Wide-beam laser direct energy deposition (LDED) has been widely used due to its superior deposition efficiency. To achieve optimal laser-powder coupling, this technique typically employs rectangular powder nozzles. This study establishes a simulation model to systematically investigate the powder flow field characteristics of rectangular symmetric nozzles. Through parametric analysis of powder feeding rate, carrier gas flow rate, and shielding gas flow rate, the effects on powder stream convergence behavior are quantitatively evaluated to maximize powder utilization efficiency. Key findings reveal that, while the powder focal plane position is predominantly determined by nozzle geometry, powder feeding parameters exhibit negligible influence on flow field intersections. The resulting powder spot demonstrates a rectangular profile slightly exceeding the laser spot dimensions, and the powder concentration exhibits a distinctive flat-top distribution along the laser’s slow axis, contrasting with a Gaussian distribution along the scanning direction. Experimental validation through powder collection tests confirms strong agreement with the simulation results. Furthermore, a mathematical model was developed to accurately describe the powder concentration distribution at the focal plane. These findings provide fundamental theoretical guidance for optimizing powder feeding systems in wide-beam LDED applications. Full article

Gas-atomized powder characteristics significantly impact additive manufacturing processes. Two innovative nozzles, semi-converging–diverging nozzle type II and fully converging–diverging nozzle type III, were designed based on the traditional cylindrical nozzle type I. Utilizing the k-ε model and Discrete Phase Model (DPM), the flow field evolution and powder characteristics of these nozzles were analyzed at gas pressures ranging from 4 to 8 MPa. The results indicate that in the gas-phase flow field both nozzle type II and nozzle type III can achieve a performance comparable to that of nozzle type I at significantly lower gas pressures. Specifically, nozzle type II operates effectively with a reduction of approximately 1 MPa compared to nozzle type I, while nozzle type III demonstrates an even greater advantage with a pressure reduction of about 2 MPa. In the gas–melt-phase flow field, nozzle type III still has the effect of reducing the pressure by approximately 2 MPa compared to nozzle type I. The melt fracture process under nozzle type III is divided into three distinct stages: the formation of large droplets, a transition area for fragmentation, and a fully fragmented region. This research effectively reduces energy losses and offers novel insights as well as recommendations for applications related to atomization technology. Full article

The bypass dual-throat nozzle is based on the dual-throat nozzle, which is a fluidic thrust vector nozzle suitable for integration into rocket motors in a symmetrical manner. As the effects of gas–solid two-phase flows are essential for solid rocket motors (SRMs), this study employs the RNG k–ε turbulence model and a particle trajectory model to numerically simulate the three-dimensional flow field inside a fixed-geometry axisymmetric bypass dual-throat nozzle to investigate its two-phase flow characteristics and thrust vectoring performance. Numerical results reveal that the smaller-diameter particles exhibit better flow-following characteristics and have a more significant impact on nozzle performance. As particle size increases, particle trajectories gradually rise within the cavity and converge toward the nozzle axis until a critical value is exceeded, after which the distribution tends to disperse. Particle deposition occurs at the bends of the bypass channel, the upstream converging section of the nozzle, and the converging section of the cavity, underscoring the need for a reinforced geometric design and thermal protection. In addition, the introduction of the particle phase into the flow reduces the thrust-vectoring angle of the nozzle and results in a loss of thrust coefficient. This research has the potential to guide the design of engines according to the incorporation of metal powder in propellants and combustion control. Full article

In the process of laser cladding, there are usually problems such as powder plugging and uneven delivery, which affect the quality of the final cladding layer. Therefore, powder convergence characteristics in laser cladding need to be further improved. Gas–solid two-phase flow technology has been widely used in the study of powder flow characteristics because it can precisely regulate the interaction between carrier air and powder flow. In this paper, we systematically review the current status of gas–solid two-phase flow in the field of laser cladding powder, deeply analyze the latest optimization progress of laser cladding nozzle design, and comprehensively explain the key progress of gas–solid two-phase flow technology in improving the uniformity and efficiency of powder field distribution. At the end of this paper, the research results are summarized and a series of prospective prospects are proposed, aiming to provide a valuable reference framework and directional guidance for the subsequent related research. Full article

