Search Results (9)

This paper thoroughly explores the feasibility of integrating a variety of intelligent electrical equipment and smart maintenance technologies within nuclear power plants to enhance the currently limited level of intelligence of these systems and better support operational and maintenance tasks. Initially, this paper outlines the demands and challenges of intelligent electrical systems in nuclear power plants, highlighting the current state of development of intelligent electrical systems, including new applications of artificial intelligence and big data technologies in power grid companies, such as intelligent defect recognition through image recognition, intelligence-assisted inspections, and intelligent production commands. This paper then provides a detailed introduction to the architecture of intelligent electrical equipment, encompassing the smart electrical equipment layer, the smart control system layer, and the cloud platform layer. It discusses the intelligentization of medium- and low-voltage electrical equipment, such as smart circuit breakers, smart switchgear, and low-voltage distribution systems, emphasizing the importance of intelligentization in improving the safety, reliability, and maintenance efficiency of medium- and low-voltage distribution equipment in nuclear power plants. Furthermore, this paper addresses issues in the intelligentization of nuclear power plant electrical systems, such as information silos, the inefficiency of traditional manual inspection processes, and the lack of comprehensive intelligent design and evaluation standards, proposing corresponding solutions. Additionally, this paper presents the trends in intelligent operation and maintenance technology and applications, including primary and secondary fusion technology, intelligent patrol system architecture, intelligent inspection based on non-destructive testing, and a comprehensive solution based on inspection robots. The application of these technologies aids in achieving automated inspection, real-time monitoring, and the intelligent diagnosis of electrical equipment in nuclear power plants. Finally, this paper proposes basic principles for the development of intelligent electrical systems in nuclear power plants, including intelligent architecture, the evolutionary path, and phased goals and key technologies. It emphasizes the gradual transition from automation to digitization and then to intelligentization and presents a specific implementation plan for the intelligentization of the electrical systems in nuclear power plants. This paper concludes with a summary of short-term and long-term goals for improving the performance of nuclear power plant electrical systems through intelligent technologies and prospects for the application of intelligent technologies in the operation and maintenance of nuclear power plants in the future. Full article

Currently, over 100 nuclear power units globally have been in operation for more than 40 years. Hindered by the limitations of computer technology at the time, these nuclear facilities lack detailed electronic drawings. Activities such as equipment replacement and process circuit system modifications during operation result in discrepancies between paper drawings and actual conditions. Given the complexity and irreversibility of nuclear facility decommissioning activities, virtual simulation technology is often employed before the decommissioning process begins to assist in designing and validating decommissioning plans. Consequently, the creation of high-precision 3D models is crucial for subsequent decommissioning designs. Through innovatively utilizing laser-scanning 3D model reconstruction technology in the reconstruction of the model of China’s first heavy water research reactor undergoing decommissioning, this paper provides an overview of the process of laser-scanning 3D model reconstruction and its application in reconstructing the heavy water research reactor model. Using a 3D laser scanner, four decommissioning areas of the heavy water research reactor, including the reactor building, secondary water pump room, ventilation center, and low-level radioactive wastewater storage tank area, were subjected to 3D laser scanning. The acquired point cloud data from 572 scanning stations were processed using point cloud processing software for denoising, stitching, and triangulation. The triangulated model was then imported into modeling software for 3D reconstruction, ultimately establishing a digitalized model of the heavy water research reactor suitable for subsequent decommissioning simulation and design. Full article

