the characterization of the communication channel show some theoretical approaches and, rarely, measurements guidelines and experimental results. In addition, to the best of the author’s knowledge, there are no surveys that comprehensively address these aspects. To compensate for this lack of information, a survey of the state of the art concerning BTPLC systems and the measurement methods that assist their installation, assessment, and maintenance is presented. The primary goal is to provide the interested readers with a thorough understanding of the matter and identify the current research gaps, in order to drive future research towards the most significant issues. Full article

Electrical power is essential in human life. Thus, the security and reliability of its supply are of critical importance in a country’s industrial and economic development. The leakage and improper use of electricity may cause serious problems such as fire and electrocution. To prevent such incidents and minimize the loss of life and property, a leakage current detector and warning system are developed in this study. With a high-precision current transformer and high-gain linear converter, the detector effectively detects leakage current over 1 mA, which is validated in different methods. The detector can be integrated into widely used electric meters (Taipower Datong’s sub-meter model D4S) easily, and information on detected leakage current is transmitted to the cloud server through narrowband IoT wireless communication (NB-IoT) to warn users and management personnel of the electrical power line. The proposed detector and system are expected to prevent the fire caused by leakage current which was the main cause of the fire at homes and buildings and can be an effective means to manage the electrical powerline system and metering facilities. Full article

G3-powerline communication (G3-PLC) is a robust communication protocol originally developed for smart metering in low-voltage power distribution networks. Modeling G3-PLC modems is an essential task to investigate electromagnetic compatibility (EMC) issues related to the coexistence of the PLC signal with the high-frequency noise affecting low-voltage networks, mainly due to the presence of power converters and non-linear loads. Since detailed information on the modem internal architecture is usually not available to the end-user, this work investigates the possibility of developing behavioral (black-box) models of G3-PLC modems, whose parameters can be estimated starting from measurements carried out at the modem output ports. To this end, suitable test benches are set up and used for model-parameter extraction as well as for validation purposes. Experiments have proven that an equivalent representation involving non-ideal voltage sources (i.e., in terms of extended Thevenin/Norton equivalent circuits) is no longer feasible for the transmitting modem, since the presence of a closed-loop control system invalidates the linearity assumption. Hence, while the receiving modem is still modeled through an impedance matrix (since it behaves as a linear device), an alternative representation is proposed for the transmitting modem, which resorts to the use of two ideal voltage sources in accordance with the substitution theorem. Experimental results prove that the proposed modeling strategy leads to satisfactory predictions of the currents propagating on the PLC system in the frequency interval of interest. Hence, it could be used in combination with high-frequency models of the other components in the network to investigate EMC and the coexistence of the PLC signal with the high-frequency noise generated by power converters. Full article

Researchers at many different institutions around the world study voltage and current waveform distortions in power networks using a variety of techniques. Due to the uncontrolled growing number of nonlinear devices supplied by electrical energy, more severe supraharmonic pollution has been observed. A bibliometric analysis of the topic development between 2013 and 2022 is presented in the paper. Using the selected search tools, a comparative review of articles published in the last three years was conducted. It organizes the existing knowledge about supraharmonic pollution generated by nonlinear devices and identifies current research challenges associated with the spread of these disturbances in electrical networks. The most frequently discussed topics by researchers are those that deal with the level of emissions generated by supraharmonic sources and their effects on components of the power system. The second most prominent research direction is the detection, measurement, analysis, and severity evaluation of supraharmonic pollution. Finally, the authors discuss areas of study related to the topic that offers perspectives for future research. The impact of high-frequency component pollution generated by nonlinear loads on emissions intentionally designed to carry communications signals through electrical networks needs to be explored under various power supply conditions. Full article

Within this paper, a PLC system that takes advantage of the loop resonance of an entire DC-PV string configured as a circular signal path is developed and implemented. Low cost and extremely simple transceivers intended to be installed within each PV module of a string have been designed and successfully tested. In addition, an anti-saturation coil has been conceived to avoid saturation of the core when the entire DC current of the string flows through it. Bi-directional half-duplex communication was successfully executed with up to a 1 MHz carrier frequency (150 kbps bitrate), using a simple ASK modulation scheme. The transmission and reception performance are presented, along with the overall system cost in comparison to the previous literature. Full article

