Search Results (38)

Continuous monitoring of respiratory patterns is essential for disease diagnosis and daily health care. Contact medical devices enable reliable respiratory monitoring, but can cause discomfort and are limited in some settings. Radar offers a noncontact respiration measurement method for continuous, real-time, high-precision monitoring. However, it is difficult for a single radar to characterize the coordination of chest and abdominal movements during measured breathing. Moreover, motion interference during prolonged measurements can seriously affect accuracy. This study proposes a dual radar system with customized narrow-beam antennas and signals to measure the chest and abdomen separately, and an adaptive dynamic time warping (DTW) algorithm is used to effectively suppress motion interference. The system is capable of reconstructing respiratory waveforms of the chest and abdomen, and robustly extracting various respiratory parameters via motion interference. Experiments on 35 healthy subjects, 2 patients with chronic obstructive pulmonary disease (COPD), and 1 patient with heart failure showed a high correlation between radar and respiratory belt signals, with correlation coefficients of 0.92 for both the chest and abdomen, a root mean square error of 0.80 bpm for the respiratory rate, and a mean absolute error of 3.4° for the thoracoabdominal phase angle. This system provides a noncontact method for prolonged respiratory monitoring, measurement of chest and abdominal asynchrony and apnea detection, showing promise for applications in respiratory disorder detection and home monitoring. Full article

The respiration rate (RR) is an important vital sign for early detection of health deterioration in critically unwell patients. Its current measurement has limitations, relying on visual counting of chest movements. The design of a new RR measurement device utilizing a self-heating thermistor is described. The thermistor is integrated into a hand-held air chamber with a funnel attachment to sensitively detect respiratory airflow. The exhaled respiratory airflow reduces the temperature of the thermistor that is kept at a preset temperature, and its temperature recovers during inhalation. A microcontroller provides signal processing, while its display screen shows the respiratory signal and RR. The device was evaluated on 27 healthy adult volunteers, with a mean age of 32.8 years (standard deviation of 8.6 years). The RR measurements from the device were compared with the visual counting of chest movements, and the contact method of inductance plethysmography that was implemented using a commercial device (SOMNOtouch™ RESP). Statistical analysis, e.g., correlations were performed. The RR measurements from the new device and SOMNOtouch™ RESP, averaged across the 27 participants, were 14.6 breaths per minute (bpm) and 14.0 bpm, respectively. The device has a robust operation, is easy to use, and provides an objective measure of the RR in a noncontact manner. Full article

Non-contact human respiration rate monitoring can be used for sleep apnea detection and home care. Typically, the human body does not remain stationary for long periods, and body movement can significantly affect the performance of non-contact respiratory monitoring. Because the breathing rate generally remains stable over short periods, using measurements from only a portion of the radar echo signals does not result in significant errors, and these errors will be smaller than those caused by body movement. However, selecting a window size that is too short reduces frequency resolution, leading to increased estimation errors. Choosing an appropriate window length can improve estimation accuracy. In this paper, we propose an algorithm to determine whether the subject is stationary and select the received signal with minimal body movement. Experimental results are compared using alternative schemes, including fast Fourier transform (FFT), short-time Fourier transform (STFT), and RGB-D camera-assisted methods, in terms of root mean square error (RMSE) performance. Full article

We provide new insights into the performance of camera-based heart and respiration rate extraction and evaluate its usability for replacing spot checks conducted in the general ward. A study was performed comprising of 36 ICU patients recorded for a total time of 699 h. The 5 beats/minute agreement between camera and ECG-based heart rate measurements was 81.5%, with a coverage of 81.9%, where the largest gap between measurements was 239 min. The challenges encountered in heart rate monitoring were limited visibility of the patient’s face and irregular heart rates, which led to poor agreement between camera- and ECG-based heart rate measurements. To prevent non-breathing motion from causing error in respiration rate extraction, we developed a metric which was used to detect non-breathing motion. The 3 breaths/minute agreement between the camera- and contact-based respiration rate measurements was 91.1%, with a coverage of 59.1%, where the largest gap between measurements was 114 min. Encountered challenges were the morphology of the respiration signal and irregular breathing. While a few challenges need to be overcome, the results show promise for the usability of camera-based heart and respiration rate monitoring as a replacement for spot checks of these vital parameters conducted in the general ward. Full article

