The recent advancements in low-dimensional material-based photodetectors have provided valuable insights into the fundamental properties of these materials, the design of their device architectures, and the strategic engineering approaches that have facilitated their remarkable progress. This review work consolidates and provides a comprehensive review of the recent progress in group-10 two-dimensional (2D) palladium diselenide (PdSe₂)-based photodetectors. This work first offers a general overview of the various types of PdSe₂ photodetectors, including their operating mechanisms and key performance metrics. A detailed examination is then conducted on the physical properties of 2D PdSe₂ material and how these metrics, such as structural characteristics, optical anisotropy, carrier mobility, and bandgap, influence photodetector device performance and potential avenues for enhancement. Furthermore, the study delves into the current methods for synthesizing PdSe₂ material and constructing the corresponding photodetector devices. The documented device performances and application prospects are thoroughly discussed. Finally, this review speculates on the existing trends and future research opportunities in the field of 2D PdSe₂ photodetectors. Potential directions for continued advancement of these optoelectronic devices are proposed and forecasted. Full article

Tungsten diselenide (${\mathrm{WSe}}_2$) has emerged as a promising ambipolar semiconductor material for field-effect transistors (FETs) due to its unique electronic properties, including a sizeable band gap, high carrier mobility, and remarkable on–off ratio. However, engineering the contacts to ${\mathrm{WSe}}_2$ remains an issue, and high contact barriers prevent the utilization of the full performance in electronic applications. Furthermore, it could be possible to tune the contacts to ${\mathrm{WSe}}_2$ for effective electron or hole injection and consequently pin the threshold voltage to either conduction or valence band. This would be the way to achieve complementary metal–oxide–semiconductor devices without doping of the channel material.This study investigates the behaviour of two-dimensional ${\mathrm{WSe}}_2$ field-effect transistors with multi-layer palladium diselenide (${\mathrm{PdSe}}_2$) as a contact material. We demonstrate that ${\mathrm{PdSe}}_2$ contacts favour hole injection while preserving the ambipolar nature of the channel material. This consequently yields high-performance p-type ${\mathrm{WSe}}_2$ devices with ${\mathrm{PdSe}}_2$ van der Waals contacts. Further, we explore the tunability of the contact interface by selective laser alteration of the ${\mathrm{WSe}}_2$ under the contacts, enabling pinning of the threshold voltage to the valence band of ${\mathrm{WSe}}_2$, yielding pure p-type operation of the devices. Full article

One-dimensional (1D) novel pentagonal materials have gained significant attention as a new class of materials with unique properties that could influence future technologies. In this report, we studied the structural, electronic, and transport properties of 1D pentagonal PdSe₂ nanotubes (p-PdSe₂ NTs). The stability and electronic properties of p-PdSe₂ NTs with different tube sizes and under uniaxial strain were investigated using density functional theory (DFT). The studied structures showed an indirect-to-direct bandgap transition with slight variation in the bandgap as the tube diameter increased. Specifically, (5 × 5) p-PdSe₂ NT, (6 × 6) p-PdSe₂ NT, (7 × 7) p-PdSe₂ NT, and (8 × 8) p-PdSe₂ NT are indirect bandgap semiconductors, while (9 × 9) p-PdSe₂ NT exhibits a direct bandgap. In addition, under low uniaxial strain, the surveyed structures were stable and maintained the pentagonal ring structure. The structures were fragmented under tensile strain of 24%, and compression of −18% for sample (5 × 5) and −20% for sample (9 × 9). The electronic band structure and bandgap were strongly affected by uniaxial strain. The evolution of the bandgap vs. the strain was linear. The bandgap of p-PdSe₂ NT experienced an indirect–direct–indirect or a direct–indirect–direct transition when axial strain was applied. A deformability effect in the current modulation was observed when the bias voltage ranged from about 1.4 to 2.0 V or from −1.2 to −2.0 V. Calculation of the field effect I–V characteristic showed that the on/off ratio was large with bias potentials from 1.5 to 2.0 V. This ratio increased when the inside of the nanotube contained a dielectric. The results of this investigation provide a better understanding of p-PdSe₂ NTs, and open up potential applications in next-generation electronic devices and electromechanical sensors. Full article

In this study, we investigate the electrical transport properties of back-gated field-effect transistors in which the channel is realized with two-dimensional transition metal dichalcogenide nanosheets, namely palladium diselenide (PdSe₂) and molybdenum disulfide (MoS₂). The effects of the environment (pressure, gas type, electron beam irradiation) on the electrical properties are the subject of an intense experimental study that evidences how PdSe₂-based devices can be reversibly tuned from a predominantly n-type conduction (under high vacuum) to a p-type conduction (at atmospheric pressure) by simply modifying the pressure. Similarly, we report that, in MoS₂-based devices, the transport properties are affected by pressure and gas type. In particular, the observed hysteresis in the transfer characteristics is explained in terms of gas absorption on the MoS₂ surface due to the presence of a large number of defects. Moreover, we demonstrate the monotonic (increasing) dependence of the width of the hysteresis on decreasing the gas adsorption energy. We also report the effects of electron beam irradiation on the transport properties of two-dimensional field-effect transistors, showing that low fluences of the order of few e^-/nm² are sufficient to cause appreciable modifications to the transport characteristics. Finally, we profit from our experimental setup, realized inside a scanning electron microscope and equipped with piezo-driven nanoprobes, to perform a field emission characterization of PdSe₂ and MoS₂ nanosheets at cathode–anode separation distances as small as 200 nm. Full article
