Adjacent cyclic explosions significantly impact the stability of underground anchored caverns. Based on the similar model test of the vault explosion of the anchored cavern, the dynamic analysis finite element software ANSYS/LSDYNA(18.0) was used to establish a model of the straight wall side explosion of the underground anchored cavern and conduct a numerical simulation. When the total amount of explosion load is the same, we compared the stress time history curve, displacement time history curve, tunnel wall displacement, and circumferential strain curve of the surrounding rock in the underground anchored cavern (under both a high-level single-side blast and a low-level cyclic side blast). We obtained the dynamic response rules of the surrounding rock. By comparing the damage evolution process of the surrounding rock in the two situations, the damage accumulation law of the surrounding rock was analyzed. At the same time, the axial stress distribution characteristics of underground anchor cavern anchors under the action of cyclic explosion were studied. The findings demonstrate that when the total level of blast load adjacent to the cavern is the same, the displacement and circumferential peak strain of surrounding rock and the axial stress of rock bolt in the high-level single explosion are greater than those in the low-level cyclic explosion. However, compared to a single explosion, the rock mass suffers more damage in the cyclic explosion. This study will provide engineers with information that will assist them with a better understanding of the cumulative damage mechanisms of surrounding rock, as well as the stress characteristics of rock bolts under dynamic loads near the explosion site, which will be used to design underground caves with anti-blast features. Full article

This paper presents a part of an extensive experimental campaign performed at the National Technical University of Athens (NTUA) with the purpose of investigating the behavior of chemical anchors embedded in solid brick masonry. Anchors are tested in tension under monotonic or repeated loading. All tests are performed under displacement-controlled conditions. The experimental setup and the instrumentation are presented, along with the investigated parameters and the rationale for the selection of the values of those parameters. In this part of the experimental work, comprising fifty-six (56) tests, the examined parameters are the anchor locations (in mortar joints and in the center of bricks), the state of the substrate (cracked or uncracked), the width of the crack crossing the anchor or at its vicinity (up to 1.20 mm), as well as the loading history (monotonic or repeated). In the tests presented herein, the embedment length of the anchors is equal to 100 mm. The anchors are embedded in solid brick masonry wallettes, and subjected to a normal compressive stress equal to 0.20 MPa. The observed failure modes are explained, and the overall behavior of anchors subjected to tension is presented and commented upon, along with the effect of the investigated parameters on the measured tension resistance, and on the corresponding displacement. Full article

Using a significant number of transverse hoops in the joint’s core is one recognized way for achieving the requirements of strength, stiffness, and ductility under dynamic loading in a column joint. The shear capacity of a joint is influenced by the concrete’s compressive strength, the anchoring of longitudinal beam reinforcement, the number of stirrups in the joint, and the junction’s aspect ratio. Seismic motion on the beam may produce shear capacity and bond breaking in the joint, causing the joint to fracture. Furthermore, due to inadequate joint design and details, the entire structure is jeopardized. In this study, the specimens were divided into two groups for corner and interior beam–column joints based on the joint reinforcement detailing. The controlled specimen has joint detailing as per IS 456:2000, and the strengthened specimen has additional diagonal cross bars (modified reinforcement technique) at the joints detailed as per IS 456:200. The displacement time history curve, load-displacement response curves, load-displacement hysteretic curve, and load cycle vs. shear stress were used to compare the results of the controlled and strengthened specimens. The findings show that adding diagonal cross bars (modified reinforcing techniques) to beam–column joints exposed to cyclic loads enhances their performance. The inclusion of a diagonal cross bar increased the stiffness of the joint by giving an additional mechanism for shear transfer and ductility, as well as greater strength with minimum cracks. Full article

In the present study, the authors attempted to predict the fatigue lifetime of a real-scale integral concrete bridge with H-shaped steel piles resulting from working and environmental conditions. In this regard, various types of nonproportional variable amplitude loads were applied on the bridge, such as temperature variations and sea waves clash. To this end, CATIA software was used to model the real-scale bridge with its accessories, such as a concrete deck, concrete anchors (walls), I-shaped concrete beams (Ribs), and steel piles. Subsequently, stress analysis was performed to determine the critical area apt to fail. The results showed that steel piles are the most critical bridge components. As a result, in future analysis, the purpose will be to study this critical area, and the effect of relative humidity on the fatigue properties of concrete was ignored. Subsequently, the time history of stress tensor components in the critical area was obtained by performing transient dynamic analysis. Various well-known equivalent stress fatigue theories (von Mises, Findley, Dang Van, McDiarmid, Carpinteri–Spagnoli, Modified Findley, Modified McDiarmid, and Liu–Zenner) were utilized to calculate the equivalent stress caused by the simultaneous effect of temperature variations and sea waves clash. Eventually, the fatigue life of the structure was predicted by employing the rainflow counting algorithm and the Palmgren–Miner damage accumulation rule. The results indicated a reduction in the multiaxial fatigue life of the structure under the simultaneous effects of two phenomena, the daily temperature variations and the sea waves clash, of approximately 87% and 66%, respectively, compared with the fatigue life of the structure under either the effect of temperature changes or the effect of sea waves clash, separately. Therefore, it was necessary to consider all the cyclic loads in the structural design step to estimate the fatigue life of the structure. Moreover, the findings of this case study revealed that the lowest value of multiaxial fatigue lifetime is related to the application of the Liu-Zenner criterion. In other words, this criterion is more conservative than the other used criteria. Full article

