Search Results (51)

In optical frequency domain reflectometry (OFDR), the random optical noise in Rayleigh backscattering and the sliding window length in the algorithm cause a trade-off between sensing spatial resolution and accuracy. This paper proposes a novel high-spatial-resolution high-accuracy OFDR distributed sensor based on a seamless femtosecond weak fiber Bragg grating (WFBG) array. Using femtosecond laser point-by-point (PbP) inscription technology, a 5 cm long seamless weak grating array was successfully fabricated on a polyimide fiber, consisting of ten 5 mm long WFBGs. The experimental results demonstrate that a sensing spatial resolution of 533 μm and a wavelength demodulation accuracy of ±2.05 pm were achieved for the first time. Full article

Distributed Acoustic Sensing (DAS) has emerged as a groundbreaking technology in seismology, transforming fiber-optic cables into dense, cost-effective seismic monitoring arrays. DAS makes use of Rayleigh backscattering to detect and measure dynamic strain and vibrations over extended distances. It can operate using both pre-existing telecommunication networks and specially designed fibers. This review explores the principles of DAS, including Coherent Optical Time Domain Reflectometry (COTDR) and Phase-Sensitive OTDR (ϕ-OTDR), and discusses the role of optoelectronic interrogators in data acquisition. It examines recent advancements in fiber design, such as helically wound and engineered fibers, which improve DAS sensitivity, spatial resolution, and the signal-to-noise ratio (SNR). Additionally, innovations in deployment techniques include cemented borehole cables, flexible liners, and weighted surface coupling to further enhance mechanical coupling and data accuracy. This review also demonstrated the applications of DAS across earthquake detection, microseismic monitoring, reservoir characterization and monitoring, carbon storage sites, geothermal reservoirs, marine environments, and urban infrastructure surveillance. The study highlighted several challenges of DAS, including directional sensitivity limitations, vast data volumes, and calibration inconsistencies. It also addressed solutions to these problems, such as advances in signal processing, noise suppression techniques, and machine learning integration, which have improved real-time analysis and data interpretability, enabling DAS to compete with traditional seismic networks. Additionally, modeling approaches such as full waveform inversion and forward simulations provide valuable insights into subsurface dynamics and fracture monitoring. This review highlights DAS’s potential to revolutionize seismic monitoring through its scalability, cost-efficiency, and adaptability to diverse applications while identifying future research directions to address its limitations and expand its capabilities. Full article

Interest in adhesively bonded joints has significantly increased due to their numerous advantages over other joining techniques. However, they are frequently used in structures subjected to fatigue loading, which might cause defects such as cracks within the bondline. Thus, timely detection, localization, and size estimation of such defects are crucial for ensuring structural safety. This study focused on experimentally investigating crack length estimation in adhesively bonded joints under mode II fatigue loading. To analyze the crack growth, a comprehensive comparison was conducted between various techniques, such as visual testing, digital image correlation, optical backscatter reflectometry, and the analytical compliance-based beam method. In interrupted fatigue tests (static acquisition), digital image correlation and optical backscatter reflectometry exhibited consistent damage sensitivity, estimating larger crack lengths compared to visual testing by approximately 3 mm and 5 mm, respectively. The optical backscatter reflectometry in uninterrupted tests (dynamic acquisition) showed significantly larger estimations, approximately double those of static ones. This demonstrated its potential to detect possible damage within the adhesive that might not be detected by other methods, as shown previously for quasi-static loading conditions. Its capability in early damage detection under the dynamic regime makes it a valuable tool for continuous monitoring. Furthermore, a comparison of optical backscatter reflectometry’s performance in quasi-static, static, and dynamic acquisitions indicated a potentially larger process zone under quasi-static loading, a finding confirmed by the compliance-based beam method. Full article

