Search Results (183)

This work devised an on-device learning approach to self-calibrate Micro-Electro-Mechanical Systems-based Inertial Measurement Units (MEMS-IMUs), integrating a digital signal processor (DSP), an accelerometer, and a gyroscope in the same package. The accelerometer and gyroscope stream their data in real time to the DSP, which runs artificial intelligence (AI) workloads. The real-time sensor data are subject to errors, such as time-varying bias and thermal stress. To compensate for these drifts, the traditional calibration method based on a linear model is applicable, and unfortunately, it does not work with nonlinear errors. The algorithm devised by this study to reduce such errors adopts Radial Basis Function Neural Networks (RBF-NNs). This method does not rely on the classical adoption of the backpropagation algorithm. Due to its low complexity, it is deployable using kibyte memory and in software runs on the DSP, thus performing interleaved in-sensor learning and inference by itself. This avoids using any off-package computing processor. The learning process is performed periodically to achieve consistent sensor recalibration over time. The devised solution was implemented in both 32-bit floating-point data representation and 16-bit quantized integer version. Both of these were deployed into the Intelligent Sensor Processing Unit (ISPU), integrated into the LSM6DSO16IS Inertial Measurement Unit (IMU), which is a programmable 5–10 MHz DSP on which the programmer can compile and execute AI models. It integrates 32 KiB of program RAM and 8 KiB of data RAM. No permanent memory is integrated into the package. The two (fp32 and int16) RBF-NN models occupied less than 21 KiB out of the 40 available, working in real-time and independently in the sensor package. The models, respectively, compensated between 46% and 95% of the accelerometer measurement error and between 32% and 88% of the gyroscope measurement error. Finally, it has also been used for attitude estimation of a micro aerial vehicle (MAV), achieving an error of only 2.84°. Full article

Solid-lubricated rolling bearings are widely used in the aerospace field and are key components to support spacecraft rotors. During the start-up of the engine, the sharp acceleration may cause bearing skidding, resulting in damage of the solid lubricating film and a reduction in the remaining useful life of the bearing. However, the existing research on the tribo-dynamic responses of solid-lubricated ball bearings mostly relies on semi-empirical tribological models, which are limited in their ability to reveal the micro–macro sliding mechanisms of the ball–raceway contact interface. In this paper, a novel tribo-dynamic model for solid-lubricated angular contact ball bearings is developed by applying Kalker’s rolling contact theory to the Gupta dynamic model. The interpolation method is adopted to calculate contact parameters to improve the model’s efficiency. Using the proposed model, the dynamic response of the bearing in the acceleration process is studied, and the mechanism and influence characteristics of skidding, over-skidding, and creepage of the rolling element are analyzed. The results show that the main reason for skidding is that the traction force is not enough to overcome the resistance, and the gyroscopic effect is the main cause of over-skidding, which follows the principle of conservation of the angular momentum of the ball. Full article

Inertial navigation systems (INSs) provide autonomous position estimation capabilities independent of global navigation satellite systems (GNSSs). However, the high cost of traditional sensors, such as fiber-optic gyroscopes (FOGs), limits their widespread adoption. In contrast, micro-electromechanical system (MEMS)-based inertial measurement units (IMUs) offer a low-cost alternative; however, their lower accuracy and sensor bias issues, particularly in maritime environments, remain considerable obstacles. This study proposes an improved method for bias estimation by comparing the estimated values from a trajectory generator (TG)-based acceleration and angular-velocity estimation system with actual measurements. Additionally, for X- and Y-axis accelerations, we introduce a method that leverages the correlation between altitude differences derived from an INS/GNSS/gyrocompass (IGG) and those obtained during the TG estimation process to estimate the bias. Simulation datasets from experimental voyages validate the proposed method by evaluating the mean, median, normalized cross-correlation, least squares, and fast Fourier transform (FFT). The Butterworth filter achieved the smallest angular-velocity bias estimation error. For X- and Y-axis acceleration bias, altitude-based estimation achieved differences of 1.2 × 10⁻² m/s² and 1.0 × 10⁻⁴ m/s², respectively, by comparing the input bias using 30 min data. These methods enhance the positioning and attitude estimation accuracy of low-cost IMUs, providing a cost-effective maritime navigation solution. Full article

