This study examined the impact of temperature optimization on indium tin oxide (ITO) films in monolithic HJT/perovskite tandem solar cells. ITO films were deposited using magnetron sputtering at temperatures ranging from room temperature (25 °C) to 250 °C. The sputtering target was ITO, with a mass ratio of In₂O₃ to SnO₂ of 90% to 10%. The effects of temperature on the ITO film were analyzed using X-ray diffraction (XRD), spectroscopic ellipsometry, and sheet resistance measurements. Results showed that all ITO films exhibited a polycrystalline morphology, with diffraction peaks corresponding to planes (211), (222), (400), (440), and (622), indicating a cubic bixbyite crystal structure. The light transmittance exceeded 80%, and the sheet resistance was 75.1 Ω/sq for ITO deposited at 200 °C. The optical bandgap of deposited ITO films ranged between 3.90 eV and 3.93 eV. Structural and morphological characterization of the perovskite solar cell was performed using XRD and FE-SEM. Tandem solar cell performance was evaluated by analyzing current density-voltage characteristics under simulated sunlight. By optimizing the ITO deposition temperature, the tandem cell achieved a power conversion efficiency (PCE) of 16.74%, resulting in enhanced tandem cell efficiency. Full article

A metal oxide-based interconnecting and window layer consisting of a molybdenum oxide (MoO₃)/Zn-doped In₂O₃ (IZO) bilayer was investigated in efficient solution-processed perovskite/n-Si monolithic tandem solar cells using formamidinium cesium lead triiodide, FA_0.9Cs_0.1PbI₃, and poly(3,4-ethylenedioxythiophene)/poly(polystyrene sulfonate) (PEDOT:PSS). The MoO₃/IZO bilayer with and without Au nanoparticle play a significant role in the charge extraction and recombination within the interconnecting layer and the window layer of the top cell, respectively. A power conversion efficiency of 18–19% was achieved with a short-circuit current, J_sc, of 17.8 mA/cm²; an open-circuit voltage, V_oc, of 1.48 V; and an FF of 0.74 by adjusting the layer thicknesses of MoO₃ (5 nm), Au nanoparticle layer (5 nm), and sputtered IZO (42 nm for ICL and 80 nm for window layer). Full article

Tandem solar cells are widely considered the industry’s next step in photovoltaics because of their excellent power conversion efficiency. Since halide perovskite absorber material was developed, it has been feasible to develop tandem solar cells that are more efficient. The European Solar Test Installation has verified a 32.5% efficiency for perovskite/silicon tandem solar cells. There has been an increase in the perovskite/Si tandem devices’ power conversion efficiency, but it is still not as high as it might be. Their instability and difficulties in large-area realization are significant challenges in commercialization. In the first part of this overview, we set the stage by discussing the background of tandem solar cells and their development over time. Subsequently, a concise summary of recent advancements in perovskite tandem solar cells utilizing various device topologies is presented. In addition, we explore the many possible configurations of tandem module technology: the present work addresses the characteristics and efficacy of 2T monolithic and mechanically stacked four-terminal devices. Next, we explore ways to boost perovskite tandem solar cells’ power conversion efficiencies. Recent advancements in the efficiency of tandem cells are described, along with the limitations that are still restricting their efficiency. Stability is also a significant hurdle in commercializing such devices, so we proposed eliminating ion migration as a cornerstone strategy for solving intrinsic instability problems. Full article

In this study, we investigated the pathways for integration of perovskite and silicon solar cells through variation of the properties of the interconnecting layer (ICL). The user-friendly computer simulation software wxAMPS was used to conduct the investigation. The simulation started with numerical inspection of the individual single junction sub-cell, and this was followed by performing an electrical and optical evaluation of monolithic 2T tandem PSC/Si, with variation of the thickness and bandgap of the interconnecting layer. The electrical performance of the monolithic crystalline silicon and CH₃NH₃PbI₃ perovskite tandem configuration was observed to be the best with the insertion of a 50 nm thick (E_g ≥ 2.25 eV) interconnecting layer, which directly contributed to the optimum optical absorption coverage. These design parameters improved the optical absorption and current matching, while also enhancing the electrical performance of the tandem solar cell, which benefited the photovoltaic aspects through lowering the parasitic loss. Full article