In this paper, a method for detection of crack locations and the width of basin insulators is proposed. Based on the optical frequency domain reflectometry (OFDR) system, the system utilizes an FBG with high feedback for strain as well as temperature, which is affixed to the surface of the tub insulator, and a common single-mode optical fiber, which is used for transmitting data and connected to the optical backscattering reflectometry interrogator. The interrogator measures the backscattered light from the FBG, which varies with temperature or strain. The method has been used to measure the location and width of several different cracks and can locate the crack position with a spatial resolution of 1 mm and measure the crack width with a resolution of 0.77 mm. The method has been used to measure the position and width of insulators. This method provides a simple and fast approach to crack detection in insulators. Full article

In this paper, we propose and demonstrate a network analysis optical frequency domain reflectometer (NA-OFDR) for distributed temperature measurements at high spatial (down to ≈3 cm) and temperature resolution. The system makes use of a frequency-stepped, continuous-wave (cw) laser whose output light is modulated using a vector network analyzer. The latter is also used to demodulate the amplitude of the beat signal formed by coherently mixing the Rayleigh backscattered light with a local oscillator. The system is capable of attaining high measurand resolution (≈50 mK at 3-cm spatial resolution) thanks to the high sensitivity of coherent Rayleigh scattering to temperature. Furthermore, unlike the conventional optical-frequency domain reflectometry (OFDR), the proposed system does not rely on the use of a tunable laser and therefore is less prone to limitations related to the laser coherence or sweep nonlinearity. Two configurations are analyzed, both numerically and experimentally, based on either a double-sideband or single-sideband modulated probe light. The results confirm the validity of the proposed approach. Full article

The Jones matrix and the Mueller matrix of the coherent Rayleigh backscattering (RB) in single-mode fibers (SMFs) have been derived recently. It has been shown that both matrices depict two polarization effects—birefringence and polarization-dependent loss (PDL)—although the SMF under investigation is purely birefringent, having no PDL. In this paper, we aim to perform a theoretical analysis of both matrices using polar decomposition. The derived sub-Jones/Mueller matrices, representing birefringence and PDL, respectively, can be used to investigate the polarization properties of the coherent RB. As an application of the theoretical results, we use the derived formulas to investigate the polarization properties of the optical signals in phase-sensitive optical time-domain reflectometry (φ-OTDR). For the first time, to our knowledge, by using the derived birefringence–Jones matrix, the common optical phase of the optical signal in φ-OTDR is obtained as the function of the forward phase and birefringence distributions. By using the derived PDL–Mueller matrix, the optical intensity of the optical signal in φ-OTDR is obtained as the function of the forward phase and birefringence distributions as well as the input state of polarization (SOP). Further theoretical predictions show that, in φ-OTDR, the common optical phase depends on only the local birefringence in the first half of the fiber section, which is occupied by the sensing pulse, irrelevant of the input SOP. However, the intensity of the φ-OTDR signal is not a local parameter, which depends on the input SOP and the birefringence distribution along the entire fiber section before the optical pulse. Moreover, the PDL measured in φ-OTDR is theoretically proven to be a local parameter, which is determined by the local birefringence and local optical phase distributions. Full article

The properties of the state of polarization (SOP) and the degree of polarization (DOP) of Rayleigh backscattered light (RBL) in single-mode fibers (SMF) are investigated theoretically and experimentally when the incident probe is a perfectly coherent continuous-wave (CW) light. It is concluded that the instantaneous DOP of the coherently superposed RBL is always 100%, and the instantaneous SOP is determined by the distributions of the birefringence and the optical phase along the SMF. Therefore, the instantaneous SOP of the coherently superposed RBL does not have a constant relationship with the SOP of the incident CW probe. Furthermore, the instantaneous SOP varies randomly with time because the optical phase is very sensitive to ambient temperature and vibration even in the lab environment. Further theoretical derivation and experimental verification demonstrate, for the first time, that the temporally averaged SOP of the coherently superposed RBL has a simple constant relationship with the SOP of the incident CW probe, and the temporally averaged DOP is 1/3 in an SMF with low and randomly distributed birefringence. The derived formulas and obtained findings can be used to enhance the modelling and improve the performances of phase-sensitive optical time-domain reflectometry and other Rayleigh backscattering based fiber-optic sensors. Full article

