Search Results (21)

The thermal history of a part deposited via wire arc additive manufacturing (WAAM) and hence its as-built properties can vary significantly depending on the thermal management applied, especially for metallurgically complex materials. Thus, this work aimed to assess the feasibility of processing thin-walled Scalmalloy^® (Al-Mg-Sc-Zr) structures by WAAM while examining the effects of arc energy and heat dissipation on their response to direct age-hardening heat treatment (without solution annealing). As a complement, the geometry, porosity, and processing time of such parts were also analyzed. The walls were built via the cold metal transfer (CMT) deposition process with different arc energy levels in combination with near-immersion active cooling (NIAC) settings (as thermal management solution), as well as with natural cooling (NC), resulting overall in both low surface waviness and porosity levels. Based on hardness testing, the resultant Scalmalloy^® direct-aging response (relative increase in hardness after direct age-hardening from WAAM as-built state) depended more on the arc energy per unit length of deposit applied. In contrast, the other thermal management approaches (NIAC or NC) helped in maintaining Sc in a supersaturated solid solution during deposition. Thus, Scalmalloy^® strengthening was demonstrated as feasibly triggered by means of a post-WAAM direct age-hardening heat treatment solely. Additionally, in comparison with a thermally equivalent (same interpass temperature) condition based on NC, the NIAC technique allowed the achievement of such a positive result on direct-aging response with much shorter WAAM processing times, therefore improving productivity. Full article

This paper deals with the influence of micro-pulsed direct current on microstructure and mechanical properties of gas tungsten arc welding (GTAW) weldments of Ti-6Al-4V (Ti-64). Bead-on-plate GTA welds were made on the samples in the un-pulsed and micro-pulsed (125 Hz and 250 Hz) conditions. Post-weld heat treatment (PWHT) was performed on a few coupons at 700 °C for 3 h in an inert atmosphere, followed by furnace cooling. In the microstructure, the fusion zone (FZ), base metal (BM), and heat-affected zone (HAZ) can be easily distinguished. The top surface of the FZ has large columnar grains because of lower heat loss to the surrounding atmosphere, and the bottom region of the FZ has comparatively smaller equiaxed grains. The micro-pulsed samples’ FZ grain size was lower than that of those made without pulsing. This shows that high-frequency current has substantially refined prior β grains. The microstructure of the FZ is characterized by an acicular morphology composed of α, martensitic α′, and retained β phases. The FZ’s hardness was higher than the BM due to the presence of martensitic α′. Additionally, the hardness in the HAZ was elevated due to the formation of finer martensitic α′. Micro-pulsed DC welding led to improved mechanical properties, including higher hardness, ultimate tensile strength (UTS), and ductility compared to un-pulsed welding. This enhancement is attributed to the grain refinement achieved with micro-pulsed DC. After PWHT, the prior β grain size remained relatively unchanged compared to the as-welded condition. However, the hardness in the FZ decreased due to the decomposition of α′ into α and β phases. The ductility of all samples improved as a result of the widening of the diffusional α phase. Full article

Additive manufacturing of duplex (DSS) and super duplex stainless steel (SDSS) has been successfully demonstrated using laser powder bed fusion (LPBF) in recent years. Owing to the high cooling rates, as-built LPBF-processed DSS and SDSS exhibit close to 100% ferritic microstructures and require heat treatment at 1000–1300 °C to obtain the desired duplex microstructure. In this work, the mechanical properties of DSS and SDSS processed via LPBF were investigated in three building directions (vertical, horizontal, diagonal) and three processing conditions (as-built, stress-relieved, annealed, and quenched) using uniaxial tensile testing. As-built samples exhibited tensile and yield strength greater than 1000 MPa accompanied by less than 20% elongation at break. In comparison, the water-quenched samples and samples annealed at 1100 °C exhibited elongation at break greater than 34% with yield and tensile strength values less than 950 MPa. Stress relief annealing at 300 °C had a negligible impact on the mechanical properties. Austenite formation upon high-temperature annealing restored the reduced ductility of the as-built samples. The as-built and stress-relieved SDSS showed the highest yield and tensile strength values in the horizontal build direction, reaching up to ≈1400 and ≈1500 MPa (for SDSS), respectively, as compared to the vertical and diagonal directions. Fractographic investigation after tensile testing revealed predominantly a quasi-ductile failure mechanism, showing fine size dimple formation and cleavage facets in the as-built state and a fully ductile fracture in the annealed and quenched conditions. The findings in this study demonstrate the mechanical anisotropy of DSS and SDSS along three different build orientations, 0°, 45°, 90°, and three post-processing conditions. Full article

