Compression via pressure waves is an effective but specific way of compressing gases. This paper presents a broad overview of work related to the use of unsteady processes in the construction of micro-engines. The main advantages of wave rotors, such as a low rotor speed, self-cooling channels, high compression in a single stage, and the possibility of operating at a very small geometric scale, are addressed, and their disadvantages, such as the requirement of the precise synchronization of wave processes and poor torque-generation properties, are also outlined. This review highlights the possibility of operating at a geometric scale, which conventional solutions have failed to achieve. In the thermodynamic cycle of a micro-engine, a compression process carried out in an unsteady manner is superior in efficiency to stationary solutions. On the contrary, in the expansion process, fluid inertia is an obstacle to the full utilization of the thermal energy transferred to the fluid in the combustion chamber. The best solution is, therefore, a favorable combination of both features, leading to unsteady compression and steady-state expansion in the heat engine cycle. This article presents an overview of the existing technical solutions and published research results devoted to the construction of pressure wave compression micro-engines: patents, scientific publications describing various research methods, numerical calculations, and the experimental results of unusual technical solutions. Characteristic solutions and problems arising in the development of these methods, which range from superchargers to autonomous engines, are presented and discussed. Directions for further research are suggested. Full article

The current study proposes a novel design configuration of a hydrogen-fueled micro cylindrical combustor. The newly developed design consists of a single-channel inlet and a double-channel outlet with a heat-recirculating structure aimed at enhancing the heat transfer mechanism from the combustion to the walls. Investigations are conducted using three-dimensional numerical simulation means, and emphasis is placed on assessing the effects of the novel design structure on key thermal parameters and nitrogen oxide (NO_x) emissions. The numerical modeling approach is first validated against the experimental and numerical data available in the literature. A parametric study is then conducted by means of varying the length and width of the heat-recirculating channel, inlet velocity, and inlet equivalence ratio. The findings revealed that the novel design configuration significantly improves thermal performance and curtails NO_x emissions in comparison with those of the conventional structure. For example, the proposed design leads the radiation efficiency to increase by roughly 10%. The increase in the width of the preheating channel yields further optimization by boosting the heat transfer process from the flame to the walls. Elevating the inlet velocity exhibits a pronounced increase in the mean wall temperature and a more uniform distribution of the wall temperature. However, the exhaust gas temperature increases with increasing inlet velocity, leading to a reduction in the exergy and radiation efficiencies. The equivalence ratio of unity optimizes key thermal parameters, as the lean and rich conditions suffer from low hydrogen and oxygen contents, respectively. Full article

Understanding and improving the performance of miniature devices powered by micro-combustion have been the focus of continued attention of researchers recently. The goal of the present work is to investigate the behavior of premixed methane–air combustion in a quartz microreactor with an externally controlled wall temperature. Specifically, the impacts of the flow inlet velocity, the equivalence ratio, and the microreactor channel size are examined. This study is conducted by means of computational simulations, and the results are validated against prior experimental data, as well as by other similar studies in the literature. Utilizing simulation results with detailed chemistry, the present work provides more in-depth insight into a variety of phenomena, such as ignition, flame propagation, flames with repetitive extinctions and ignitions (FREI), and flame stabilization. In particular, the ignition, the flame span, and the FREI-related characteristics are scrutinized to understand the underlying physics of the flame stability/instability modes. It is shown that the flames appear stable at higher inlet velocities, while the FREI mode is detected at a lower inlet velocity, depending on the equivalence ratio and the channel size. The findings also explain how different operating conditions impact the flame characteristics in both stability modes. Full article

As the demand for powerful, light energy sources continues to grow, traditional electrochemical batteries are no longer sufficient and combustion-based power generation devices have become an attractive alternative due to their high energy density, compact size, fast recharging time and long service life. While most research on miniature-scale combustors has focused on gaseous fuels, the use of commonly available liquid fuels has the potential to be highly portable and economical. However, the complexity of droplet atomization, evaporation, mixing and burning in a limited volume and short residence time has presented significant challenges for researchers. This review focuses on various methodologies proposed by researchers (like flow burring injector, fuel film injection, injecting into porous media, electrospray and some self-aspirating designs) to overcome these challenges, the combustion behaviour and different instabilities associated with liquid fuels at small scales. The current review intends to present a clear direction to channel the efforts made by researchers to overcome the difficulties associated with liquid fuel combustion at small scales for power generation applications. Additionally, this review aims to give an overview of power systems at the micro and meso scales that operate using liquid fuels. The methodologies introduced like electrospray requires external power, which again makes the system complex. Towards the development of standalone type power generators, the self-aspirating design which makes use of hydrostatic pressure, fuel film injection or taking advantage of exhaust gas enthalpy to preheat and evaporate the liquid fuel are the promising methodologies. Full article