In the field of psychology and cognition within closed cabins, noncontact vital sign detection holds significant potential as it can enhance the user’s experience by utilizing objective measurements to assess emotions, making the process more sustainable and easier to deploy. To evaluate the capability of noncontact methods for emotion recognition in closed spaces, such as submarines, this study proposes an emotion recognition method that employs a millimeter-wave radar to capture respiration signals and uses a machine-learning framework for emotion classification. Respiration signals were collected while the participants watched videos designed to elicit different emotions. An automatic sparse encoder was used to extract features from respiration signals, and two support vector machines were employed for emotion classification. The proposed method was experimentally validated using the FaceReader software, which is based on audiovisual signals, and achieved an emotion classification accuracy of 68.21%, indicating the feasibility and effectiveness of using respiration signals to recognize and assess the emotional states of individuals in closed cabins. Full article

This paper deals with the non-contact measurement of heartbeat and respiration using a millimeter-wave multiple-input–multiple-output (MIMO) frequency-modulated continuous-wave (FM-CW) radar. Monitoring heartbeat and respiration is useful for detecting cardiac diseases and understanding stress levels. Contact sensors are not suitable for these sorts of long-term measurements due to the discomfort and skin irritation they cause. Therefore, the use of non-contact sensors, such as radars, is desirable. In this study, we obtained heartbeat and respiration information from phase data measured using a millimeter-wave MIMO FM-CW radar. We propose a two-wave model based on a Fourier series expansion and extract respiration and heartbeat information as a minimization problem. This model makes it possible to produce respiration and heartbeat waveforms. The produced heartbeat waveform can be used for estimating the interbeat interval (IBI). Experiments were conducted to confirm the usefulness of the proposed method. Moreover, the estimated results were compared with the contact sensor’s results. The results for both types of sensors were in good agreement. Full article

Flexible humidity sensors (FHSs) with fast response times and durability to high-humidity environments are highly desirable for practical applications. Herein, an FHS based on crosslinked sodium alginate (SA) and MXene was fabricated, which exhibited high sensitivity (impedance varied from 10⁷ to 10⁵ Ω between 10% and 90% RH), good selectivity, prompt response times (response/recover time of 4 s/11 s), high sensing linearity (R² = 0.992) on a semi-logarithmic scale, relatively small hysteresis (~5% RH), good repeatability, and good resistance to highly humid environments (negligible changes in sensing properties after being placed in 98% RH over 24 h). It is proposed that the formation of the crosslinking structure of SA and the introduction of MXene with good conductivity and a high specific surface area contributed to the high performance of the composite FHS. Moreover, the FHS could promptly differentiate the respiration status, recognize speech, and measure fingertip movement, indicating potential in breath monitoring and non-contact human–machine interactions. This work provides guidance for developing advanced flexible sensors with a wide application scope in wearable electronics. Full article

(1) Objective: This study aims to lay a foundation for noncontact intensive care monitoring of premature babies. (2) Methods: Arterial oxygen saturation and heart rate were measured using a monochrome camera and time-division multiplex controlled lighting at three different wavelengths (660 nm, 810 nm and 940 nm) on a piglet model. (3) Results: Using this camera system and our newly designed algorithm for further analysis, the detection of a heartbeat and the calculation of oxygen saturation were evaluated. In motionless individuals, heartbeat and respiration were separated clearly during light breathing and with only minor intervention. In this case, the mean difference between noncontact and contact saturation measurements was 0.7% (RMSE = 3.8%, MAE = 2.93%). (4) Conclusions: The new sensor was proven effective under ideal animal experimental conditions. The results allow a systematic improvement for the further development of contactless vital sign monitoring systems. The results presented here are a major step towards the development of an incubator with noncontact sensor systems for use in the neonatal intensive care unit. Full article