Copper-based materials have long been used for their outstanding thermal and electrical conductivities in various applications, such as heat exchangers, induction heat coils, cooling channels, radiators, and electronic connectors. The development of advanced copper alloys has broadened their utilization to include structural applications in harsh service conditions found in industries like oil and gas, marine, power plants, and water treatment, where good corrosion resistance and a combination of high strength, wear, and fatigue tolerance are critical. These advanced multi-component structures often have complex designs and intricate geometries, requiring extensive metallurgical processing routes and the joining of the individual components into a final structure. Additive manufacturing (AM) has revolutionized the way complex structures are designed and manufactured. It has reduced the processing steps, assemblies, and tooling while also eliminating the need for joining processes. However, the high thermal conductivity of copper and its high reflectivity to near-infrared radiation present challenges in the production of copper alloys using fusion-based AM processes, especially with Yb-fiber laser-based techniques. To overcome these difficulties, various solutions have been proposed, such as the use of high-power, low-wavelength laser sources, preheating the build chamber, employing low thermal conductivity building platforms, and adding alloying elements or composite particles to the feedstock material. This article systematically reviews different aspects of AM processing of common industrial copper alloys and composites, including copper-chrome, copper-nickel, tin-bronze, nickel-aluminum bronze, copper-carbon composites, copper-ceramic composites, and copper-metal composites. It focuses on the state-of-the-art AM techniques employed for processing different copper-based materials and the associated technological and metallurgical challenges, optimized processing variables, the impact of post-printing heat treatments, the resulting microstructural features, physical properties, mechanical performance, and corrosion response of the AM-fabricated parts. Where applicable, a comprehensive comparison of the results with those of their conventionally fabricated counterparts is provided. Full article

Additive manufacturing of Duplex Stainless Steels (DSS) and Super Duplex Stainless Steels (SDSS) has been successfully demonstrated using LPBF in recent years, however, both alloys feature an almost fully ferritic microstructure in the as-built condition due to the fast cooling rates associated with the Laser Powder Bed Fusion (LPBF) process. Blends of DSS and SDSS powders were formulated with austenitic stainless-steel 316L powder, aiming to achieve increased austenite formation during in the LPBF as-built condition to potentially minimize the post heat treatments (solution annealing and quenching). Powder characteristics were investigated and process parameters were optimized to produce near fully dense parts. Nanoindentation (NI) tests were conducted to measure, not only the local mechanical properties and correlate them with the as-built microstructure, but also to gain a deeper understanding in the deformation behavior of individual phases that cannot be studied directly by macroscopic tensile tests. Scanning Electron Microscopy (SEM) and Electron Backscatter Diffraction (EBSD) were employed for microstructural analysis and phase quantification. The microstructural analysis and EBSD phase maps revealed an increase in austenite in the as-built microstructures. Blend 1 resulted in a duplex microstructure consisting of 10% austenite at the XY plane and 20% austenite at the XZ plane. The austenite content increased with increasing proportion of 316L stainless steel in the powder blends. The DSS blend required a much higher volumetric energy density for the fabrication of near fully dense parts. This imposed a slower solidification and a higher melt pool homogeneity, allowing for adequate diffusion of the austenite stabilizing elements. The presented workflow and findings from this study provide valuable insights into powder mixing for the development of custom alloys for rapid material screening in LPBF. Full article