Unmanned aerial vehicles (UAV)s have unique requirements that demand engines with high power-to-weight ratios, fuel efficiency, and reliability. As such, combustion engines used in UAVs are specialized to meet these requirements. There are several types of combustion engines used in UAVs, including reciprocating engines, turbine engines, and Wankel engines. Recent advancements in engine design, such as the use of ceramic materials and microscale combustion, have the potential to enhance engine performance and durability. This article explores the potential use of combustion-based engines, particularly microjet engines, as an alternative to electrically powered unmanned aerial vehicle (UAV) systems. It provides a review of recent developments in UAV engines and micro combustors, as well as studies on flame stabilization techniques aimed at enhancing engine performance. Heat recirculation methods have been proposed to minimize heat loss to the combustor walls. It has been demonstrated that employing both bluff-body stabilization and heat recirculation methods in narrow channels can significantly improve combustion efficiency. The combination of flame stabilization and heat recirculation methods has been observed to significantly improve the performance of micro and mesoscale combustors. As a result, these technologies hold great promise for enhancing the performance of UAV engines. Full article

This paper presents an experimental study investigating the effects of water-in-gasoline emulsion (WiGE) on the performance and emissions of a turbocharged PFI spark-ignition engine. The emulsions were produced through a micro-channels emulsifier, potentially capable to work inline, without addition of surfactants. Measurements were performed at a 3000 rpm speed and net Indicated Mean Effective Pressure (IMEP) of 16 bar: the engine point representative of commercial ECU map was chosen as reference. In this condition, the engine, fueled with gasoline, runs overfueled (λ = 0.9) to preserve the integrity of the turbocharger from excessive temperature, and the spark timing corresponds to the knock limit. Starting from the reference point, two different water contents in emulsion were tested, 10% and 20% by volume, respectively. For each selected emulsion, at λ = 0.9, the spark timing was advanced from the reference point value to the new knock limit, controlling the IMEP at a constant level. Further, the cooling effect of water evaporation in WiGE allowed it to work at stoichiometric condition, with evident benefits on the fuel economy. Main outcomes highlight fuel consumption improvements of about 7% under stoichiometric mixture and optimized spark timing, while avoiding an excessive increase in turbine thermal stress. Emulsions induce a slight worsening in the HC emissions, arising from the relative impact on combustion development. On the other hand, at stoichiometric condition, HC and CO emissions drop with a corresponding increase in NO. Full article

Thermoelectric generators are devices that harvest waste heat and convert it into useful power. They are considered as an additional power source in the domestic sector, but they can also be installed in off-grid objects. In addition, they are a promising solution for regions where there is a lack of electricity. Since biomass heating and cooking stoves are widely used, it is very appropriate to integrate thermoelectric generators with wood-fired stoves. This paper shows the experimental analysis of a micro-cogeneration system equipped with a wood-fired stove and two prototypical constructions of thermoelectric generators dedicated to mounting on the flue gas channel. The first version was equipped with one basic thermoelectric module and used to test various cooling methods, while the second construction integrated four basic thermoelectric modules and a water-cooling system. During the tests conducted, the electricity generated in the thermoelectric generators was measured by the electronic load, which allowed the simulation of various operating conditions. The results obtained confirm the possibility of using thermoelectric generators to generate power from waste heat resulting from the wood-fired stove. The maximum power obtained during the discussed combustion process was 15.4 W (if this value occurred during the entire main phase, the energy generated would be at a level of approximately 30 Wh), while the heat transferred to the water was ca. 750 Wh. Furthermore, two specially introduced factors (CPC and CPTC) allowed the comparison of developed generators, and the conclusion was drawn that both developed constructions were characterized by higher CPC values compared to available units in the market. By introducing thermoelectric modules characterized by higher performance, a higher amount of electricity generated may be provided, and sufficient levels of current and voltage may be achieved. Full article

With the rapid development of portable devices and micro-small sensors, the demand for small-scale power supplies and high-energy-density energy supply systems is increasing. Comparing with the current popular lithium batteries, micro-scale burners based on micro-thermal photoelectric systems have features of high power density and high energy density, the micro-scale burner is the most critical part of the micro-thermal photovoltaic system. In this paper, the combustor was designed as a heat cycle structure and filled with porous media to improve the combustion characteristics of the micro combustor. In addition, the influence of the porous media distribution on the burner center temperature and wall temperature distribution were studied through numerical simulation. Furthermore, the temperature distribution of the combustor was studied by changing the porous media parameters and the wall parameters. The research results show that the heat cycle structure can reduce heat loss and improve combustion efficiency. When the combustion chamber is filled with porous media, it makes the radial center temperature rise by about 50 K and the temperature distribution more uniform. When filling the heat cycle channel with porous media the wall temperature can be increased. Finally, the study also found that as methane is combusted in the combustor, the temperature of the outer wall gradually increases as the intake air velocity increases. The results of this study provide a theoretical and practical basis for the further design of high-efficiency combustion micro-scale burners in the future. Full article

