The joining zone includes three main parts, which comprise an isothermal solidification zone (ISZ), the athermal solidification zone (ASZ), and a diffusion affected zone (DAZ). Field emission scanning electron microscopy (FESEM) was used here to observe the microstructure equipped with ultra-thin window energy dispersive X-ray spectrometer (EDS) system. Additionally, electrochemical impedance spectroscopy (EIS) and cyclic potentiodynamic polarization tests were conducted to evaluate the effect of the DB process on the corrosion resistance of the Inconel 625 superalloy. In the bonding time period, some Mo- and Cr-rich boride precipitations and Ni-rich γ-solid solution phases with hardened alloy elements, such as Mo and Cr, formed in DAZ and ASZ, respectively, because of the inter-diffusion of melting point depressants (MPD). Moreover, during cooling cycles, Ni-Cr-B, Ni-Mo-B, Ni-Si-B, and Ni-Si phase compounds were formed in the ASZ area at 1110–850 °C. The DAZ area developed by borides compound with cubic, needle, and grain boundary morphologies. The corrosion tests indicated that the DB process led to a reduction in the passive region and increased the sensitivity to pitting corrosion. Full article

This paper presents a real-time remote water level monitoring system based on dense wavelength division multiplexing (DWDM)-passive optical fiber sensor (OFS) network for the application of the Internet of Things (IoT). This network employs a broadband light source based on amplified spontaneous emission (ASE) as a seed light. This ASE light is spectrum-sliced by an athermal type arrayed waveguide grating (200 GHz × 16 channel), then distributed towards multiple sensing units (SU). Here, 16 SUs are installed vertically at the specified height in the water pool according to the design specification (i.e., spatial resolution). Then, each SU reflects an optical spectrum having a different reflection coefficient depending on the surrounding medium (e.g., air or water). By measuring these reflected optical spectra with an optical spectrum analyzer, the water level can be easily recognized in real time. However, as the sensing distance increases, system performance is severely degraded due to the Rayleigh Back-Scattering of the ASE light. As a result, the remote sensing capability is limited at a short distance (i.e., <10 km). To overcome this limitation, we propose a simple signal processing technique based on feature extraction of received optical spectra, which includes embedding a peak detection algorithm with a signal validation check. For the specific, the proposed signal processing performs the peak power detection, signal quality monitoring, and determination/display of the actual water level through three function modules, i.e., data save/load module, signal processing module, and Human–Machine Interface display module. In particular, the signal quality of the remote sensing network can be easily monitored through several factors, such as the number of spectral peaks, the wavelength spacing between neighboring peaks and the pattern of detected peak power. Moreover, by using this validation check algorithm, it is also possible to diagnose various error types (such as peak detection error, loss of data and so on) according to the pattern of measured optical spectra. As a result, the IoT sensor network can recognize 17 different level statuses for the water level measurement from a distance of about 25 km away without active devices such as optical amplifiers (i.e., passive remote sensing). Full article

The remote sensing imaging requirements of aerial cameras require their optical system to have wide temperature adaptability. Based on the optical passive athermal technology, the expression of thermal power offset of a single lens in the catadioptric optical system is first derived, and then a mathematical model for efficient optimization of materials is established; finally, the mechanical material combination (mirror and housing material) is optimized according to the comprehensive weight of offset with temperature change and the position change of the equivalent single lens, and achieve optimization of the lens material on an athermal map. In order to verify the effectiveness of the method, an example of a catadioptric aerial optical system with a focal length of 350 mm is designed. The results show that in the temperature range of −40 °C to 60 °C, the diffraction-limited MTF of the designed optical system is 0.59 (at 68 lp/mm), the MTF of each field of view is greater than 0.39, and the thermal defocus is less than 0.004 mm, which is within one time of the focal depth, indicating that the imaging quality of the optical system basically does not change with temperature, meeting the stringent application requirements of the aerial camera. Full article