This paper describes a novel micro-electro-mechanical system (MEMS) tuning fork gyroscope (TFG) design that employs a chevron-shaped displacement mechanism to amplify the displacement generated by the Coriolis force, thereby increasing the TFG’s mechanical sensitivity. This approach was evaluated using both theoretical modeling and finite element analysis (FEA), and the results showed a high degree of agreement between the two methods. A conventional TFG having a comparable area was also designed and analyzed for comparison purposes. By introducing the displacement amplification mechanism, the proposed MEMS TFG design provides an output displacement about 2.5 times higher than the conventional design, according to the computation, without increasing the device footprint. Theoretical analysis and FEA on the TFG with amplification and a conventional TFG confirmed that the amplified displacement significantly improves the mechanical sensitivity of the gyroscope compared to conventional TFG designs. Full article

According to South Korea’s Ministry of Employment and Labor, approximately 25,000 construction workers suffered from various injuries between 2015 and 2019. Additionally, about 500 fatalities occur annually, and multiple studies are being conducted to prevent these accidents and quickly identify their occurrence to secure the golden time for the injured. Recently, AI-based video analysis systems for detecting safety accidents have been introduced. However, these systems are limited to areas where CCTV is installed, and in locations like construction sites, numerous blind spots exist due to the limitations of CCTV coverage. To address this issue, there is active research on the use of MEMS (micro-electromechanical systems) sensors to detect abnormal conditions in workers. In particular, methods such as using accelerometers and gyroscopes within MEMS sensors to acquire data based on workers’ angles, utilizing three-axis accelerometers and barometric pressure sensors to improve the accuracy of fall detection systems, and measuring the wearer’s gait using the x-, y-, and z-axis data from accelerometers and gyroscopes are being studied. However, most methods involve use of MEMS sensors embedded in smartphones, typically attaching the sensors to one or two specific body parts. Therefore, in this study, we developed a novel miniaturized IMU (inertial measurement unit) sensor that can be simultaneously attached to multiple body parts of construction workers (head, body, hands, and legs). The sensor integrates accelerometers, gyroscopes, and barometric pressure sensors to measure various worker movements in real time (e.g., walking, jumping, standing, and working at heights). Additionally, incorporating PPG (photoplethysmography), body temperature, and acoustic sensors, enables the comprehensive observation of both physiological signals and environmental changes. The collected sensor data are preprocessed using Kalman and extended Kalman filters, among others, and an algorithm was proposed to evaluate workers’ safety status and update health-related data in real time. Experimental results demonstrated that the proposed IMU sensor can classify work activities with over 90% accuracy even at a low sampling rate of 15 Hz. Furthermore, by integrating internal filtering, communication modules, and server connectivity within an application, we established a cyber–physical system (CPS), enabling real-time monitoring and immediate alert transmission to safety managers. Through this approach, we verified improved performance in terms of miniaturization, measurement accuracy, and server integration compared to existing commercial sensors. Full article

The scale factor of thermal sensitivity serves as a crucial performance metric for micro-electromechanical system (MEMS) gyroscopes, and is commonly employed to assess the temperature stability of inertial sensors. To improve the temperature stability of the scale factor of MEMS gyroscopes, a self-compensation method is proposed. This is achieved by integrating the primary and secondary relevant parameters of the scale factor using the partial least squares regression (PLSR) algorithm. In this paper, a scale factor prediction model is presented. The model indicates that the resonant frequency and demodulation phase angle are the primary correlation terms of the scale factor, while the drive control voltage and quadrature feedback voltage are the secondary correlation terms of the scale factor. By employing a weighted fusion of correlated terms through PLSR, the scale factor for temperature sensitivity is markedly enhanced by leveraging the predicted results to compensate for the output. The results indicate that the maximum error of the predicted scale factor is 0.124% within the temperature range of −40 °C to 60 °C, and the temperature sensitivity of the scale factor decreases from 6180 ppm/°C to 9.39 ppm/°C. Full article

The micro disk resonator gyroscope is a micro-mechanical device with potential for navigation-grade applications, where the performance is significantly influenced by the quality factor, which is determined by various energy dissipation mechanisms within the micro resonant structure. To enhance the quality factor, these gyroscopes are typically enclosed in high-vacuum packaging. This paper investigates a wafer-level high-vacuum-packaged (<0.1 Pa) cobweb-like disk resonator gyroscope, presenting a systematic and comprehensive theoretical analysis of the energy dissipation mechanisms, including air damping, thermoelastic damping, anchor loss, and other factors. Air damping is analyzed using both a continuous fluid model and an energy transfer model. The analysis results are validated through quality factor testing on batch samples and temperature characteristic testing on individual samples. The theoretical results obtained using the energy transfer model closely match the experimental measurements, with a maximum error in the temperature coefficient of less than 2%. The findings indicate that air damping and thermoelastic damping are the predominant energy dissipation mechanisms in the cobweb-like disk resonant gyroscope under high-vacuum conditions. Consequently, optimizing the resonator to minimize thermoelastic and air damping is crucial for designing high-performance gyroscopes. Full article

