To break through the bottleneck in the mapping of the mechanoluminescent (ML) intensity field to the strain field, a quantification method for full-field strain measurement based on pixel-level data fusion is proposed, integrating ML imaging with digital image correlation (DIC) to achieve precise reconstruction of the strain field. Experiments are conducted using aluminum alloy specimens coated with ML film sensor on their surfaces. During the tensile process, ML images of the films and speckle images of the specimen backsides are simultaneously acquired. Combined with DIC technology, high-precision full-field strain distributions are obtained. Through spatial registration and region matching algorithms, a quantitative calibration model between ML intensity and DIC strain is established. The research results indicate that the ML intensity and DIC strain exhibit a significant linear correlation (R² = 0.92). To verify the universality of the model, aluminum alloy notched specimen tests show that the reconstructed strain field is in good agreement with the DIC and finite element analysis results, with an average relative error of 0.23%. This method enables full-field, non-contact conversion of ML signals into strain distributions with high spatial resolution, providing a quantitative basis for studying ML response mechanisms under complex loading. Full article

Rare earth and transition metal ion-doped CaZnOS has garnered significant attention for its exceptional mechanoluminescence (ML) performance under mild mechanical stimuli and its capability for multicolor emissions. Since powdered phosphors are not directly usable, they require encapsulation within with polymers to create stable structures. This study investigates Mn²⁺-doped CaZnOS (CaZnOS:Mn²⁺) as the ML phosphor, optimizing its performance by varying the Mn²⁺ content, resulting in bright orange-red emissions from the d-d transitions of the Mn²⁺ activator. A quantum efficiency of 59.08% was achieved through the self-sensitization of the matrix lattice and energy transfer to the Mn²⁺ luminescent centers. The enhancement in ML due to Mn²⁺ doping is attributed to the reduced trap depth and increased trap concentration. Encapsulation with four polymers—PDMS, PU, SIL, and RTV-2—was explored to further optimize ML performance. Among these, PDMS provides the best ML output and sensitivity, owing to its slightly cross-linked structure and good triboelectric properties. The optimized CaZnOS:0.03Mn²⁺/PDMS composite, featuring excellent flexibility and recoverability, shows great potential for applications in anti-counterfeiting encryption, stress sensors, and wearable devices. Full article

Recent developments in lighting and display technologies have led to an increased focus on materials and phosphors with high efficiency, chemical stability, and eco-friendliness. Mechanoluminescence (ML) is a promising technology for new lighting devices, specifically in pressure sensors and displays. CaZnOS has been identified as an efficient ML material, with potential applications as a stress sensor. This study focuses on optimizing the mechanoluminescent properties of CaZnOS:Tb through microwave-assisted synthesis. We successfully synthesized CaZnOS doped with Tb3+ using this method and compared it with samples obtained through conventional solid-state methods. We analyzed the material’s characteristics using various techniques to investigate their structural, morphological, and optical properties. We then studied the material’s mechanoluminescent properties through single impacts with varying energies. Our results show that materials synthesized through microwave methods exhibit similar optical and, primarily, mechanoluminescent properties, making them suitable for use in photonics applications. The comparison of the microwave and conventional solid-state synthesis methods highlights the potential of microwave-assisted methods to optimize the properties of mechanoluminescent materials for practical applications. Full article

Electronic skin (e-skin) has the potential to detect large-scale strain, which is typically achieved by integrating multiple strain sensors into an array. However, the latency and limited resolution of sensing have hindered its large-scale sensing applications. Here, we have developed a high-resolution detection sensing system capable of detecting static and dynamic strain with a simple fabrication process by combining capacitive and mechanoluminescent (ML) sensor units. An elastic polydimethylsiloxane (PDMS) composite film doped with ZnS:Cu and BaTiO₃(BT) particles are fabricated as the functional film of the capacitive sensor. In contrast, the transparent electrode was fabricated on the surface of the as-prepared film. By incorporating BT nanoparticles into the elastic substrate, the ML intensity of the ZnS:Cu was improved up to 2.89 times that without BT addition, and the sensitivity of the capacitive sensor was increased as well. The capacitive part of the sensor presented a GF of 0.9 and good stability, while the ML part exhibited excellent performance, making it suitable for both static and dynamic sensing. Furthermore, the strain sensor integrated by 10 × 10 sensing units is demonstrated to detect large-scale strain with high resolution. Moreover, finger joint strain distribution tracking is achieved by attaching the strain sensor unit to the finger joint. With these characteristics, the e-skin may have great potential for bio-motion monitoring and human-computer interaction applications. Full article

It is becoming increasingly important to develop innovative self-powered, low-cost, and flexible sensors with the potential for structural health monitoring (SHM) applications. The mechanoluminescence (ML)-perovskite sensor is a potential candidate that combines the light-emitting principles of mechanoluminescence with the light-absorbing properties of perovskite materials. Continuous in-situ SHM with embedded sensors necessitates long-term stability. A highly stable cesium lead bromide photodetector with a carbon-based electrode and a zinc sulfide (ZnS): copper (Cu) ML layer was described in this article. The addition of a magnesium iodide (MgI₂) interfacial modifier layer between the electron transport layer (ETL) and the Perovskite interface improved the sensor’s performance. Devices with the modified structure outperformed devices without the addition of MgI₂ in terms of response time and impact-sensing applications. Full article