Due to increasing demand for clean and green energy, a need exists for fuels with low emissions, such as synthetic gas (syngas), which exhibits excellent combustion properties and has demonstrated promise in low-emission energy production, especially at microscales. However, due to complicated flame properties in microscale systems, it is of utmost importance to describe syngas combustion and comprehend its properties with respect to its boundary and inlet conditions, and its geometric characteristics. The present work studied premixed syngas combustion in a two-dimensional channel, with a length of 20 mm and a half-width of 1 mm, using computational approaches. Specifically, a fixed temperature gradient was imposed at the upper wall, from 300 K at the inlet to 1500 K at the outlet, to preheat the mixture, accounting for the conjugate heat transfer through the walls. The detailed chemistry of the ignition process was imitated using the San Diego mechanism involving 46 species and 235 reactions. For the given boundary conditions, stoichiometric premixed syngas containing various compositions of carbon monoxide, methane, and hydrogen, over a range of inlet velocities, was simulated, and various combustion phenomena, such as ignition, flame stabilization, and flames with repeated extinction and ignition (FREI), were analyzed using different metrics. The flame stability and the ignition time were found to correlate with the inlet velocity for a given syngas mixture composition. Similarly, for a given inlet velocity, the correlation of the flame properties with respect to the syngas composition was further scrutinized. Full article

A three-dimensional CFD model of a novel configuration of catalytic micro-combustor inspired by the nasal geometry of reindeer was developed using the commercial code ANSYS Fluent 19.0. The thermal behavior of this nature-inspired (NI) configuration was investigated through simulations of lean propane/air combustion performed at different values of residence time (i.e., inlet gas velocity) and (external convective) heat transfer coefficient. Simulations at the same conditions were also run for a standard parallel-channel (PC) configuration of equivalent dimensions. Numerical results show that the operating window of stable combustion is wider in the case of the NI configuration. In particular, the blow-out behavior is substantially the same for the two configurations. Conversely, the extinction behavior, which is dominated by competition between the heat losses towards the external environment and the heat produced by combustion, differs. The NI configuration exhibits a greater ability than the PC configuration to keep the heat generated by combustion trapped inside the micro-reactor. As a consequence, extinction occurs at higher values of residence time and heat transfer coefficient for this novel configuration. Full article

Improving the flame stability and thermal behavior of the micro-combustor (MC) are major challenges in microscale combustion. In this paper, the micro combustions of an H₂/air premixed flame in a swirl MC with various channel diameters (D_in = 2, 3, 4 mm) were analyzed based on an established three-dimensional numerical model. The effects of hydrogen mass flow rate, thermal conductivity of walls, and the preferential transport of species were investigated. The results indicated that the flame type was characterized by the presence of two recirculation zones. The flame was anchored by the recirculation zones, and the anchoring location of the flame root was the starting position of the recirculation zones. The recirculation zones had a larger distribution of local equivalence ratio, especially in the proximity of the flame root, indicating the formation of a radical pool. The combustion efficiency increased with an increasing D_in due to the longer residence time of the reactants. Furthermore, the MC with D_in = 2 mm obtained the highest outer wall temperature distribution. However, the MC with D_in = 4 mm had a better uniformity of outer wall temperature and large emitter efficiency due to the larger radiation surface. An increase in thermal conductivity boosts the thermal performance of combustion efficiency, emitter efficiency, and wall temperature uniformity. But there is a critical point of thermal conductivity that can increase the thermal performance. The above results can offer us significant guidance for designing MC with high thermal performance. Full article

While there has been some recognition regarding the impact of thermal boundary conditions (adiabatic versus isothermal) on premixed flame propagation mechanisms in micro-channels (hydraulic diameters <10 mm), their impact in macro-channels has often been overlooked due to small surface-area-to-volume ratios of the propagating combustion wave. Further, the impact of radiative losses has also been neglected due to its anticipated insignificance based on scaling analysis and the high computational cost associated with resolving it’s spatial, temporal, directional, and wavelength dependencies. However, when channel conditions promote flame acceleration and deflagration-to-detonation transitions (DDT), large pressures are encountered in the vicinity of the combustion wave, thereby increasing the magnitude of radiative losses which in turn can impact the strength and velocity of the combustion wave. This is demonstrated for the first time through simulations of lean (equivalence ratio: 0.5) hydrogen-air mixtures in a macro-channel (hydraulic diameter: 174 mm) with obstacles (Blockage ratio: 0.51). By employing Planck mean absorption coefficients in conjunction with the P-1 radiation model, radiative losses are shown to affect the run-up distances to DDT in a long channel (length: 11.878 m). As anticipated, the differences in run-up distances resulting from radiative losses only increased with system pressure. Full article

The present article deals with the design of a micro turbogas turbine suitable for on board applications, e.g., as a power generator on hybrid transit bus, characterized by a simple constructive approach. Deriving the machine layout from an existing KJ-66 aircraft model engine, the authors propose a theoretical design of a compact, lightweight turbogas turbine, by investigating the technical possibility and limits of the proposed design. In particular, a different combustion chamber layout has been proposed, and fuel adduction channels for different swirler designs have been simulated via ANSYS Fluent in order to identify a satisfactory fuel spreading. As a result, the complete characterization of the design parameters and geometries has been performed, and a series of RANS simulations has been used in order to identify an optimal swirler configuration. Full article