Inconel 718 is a nickel-based superalloy with excellent creep properties and good tensile and fatigue strength. In the field of additive manufacturing, it is a versatile and widely used alloy due to its good processability in the powder bed fusion with laser beam (PBF-LB) process. The microstructure and mechanical properties of the alloy produced by PBF-LB have already been studied in detail. However, there are fewer studies on the creep resistance of additively manufactured Inconel 718, especially when the focus is on the build direction dependence and post-treatment by hot isostatic pressing (HIP). Creep resistance is a crucial mechanical property for high-temperature applications. In this study, the creep behavior of additively manufactured Inconel 718 was investigated in different build orientations and after two different heat treatments. The two heat treatment conditions are, first, solution annealing at 980 °C followed by aging and, second, HIP with rapid cooling followed by aging. The creep tests were performed at 760 °C and at four different stress levels between 130 MPa and 250 MPa. A slight influence of the build direction on the creep properties was detected, but a more significant influence was shown for the different heat treatments. The specimens after HIP heat treatment show much better creep resistance than the specimens subjected to solution annealing at 980 °C with subsequent aging. Full article

Laser-aided additive manufacturing is used for complex shapes and Ni-based superalloy parts. This study aimed to optimize the additive manufacturing process of Hastelloy X alloy to obtain its excellent mechanical properties without pores or cracks in the additively manufactured parts. The additively manufactured Hastelloy X was analyzed by comparing porosity, microstructure, and mechanical properties in as-built and post-heat treatment conditions. In addition, the pores existing inside the as-built specimen considerably decreased after the hot isostatic press (HIP) treatment. Furthermore, cell/columnar microstructures were observed owing to a fast cooling rate in the as-built condition. However, after heat treatment, dendrite structures disappeared, and recrystallized equiaxed grains were observed. The tensile test results showed that there was mechanical anisotropy along the vertical and horizontal directions, and as the microstructure changed to equiaxed grains after heat treatment, the mechanical anisotropy decreased, and the high-temperature properties improved. Full article

Ti-4Al-5Mo-5V-5Cr-1Nb (wt.%) is a new type of high-strength (~1300 MPa) titanium (Ti) alloy developed for aerospace applications. Until now, the research on its welding and subsequent heat treatment is barren. Herein, we employed electron beam welding (EBW) to a solutionized Ti-4Al-5Mo-5V-5Cr-1Nb with a phase constituent of α + β and investigated its microstructure and mechanical properties in both as-welded (AW) and post-weld aging treated (PWAT) conditions. Results showed that due to the thermal input of the welding process, the α phase in the original microstructure of base material (BM) transformed into the β phase in the fusion zone (FZ). Similar microstructural evolution was observed for the heat-affected zone (HAZ) near the FZ (Near-HAZ), whereas the HAZ far away from FZ (Far-HAZ) contained a small amount of round α phase (ghost α) due to its slower cooling rate. Such a microstructural change resulted in poor tensile strength (~780 Mpa) for the as-welded joint. After PWAT, a large number of acicular α precipitated in the FZ and HAZ and its size (S) in different zones followed the order of S_Far-HAZ < S_FZ ≈ S_Near-HAZ < S_BM. The presence of α_s precipitates remedied the tensile strength of the weld joint almost to the same as that of the BM. The present findings established the foundation of the application of this high-strength Ti alloy. Full article

