High-precision monitoring of glacier motion provides crucial information for a thorough understanding of the dynamic characteristics and development patterns of glaciers, which serves as a scientific basis for the prevention and management of glacier-related disasters. Zelongnong Glacier, located in Tibet, China, has experienced glacier surges, collapse, and hazard chains four times in the last 70 years. On 10 September 2020, a major glacier hazard chain occurred in this region. To reveal the influencing factors of the glacier motion, we monitor the Zelongnong Glacier motions with 65 scenes of TerraSAR/PAZ images from 2022 to 2023, where the Pixel Offset Multidimensional Small Baseline Subset (PO-MSBAS) method is employed for three-dimensional time series inversion. As the registration window size directly affects the matching success rate, deformation accuracy, and signal-to-noise ratio (SNR) during the offset tracking processing, we adopt a variable window-weighted cross-correlation strategy. The strategy balances the advantages of different window sizes, effectively reducing noise while preserving certain details in the offset results. The standard deviation in stable areas is also significantly lower than that obtained using smaller window sizes in conventional methods. The results reveal that the velocity of the southern glacier tributary was larger than the one in the northern tributary. Specifically, the maximum velocity in the northern tributary reached 45.07 m/year in the horizontal direction and −7.45 m/year in the vertical direction, whereas in the southern tributary, the maximum velocity was 50.15 m/year horizontally and 50.66 m/year vertically. The southern tributary underwent two bends before merging with the mainstream, leading to a more complex motion pattern. Lastly, correlation reveals that the Zelongnong Glacier was affected by the combined influence of temperature and precipitation with a common period of around 90 days. Full article

Time-series ground deformation monitoring and reservoir parameter inversion are crucial for the dynamic assessment of oilfield resources and sustainable exploitation in oilfields. As some of the regions with the richest oil reserves in China, the oilfield areas in the western Qaidam Basin were selected as a typical study area. Firstly, we used SAR images collected by the Sentinel-1A satellite from January 2021 to December 2022 and applied the multidimensional small baseline subset (MSBAS) method to obtain vertical and east–west deformation measurements. On this basis, a nonlinear Bayesian inversion method was applied to model the shallow reservoir in a series of complex deformation areas, based on a single-source model and a multi-source model, respectively. As a result, the ground deformation monitoring results obtained by long time-series InSAR clearly reflect the uneven ground deformation caused by the oil extraction and water injection operation processes. There was slight subsidence in the Huatugou oilfield, while significant uplift deformation occurred in the Ganchaigou oilfield and the Youshashan oilfield, with a maximum uplift rate of 48 mm/year. Further analysis indicated that the introduction of the 2D deformation field helps to improve the robustness of oilfield reservoir parameter inversion. Moreover, the dual-source model is more suitable than the single-source model for inverting reservoir parameters of complex deformation. This study not only fills the gap of InSAR deformation monitoring for the oilfields in the western Qaidam Basin but also provides a theoretical reference for the model and method selection of reservoir parameter inversion in other oilfields. Full article

On 11 October and 3 November 2018, two large landslides occurred in Baige Village, Tibet, China, forcing the Jinsha River to be cut off and form a dammed lake, resulting in massive economic damages and deaths. This paper uses ground-based radar (GBR) and spaceborne interferometric synthetic aperture radar (InSAR) technologies to perform dynamic monitoring of the Baige landslide. Firstly, the GBR results suggest that the cumulative deformation from 4 to 10 December 2018 was 1.4 m, and the landslide still exhibits a risk of instability. Secondly, with the Sentinel-1A ascending and descending orbit images from December 2018 to February 2022, the InSAR-stacking technology assisted by the generic atmospheric correction online service (GACOS) and the multidimensional small baseline subset (MSBAS) method are utilized to obtain the annual deformation velocity and cumulative deformation in the satellite radar line of sight (LOS) direction of the landslide. Finally, according to the spatial–temporal deformation characteristics of feature points, combined with optical images, field investigation, and geological conditions, the development trend and inducing factors of the Baige landslide are comprehensively analyzed. It is shown that the Baige landslide is in constant motion at present, and the deformation is spreading from the slope to its right side. This research establishes a framework of combining emergency monitoring (i.e., GBR) with long-term monitoring (i.e., spaceborne InSAR). The framework is more conducive to obtaining the deformation and evolution of landslides, providing a greater possibility for studying the development trend and risk assessment of landslides, and assisting in reducing or even avoiding the losses caused by landslides. Full article

Bedding-controlled landslides are a common geological hazard for open-pit metal mines and occur on layered rock slopes. It can spread spatially over the final boundary of the dip slope and persist throughout the entire life cycle of the mine, substantially compromising the safety of mining operations. Identifying potential landslide areas and determining the landslide mechanism is crucial for the safety production and slope management of mines. This study proposes a combination of satellite radar interferometry measurement and numerical simulation to determine the landslide mechanism of the bedding-controlled slope in open-pit mines. First, the multidimensional small baseline subset (MSBAS) technique of interferometric synthetic aperture radar (InSAR) is used to capture deformation information in the vertical and east–west directions of the slope, locate large-scale and long-term movements, and preliminarily determine the trend of landslides. Then, a layered slope damage constitutive model is established, and a three-dimensional stability calculation of the layered slope is performed using COMSOL Multiphysics 5.3 software based on the strength reduction method to study the development and evolution process of landslides. The effectiveness of the method is validated by a large-scale bedding-controlled slope failure in the Nanfen open-pit mine in Liaoning, China, revealing the failure mechanism of the slope under excavation conditions. The study shows that the eastern slope bedding-controlled landslide in the Nanfen open-pit mine is a multizone composite-mode landslide caused by excavation, which belongs to the shear–slip–tension deformation failure mechanism as a whole. This study provides a new method for analyzing the mechanism of layered rock slope landslides under mining activities in open-pit mines, which can be used to assess and predict similar landslides. Full article