Delamination is a typical defect of carbon fiber-reinforced composite laminates. Detecting delamination is very important in the performance of laminated composite structures. Structural Health Monitoring (SHM) methods using the latest sensors have been proposed to detect delamination that occurs during the operation of laminated composite structures. However, most sensors used in SHM methods measure data in the contact form and do not provide visual information about delamination. Research into mechanoluminescent sensors (ML) that can address the limitations of existing sensors has been actively conducted for decades. The ML sensor responds to mechanical deformation and emits light proportional to mechanical stimuli, thanks it can provide visual information about changes in the physical quantity of the entire structure. Many researchers focus on detecting cracks in structures and impact damage with the ML sensor. This paper presents a method of detecting the delamination of composites using ML sensors. A Convolutional AutoEncoder (CAE) was used to automatically extract the delamination positions from light emission images, which offers better performance compared to edge detection methods. Full article

Non-destructive testing of carbon-fiber-reinforced plastic (CFRP) laminates with bidirectional fiber bundles (twill-weave) using a mechanoluminescence (ML) technique was proposed. The dynamic strain distributions and fracture phenomena of the CFRP laminates in the tensile testing were evaluated by the fabricated ML sensor consisting of SrAl₂O₄:Eu (SAOE) powder and epoxy resin. The ML images for the ML sensor attached to the CFRP laminates with bidirectional fiber bundles gave a net-like ML intensity distribution similar to the original twill weave pattern. Specifically, it was found that the ML intensity on the longitudinal fiber bundle, which is the same as the tensile direction, is higher than that on the transverse fiber bundle. This indicates that the ML sensor can visualize the load share between fiber bundles in different directions of the CFRP laminate with high spatial resolution. Meanwhile, the ML sensor could also visualize the ultrafast discontinuous fracture process of the CFRP laminates and its stress distribution. The amount of SAOE powder in the ML sensor affects the tracking performance of the crack propagation. A higher SAOE amount leads to a fracture of the ML sensor itself, and a lower SAOE amount leads to poor ML characteristics. Full article

Recent developments in sensing technologies have triggered a lot of research interest in exploring novel self-powered, inexpensive, compact and flexible pressure sensors with the potential for structural health monitoring (SHM) applications. Herein, we assessed the performance of an embedded mechanoluminescent (ML) and perovskite pressure sensor that integrates the physical principles of mechanoluminescence and perovskite materials. For a continuous in-situ SHM, it is crucial to evaluate the capabilities of the sensing device when embedded into a composite structure. An experimental study of how the sensor is affected by the embedment process into a glass fiber-reinforced composite has been conducted. A series of devices with and without ML were embedded within a composite laminate, and the signal responses were collected under different conditions. We also demonstrated a successful encapsulation process in order for the device to withstand the composite manufacturing conditions. The results show that the sensor exhibits distinct signals when subjected to different load conditions and can be used for the in-situ SHM of advanced composite structures. Full article

This paper presents a miniature spectrometer fabricated based on a G-Fresnel optical device (i.e., diffraction grating and Fresnel lens) and operated by an image-processing algorithm, with an emphasis on the color space conversion in the range of visible light. The miniature spectrometer will be cost-effective and consists of a compact G-Fresnel optical device, which diffuses mixed visible light into the spectral image and a μ-processor platform embedded with an image-processing algorithm. The RGB color space commonly used in the image signal from a complementary metal–oxide–semiconductor (CMOS)-type image sensor is converted into the HSV color space, which is one of the most common methods to express color as a numeric value using hue (H), saturation (S), and value (V) via the color space conversion algorithm. Because the HSV color space has the advantages of expressing not only the three primary colors of light as the H but also its intensity as the V, it was possible to obtain both the wavelength and intensity information of the visible light from its spectral image. This miniature spectrometer yielded nonlinear sensitivity of hue in terms of wavelength. In this study, we introduce the potential of the G-Fresnel optical device, which is a miniature spectrometer, and demonstrated by measurement of the mechanoluminescence (ML) spectrum as a proof of concept. Full article

The monitoring of stress changes in structural components under various kinds of dynamical loading is crucial for the assessment of their integrity and lifetime. In addition to many methodologies available, such as strain gauges, optical fiber sensors, X-Ray diffraction and digital image correlation, we introduce a novel non-contact method to visualize stress distributions based on mechanoluminescence (ML). ML is a phenomenon occurring in some materials that emit light upon an applied stress level. In this paper, we develop the ML material (Ca_0.4Sr_0.6)Al₂Si₂O₈:1%Eu²⁺,1%Ho³⁺, a glow-in-the-dark material, to visualize stress distribution in a disc, as well as the stress field of an ultrasonic transducer. The properties of defects in the ML phosphors, which are responsible for ML in this material, are vital for stress visualization. Full article