The cold-end system of a nuclear power plant is a key complex node connecting the power generation system with the variable environmental conditions, and its operation, economy, and stability have become the main obstacles to further improving the performance of the first and second circuits. The current research on the interactions between the cold-end system and the thermal cycle of nuclear power mainly adopts the micropower model, while the existing condenser model does not take into account the influence of the turbine exhaust resistance and exhaust flow and other factors on the condenser vacuum change caused by the change in the circulating water flow rate and temperature in determining the optimal vacuum. This ignores the interactions between the equipment and the interconnections between the parameters, which results in the reduction of the model’s accuracy. This paper takes a nuclear power unit as an example, adopts the “constant flow calculation” method to calculate the heat balance of the two-loop thermal system of the nuclear power plant, and constructs an integrated simulation model of the reaction environment variables, the cold-end system, and the thermal cycle. Taking the circulating water temperature and flow rate as variables, the errors of the separate condenser model and the coupled model in circulating water parameter changes were obtained under the condition of satisfying the thermal system operation, and the circulating water temperature and flow rate change ranges applied by the separate condenser model were analyzed in order to reduce the amount of calculations when the unit power error was 1%. The results show that the circulating water temperature is 4 °C, the applicable range of the circulating water flow rate is 42 m³/s to the rated flow rate, the applicable range of the circulating water temperature is 20 °C, the applicable range of the circulating water flow rate is 32.12 m³/s to the rated flow rate, the applicable range of the circulating water temperature is 26 °C, the applicable range of the circulating water flow rate is 38.63 m³/s to the rated flow rate, the applicable range of the circulating water temperature is 30 °C, and the applicable range of the circulating water flow rate is 45 m³/s to the rated flow rate. At a circulating water temperature of 26 °C, the applicable range of the circulating water flow is between 38.63 m³/s and the rated flow; at a circulating water temperature of 30 °C, the applicable range of the circulating water flow is between 45.64 m³/s and the rated flow. Full article

This study quantitatively analysed the influence of cooling water parameters on the performance of a modular high-temperature gas-cooled reactor (MHTGR) nuclear power plant (NPP). The secondary circuit system and cold-end system were modelled using EBSILON software, version 16.0. The influence of cooling water inlet temperature and mass flow rate on the thermal performance of the secondary circuit system was analysed over the full power range with the goal of optimising net power. Under 100% rated condition, for each 1 °C increase in cooling water inlet temperature between 10 and 33 °C, the net power and cycle efficiency decreased by 0.67 MW and 0.14%, respectively, whereas the heat consumption rate increased by 28.72 kJ/(kW·h). The optimal cooling water mass flow rates corresponding to cooling water inlet temperatures of 16 °C and 33 °C were obtained. The optimal cooling water mass flow rate decreased nonlinearly with decreasing power levels. At a cooling water inlet temperature of 33 °C, an increase in cooling water mass flow rate from the designed value (7697.61 kg/s) to the optimal value (10,922.14 kg/s) resulted in a 1.03 MW increase in net power. These findings provide guidelines for MHTGR NPP operation optimisation and economic improvement, especially under high-temperature weather conditions. Full article

Natural circulation loops are thermohydraulic circuits used to transport heat from a source to a sink in the absence of a pump, using the forces induced by the thermal expansion of a working fluid to circulate it. Natural circulation loops have a wide range of engineering applications such as in nuclear power plants, solar systems, and geothermic and electronic cooling. The Lattice Boltzmann Method was applied to the simulation of this thermohydraulic system. This numerical method has several interesting features for engineering applications, such as parallelization capabilities or direct temporal convergence. A 2D model of a single-phase natural circulation mini-loop with a small inner diameter was implemented and tested under different operation conditions following a double distribution function approach (coupling a lattice for the fluid and a secondary lattice for the thermal field). An analytical relationship between the Reynolds number and the modified Grashof number was used to validate the numerical model. Two regimes were found for the circulation, a laminar regime for low Reynolds numbers and a non-laminar regime characterized by a traveling vortex near the heater and cooler’s walls. Both regimes did not present flux inversion and are considered stable. The recirculation of the fluid can explain some of the heat transfer characteristics in each regime. Changing the Prandtl number to a higher value affects the transient response, increasing the temperature and velocity oscillations before reaching the steady state. Full article