The noninvasive measurement and sensing of vital bio signs, such as respiration and cardiopulmonary parameters, has become an essential part of the evaluation of a patient’s physiological condition. The demand for new technologies that facilitate remote and noninvasive techniques for such measurements continues to grow. While previous research has made strides in the continuous monitoring of vital bio signs using lasers, this paper introduces a novel technique for remote noncontact measurements based on radio frequencies. Unlike laser-based methods, this innovative approach offers the advantage of penetrating through walls and tissues, enabling the measurement of respiration and heart rate. Our method, diverging from traditional radar systems, introduces a unique sensing concept that enables the detection of micro-movements in all directions, including those parallel to the antenna surface. The main goal of this work is to present a novel, simple, and cost-effective measurement tool capable of indicating changes in a subject’s condition. By leveraging the unique properties of radio frequencies, this technique allows for the noninvasive monitoring of vital bio signs without the need for physical contact or invasive procedures. Moreover, the ability to penetrate barriers such as walls and tissues opens new possibilities for remote monitoring in various settings, including home healthcare, hospital environments, and even search and rescue operations. In order to validate the effectiveness of this technique, a series of experiments were conducted using a prototype device. The results demonstrated the feasibility of accurately measuring respiration patterns and heart rate remotely, showcasing the potential for real-time monitoring of a patient’s physiological parameters. Furthermore, the simplicity and low-cost nature of the proposed measurement tool make it accessible to a wide range of users, including healthcare professionals, caregivers, and individuals seeking to monitor their own health. Full article

Breathing temporarily pauses during swallowing, and the occurrence of inspiration before and after these pauses may increase the likelihood of aspiration, a serious health problem in older adults. Therefore, the automatic detection of these pauses without constraints is important. We propose methods for measuring respiratory movements during swallowing using millimeter wave radar to detect these pauses. The experiment involved 20 healthy adult participants. The results showed a correlation of 0.71 with the measurement data obtained from a band-type sensor used as a reference, demonstrating the potential to measure chest movements associated with respiration using a non-contact method. Additionally, temporary respiratory pauses caused by swallowing were confirmed by the measured data. Furthermore, using machine learning, the presence of respiring alone was detected with an accuracy of 88.5%, which is higher than that reported in previous studies. Respiring and temporary respiratory pauses caused by swallowing were also detected, with a macro-averaged F1 score of 66.4%. Although there is room for improvement in temporary pause detection, this study demonstrates the potential for measuring respiratory movements during swallowing using millimeter wave radar and a machine learning method. Full article

The measurement and analysis of vital signs are a subject of significant research interest, particularly for monitoring the driver’s physiological state, which is of crucial importance for road safety. Various approaches have been proposed using contact techniques to measure vital signs. However, all of these methods are invasive and cumbersome for the driver. This paper proposes using a non-contact sensor based on continuous wave (CW) radar at 24 GHz to measure vital signs. We associate these measurements with distinct temporal neural networks to analyze the signals to detect and extract heart and respiration rates as well as classify the physiological state of the driver. This approach offers robust performance in estimating the exact values of heart and respiration rates and in classifying the driver’s physiological state. It is non-invasive and requires no physical contact with the driver, making it particularly practical and safe. The results presented in this paper, derived from the use of a 1D Convolutional Neural Network (1D-CNN), a Temporal Convolutional Network (TCN), a Recurrent Neural Network particularly the Bidirectional Long Short-Term Memory (Bi-LSTM), and a Convolutional Recurrent Neural Network (CRNN). Among these, the CRNN emerged as the most effective Deep Learning approach for vital signal analysis. Full article