As the core component of the all-metal micro resonant gyroscope, the structural parameters and form and position errors of the resonator significantly influence its vibration characteristics, and consequently, the accuracy of the gyroscope. By establishing the finite element model of an ideal hemispherical resonator and optimizing the meshing method, we refined the frequency difference to 0.1 Hz, enhancing the accuracy of the simulation model. Through finite element simulation, we examined the impact of various structural parameters and processing errors on the natural frequencies of each mode. We analyzed how form and position errors, including shell thickness error, central axis error, equatorial plane error, and edge rectangular tooth position error, affect the frequency splitting of the resonator. We provided optimization suggestions for the structural parameters, ensuring frequency splitting variations of less than 1 Hz. Theoretical modeling and simulation analysis indicated that the primary factors influencing the vibration modes and frequency splitting are the rectangular tooth structure and shell thickness. Following the optimized parameters, the frequency splitting of the All-Metal Micro Resonant Hemisphere was reduced by an order of magnitude to 14 Hz, demonstrating that these optimized conditions can significantly enhance the resonator’s performance. Full article

This paper introduces a methodology to compensate inertial Micro-Electro-Mechanical System (IMU-MEMS) time-varying calibration loss, induced by stress and aging. The approach relies on a periodic assessment of the sensor through specific stimuli, producing outputs which are compared with the response of a high-precision sensor, used as ground truth. At any re-calibration iteration, differences with respect to the ground truth are approximated by quantization-aware trained tiny neural networks, allowing calibration-loss compensations. Due to the unavailability of aging IMU-MEMS datasets, a synthetic dataset has been produced, taking into account aging effects with both linear and nonlinear calibration loss. Also, field-collected data in conditions of thermal stress have been used. A model relying on Dense and 1D Convolution layers was devised and compensated for an average of 1.97 g and a variance of 1.07 g², with only 903 represented with 16 bit parameters. The proposed model can be executed on an intelligent signal processing inertial sensor in 126.4 ms. This work represents a step forward toward in-sensor machine learning computing through integrating the computing capabilities into the sensor package that hosts the accelerometer and gyroscope sensing elements. Full article

Autonomous Underwater Vehicles (AUVs) are widely used for hydrological monitoring, underwater exploration, and geological surveys. However, AUVs face limitations in underwater navigation due to the high costs associated with Strapdown Inertial Navigation System (SINS) and Doppler Velocity Log (DVL), hindering the development of low-cost vehicles. Micro Electro Mechanical System Inertial Measurement Units (MEMS IMUs) are widely used in industry due to their low cost and can output acceleration and angular velocity, making them suitable as an Attitude Heading Reference System (AHRS) for low-cost vehicles. However, poorly calibrated MEMS IMUs provide an inaccurate angular velocity, leading to rapid drift in orientation. In underwater environments where AUVs cannot use GPS for position correction, this drift can have severe consequences. To address this issue, this paper proposes Underwater Gyros Denoising Net (UGDN), a method based on dilated convolutions and LSTM that learns and extracts the spatiotemporal features of IMU sequences to dynamically compensate for the gyroscope’s angular velocity measurements, reducing attitude and heading errors. In the experimental section of this paper, we deployed this method on a dataset collected from field trials and achieved significant results. The experimental results show that the accuracy of MEMS IMU data denoised by UGDN approaches that of fiber-optic SINS, and when integrated with DVL, it can serve as a low-cost underwater navigation solution. Full article

To enhance the performance of micro-hemispherical gyroscopes, achieving low-damage and high-surface-quality trimming is essential. This enables greater stability and reliability for the gyroscopes. Current methods for reducing frequency split often come with drawbacks such as high cost, adverse effects on the Q-factor, or surface damage. In this paper, a chemical etching trimming method is proposed to reduce frequency split in micro-hemispherical resonators. This method allows for trimming with minimal damage, while also being cost-effective and easy to implement. The theoretical basis of this method was analyzed, followed by a simulation to determine the optimal trimming range and location on the resonator. The simulated Q-factor analysis before and after trimming preliminarily validated the method’s low-damage characteristics. Ultimately, the frequency split of the resonator was reduced to below 1 Hz. Additionally, test results of the Q-factor and surface quality before and after trimming further confirmed that chemical etching offers effective low-damage trimming capabilities. The proposed method holds significant potential for improving the performance of micro-hemispherical resonator gyroscopes. Full article