This paper discusses the latest progress in research on ant nests and explores innovative scientific concepts associated with underground ant nests from the perspective of bionics. The methods used by scholars to study the structure of ant nests and the interaction between the structure itself and the individual ants are investigated. The structural characteristics of the ant nest, its internal environment and ventilation characteristics are discussed in detail. In addition, this paper presents an innovative project in which the effect of underground ant nests on soil geotechnical properties and the effect of calcined ant nest soil powder, from the perspective of civil engineering, are addressed. Practical examples of the application of the structural and inter-relational aspects of subterranean ant nests in the field of architectural bionics are also provided, from the perspectives of construction, morphology, function and material. This review attempts to integrate civil engineering, architecture and biology, enlighten architects and biologists on converging their thinking, provide new ideas regarding underground ant colony nests, and provide references for long-term human habitation. Full article

At present, the selection of optimal technological parameters for laser powder bed fusion (LPBF) is determined by the requirements of the fusion process. The main parameters that are commonly varied include laser power (P), scanning speed (v), hatch spacing (h), and layer thickness (t). The productivity of the LPBF process (the increment in the fused volume of the material) is equal to the product of the last three parameters, and the mechanical properties are largely determined by the volumetric fusion energy density, which is equal to the ratio of laser power to productivity. While ensuring maximum process productivity, it is possible to obtain acceptable quality characteristics—mechanical properties, surface roughness, etc.—for a certain range of LPBF technological parameters. In these cases, several quality characteristics act as constraints on the optimization process, and productivity and the key quality characteristics become components of the objective function. Therefore, this article proposes a formalized representation of the optimization problem for the LPBF process, including the derivation of the objective function with the constraint matrix, and provides a solution to the problem using the linear programming (LP) method. The advantages of the proposed method include the guaranteed convergence of the solution with an unlimited number of constraints; the disadvantage concerns the adequacy of the solution, which is limited by a relatively narrow range of parameter changes. The proposed method was tested in determining the optimal LPBF parameters for an HN58MBYu powder LP model that included 13 constraints and an objective function with two target parameters. The obtained results made it possible to increase the productivity by 15% relative to the basic technological parameters. Full article

In order to study the morphology characteristics of the PTFE/Al reactive shaped charge jet and the chemical reaction during the jet formation, PTFE/Al reactive liners with aluminum particle sizes of 5 μm and 100 μm were prepared. The parameters of the Johnson–Cook constitutive model of PTFE/Al reactive materials (RMs) were obtained through quasi-static compression experiments and SHPB (Split Hopkinson Pressure Bar) experiments. X-ray imaging technology was used to photograph the shape of reactive shaped charges jet at two different time points. The AUTODYN secondary development technology was used to simulate the jet formation, and the simulation results are compared with the experimental results. The results show that the simulation results are close to the experimental results, and the error is in the range of 4–8%. Through analysis, it is observed that the RMs reacted during the PTFE/Al reactive shaped charge jet formation, and due to the convergence of the inner layer of the liner during the jet formation, the chemical reaction of the jet is from inside to outside. Secondly, the particle size of aluminum powder has an influence on the chemical reaction and morphology of the jet. During the jet formation, there were fewer RMs reacted when the PTFE/Al reactive liners were prepared with 100 μm aluminum powder. Compared with 5 μm aluminum powder, when the aluminum powder is 100 μm, the morphology of the jet is more condensed, which is conducive to generating greater penetration depth. Full article

A 3D model was established to accurately simulate the internal and external powder stream characteristics of the coaxial discrete three-beam nozzle for laser metal deposition. A k-ε turbulence model was applied in the gas flow phase, and powder flow was coupled to the gas flow by a Euler-Lagrange approach as a discrete phase model. The simulated powder stream morphology was in good agreement with the experimental results of CCD and high-speed camera imaging. The simulation results showed that the length, diameter and shrinkage angle of the powder passage in the nozzle have different effects on the velocity and convergence characteristics of the powder stream. The influence of different particle size distribution and the inner laser shielding gas on the powder stream were also discussed in this study. By analyzing the powder stream caused by different incident directions of powder passage, and the collision process between powder and the inner wall, the basic principle of controlling powder stream convergence was obtained. Full article
