Search Results (8)

This paper presents a novel analytical approach for the efficient design of a particular class of 2D FIR filters, having a frequency response with an elliptically shaped support in the frequency plane. The filter design is based on a Gaussian shaped prototype filter, which is frequently used in signal and image processing. In order to express the Gaussian prototype frequency response as a trigonometric polynomial, we developed it into a Fourier series up to a specified order, given by the imposed approximation precision. We determined analytically a 1D to 2D frequency transformation, which was applied to the factored frequency response of the prototype, yielding directly the factored frequency response of a directional, elliptically shaped 2D filter, with specified selectivity and an orientation angle. The designed filters have accurate shapes and negligible distortions. We also designed a 2D uniform filter bank of elliptical filters, which was then applied in decomposing a test image into sub-band images, thus proving its usefulness as an analysis filter bank. Then, the original image was accurately reconstructed from its sub-band images. Very selective directional elliptical filters can be used in efficiently extracting straight lines with specified orientations from images, as shown in simulation examples. A computationally efficient implementation at the system level was also discussed, based on a polyphase and block filtering approach. The proposed implementation is illustrated for a smaller size of the filter kernel and input image and is shown to have reduced computational complexity due to its parallel structure, being much more arithmetically efficient compared not only to the direct filtering approach but also with the most recent similar implementations. Full article

This paper presents a design approach for a class of rotationally invariant 2D filters of finite impulse response (FIR) type, which may form circular filter banks with imposed specifications. The design is conducted analytically in the frequency domain and starts from a maximally flat low-pass prototype based on a trapezoidal function with specified width and slope. Its trigonometric approximation is derived using the Fourier series expressed analytically, truncated to a number of terms depending on the imposed accuracy. The chosen trapezoidal function leads to significantly smaller ringing oscillations compared to the approximation of an ideal square characteristic. By shifting the LP prototype to various frequencies, the desired filter bank is generated, where the component filters have a specified bandwidth, steepness, and overlap. The 2D circular filter bank results by applying a specific frequency mapping to the factored frequency response of the prototype filter. Thus, the frequency responses of the 2D filter bank components will also result in factored form, which is an advantage in implementation. The circular filter bank is designed in two versions, a uniform and a non-uniform (dyadic) filter bank. The designed filter banks have accurate shapes and relatively low order for the specified parameters. These filter banks are then used in a sub-band image decomposition application. Finally, an efficient implementation of these filters at the system level is proposed based on polyphase decomposition and the block filtering technique with a high degree of parallelism, resulting in a lower computational complexity. Full article

This paper proposes an analytical design procedure for 2D FIR circular filter banks and also a novel, computationally efficient implementation of the designed filter bank based on a polyphase structure and a block filtering approach. The component filters of the bank are designed in the frequency domain using a specific frequency transformation applied to a low-pass, band-pass and high-pass 1D prototype with a specified Gaussian shape and imposed specifications (peak frequency, bandwidth). The 1D prototype filter frequency response is derived in a closed form as a trigonometric polynomial with a specified order using Fourier series, and then it is factored. Since the design starts from a 1D prototype with a factored transfer function, the frequency response of the designed 2D filter bank components also results directly in a factored form. The designed filters have an accurate shape, with negligible distortions at a relatively low order. We present the design of two types of circular filter banks: uniform and non-uniform (dyadic). An example of image analysis with the uniform filter bank is also provided, showing that the original image can be accurately reconstructed from the sub-band images. The proposed implementation is presented for a simpler case, namely for a smaller size of the filter kernel and of the input image. Using the polyphase and block filtering approach, a convenient implementation at the system level is obtained for the designed 2D FIR filter, with a relatively low computational complexity. Full article

Considering the problem that the timing synchronization calculation in high-speed remote sensing signal reception is complex and it is difficult for it to be parallel, this paper deduces and designs a parallel timing error estimation and correction scheme. This paper presents the design of polyphase DFT filter banks with non-maximum decimation. The feedforward timing error estimation and correction method is then improved to enhance synchronization performance. Finally, an implementation scheme for parallel timing error estimation and correction is proposed using the polyphase filter bank time domain decomposition method and the filter polyphase model. In the estimation module, the parallel implementation structure of the joint second-order and fourth-order cyclic statistics methods is designed, which improves the estimation accuracy. In the correction module, a fractional delay filtering method with higher accuracy is adopted in order to improve the calibration accuracy and reduce the computational complexity. The timing synchronization of a high-speed remote sensing signal with timing error is simulated and verified. The experimental results show that the parallel method proposed in this paper greatly reduces the processing speed of subband data, and has a good synchronization performance, which is close to the theoretical limit in the demodulation error rate. This paper utilizes a multi-phase DFT filter bank architecture to achieve parallel timing synchronization, which presents a novel approach for the future parallel reception of high-speed remote sensing signals. Full article