Although post-heat treatment can improve the fatigue life of selective laser melting (SLM)-fabricated cobalt chromium molybdenum (CoCrMo) alloys, the effect of cooling conditions on the fatigue properties of such alloys remains unclear. In this study, we fabricated SLM CoCrMo alloy specimens and, after heat-treating them, cooled them either via furnace-cooling (FC) or air-cooling (AC). Subsequently, we analyzed their microstructures using scanning electron microscopy combined with energy-dispersive X-ray spectroscopy, electron backscattered diffraction, confocal laser scanning microscopy, and X-ray diffraction. Tensile and Vickers hardness (HV) tests and axial-fatigue tests were also conducted to assess their mechanical and fatigue properties, respectively. The microstructures of all samples showed homogeneous equiaxed grains, with the grains and precipitates of the AC samples (grain size: 84.9 μm) smaller than those of the FC samples (grain size: 109.7 μm). The AC samples exhibited better ductility than the FC samples. However, we observed no significant differences in the 0.2% yield strength and HV tests. The S–N curve derived from the fatigue tests showed that the AC samples had greater fatigue life than the FC samples. Therefore, a high cooling rate during post-heat treatment is effective in reducing grain and precipitate sizes, resulting in improved ductility and fatigue life. Full article

High-strength steel is widely used in hot forging products for application to the oil and gas industry because it has good mechanical properties under severe environment. In order to apply to the extreme environment industry requiring high temperature and high pressure, heat treatments such as austenitizing, quenching and tempering are required. The microstructure of high-strength steel after heat treatment has various microstructures such as Granular Bainite (GB), Acicular Ferrite (AF), Bainitic Ferrite (BF), and Martensite (M) depending on the heat treatment conditions and cooling rate. Especially in large forged products, the difference in microstructure occurs due to the difference in the forging ratio depending on the location and the temperature gradient according to the thickness during post-heat treatment. Therefore, this study attempted to quantitatively analyze various phases of F70 high-strength steel according to the austenitizing temperature and hot forging ratio using the existing EBSD analysis method. In addition, the correlation between microstructure and mechanical properties was investigated through various phase analysis and fracture behavior of high-strength steel. We found that various microstructures of strength steel depend on the austenitizing temperature and hot forging ratio, and influence the mechanical properties and fracture behavior. Full article

In the present work, the effects of electrolytic hydrogen charging of T92 steel weldments on their room-temperature tensile properties were investigated. Two circumferential weldments between the T92 grade tubes were produced by gas tungsten arc welding using the matching Thermanit MTS 616 filler material. The produced weldments were individually subjected to considerably differing post-welding heat treatment (PWHT) procedures. The first-produced weldment was conventionally tempered (i.e., short-term annealed below the Ac₁ critical transformation temperature of the T92 steel), whereas the second one was subjected to its full renormalization (i.e., appropriate reaustenitization well above the T92 steel Ac₃ critical transformation temperature and subsequent air cooling), followed by its conventional subcritical tempering. From both weldments, cylindrical tensile specimens of cross-weld configuration were machined. The room-temperature tensile tests were performed for the individual welds’ PWHT states in both hydrogen-free and electrolytically hydrogen-charged conditions. The results indicated higher hydrogen embrittlement susceptibility for the renormalized-and-tempered weldments, compared to the conventionally tempered ones. The obtained findings were correlated with performed microstructural and fractographic observations. Full article

The aim of this research was to investigate the effect of different heat treatment conditions of AA2519 friction stir welded joints on their microstructure and residual stresses. The following welding parameters have been used: 500 rpm tool rotation speed, 150 mm/min tool traverse speed, tool tilt angle 2°, pressure force 17 kN. The welded material was investigated in three different configurations: HT0, HT1, and HT2. The first type of weld (HT-0) was made using AA2519 alloy in non-precipitation hardened state and examined in such condition. The second type of weld (HT-1) has been performed on AA2519-T62, that corresponds to precipitation hardening condition. The last type of weld (HT2) was performed on annealed AA2519 and the obtained welds were subjected to the post-weld precipitation hardening process. The heat treatment was carried out in two stages: solution heat treatment (530 °C/2 h + cooling in cold water) and aging (165 °C/1 0 h). Residual stresses were measured using X-Ray diffraction patterns obtained from Bruker D8 Discover X-ray diffractometer utilizing the concepts of Euler cradle and polycapillary primary beam optics. The conducted research indicates that the best material properties: homogenous microstructure and uniform distribution of microhardness and compressive state of residual stresses were obtained for the HT-2 series samples subjected to heat treatment after the friction stir welding (FSW) process. Full article