The reactor coolant pump (RCP) is the only rotating equipment in the primary circuit system of a nuclear power plant and the “heart” of the nuclear reactor. The L formula is defined, and the L/h_imp is introduced to study the influence of impeller blade type on the performance of the RCP. Twenty groups of models are designed, the concept of arc height ratio is proposed from the perspective of h_imp and L, and the distribution of internal entropy production within the impeller of the RCP under different Ls and h_imps of the impeller blade type is analyzed. The results show that when himp remains un-changed and L increases, the low-pressure area at the inlet of the impeller expands while the high-pressure area at the outlet decreases under the design flow or large flow conditions. The smoother blade profile reduces the occurrence of secondary flow phenomena and makes the RCP pressure distribution more uniform. Under design flow and large flow conditions, smaller L/h_imp and higher h_imp lead to higher efficiency and head performance. However, higher efficiency and lower head performance can be achieved under small flow conditions with larger L/h_imp and lower h_imp. Full article

A nuclear power plant is a complex coupling system, which features multi-physics coupling between reactor physics and thermal-hydraulics in the reactor core, as well as the multi-circuit coupling between the primary circuit and the secondary circuit by the shared steam generator (SG). Especially in the pebble-bed modular HTR nuclear power plant, different nuclear steam supply modules are further coupled together through the shared main steam pipes and the related equipment in the secondary circuit, since the special configuration of multiple reactor modules connects to a steam turbine. The JFNK (Jacobian-Free Newton–Krylov) method provides a promising coupling framework to solve the whole HTR nuclear power plant problem, due to its excellent convergence rate and strong robustness. In this work, the JFNK method was modified and applied to the steady-state calculation of the HTR secondary circuit, which plays an important role in simultaneous solutions for the whole HTR nuclear power plant. The main components in the secondary circuit included SG, steam turbine, condenser, feed pump, high/low-pressure heat exchanger, deaerator, as well as the extraction steam from the steam turbine. The results showed that the JFNK method can effectively solve the steady state issue of the HTR secondary circuit. Moreover, the JFNK method could converge well within a wide range of initial values, indicating its strong robustness. Full article

This study presents an industrial fault diagnosis system based on the cubic dynamic uncertain causality graph (cubic DUCG) used to model and diagnose industrial systems without sufficient data for model training. The system is developed based on cloud native technology. It contains two main parts, the diagnostic knowledge base and the inference method. The knowledge base was built by domain experts modularly based on professional knowledge. It represented the causality between events in the target industrial system in a visual and graphical form. During the inference, the cubic DUCG algorithm could dynamically generate the cubic causal graph according to the real-time data and perform the logic and probability calculations based on the generated cubic DUCG models, visually displaying the dynamic causal evolution of faults. To verify the system’s feasibility, we rebuild a fault-diagnosis model of the secondary circuit system of No. 1 at the Ningde nuclear power plant based on the new system. Twenty-four fault cases were used to test the diagnostic accuracy of the system, and all faults were correctly diagnosed. The results showed that it was feasible to use the cubic DUCG platform for fault diagnosis. Full article

The article first summarizes case studies on the three basic types of treated water used in power plants and heating stations. Its main focus is Czechia as the representative of Eastern European countries. Water as the working medium in the power industry presents the three most common cycles—the first is make-up water for boilers, the second is cooling water and the third is represented by a specific type of water (e.g., liquid waste mixtures, primary and secondary circuits in nuclear power plants, turbine condensate, etc.). The water treatment technologies can be summarized into four main groups—(1) filtration (coagulation) and dosing chemicals, (2) ion exchange technology, (3) membrane processes and (4) a combination of the last two. The article shows the ideal industry-proven technology for each water cycle. Case studies revealed the economic, technical and environmental advantages/disadvantages of each technology. The percentage of technologies operated in energetics in Eastern Europe is briefly described. Although the work is conceived as an overview of water treatment in real operation, its novelty lies in a technological model of the treatment of turbine condensate, recycling of the cooling tower blowdown plus other liquid waste mixtures, and the rejection of colloidal substances from the secondary circuit in nuclear power plants. This is followed by an evaluation of the potential novel technologies and novel materials. Full article