A derailment detection algorithm for railway freight cars based on micro inertial measurement units was designed to address the complex issue of the disassembly and assembly of derailment braking devices. Firstly, a horizontal attitude measurement model for freight cars was established, and attitude measurement algorithms based on gyroscopes and accelerometers were introduced. Subsequently, a high-precision attitude measurement algorithm based on variational Bayesian Kalman filtering was proposed, which used acceleration information as the observation data to correct attitude errors. In order to improve the accuracy of derailment detection, a dual-model instantaneous attitude difference measurement technique was further proposed. In order to verify the effectiveness of the algorithm, offline data from simulation experiments and in-vehicle experiments were used to validate the proposed algorithm. The results showed that the proposed algorithm can effectively improve the measurement accuracy of horizontal attitude changes, reducing the error by 89% compared to pure inertial attitude calculation, laying a technical foundation for improving the accuracy of derailment detection. Full article

Micro-electro-mechanical systems inertial measurement units (MEMS-IMUs) are increasingly being employed for measuring the attitude of bottom hole assemblies (BHAs). However, the reliability and measurement precision of a single MEMS-IMU may not meet drilling’s stringent needs. Redundant MEMS-IMU systems can effectively enhance the reliability and precision. This paper proposes a redundant configuration method for MEMS sensors tailored to BHA attitude measurement. Firstly, based on reliability theory and a cost-benefit analysis, considering factors such as cost, size, and reliability, the optimal number of sensors in the redundant system was determined to be six. Considering the structural characteristics of the BHA, a hollow hexagonal prism-shaped redundant configuration scheme was proposed, ensuring the circulation of drilling fluid within the drill pipe. Next, by employing Kalman filtering to integrate the output data from the six sensors, a virtual IMU (VIMU) was formed. Finally, experimental verification was carried out. The results confirmed that, after redundancy implementation, the velocity random walk of the accelerometer decreased by an average of 58% compared to a single MEMS-IMU, and bias instability was reduced by an average of 54%. The angular random walk of the gyroscope decreased by an average of 58%, and bias instability was reduced by an average of 37%. This research provides a theoretical foundation for enhancing the precision and reliability of BHA attitude measurements. Full article

Vibrational environments can cause drift or changes in Micro-Electro-Mechanical System (MEMS) gyroscope rotor parameters, potentially impacting their performance. To improve the effective use of MEMS gyroscopes, this study introduced a method for evaluating the reliability of parameter degradation under vibration. We analyzed the working principle of MEMS gyroscope rotors and investigated how vibration affects their parameters. Focusing on zero bias and scale factor as key performance indicators, we developed an accelerated degradation model using the distributional assumption method. We then collected degradation data for these parameters under various vibration conditions. Using the Copula function, we established a reliability assessment approach to evaluate the degradation of the MEMS gyroscope rotor’s zero bias and scale factor under vibration, enabling the determination of reliability for these parameters. Experimental findings confirmed that increasing stress levels lead to reduced failure times and increased failure rates for MEMS gyroscope rotors, with significant changes observed in the zero bias parameter. Our evaluation method effectively characterizes changes in the reliability of the MEMS gyroscope rotor’s scale factor and zero bias over time, providing valuable information for practical applications of MEMS gyroscopes. Full article

While the availability of low-cost micro electro-mechanical systems (MEMS) accelerometers, gyroscopes, and magnetometers initially seemed to promise the possibility of using them to easily track the position and orientation of virtually any object that they could be attached to, this promise has not yet been fulfilled. Navigation-grade accelerometers and gyroscopes have long been the basis for tracking ships and aircraft, but the signals from low-cost MEMS accelerometers and gyroscopes are still orders of magnitude poorer in quality (e.g., bias stability). Therefore, the applications of MEMS inertial measurement units (IMUs), containing tri-axial accelerometers and gyroscopes, are currently not as extensive as they were expected to be. Even the addition of MEMS tri-axial magnetometers, to conform magnetic, angular rate, and gravity (MARG) sensor modules, has not fully overcome the challenges involved in using these modules for long-term orientation estimation, which would be of great benefit for the tracking of human–computer hand-held controllers or tracking of Internet-Of-Things (IoT) devices. Here, we present an algorithm, GMVDμK (or simply GMVDK), that aims at taking full advantage of all the signals available from a MARG module to robustly estimate its orientation, while preventing damaging overcorrections, within the context of a human–computer interaction application. Through experimental comparison, we show that GMVDK is more robust to magnetic disturbances than three other MARG orientation estimation algorithms in representative trials. Full article