Laser powder-bed fusion (LPBF) has significantly gained in importance and has become one of the major fabrication techniques within metal additive manufacturing. The fast cooling rates achieved in LPBF due to a relatively small melt pool on a much larger component or substrate, acting as heat sink, result in fine-grained microstructures and high oversaturation of alloying elements in the α-aluminum. Al–Si–Mg alloys thus can be effectively precipitation hardened. Moreover, the solidified material undergoes an intrinsic heat treatment, whilst the layers above are irradiated and the elevated temperature in the built chamber starts the clustering process of alloying elements directly after a scan track is fabricated. These silicon–magnesium clusters were observed with atom probe tomography in as-built samples. Similar beneficial clustering behavior at higher temperatures is known from the direct-aging approach in cast samples, whereby the artificial aging is performed immediately after solution annealing and quenching. Transferring this approach to LPBF samples as a possible post-heat treatment revealed that even after direct aging, the outstanding hardness of the as-built condition could, at best, be met, but for most instances it was significantly lower. Our investigations showed that LPBF Al–Si–Mg exhibited a high dependency on the quenching rate, which is significantly more pronounced than in cast reference samples, requiring two to three times higher quenching rate after solution annealing to yield similar hardness results. This suggests that due to the finer microstructure and the shorter diffusion path in Al–Si–Mg fabricated by LPBF, it is more challenging to achieve a metastable oversaturation necessary for precipitation hardening. This may be especially problematic in larger components. Full article

Modern weldable high strength steel grades are typically based on low-carbon alloy concepts using microalloying for obtaining a good strength-toughness balance. Such steel grades having a yield strength in the range of 420 to 690 MPa are very commonly used in pipelines, heavy vehicles, shipbuilding and general structural applications. Thermomechanical processing during hot rolling combined with accelerated cooling is an established means of producing such steel grades. Considering the alloying concepts, the use of niobium and molybdenum, and in selected cases boron, is very efficient to achieve high strength and good toughness. However, all targeted applications of such high strength steels involve extensive welding. Thus, heat affected zone properties are of particular importance. The present paper investigates the effects of Nb, Mo and Ti on the heat affected zone properties. Variations of the Mn and Si contents are considered as well. Additionally, the influence of post-weld heat treatment in the coarse-grained heat-affected zone (HAZ) is considered. In this approach, HAZ subzones were generated using laboratory weld cycle simulations in combination with systematic variation of alloying elements to scrutinize and interpret their specific effects. The results indicate that Mo and Nb, when alloyed in the typical range, provide excellent HAZ toughness and guarantee sufficiently low ductile-to-brittle transition temperature. An alloy combination of Nb, Mo and Ti improves performance under hot deformation conditions and toughness after post-weld heat treatment. Full article

Laser Engineered Net Shaping (LENS^TM) is currently a promising and developing technique. It allows for shortening the time between the design stage and the manufacturing process. LENS is an alternative to classic metal manufacturing methods, such as casting and plastic working. Moreover, it enables the production of finished spatial structures using different types of metallic powders as starting materials. Using this technology, thin-walled honeycomb structures with four different cell sizes were obtained. The technological parameters of the manufacturing process were selected experimentally, and the initial powder was a spherical Ti6Al4V powder with a particle size of 45–105 µm. The dimensions of the specimens were approximately 40 × 40 × 10 mm, and the wall thickness was approximately 0.7 mm. The geometrical quality and the surface roughness of the manufactured structures were investigated. Due to the high cooling rates occurring during the LENS process, the microstructure for this alloy consists only of the martensitic α’ phase. In order to increase the mechanical parameters, it was necessary to apply post processing heat treatment leading to the creation of a two-phase α + β structure. The main aim of this investigation was to study the energy absorption of additively manufactured regular cellular structures with a honeycomb topology under static and dynamic loading conditions. Full article