Synthetic Aperture Radar images have recently been utilized in glacier surface flow velocity research due to their continuously improving imaging technology, which increases the resolution and scope of research. In this study, we employed the offset tracking and multidimensional small baseline subset (MSBAS) technique to extract the surface flow velocity of the Siachen Glacier from 253 Sentinel-1 images. From 2017 to 2021, the Siachen Glacier had an average flow velocity of 38.25 m a⁻¹, with the highest flow velocity of 353.35 m a⁻¹ located in the upper part of a tributary due to the steep slope and narrow valley. The inter-annual flow velocity fluctuations show visible seasonal patterns, with the highest flow velocity observed between May and July and the lowest between December and January. Mass balance calculated by the geodetic method based on AST14DEM indicates that the Siachen Glacier experienced a positive mass change (0.07 ± 0.23 m w.e. a⁻¹) between 2008 and 2021. However, there was significant spatial heterogeneity revealed in the distribution, with surface elevation changes showing a decrease in the glacier tongue while thickness increased in two other western tributaries of the Siachen Glacier. The non-surface parallel flow component is correlated with the strain rate and mass balance process, and correlation analysis indicates a positive agreement between these two variables. Therefore, using glacier flow velocities obtained from the SAR approach, we can evaluate the health of the glacier and obtain crucial factors for the glacier’s dynamic model. Two western tributaries of the Siachen Glacier experienced mass gain in the past two decades, necessitating close monitoring of flow velocity changes in the future to detect potential glacier surges. Full article

In this study we used RADARSAT-2 and Sentinel-1 Synthetic Aperture Radar data for measuring subsidence above a flooded potash mine, which is almost entirely located within the city of Berezniki (Perm Krai, Russia), population 150,000. This area has experienced very fast subsidence since October 2006 when the integrity of the Berezniki-1 mine was compromised, resulting in water intrusion, subsequent flooding and closure of the mine. Due to the ongoing dissolution of carnallite, subsidence in this region is expected to continue in the foreseeable future. In addition to rapid subsidence, at least five sinkholes have formed in the region, with the largest being 440 × 320 m. We observed ground subsidence during the period October 2011–April 2014 (RADARSAT-2) with a vertical rate up to 14 cm/year and horizontal rate up to 10 cm/year; during the period July 2016–June 2020 (Sentinel-1) with a vertical rate up to 17 cm/year. Our results were validated by precise leveling, with a coefficient of correlation of 0.75. Subsidence faster than 17 cm/year observed by precise leveling was not resolvable with Differential Interferometric Synthetic Aperture Radar (DInSAR). Our results show the complementary nature of ground-based and space-borne measurement techniques. The precise leveling captures subsidence along profile lines with high precision but lower temporal resolution, while DInSAR captures subsidence with high spatial and temporal resolutions but with lower precision. DInSAR is also significantly affected by decorrelation outside of urban areas. An important advantage of our methodology is the ability to measure the horizontal east component of the ground deformation when both, ascending and descending, data are available. This measurement directly characterizes the level of anthropogenic load on buildings and infrastructure. We recommend continuing monitoring subsidence using both measurement techniques, which can also be complemented by continuous Global Navigation Satellite System (GNSS). Full article

The extraction of high-accuracy co- and post-seismic deformation fields and inversions of seismic slip distributions is significant in the comprehension of seismogenic mechanisms. On 12 November 2017, a M_W 7.3 earthquake occurred on the border between Iran and Iraq. To construct the co-seismic deformation field, Sentinel-1A synthetic aperture radar (SAR) images from three tracks were used. Based on a prior knowledge, least-squares iterative approximation was employed to construct the three-dimensional (3D) co-seismic deformation field. to derive a time series of 2D post-seismic deformation, the multidimensional small baseline subset (MSBAS) technique was use. Co-seismic deformation fields were asymmetric; the maximum relative displacement was nearly 90cm in the radar line-of-sight between two centers of co-seismic deformation. The 3D co-seismic deformation field showed southwestward horizontal motion and continuous subsidence-to-uplift variation from northeast to southwest. The two-dimensional (2D) post-seismic deformation time series showed a gradual decaying trend and good correspondence with the aftershock distribution. The main mechanism of post-seismic deformation was an afterslip of the post-seismic faults. We used the elastic half-space model to invert co-seismic deformation fields and obtain source parameters of the slip model. The maximum and average slips were 2.5 and 0.72 m, respectively. The average slip angle was 126.38° and the moment magnitude was M_W 7.34. The results of this study will contribute to research on regional tectonic activities. Full article