Nowadays, automotive wire harnesses have become very complex systems as the number of electronic components and Electronic Control Units (ECUs) inside a vehicle have increased dramatically. To manage this complexity, and to support the automotive systems of tomorrow, new communication techniques need to be investigated. In this work, a direct modulated Power-Line Communication (PLC) method is proposed to drastically reduce the number of interconnections and give advantages in cost, complexity, and weight. Two transmitter topologies based on a Switching Capacitor approach are presented and implemented in a Test Chip fabricated in a 180 nm HV-CMOS SOI technology. The proposal is validated by communication tests connecting the designed chip and a discrete component-based demonstrator receiver through an unshielded twisted pair cable. Compared to commercially available solutions, the proposed approach can reach a data rate of 2 Mbps, making it able to implement high-speed event-driven networks, such as the Controller Area Network (CAN). Full article

Electric powerline corridors are informal green spaces that encompass large areas of land and have the potential to support biodiversity in urban and suburban landscapes. However, the extent to which these corridors provide novel habitats compared to the surrounding landscape is unclear. Biodiversity in corridors is often compared to that of “natural” habitats despite the fact that the corridors are subject to frequent vegetation management. In urban and suburban landscapes, residential yards may provide a more appropriate comparison because they are a dominant type of green space and are also characterized by frequent vegetation management. We conducted a study of the biodiversity in suburban powerline corridors in northern Illinois, USA, and compared it to the biodiversity found in nearby residential yards. Our goal was to determine whether powerline corridors added ecological value to these suburban landscapes. We included three different management styles of powerline corridors: (1) frequently mowed and kept as lawn, (2) brush mowed on a five-year cycle (“old-field”), and (3) restored and/or maintained as native prairie. We measured the species richness and composition of plants, birds, and insect pollinators in corridors and yards. The corridor management types and comparison yards differed significantly in the richness of all three taxa, with old-field and/or prairie sites having greater species richness than mown corridors and/or comparison yards. Community composition also differed by management category. While the species richness of old-field sites tended to be high, prairie sites generally had more species of conservation interest. Our study shows that both old-field- and prairie-managed powerline corridors add habitat value to Midwestern U.S. suburban landscapes by providing alternative habitat types that support many species. Nonetheless, we suggest that managers looking to specifically support native and/or grassland specialist species in this region should manage sites as prairies when possible. Full article

Digital communication over power lines is an active field of research and most studies in this field focus on low-voltage (LV) and medium-voltage (MV) power systems. Nevertheless, as power companies are starting to provide communication services and as smart-grid technologies are being incorporated into power networks, high-voltage (HV) power-line communication has become attractive. The main constraint of conventional HV power-line carrier (PLC) systems is their unfeasibility for being migrated to wideband channels, even with a high signal-to-noise ratio (SNR). In this scenario, none of the current linear/non-linear equalizers used in single carrier schemes achieve the complete compensation of the highly dispersive conditions, which limits their operation to 4 kHz channels. In this paper, a new PLC-channel model is introduced for transmission lines incorporating the effects of the coupling equipment. In addition, the use of the single-carrier frequency-division modulation (SC-FDM) is proposed as a solution to operate PLC systems in a wide bandwidth, achieving transmission speeds above those of the conventional PLC system. The results presented in this paper demonstrate the superior performance of the SC-FDM-PLC over conventional PLC systems, obtaining a higher transmission capacity in 10 to 30 times. Full article

Narrowband power-line communication seems to be a suitable communication technology designed for off-grid renewable energy solutions. Existing electrical installations can be designed both for the transmission of electricity and for the communication of electrical equipment operating inside such an installation. This study presents an implementation of the above-mentioned off-grid communication system and examines the basic problems related to its exploitation. The authors of this article focused their attention primarily on examining the disturbance of the communication channel caused by the use of typical electrical devices, such as: a light bulb, a kettle, etc. used in a household. The aim of the research was also to find the impact of switching on individual devices and their combinations on the disturbances during data transmission. Measurements of incorrectly transmitted data packets were carried out and then the test results were referred to the error measures. Moreover, the influence of the carrier frequencies on the signal attenuation and the method of eliminating the existing interferences were also discussed. Full article

Considering the intrinsic benefits of power line communications, the long-lasting lifetime of industrial systems and the growth of IoT, PLC technologies will be part of the worldwide industrial landscape for many decades. This paper discusses the history of the G3-PLC technology and current challenges and opportunities identified in real systems. Finally, it introduces recent evolutions within the G3-PLC standard, which bring additional performance and versatility, enhancing the relevance of G3-PLC as a complementary technology to other telecommunication systems in a 5G-driven telecommunication technology landscape. Full article
