This study explores the use of Multi-Objective Genetic Algorithm (MOGA) for thermodynamic characteristics of serrated plate-fin heat exchanger (PFHE) under numerical simulation method. Numerical investigations on the important structural parameters of the serrated fin and the j factor and the f factor of PFHE are conducted, and the experimental correlations about the j factor and the f factor are determined by comparing the simulation results with the experimental data. Meanwhile, based on the principle of minimum entropy generation, the thermodynamic analysis of the heat exchanger is investigated, and the optimization calculation is carried out by MOGA. The comparison results between optimized structure and original show that the j factor increases by 3.7%, the f factor decreases by 7.8%, and the entropy generation number decreases by 31%. From the data point of view, the optimized structure has the most obvious effect on the entropy generation number, which shows that the entropy generation number can be more sensitive to the irreversible changes caused by the structural parameters, and at the same time, the j factor is appropriately increased. Full article

The acquirement of the flow information in plate-fin heat exchanger (PFHE) is limited by its metal structure and complex flow condition. This work develops a new distributed optical measurement system to obtain flow information and boiling intensity. The system utilizes numerous optical fibers installed at the surface of the PFHE to detect optical signals. The attenuation and fluctuation of the signals reflect the variation of the gas-liquid interfaces and can be further used to estimate the boiling intensity. Practical experiments of flow boiling in PFHE with different heating fluxes have been carried out. The results verify that the measurement system can obtain the flow condition. Meanwhile, according to the results, the boiling development in PFHE can be divided into four stages with the increase in the heating flux, including the unboiling stage, initiation stage, boiling developing stage, and fully developed stage. Full article

Heat exchangers are usually designed using a sophisticated process of trial-and-error to find proper values of unknown parameters which satisfy given requirements. Recently, the design of heat exchangers using evolutionary optimization algorithms has received attention. The major aim of the present study is to propose an improved Gaussian quantum-behaved particle swarm optimization (GQPSO) algorithm for enhanced optimization performance and its verification through application to a multivariable thermal-economic optimization problem of a crossflow plate–fin heat exchanger (PFHE). Three single objective functions: the number of entropy generation units (NEGUs), total annual cost (TAC), and heat exchanger surface area (A), were minimized separately by evaluating optimal values of seven unknown variables using four different PSO-based methods. By comparing the obtained best fitness values, the improved GQPSO approach could search quickly for better global optimal solutions by preventing particles from falling to the local minimum due to its modified local attractor scheme based on the Gaussian distributed random numbers. For example, the proposed GQPSO could predict further improved best fitness values of 40% for NEGUs, 17% for TAC, and 4.5% for A, respectively. Consequently, the present study suggests that the improved GQPSO approach with the modified local attractor scheme can be efficient in rapidly finding more suitable solutions for optimizing the thermal-economic problem of the crossflow PFHE. Full article

This paper presents an investigation on the optimum design for a plate-fin heat exchanger (PFHE) of a gas and supercritical carbon dioxide combined cycle which uses thermal oil as intermediate heat-transfer fluid. This may promote the heat transfer from low heat-flux exhaust to a high heat-flux supercritical carbon dioxide stream. The number of fin layers, plate width and geometrical parameters of fins on both sides of PFHE are selected as variables to be optimized by a non-dominated sorting genetic algorithm-II (NSGA-II), which is a multi-objective genetic algorithm. For the confliction of heat transfer area and pressure drop on the exhaust side, which are the objective indexes, the result of NSGA-II is a Pareto frontier. The technique for order of preference by similarity to ideal solution (TOPSIS) approach is applied to choose the optimum solution from the Pareto frontier. Finally, further simulation is performed to analyze the effect of each parameter to objective indexes and confirm the rationality of optimization results. Full article

This study aims to provide an experimental investigation and comparison of the condensation heat transfer characteristics in a plate–fin heat exchanger (PFHE). The heat flux, mass flux, and saturation pressure were adjusted as experimental parameters to verify the effects on the condensation heat transfer. In addition, condensation heat transfer correlation of two-stream PFHEs was provided based on the experimental data for utilization as a design reference for the heat exchanger. The turbulence is the most influential in heat transfer. One of the ways to foster turbulence is to increase shear stress. The higher flow velocity results in the higher shear stress. That was why increasing mass flux or the flow with higher vapor quality showed the higher heat transfer coefficient (HTC). Refrigerant properties such as viscosity and specific volume of vapor changed according to the saturation pressure. It is expected they affect the degree of turbulence too in similar manners. The mass flux was more influential than the heat flux and saturation pressure. Thus, the equivalent mass flux of the refrigerant is dominant in the derived correlation model. The average difference between experimental and calculated HTC from correlations was about 6.5%. Multi-stream PFHE comprises an additional heat transfer surface, which implies a more active droplet formation. The average pressure drop in the multi-stream is 15% larger than that of the two-stream. Full article

A plate fin heat exchanger (PFHE) is a critical part of the cryogenic industry. A plate fin heat exchanger has many applications, but it is commonly used in the liquefied natural gas (LNG) industry for the gasification/liquefaction process. During this gasification to the liquefaction process, there is a large temperature gradient. Due to this large temperature gradient, stresses are produced that directly influence the braze joint of PFHE. Significant work has been carried out on heat transfer and the flow enhancement of PFHE; however, little attention has been paid to structural stability and stresses produced in these brazed joints. Due to these stresses, leakages in PFHE are observed, mostly in braze joints. In the current study, standard fin design is analyzed. In addition, the structural stability of brazed joints under standard conditions is also tested. Two techniques are used here to analyze fins, using the finite element method (FEM), first by examining the whole fin brazed joint on the basis of experimentally calculated yield strength and second by dividing the braze seam into three sections and defining individual strength for each section of the seam to find stress magnitude on the basis of heat-affected zones. Moreover, by using two different techniques to analyze brazed joints, the stresses in the lower face of the brazed joint were increased by 13% and decreased by 18% in the upper face using different zone techniques as compared to standard full braze seam analysis. It can be concluded that different zone techniques are better in predicting stresses as compared to simple full braze seam analysis using the finite element method since stresses along the lower face are more critical. Full article