Spectral lines can be analysed to determine the physical properties of molecular clouds and the astrochemical processes in the formation area of massive stars. To improve the observation technology of radio astronomy, this paper proposes and compares two spectral analysis algorithms (improved weighted overlap-add (IWOLA) + FFT and IWOLA + weighted overlap-add (WOLA)). The proposed algorithms can obtain an ultra-high-frequency resolution for real-valued wideband signals, eliminate the signal overlapping interference between adjacent channels, substantially decrease the required hardware resources, especially multipliers, adders, and memory resources, and reduce the system design complexity. The IWOLA + FFT algorithm consists of an improved weighted overlap-add (IWOLA) filter bank, fast Fourier transform (FFT), a specific decimation for the output data from the IWOLA filter bank, and a selection for part of the output data from the FFT. The IWOLA + WOLA algorithm consists of the same modules as the IWOLA + FFT algorithm, with the second-stage FFT replaced by the modules of the weighted overlap-add (WOLA) filter bank and the accumulation for each sub-band. Based on an analysis of the underlying principles and characteristics of both algorithms, the IWOLA + FFT algorithm demonstrated a spectrum with a high frequency resolution and a comparable performance to an ultra-large-scale FFT, based on two smaller FFTs and a flexible architecture instead of a ultra-large-scale FFT. The IWOLA + WOLA algorithm contains the same function as the IWOLA + FFT algorithm and demonstrates a higher performance. The proposed algorithms eliminated the interference between the adjacent channels within the entire Nyquist frequency bandwidth. The simulation results verify the accuracy and spectral analysis performances of the proposed algorithms. Full article

This paper proposes a novel technique to improve a spectral statistical filter for speech enhancement, to be applied in wearable hearing devices such as hearing aids. The proposed method is implemented considering a 32-channel uniform polyphase discrete Fourier transform filter bank, for which the overall algorithm processing delay is 8 ms in accordance with the hearing device requirements. The proposed speech enhancement technique, which exploits the concepts of both non-negative sparse coding (NNSC) and spectral statistical filtering, provides an online unified framework to overcome the problem of residual noise in spectral statistical filters under noisy environments. First, the spectral gain attenuator of the statistical Wiener filter is obtained using the a priori signal-to-noise ratio (SNR) estimated through a decision-directed approach. Next, the spectrum estimated using the Wiener spectral gain attenuator is decomposed by applying the NNSC technique to the target speech and residual noise components. These components are used to develop an NNSC-based Wiener spectral gain attenuator to achieve enhanced speech. The performance of the proposed NNSC–Wiener filter was evaluated through a perceptual evaluation of the speech quality scores under various noise conditions with SNRs ranging from -5 to 20 dB. The results indicated that the proposed NNSC–Wiener filter can outperform the conventional Wiener filter and NNSC-based speech enhancement methods at all SNRs. Full article

This paper proposes a technique for improving statistical-model-based voice activity detection (VAD) in noisy environments to be applied in an auditory hearing aid. The proposed method is implemented for a uniform polyphase discrete Fourier transform filter bank satisfying an auditory device time latency of 8 ms. The proposed VAD technique provides an online unified framework to overcome the frequent false rejection of the statistical-model-based likelihood-ratio test (LRT) in noisy environments. The method is based on the observation that the sparseness of speech and background noise cause high false-rejection error rates in statistical LRT-based VAD—the false rejection rate increases as the sparseness increases. We demonstrate that the false-rejection error rate can be reduced by incorporating likelihood-ratio order statistics into a conventional LRT VAD. We confirm experimentally that the proposed method relatively reduces the average detection error rate by 15.8% compared to a conventional VAD with only minimal change in the false acceptance probability for three different noise conditions whose signal-to-noise ratio ranges from 0 to 20 dB. Full article

In order to ease the conflict between the bandwidth demand of high-rate wireless communication and the shortage of spectrum resources, a wideband spectrum sensing method based on reconfigurable filter bank (RFB) with adjustable resolution is presented. The wideband signals are uniformly divided into multi-narrowband signals by RFB, which is designed by polyphase uniform Discrete Fourier Transform (DFT) modulation, and each sub-band is sensed by energy detection. According to the idle proportion of detected sub-bands, the number of RFB sub-bands is reset in next spectrum-sensing time. By simulating with collected wideband dataset, the influence of filter bank sub-bands number and idle state proportion on the sensing results is analyzed, and then on the basis of the trade-off between spectrum-sensing resolution and computational complexity, the optimal sub-bands number of filter bank is selected, so as to improve the detection performance and save resources. Full article