We have shown the opportunity to use the unique inhomogeneities of the internal structure of an optical fiber waveguide for remote authentication of users or an optic fiber line. Optical time domain reflectometry (OTDR) is demonstrated to be applicable to observing unclonable backscattered signal patterns at distances of tens of kilometers. The physical nature of the detected patterns was explained, and their characteristic spatial periods were investigated. The patterns are due to the refractive index fluctuations of a standard telecommunication fiber. We have experimentally verified that the patterns are an example of a physically unclonable function (PUF). The uniqueness and reproducibility of the patterns have been demonstrated and an outline of authentication protocol has been proposed. Full article

Determination of the poloidal magnetic field distribution in tokamaks is of prime importance for the successful operation of tokamaks. In this paper, we propose a polarization-sensitive reflectometry-based optical fiber sensor for measuring the spatial distribution of the poloidal magnetic field in tokamaks. The measurement method exploits the Rayleigh backscattering and Faraday magneto-optic effect in optical fibers. The former is an intrinsic property of optical fibers and enables distributed polarization measurements, while the latter arises in the presence of a magnetic field parallel to the optical fiber axis and rotates the polarization state of the light. When an optical fiber is looped around a toroidal section of the vacuum vessel, the local polarization rotation of the light is proportional to the local poloidal magnetic field in the tokamak. The proposed method is discussed theoretically and experimentally using the results from JET. The obtained magnetic field measurement shows a good agreement with that of the internal discrete coils. A potential solution to recover the magnetic field data from the noise-affected region of the optical measurement is proposed and is demonstrated through simulations using the JET magnetic field configuration. Full article

An innovative optical frequency-domain reflectometry (OFDR)-based distributed temperature sensing method is proposed that utilizes a Rayleigh backscattering enhanced fiber (RBEF) as the sensing medium. The RBEF features randomly high backscattering points; the analysis of the fiber position shift of these points before and after the temperature change along the fiber is achieved using the sliding cross-correlation method. The fiber position and temperature variation can be accurately demodulated by calibrating the mathematical relationship between the high backscattering point position along the RBEF and the temperature variation. Experimental results reveal a linear relationship between temperature variation and the total position displacement of high backscattering points. The temperature sensing sensitivity coefficient is 7.814 μm/(m·°C), with an average relative error temperature measurement of −1.12% and positioning error as low as 0.02 m for the temperature-influenced fiber segment. In the proposed demodulation method, the spatial resolution of temperature sensing is determined by the distribution of high backscattering points. The temperature sensing resolution depends on the spatial resolution of the OFDR system and the length of the temperature-influenced fiber. With an OFDR system spatial resolution of 12.5 μm, the temperature sensing resolution reaches 0.418 °C per meter of RBEF under test. Full article

We introduce a technique to generate and read the digital signature of the networks, channels, and optical devices that possess the fiber-optic pigtails to enhance physical layer security (PLS). Attributing a signature to the networks or devices eases the identification and authentication of networks and systems thus reducing their vulnerability to physical and digital attacks. The signatures are generated using an optical physical unclonable function (OPUF). Considering that OPUFs are established as the most potent anti-counterfeiting tool, the created signatures are robust against malicious attacks such as tampering and cyber attacks. We investigate Rayleigh backscattering signal (RBS) as a strong OPUF to generate reliable signatures. Contrary to other OPUFs that must be fabricated, the RBS-based OPUF is an inherent feature of fibers and can be easily obtained using optical frequency domain reflectometry (OFDR). We evaluate the security of the generated signatures in terms of their robustness against prediction and cloning. We demonstrate the robustness of signatures against digital and physical attacks confirming the unpredictability and unclonability features of the generated signatures. We explore signature cyber security by considering the random structure of the produced signatures. To demonstrate signature reproducibility through repeated measurements, we simulate the signature of a system by adding a random Gaussian white noise to the signal. This model is proposed to address services including security, authentication, identification, and monitoring. Full article

