Shallow geothermal energy (SGE), as an important renewable energy, playing an important role in reducing carbon emissions. In order to efficiently and sustainably utilize SGE, field investigation and storage estimation are needed. In this study, the hydrogeological data obtained from the field exploration of Jinan Start-up Area were collected and compiled. By analyzing the geotechnical property data and thermal response test results, the information of geotechnical and thermal properties and underground temperature distribution characteristics were collected. Subsequently, the analytic hierarchy process (AHP) combined with the comprehensive index method (CIM) were used to classify the shallow geothermal potential of Jinan Start-up Area. The entire area was divided into a high-potential area, medium-potential area and general area, of which 92.2% was high-potential area. The preliminary results, combined with the parameters obtained from the testing, indicate that the SGE storage at a borehole depth of 120 m is estimated to be approximately 2.68 × 10¹² kJ·K⁻¹, while the heat exchanger power of the buried pipe at the same depth is calculated to be around 1.73 × 10⁵ kW. Finally, suggestions are given for sustainable development and utilization of SGE in this area. Full article

Medium-deep borehole heat exchangers (MBHEs) have received increasing attention with respect to building heating. To avoid the thermal interference of adjacent MBHEs, the temperature distribution characteristics of medium-deep rock soil were investigated in this work. The evolution of the maximum rock-soil thermal affected radius (MTAR) over a full lifecycle was analyzed. The results showed that the rock-soil thermal affected area (RTAA) continuously expanded in both the radial and vertical directions when the MBHE continuously extracted geothermal energy during a heating season. The factors of the thermal extraction load, fluid velocity, geothermal gradient, and pipe length, impacted the RTAA in the vertical direction, while rock-soil thermal conductivity affected the RTAA in both the radial and vertical directions. Furthermore, the thermal affected radius (TAR) in deeper formations was larger, reaching even 96 m, such that thermal interference between adjacent MBHEs was more likely to occur. The MTAR in shallow formations was limited to 20 m. Consequently, a new layout form, achieved by inclining the borehole, was proposed to increase the distance between adjacent MBHEs in deep formations. The recommended incline angle was equal to or larger than four times the TAR angle. This work provides a scientific reference for promoting the application of multiple MBHE arrays. Full article

Medium-shallow borehole ground heat exchangers (BGHEs) utilize a burial depth ranging from 200 to 600 m. The heat exchange capacity of a single medium-shallow BGHE is higher than that of a single shallow BGHE. Compared to medium-deep BGHEs, the cost of medium-shallow BGHEs is lower, and both heating and cooling can be achieved, while the former can only be used for heating. However, there is a relative lack of research on the heat transfer characteristics of medium-shallow BGHEs, especially on the influence of the working fluid type on the heat transfer performance of BGHEs. This study aimed to investigate the impact of different working fluids on the performance of medium-shallow BGHEs. First, a heat transfer model for medium-shallow BGHEs was established considering the ground temperature gradient and geothermal heat flow, and its accuracy was validated using experimental test data. Second, the model was used to compare and analyze the effects of various working fluids on the heat transfer performance, pressure loss, and potential environmental benefits of BGHEs. Based on economic analysis, CO₂ was determined to be the most suitable working fluid among the organic fluids considered. Finally, the influence of the number of boreholes and the type of working fluid on the heat transfer performance of borehole clusters consisting of 2 and 4 boreholes was analyzed using the superposition principle. The results indicated that CO₂ could provide the highest heat transfer among the various working fluids selected in this study, as its heat extraction and heat dissipation were approximately 15% and 12% higher than those achieved by water. Isobutane (R600a) achieved the highest net heat and emission reduction, surpassing water by 66.7% and 73.6%, respectively. Regarding the four boreholes, the outlet temperature of the BGHEs gradually decreased at the end of each heating season. After 10 years of operation, the value decreased by approximately 2 °C. The results in this paper provide a theoretical basis and technical guidance for the rational selection of working fluids and improvements in the heat transfer performance of BGHEs, which could promote the development and application of medium-shallow geothermal energy sources. Full article

Just as the double-pipe heat exchanger is being utilized in an increasing number of applications, its research content is also deepening. For this paper, based on the air-conditioning cold and heat source project of a building in Handan, Hebei Province, a 300-meter medium-shallow well double-pipe heat exchanger was used for heating and cooling, and a corresponding heat transfer model was established. The changes of parameters such as the inlet and outlet temperature, heat exchange (with and without a temperature gradient), and borehole wall temperature distribution between a single borehole, double boreholes, and four boreholes over one year in medium-shallow wells were simulated and analyzed. By comparing the obtained experimental data and the simulation data, the accuracy of the heat transfer model was verified. This provides a theoretical basis for the further advancement of the project and lays the foundation for an in-depth study of multi-borehole double-pipe heat exchangers. Full article

To contribute to the goal of carbon neutralization, the closed-loop borehole heat exchanger system is widely applied to use geothermal energy for building cooling and heating. In this work, a new type of medium-shallow borehole heat exchanger (MSBHE) is proposed, which is coaxial type and has a depth range between 200 m to 500 m. To investigate the long-term performance of MSBHE in the area with unbalanced cooling and heating load of buildings and the sustainable load imbalance ratio under different design parameters, a comprehensive numerical model is established. The results show that the drilling depth significantly influences the sustainable load imbalance ratio of MSBHE. As the drilling depth is increased from 200 m to 500 m, the load imbalance ratio of the MSBHE increases from 20.76% to 60.29%. In contrast, the load imbalance ratio is always kept at the same level with different inlet velocities and operation modes. Furthermore, in a 9-MSBHE array system, the heat exchanger located in the middle of the array has the lowest load imbalance ratio of 48.97%, which is 15.98% lower than the borehole in the edge location. This is caused by the significant influence of the shifted-load phenomenon among MSBHEs in an array system. The findings of the work imply that this newly proposed MSBHE can sustain a notable load imbalance ratio, which is particularly applicable to the areas with a strong imbalance of annual building load. Full article

Recently, the medium-depth geothermal heat pump systems (MD-GHPs) have been applied for space heating in China. Theoretically, the MD-GHPs use deep borehole heat exchangers (DBHEs) to extract heat from the medium-depth geothermal energy with the depth of 2~3 km, thus, improving the energy performance of whole systems obviously. This paper conducts field tests of nine conventional shallow-depth geothermal heat pump systems (SD-GHPs) and eight MD-GHPs to analyze the energy performance of heat pump systems, as well as heat transfer performance of ground heat exchangers. Then the comparative studies are carried out to analyze the difference between these two ground coupled heat pump systems. Field test results show that the outlet water temperature of DBHEs in MD-GHP can reach more than 30 °C with heat extraction of 195.2 kW~302.8 kW per DBHE with a depth of 2500 m, which are much higher than that of SD-GHPs. However, the heat pumps and water pumps in the ground side should be specially designed to fit the high-temperature heat source instead of following operation mode of SD-GHPs. Then with variable speed compressor which has high energy efficiency under a wide range of load rate and compressor ratio, and with the ground-side water pumps which efficiently operate under high water resistance and low flow rate, the COP of heat pumps and COP_s of whole systems could reach 7.80 and 6.46 separately. Thus, the advantage of high-temperature heat source could be fully utilized to achieve great energy-saving effects. Full article