The primary purpose of recent research on solar cells is to achieve a higher power conversion efficiency with stable characteristics. To push the developments of photovoltaic (PV) technology, tandem solar cells are being intensively researched, as they have higher power conversion efficiency (PCE) than single-junction cells. Perovskite solar cells (PSCs) are recently used as a top cell of tandem solar cells thanks to their tunable energy gap, high short circuit current, and low cost of fabrication. One of the main challenges in PSCs cells is the stability issue. Carbon perovskite solar cells (CPSCs) without a hole transport material (HTM) presented a promising solution for PSCs’ stability. The two-terminal monolithic tandem solar cells demonstrate the commercial tandem cells market. Consequently, all the proposed tandem solar cells in this paper are equivalent to two-terminal monolithic tandem devices. In this work, two two-terminal tandem solar cells are proposed and investigated using the SCAPS-1D device simulator. Carbon perovskite solar cell (CPSC) without hole transport material (HTM) is used as the top cell with a new proposed gradient doping in the perovskite layer. This proposal has led to a substantial enhancement of the stability issue known to be present in carbon perovskite cells. Moreover, a higher PCE, exceeding 22%, has been attained for the proposed CPSC. Two bottom cells are examined, Si and CIGS-GeTe solar cells. The suggested CPSC/Si and CPSC/CIGS-GeTe tandem solar cells have the advantage of having just two junctions, which reduces the complexity and cost of solar cells. The performance parameters are found to be improved. In specific, the PCEs of the two proposed cells are 19.89% and 24.69%, respectively. Full article

Recently, emerging third-generation photovoltaic technologies have shown rapid progress in device performance; the power conversion efficiencies (PCEs) of organic bulk heterojunction (BHJ) and perovskite solar cells (PSCs) are now surpassing 19% and 25%, respectively. Despite this dramatic enhancement, their efficiencies are theoretically limited based on the detailed balance model which accounts for inevitable loss mechanisms under operational conditions. Integrated solar cells, formed by monolithically integrating two photoactive layers of perovskite and BHJ with complementary absorption, provide a promising platform for further improvement in solar cell efficiency. In perovskite/BHJ integrated solar cells (POISCs), high bandgap perovskite offers high open-circuit voltage with minimal losses while low bandgap organic BHJ extends absorption bandwidth by covering the near-infrared region, resulting in additional photocurrent gain. Different from conventional tandem solar cells, integrated solar cells contain merged photoactive layers without the need for complicated recombination layers, which greatly simplifies fabrication processes. In this review, we summarize the recent progress in POISCs, including operational mechanism and structural development, and remaining challenges on the road toward efficient devices. Full article

Toxic substance usage remains one of the major concerns that must be addressed toward the commercialization of perovskite photovoltaics. Herein, we report a highly efficient perovskite solar module (>13%) fabricated via a wet process that uses a unique aqueous Pb(NO₃)₂ precursor, eliminating the use of toxic organic solvents during perovskite film preparation. In addition, we demonstrate a unique pattern in a monolithically interconnected module structure to check the uniformity of perovskite film and the quality of laser scribing. Finally, we highlight that this aqueous Pb(NO₃)₂ precursor protocol could achieve an enormous cost reduction over conventional PbI₂ organic solutions whether in the laboratory research stage or at mass production scale, strengthening the core competitiveness of perovskite solar cells in the Darwinian ocean of photovoltaic technologies. Full article