Ultra-weak fiber Bragg grating (UWFBG) array-based phase-sensitive optical time-domain reflectometry (Φ-OTDR) utilizes the interference interaction between the reference light and the reflected light from the broadband gratings for sensing. It significantly improves the performance of the distributed acoustic sensing system (DAS) because the intensity of the reflected signal is much higher than that of the Rayleigh backscattering. This paper shows that Rayleigh backscattering (RBS) has become one of the primary noise sources in the UWFBG array-based Φ-OTDR system. We reveal the impact of the Rayleigh backscattering signal on the intensity of the reflective signal and the precision of the demodulated signal, and we suggest reducing the pulse duration to improve the demodulation accuracy. Experimental results demonstrate that using light with a 100 ns pulse duration can improve the measurement precision by three times compared with the use of a 300 ns pulse duration. Full article

Phase-sensitive optical time-domain reflectometry (φOTDR) is a technology for distributed vibration sensing, where vibration amplitudes are determined by recovering the phase of the backscattered light. Measurement noise induces phase errors, which degrades sensing performance. The phase errors, using a differentiation and cross-multiplication (DCM) algorithm, are investigated theoretically and experimentally in a φOTDR system based on a phase retrieval configuration consisting of an imbalanced Mach–Zehnder interferometer (IMZI) and a 3 × 3 coupler. Analysis shows that phase error is highly dependent on the AC component of the obtained signal, essentially being inversely proportional to the product of the power of the light backscattered from two locations. An analytical expression was derived to estimate the phase error and was confirmed by experiment. When applied to the same measurement data, the error is found to be slightly smaller than that obtained using in-phase/quadrature (I/Q) demodulation. The error, however, increases for longer measurement times. Full article

The inverse finite element method (iFEM) is a model-based technique to compute the displacement (and then the strain) field of a structure from strain measurements and a geometrical discretization of the same. Different literature works exploit the error between the numerically reconstructed strains and the experimental measurements to perform damage identification in a structural health monitoring framework. However, only damage detection and localization are performed, without attempting a proper damage size estimation. The latter could be based on machine learning techniques; however, an a priori definition of the damage conditions would be required. To overcome these limitations, the present work proposes a new approach in which the damage is systematically introduced in the iFEM model to minimize its discrepancy with respect to the physical structure. This is performed with a maximum likelihood estimation framework, where the most accurate damage scenario is selected among a series of different models. The proposed approach was experimentally verified on an aluminum plate subjected to fatigue crack propagation, which enables the creation of a digital twin of the structure itself. The strain field fed to the iFEM routine was experimentally measured with an optical backscatter reflectometry fiber and the methodology was validated with independent observations of lasers and the digital image correlation. Full article

We report non-contact laser-based Brillouin light-scattering (BLS) spectroscopy measurements of the viscoelastic properties of hyperthermally radiofrequency (RF)-heated and ablated bovine liver and chicken flesh tissues with embedded gold nanoparticles (AuNPs). The spatial lateral profile of the local surface temperature in the flesh samples during their hyperthermia was measured through optical backscattering reflectometry (OBR) using Mg–silica-NP-doped sensing fibers distributed with an RF applicator and correlated with viscoelastic variations in heat-affected and ablated tissues. Substantial changes in the tissue stiffness after heating and ablation were directly related to their heat-induced structural modifications. The main proteins responsible for muscle elasticity were denatured and irreversibly aggregated during the RF ablation. At T > 100 °C, the proteins constituting the flesh further shrank and became disorganized, leading to substantial plastic deformation of biotissues. Their uniform destruction with larger thermal lesions and a more viscoelastic network was attained via AuNP-mediated RF hyperthermal ablation. The results demonstrated here pave the way for simultaneous real-time hybrid optical sensing of viscoelasticity and local temperature in biotissues during their denaturation and gelation during hyperthermia for future applications that involve mechanical- and thermal-property-controlled theranostics. Full article