Noncontact vital sign monitoring based on radar has attracted great interest in many fields. Heart Rate Variability (HRV), which measures the fluctuation of heartbeat intervals, has been considered as an important indicator for general health evaluation. This paper proposes a new algorithm for HRV monitoring in which frequency-modulated continuous-wave (FMCW) radar is used to separate echo signals from different distances, and the beamforming technique is adopted to improve signal quality. After the phase reflecting the chest wall motion is demodulated, the acceleration is calculated to enhance the heartbeat and suppress the impact of respiration. The time interval of each heartbeat is estimated based on the smoothed acceleration waveform. Finally, a joint optimization algorithm was developed and is used to precisely segment the acceleration signal for analyzing HRV. Experimental results from 10 participants show the potential of the proposed algorithm for obtaining a noncontact HRV estimation with high accuracy. The proposed algorithm can measure the interbeat interval (IBI) with a root mean square error (RMSE) of 14.9 ms and accurately estimate HRV parameters with an RMSE of 3.24 ms for MEAN (the average value of the IBI), 4.91 ms for the standard deviation of normal to normal (SDNN), and 9.10 ms for the root mean square of successive differences (RMSSD). These results demonstrate the effectiveness and feasibility of the proposed method in emotion recognition, sleep monitoring, and heart disease diagnosis. Full article

Waste tires from traffic are a well-known environmental problem today. For this reason, the toxicity and potential biodegradation of crushed tires were tested in a respiration test with microorganisms. A non-specific soil microbial community was used. Two experimental designs and their effect on the results were compared—a test with the eluate from tires and a contact test, i.e., the solution containing tire particles during the test. The consumption of dissolved oxygen was measured in the assay over 28 days. The values obtained indicated zero biodegradation of all samples, but the toxicity of the eluates to microorganisms was different depending on whether the microorganisms were exposed only to the leachate or whether tire shred particles were still present in the leachate. In the presence of particles in solutions, the toxicity of the samples for microorganisms was higher. Additionally, the MTT (methyl tetrazolium test) viability assay was performed. The results indicated a 28% inhibition of the viability of microorganisms in samples with tire particles in comparison with eluate, where 9% inhibition was observed. The results confirmed that the contact assay (with the presence of particles) is a more natural and thorough method than the use of leachate. Full article

In this study, a noncontact fabric loop sensor based on magnetic-field-induced conductivity, which can simultaneously detect cardiac activity and respiration signals, was developed and the effects of the sensor’s shape and measurement position on the sensing performance were analyzed. Fifteen male subjects in their twenties wore sleeveless shirts equipped with various types of fabric loop sensors (spiky, extrusion, and spiral), and the cardiac activity and respiratory signals were measured twice at positions P2, P4, and P6. The measurements were verified by comparing them against the reference electrocardiogram (ECG) and respiratory signals measured using BIOPAC^® (MP150, ECG100B, RSP100C). The waveforms of the raw signal measured by the fabric loop sensor were filtered with a bandpass filter (1–20 Hz) and qualitatively compared with the ECG signal obtained from the Ag/AgCI electrode. Notwithstanding a slight difference in performance, the three fabric sensors could simultaneously detect cardiac activity and respiration signals at all measurement positions. In addition, it was verified through statistical analysis that the highest-quality signal was obtained at the measurement position of P4 or P6 using the spiral loop sensor. Full article

Human respiration reflects meaningful information, such as one’s health and psychological state. Rates of respiration are an important indicator in medicine because they are directly related to life, death, and the onset of a serious disease. In this study, we propose a noncontact method to measure respiration. Our proposed approach uses a standard RGB camera and does not require any special equipment. Measurement is performed automatically by detecting body landmarks to identify regions of interest (RoIs). We adopt a learning model trained to measure motion and respiration by analyzing movement from RoI images for high robustness to background noise. We collected a remote respiration measurement dataset to train the proposed method and compared its measurement performance with that of representative existing methods. Experimentally, the proposed method showed a performance similar to that of existing methods in a stable environment with restricted motion. However, its performance was significantly improved compared to existing methods owing to its robustness to motion noise. In an environment with partial occlusion and small body movement, the error of the existing methods was 4–8 bpm, whereas the error of our proposed method was around 0.1 bpm. In addition, by measuring the time required to perform each step of the respiration measurement process, we confirmed that the proposed method can be implemented in real time at over 30 FPS using only a standard CPU. Since the proposed approach shows state-of-the-art accuracy with the error of 0.1 bpm in the wild, it can be expanded to various applications, such as medicine, home healthcare, emotional marketing, forensic investigation, and fitness in future research. Full article