Preloaded bolted connections are one of the most used approaches for anchoring steel structures and equipment. Preload is induced by a mechanical tightening of the nut with the required torque. In the case of anchor bolts embedded in a concrete base, the prescribed tightening procedure has to be followed for safe and reliable operation. The present paper addresses the problem of anchoring a new casting pedestal using the original anchor bolts. The aim was to verify the original anchoring system’s reliable and safe operation, taking into account the current condition of the bolts. The analysed anchoring bolts are subjected to cyclic (disappearing) stress during the rotation of the casting pedestal. If the interplays between the anchor bolt and the concrete foundation were damaged, production would shut down, resulting in high economic losses. For this reason, the authors used a modified nut with a lightened first thread when investigating the actual state of the anchoring and setting the required preload. The shape and dimensions of the nut were determined based on the results of numerical modelling. The experimental measurements consisted of two phases. In the first phase, the values of axial forces in the anchor bolts at the required preload were set using the designed dynamometers. The second phase was focused on the operational measurements. The methodology of measuring the axial forces and the interpretation of the results obtained, including a comprehensive view of the anchoring safety, provides relevant evidence of the functionality and effectiveness of the proposed solution. Based on the results of the operational measurement and the prescribed handling of the casting pedestal, the lifespan of the anchoring was determined to be 3650 days under the loading cycles to date. Full article

The assessment of already installed anchorages for a possible exceeding of the service load level is a question that is gaining more and more importance, especially in building maintenance. Bonded anchors are of particular interest here, as the detection of a capacity reduction or load exceedance can cause damage to the concrete-bonded mortar behavior. This article investigates the extent to which ultrasonic methods can be used to make a prediction about the condition of anchorages in concrete and about their load history. A promising innovative assessment method has been developed. The challenges in carrying out the experimental investigations are the arrangement of the transducers, the design of the test set-up and the applicability of direct, indirect or semidirect ultrasonic transmission. The experimental investigations carried out on a test concrete mix and a bonded anchor system show that damage to the concrete structure can be detected by means of ultrasound. The results indicate the formation of cracks and therefore a weakening of the response determined by means of direct, indirect and semidirect ultrasonic transmission. However, for application under non-laboratory conditions and on anchors with unknown load history, the calibration with a reference anchor and the identification of the maximum load is required. This enables a referencing of the other loaded anchors to the unloaded conditions and allows an estimation of the load history of individual anchors. Full article

Partial ruptures in the Achilles tendon are rather uncommon and are often misinterpreted as aggravated Achilles tendinopathy, and not always considered as a differential diagnosis. The aim of this literature review was to characterize typical symptoms, to provide an overview of available diagnosis and treatment options, and to give reference points for future research. There were few studies and sparse knowledge of scientific value, making it difficult to give evidence-based recommendations. Based on the few studies and the authors’ clinical experience, a diagnosis should be based on a patient’s history with a typical sharp onset of pain and inability to fully load the tendon. Previous intratendinous cortisone injections might be present. Clinical findings are a localized tender region in the tendon and often weakness during heel raises. Ultrasound and Doppler examinations show a region with an irregular and bulging superficial tendon line, often together with localized high blood flow. Magnetic resonance Imaging (MRI) shows a hyperintense signal in the tendon on T1 and T2-weighted sequences. First-line therapy should be a conservative approach using a 2 cm heel lift for the first 6 weeks and avoiding tendon stretching (for 12 weeks). This is followed by a reduced heel lift of 1 cm and progressive tendon loading at weeks 7–12. After 12 weeks, the heel lift can be removed if pain-free, and the patient can gradually start eccentric exercises lowering the heel below floor level and gradually returning to previous sport level. If conservative management has a poor effect, surgical exploration and the excision of the partial rupture and suturing is required. Augmentation procedures or anchor applications might be useful for partial ruptures in the Achilles insertion, but this depends on the size and exact location. After surgery, the 12 to 14-week rehabilitation program used in conservative management can be recommended before the patient’s return to full tendon loading activities. Full article

In this study, we analyzed the methods and technologies used for constructing earthworks and military engineering in the latter period before the industrial revolution in Poland. The research object, the Warsaw Citadel, is a source of knowledge about military heritage from the aspect of conservation and protection of specific engineering achievements, which were dictated by early Russian geopolitical doctrine. Within the framework of the ongoing project of material heritage protection and popularization of history, the fortress has been transformed into a modern museum building. The new symbolic message of architecture was redefined, leaving behind the gloomy dominance elements in the scenery of the nearby city. In this study, reception tests of ground anchors were used for analysis. They were treated as a tool to determine the heterogeneity of fortification of historical earthworks. In the presented calculation procedure, limitations in the availability of geotechnical tests were overcome. Geological terrain layout and embankment excavation technology significantly impacted their quality and reliability. Currently, the embankments are slashed with anchored retaining walls. Ground anchors were used at short distances and were tested according to the national standard procedures. The results of the load tests are based on the physical properties of the subsoil, the conditions of contact with the supporting elements of the anchors, and the material properties. The soil interaction with the anchors is described using a rheological model, the constants of which were obtained using a fractional derivative model. The spatial variability of the rheological model parameters is presented using theoretical semivariograms matching the empirical data. The semivariograms explain the spatial correlation of the tested constants of the rheological model of the substrate with the anchors. The results of non-destructive testing were influenced by factors such as time and consolidation processes. The obtained results allowed us to directly draw conclusions about the repetitiveness of embankment features and indirectly about the quality of their construction. Full article