Perovskite/silicon tandem solar cells have strong potential for high efficiency and low cost photovoltaics. In monolithic (two-terminal) configurations, one key element is the interconnection region of the two subcells, which should be designed for optimal light management and prevention of parasitic p/n junctions. We investigated monolithic perovskite/silicon-heterojunction (SHJ) tandem solar cells with a p/n nanocrystalline silicon/silicon-oxide recombination junction for improved infrared light management. This design can additionally provide for resilience to shunts and simplified cell processing. We probed modified SHJ solar cells, made from double-side polished n-type Si wafers, which included the proposed front-side p/n tunnel junction with the p-type film simultaneously functioning as selective charge transport layer for the SHJ bottom cell, trying different thicknesses for the n-type layer. Full tandem devices were then tested, by applying a planar n-i-p mixed-cation mixed-halide perovskite top cell, fabricated via low temperature solution methods to be compatible with the processed Si wafer. We demonstrate the feasibility of this tandem cell configuration over a 1 cm² area with negligible J-V hysteresis and a V_OC ~1.8 V, matching the sum of the V_OC-s contributed by the two components. Full article

Tandem solar cells, based on perovskite and crystalline silicon absorbers, are promising candidates for commercial applications. Tin oxide (SnO₂), applied via the spin-coating method, has been among the most used electron transfer layers in normal (n-i-p) perovskite/silicon tandem cells. SnO₂ synthesized by chemical bath deposition (CBD) has not yet been applied in tandem devices. This method shows improved efficiency in perovskite single cells and allows for deposition over a larger area. Our study is the first to apply low-temperature processed SnO₂ via CBD to a homojunction silicon solar cell without additional deposition of a recombination layer. By controlling the reaction time, a tandem efficiency of 16.9% was achieved. This study shows that tandem implementation is possible through the CBD method, and demonstrates the potential of this method in commercial application to textured silicon surfaces with large areas. Full article

Nanocluster aggregation sources based on magnetron-sputtering represent precise and versatile means to deposit a controlled quantity of metal nanoparticles at selected interfaces. In this work, we exploit this methodology to produce Ag/MgO nanoparticles (NPs) and deposit them on a glass/FTO/TiO₂ substrate, which constitutes the mesoscopic front electrode of a monolithic perovskite-based solar cell (PSC). Herein, the Ag NP growth through magnetron sputtering and gas aggregation, subsequently covered with MgO ultrathin layers, is fully characterized in terms of structural and morphological properties while thermal stability and endurance against air-induced oxidation are demonstrated in accordance with PSC manufacturing processes. Finally, once the NP coverage is optimized, the Ag/MgO engineered PSCs demonstrate an overall increase of 5% in terms of device power conversion efficiencies (up to 17.8%). Full article

Monolithic perovskite–silicon tandem solar cells with MoO_x hole selective contact silicon bottom solar cells show a power conversion efficiency of 8%. A thin 15 nm-thick MoO_x contact to n-type Si was used instead of a standard p⁺ emitter to collect holes and the SiO_x/n⁺ poly-Si structure was deposited on the other side of the device for direct tunneling of electrons and this silicon bottom cell structure shows ~15% of power conversion efficiency. With this bottom carrier selective silicon cell, tin oxide, and subsequent perovskite structure were deposited to fabricate monolithic tandem solar cells. Monolithic tandem structure without ITO interlayer was also compared to confirm the role of MoO_x in tandem cells and this tandem structure shows the power conversion efficiency of 3.3%. This research has confirmed that the MoO_x layer simultaneously acts as a passivation layer and a hole collecting layer in this tandem structure. Full article

Cesium-containing triple cation perovskites are attracting significant attention as suitable tandem partners for silicon solar cells. The perovskite layer of a solar cell must strongly absorb the visible light and be transparent to the infrared light. Optical transmittance measurements of perovskite layers containing different cesium concentrations (0–15%) were carried out on purpose to evaluate the utility of the layers for the fabrication of monolithic perovskite/silicon tandem solar cells. The transmittance of the layers weakly depended on cesium concentration in the infrared spectral range, and it was more than 0.55 at 997 nm wavelength. It was found that perovskite solar cells containing 10% of cesium concentration show maximum power conversion efficiency. Full article

