We propose and demonstrate an integrated optical switch that leverages an optical phased array (OPA) and an on-chip metalens, highlighting its potential for efficient and scalable beam switching across multiple ports within a compact footprint. The device consists of an input multimode interference (MMI) coupler, a phase modulator (PM) array, a beam-transformation region featuring an on-chip metalens layer, and a tapered waveguide array serving as the output ports. The PM array, engineered to effectively manipulate multiple phases for a waveguide array using a single voltage, utilizes metal strips of varying lengths to streamline operation. The on-chip metalens, characterized by varying slot lengths, facilitates the wavefront manipulation of the fast Fourier transform, resulting in beam deflection with a focusing length of 20 µm. The simulated validation of the proposed compact optical switch demonstrated efficient beam deflection, yielding a 1 × 8 beam switching at a wavelength of 1550 nm. Combinations of diverse OPAs and metalens configurations resulted in potential scalability, allowing for the realization of optical switches with pathway numbers ranging from 4 to 16. This development of a metalens-assisted optical switch on a compact chip presents significant practical implications for enhancing data transmission efficiency and scalability in photonic integrated circuits. Full article

Buttcoupling is the most efficient way to excite surface plasmon polariton (SPP) waves at dielectric/metal interfaces in order to realize applications in broadband and ultra-compact integrated circuits (IOCs). We propose a reasonable waveguide structure to efficiently excite and collect the SPP waves supported in a plasmonic trench waveguide in the long-haul telecommunication wavelength range. Our simulation results show that the coupling efficiency between the dielectric strip waveguides and a plasmonic trench waveguide can be optimized, which is dominated by the zigzag propagation path length in the dielectric strip loaded on the metal substrate. It is noted that nearly a 100% coupling efficiency can be achieved when the distance between the excitation source and the plasmonic waveguide is about 6.76 μm. Full article

A low-profile planar millimeter-wave (MMW) folded dipole antenna fed by substrate integrated waveguide (SIW) is proposed in this letter. By etching the gaps at the proper position of 1.5λ dipole, an additional resonant mode is generated. Accordingly, the working bandwidth is greatly broadened. In addition, by appropriately adjusting the length of the dual-side parallel strip line (DSPSL), the radiated electric fields generated by the aperture of the feeding SIW and the connecting metallic vias of the folded dipole are designed with an out-of-phase potential. Hence, the cross-polarization of the presented folded dipole antenna is improved as well. As a demonstration, a prototype is fabricated and measured. The experimental results exhibit that the proposed folded dipole has a −10 dB impedance bandwidth of 58.5% (from 30.3 GHz to 53.7 GHz), a gain of around 5 dBi with more than 120 degrees beamwidth in H-plane, and a cross-polarization levels below −15 dB, covering the working frequency band. Compared with the up-to-date planar dipole antenna, the proposed folded dipole achieves the widest working bandwidth and low cross-polarization level. The proposed antenna can be used as the terminal antenna of the MMW communication system. Full article

Metamaterial analogues of electromagnetically induced transparency (EIT) enable a unique avenue to endow a coupled resonator system with quantum interference behavior, exhibiting remarkable properties in slow-wave and highly sensitive sensing. In particular, tunable and ultracompact-chip-integrated EIT-like effects reveal fantastic application prospects in plasmonic circuits and networks. Here, we demonstrate an electrically tuned on-chip EIT analogue by means of dynamic EIT modules side-coupled to ultrathin corrugated metallic strips supporting spoof surface plasmon polaritons (SSPPs). By embedding PIN diodes into the subradiant mode, on-to-off control of the destructive coupling between the radiative and subradiant modes results in dynamic chip-scale EIT-like behavior under the change of the bias voltage, allowing for an electrically tunable group delay of the surface waves. The physical mechanism of the active modulation is elucidated with the coupled mode theory. In addition, the cascaded capacity performed by installing multiple EIT modules with an interval of equivalent wavelength are also characterized on a planar plasmonic waveguide. The proposed system will pave a versatile route toward dynamic control in chip-scale functional devices. Full article

This paper proposes a coplanar waveguide (CPW)-fed semiloop antenna with switchable linear polarization and radiation pattern. This design uses a novel asymmetric coplanar strip line (ACPS) circular ring to produce even or odd modes of the CPW, which can generate vertical or horizontal polarization in the semiloop antenna. The modes of the ACPS circular ring can be switched by controlling the on/off state of the PIN diode, and only a two-bit control signal is required to select the operating mode. The proposed polarization switchable antenna uses only one metal layer of the printed circuit board. The center frequency of the dual-polarization antenna was determined to be 2.45 GHz, and the −10 dB impedance bandwidths were determined to be 12.86% and 4.92% for vertical and horizontal polarization, respectively. The antenna parameters, such as the return loss, gain, and radiation patterns, are also presented for validating the proposed design. Full article

Plasmonic chemical and biological sensors offer significant advantages such as really compact sizes and extremely high sensitivity. Biosensors based on plasmonic waveguides and resonators are some of the most attractive candidates for mobile and wearable devices. However, high losses in the metal and complicated schemes for practical implementation make it challenging to find the optimal configuration of a compact plasmon biosensor. Here, we propose a novel plasmonic refractive index sensor based on a metal strip waveguide placed under a waveguide-based racetrack ring resonator made of the same metal. This scheme guarantees effective coupling between the waveguide and resonator and low loss light transmittance through the long-range waveguide. The proposed device can be easily fabricated (e.g., using optical lithography) and integrated with materials like graphene oxide for providing adsorption of the biomolecules on the sensitive part of the optical elements. To analyze the properties of the designed sensing system, we performed numerical simulations along with some analytical estimations. There is one other interesting general feature of this sensing scheme that is worth pointing out before looking at its details. The sensitivity of the considered device can be significantly increased by surrounding the resonator with media of slightly different refractive indices, which allows sensitivity to reach a value of more than 1 μm per refractive index unit. Full article

In this paper, based on coupled hetero-cavities, multiple Fano resonances are produced and tuned in a plasmonic metal-insulator-metal (MIM) system. The structure comprises a rectangular cavity, a side-coupled waveguide, and an upper-coupled circular cavity with a metal-strip core, used to modulate Fano resonances. Three Fano resonances can be realized, which originate from interference of the cavity modes between the rectangular cavity and the metal-strip-core circular cavity. Due to the different cavity-cavity coupling mechanisms, the three Fano resonances can be divided into two groups, and each group of Fano resonances can be well tuned independently by changing the different cavity parameters, which can allow great flexibility to control multiple Fano resonances in practice. Furthermore, through carefully adjusting the direction angle of the metal-strip core in the circular cavity, the position and lineshape of the Fano resonances can be easily tuned. Notably, reversal asymmetry takes place for one of the Fano resonances. The influence of the direction angle on the figure of merit (FOM) value is also investigated. A maximum FOM of 3436 is obtained. The proposed structure has high transmission, sharp Fano lineshape, and high sensitivity to change in the background refractive index. This research provides effective guidance to tune multiple Fano resonances, which has important applications in nanosensors, filters, modulators, and other related plasmonic devices. Full article