The use of airborne-mapping technology plays a key role in the acquisition of large-scale basic geographic data information, especially in various important civil/military-mapping missions. However, most airborne-mapping cameras are limited by parameters, such as the flight altitude, working-environment temperature, and so on. To solve this problem, in this paper, we designed a panchromatic wide-spectrum optical system with a focusing function. Based on the catadioptric optical structure, the optical system approached a telecentric optical structure. Sharp images at different object distances could be acquired by micro-moving the focusing lens. At the same time, an optical passive compensation method was adopted to realize an athermalization design in the range of −40–60 °C. According to the design parameters of the optical system, we analyzed the influence of system focusing on mapping accuracy during the focusing process of the airborne-mapping camera. In the laboratory, the camera calibration and imaging experiments were performed at different focusing positions. The results show that the experimental data are consistent with the analysis results. Due to the limited experiment conditions, only a single flight experiment was performed. The results show that the airborne-mapping camera can achieve 1:5000 scale-imaging accuracy. Flight experiments for different flight altitudes are being planned, and the relevant experimental data will be released in the future. In conclusion, the airborne-mapping camera is expected to be applied in various high-precision scale-mapping fields. Full article

Temperature variation not only results in changes in refractive index, radius, thickness, and air space, but also leads to surface deformation due to the mismatch in thermal expansion coefficients between glass and mechanical materials. However, existing passive athermal optical design methods cannot optimize thermal-induced surface deformation, and optimization methods usually focus on structural optimization or thermal control rather than optical optimization. Here, we investigate the deterioration in image quality caused by thermal-induced surface deformation and propose a passive athermal optical design method to reduce deterioration. To this end, MATLAB was utilized to jointly call finite element analysis (FEA) software (COMSOL) and optical design software (Code V) to realize the data exchange of an optical–mechanical–thermal integrated analysis for iterative optical optimization. This process makes automatic iterative optimization possible by transforming parametric FEA results into Zernike coefficients in each iteration of optimization. The theoretical and design examples indicate that our method can effectively reduce the degradation in image quality with surface deformation. Our method provides an optical optimization approach for optical designers to work on a passive athermal optical design by considering thermal-induced surface deformation. Full article

High-quality cameras are fundamental sensors in assisted and autonomous driving. In particular, long-range forward-facing cameras can provide vital information about the road ahead, including detection and recognition of objects and early hazard warning. These automotive cameras should provide high-resolution images consistently under extreme operating conditions of the car for robust operation. This paper aims to introduce the design of fixed-focus, passively athermalized lenses for next-generation automotive cameras. After introducing an overview of essential and desirable features of automotive cameras and state-of-the-art, based on these features, two different camera designs that can achieve traffic sign recognition at 200 m distance are presented. These lenses are designed from scratch, with a unique design approach that starts with a graphical lens material selection tool and arrives at an optimized design with optical design software. Optical system analyses are performed to evaluate the lens designs. The lenses are shown to accomplish high contrast from $-40$ °C to 100 °C and allow for a $4\times$ increase in resolution of automotive cameras. Full article

The instability of the principal distance of the nighttime light remote-sensing camera of the Luojia 1-01 satellite directly affects the geometric accuracy of images, consequently affecting the results of analysis of nighttime light remote-sensing data. Based on the theory of optical passive athermal design, a mathematical model of optical-passive athermal design for principal distance stabilization is established. Positive and negative lenses of different materials and the mechanical structures of different materials are matched to optimize the optical system. According to the index requirements of the Luojia 1-01 camera, an image-telecentric optical system was designed under the guidance of the established mathematical model. In the temperature range of −20 °C to +60 °C, the principal distance of the system changes from −0.01 μm to +0.28 μm. After on-orbit testing, the geometric accuracy of the designed nighttime light remote-sensing camera is better than 0.20 pixels and less than index requirement of 0.3 pixels, which indicating that the principal distance maintains good stability on-orbit and meets the application requirements of nighttime light remote sensing. Full article