The industrial exploitation of perovskite solar cell technology is still hampered by the lack of repeatable and high-throughput fabrication processes for large-area modules. The joint efforts of the scientific community allowed to demonstrate high-performing small area solar cells; however, retaining such results over large area modules is not trivial. Indeed, the development of deposition methods over large substrates is required together with additional laser processes for the realization of the monolithically integrated cells and their interconnections. In this work, we develop an efficient perovskite solar module based on 2D material engineered structure by optimizing the laser ablation steps (namely P1, P2, P3) required for shaping the module layout in series connected sub-cells. We investigate the impact of the P2 and P3 laser processes, carried out by employing a UV pulsed laser (pulse width = 10 ns; λ = 355 nm), over the final module performance. In particular, a P2 process for removing 2D material-based cell stack from interconnection area among adjacent cells is optimized. Moreover, the impact of the P3 process used to isolate adjacent sub-cells after gold realization over the module performance once laminated in panel configuration is elucidated. The developed fabrication process ensures high-performance repeatability over a large module number by demonstrating the use of laser processing in industrial production. Full article

Due to the tremendous increase in power conversion efficiency (PCE) of organic–inorganic perovskite solar cells (PSCs), this technology has attracted much attention. Despite being the fastest-growing photovoltaic technology to date, bottlenecks such as current density–voltage (J–V) hysteresis have significantly limited further development. Current density measurements performed with different sweep scan speeds exhibit hysteresis and the photovoltaic parameters extracted from the current density–voltage measurements for both scan directions become questionable. A current density–voltage measurement protocol needs to be established which can be used to achieve reproducible results and to compare devices made in different laboratories. In this work, we report a hysteresis analysis of a hole-transport-material-free (HTM-free) carbon-counter-electrode-based PSC conducted by current density–voltage and impedance spectra measurements. The effect of sweep scan direction and time delay was examined on the J–V characteristics of the device. The hysteresis was observed to be strongly sweep scan direction and time delay dependent and decreased as the delay increased. The J–V analysis conducted in the reverse sweep scan direction at a lower sweep time delay of 0.2 s revealed very large increases in the short circuit current density and the power conversion efficiency of 57.7% and 56.1%, respectively, compared with the values obtained during the forward scan under the same conditions. Impedance spectroscopy (IS) investigations were carried out and the effects of sweep scan speed, time delay, and frequency were analyzed. The hysteresis was observed to be strongly sweep scan direction, sweep time delay, and frequency dependent. The correlation between J–V and IS data is provided. The wealth of photovoltaic and impendence spectroscopic data reported in this work on the hysteresis study of the HTM-free PSC may help in establishing a current density–voltage measurement protocol, identifying components and interfaces causing the hysteresis, and modeling of PSCs, eventually benefiting device performance and long-term stability. Full article

The future photovoltaic technologies based on perovskite materials are aimed to build low tech, truly economical, easily fabricated, broadly deployable, and trustworthy solar cells. Hole transport material (HTM) free perovskite solar cells (PSCs) are among the most likely architectures which hold a distinctive design and provide a simple way to produce large-area and cost-effective manufacture of PSCs. Notably, in the monolithic scheme of the HTM-free PSCs, all layers can be printed using highly reproducible and morphology-controlled methods, and this design has successfully been demonstrated for industrial-scale fabrication. In this review article, we comprehensively describe the recent advancements in the different types of mesoporous (nanostructured) and planar HTM-free PSCs. In addition, the effect of various nanostructures and mesoporous layers on their performance is discussed using the electrochemical impedance spectroscopy (EIS) technique. We bring together the different perspectives that researchers have developed to interpret and analyze the EIS data of the HTM-free PSCs. Their analysis using the EIS tool, the limitations of these studies, and the future work directions to overcome these limitations to enhance the performance of HTM-free PSCs are comprehensively considered. Full article
