Higher efficiency of rail transportation at the present stage of development of the transport industry necessitates the creation and introduction of rail vehicles with improved technical and economic characteristics among which is reduced tare weight. The issue of reducing the tare weight of wagons is quite urgent. It deals not only with the sprung mass of the wagon but also with the load on the rail track, which is under the influence of constant cyclic loads. Therefore, the present study deals with the development of a wagon covered with tarpaulin for carrying goods requiring protection against the environment. The loads inherent for operation on 1520 mm gauge lines are considered. The covered wagon mod. 11-217 is chosen as a prototype. The profiles of the covered wagon frame components are selected according to the moment of resistance of their cross-sections. It is found that the proposed design has a 16% lower tare weight than that of the prototype. The results of the strength calculation for the wagon under the main design operating modes have proved the feasibility of its structural design. The motion of the covered wagon over a track irregularity has been assessed as ‘excellent’. The results of the study will contribute to the creation of recommendations for the development of modern structures of covered wagons as well as improve the efficiency of railway transportation. Full article

The article presents the results of a determination of the load attributed to rail vehicles transported by a ferry, considering the influence of sea waves on its hull. A mathematic model describing the displacements of a train ferry, which transported rail vehicles on its decks during rolling oscillations, was created. Calculated accelerations were used to identify the load of components from a dynamics point of view and they were subsequently applied as an input to the analysis of the strength of the open wagon main-bearing structure in a standard scheme of interaction with a train ferry deck. The calculated maximal equivalent stresses in the structure of the fastening units exceeded the valid permissible values. To confirm the theoretical results, experimental studies focused on the strength analysis of the open wagon placed on the railway ferry deck, which was performed in real operational conditions. Electrical voltage sensors were used to determine stress distribution in the areas where the body was attached to the deck. In this case, sensors of the strain gauges, i.e., tensiometers, were used. The base of 25 mm is a dimensional parameter and the resistance, 124 Ohms, is the tensiometer parameter. Verification has been performed and, based on the obtained experimental results, it has been established that the hypothesis’ adequacy is not rejected. The authors developed some measures for adaption of the lashing devices for rail cars on train ferries, which can ensure their safe transportation by sea. The strength calculation demonstrated that, in the new scheme of securing the transported railway vehicles on the railway train ferry, the stresses in its structure do not exceed the permissible values. The article also includes information about the results of the strength calculation of a container placed on a roll trailer transported by a train ferry. This research will contribute to the development of measures regarding the safety of railway vehicle transportation by sea ferry and better efficiency of train ferry transportation. Full article

It is proposed to improve hopper wagon design to provide the possibility of simultaneous transportation of different types of cargo. This improvement consists of dividing the body into two separate sections, interacting with each other through a vertical wall and horizontal connecting belts. A calculation by using the FEM in the SolidWorks Simulation has been carried out to determine the strength of the construction of the two-section hopper wagon. The results of the research showed that the maximum load of the hopper wagon occurs in the first design mode (impact). However, the obtained stresses were lower than permissible by 30%. To calculate the indicators of the wagon dynamics, modeling was carried out. All received dynamics indicators were within the permissible limits. For transporting a hopper wagon on railway ferries in international traffic, it is suggested to use units for the fastening chain. Research of the dynamic load of the hopper wagon supporting structure was carried out through mathematical modeling. The strength analysis of the hopper-wagon-bearing structure was carried out. It was found out that the stresses in the hopper wagon structure did not exceed the normative values. The results of the research will contribute to the increased profitability of railway transport. Additionally, the results of the work can be useful in the creation of modern designs of wagons, including for international traffic. Full article

An articulated covered wagon design was developed. The wagon feature is that the body-bearing elements are made of circular pipes. This technical solution made it possible to reduce the tare weight of the wagon while ensuring the strength conditions. Mathematical simulation of the dynamic loading of the developed articulated covered wagon design was carried out under the main operating conditions. In the calculations of the observed quantities, an application of symmetry with regard to the longitudinal axis of the wagon was used. The accelerations, as the components of the dynamic load acting on the wagon, were determined. The dynamic loading computer simulation results of the developed wagon design are also presented. The strength analysis of the articulated covered wagon supporting structure made it possible to conclude that the strength indexes were within the allowed limits. The wagon bearing structure was analyzed for fatigue strength. The weld strength analysis results of the most loaded part of the wagon-bearing structure are presented. The results obtained for the desired quantities revealed their symmetrical distribution in the wagon structure. This research will contribute to improving the efficiency of railway transport operation. Full article

The research is concerned with the use of double walls filled with aluminium foam for an open wagon in order to decrease the dynamic stresses during the operational modes. The research presents the strength calculation for the bearing structure of an open wagon with consideration of the engineering solutions proposed. It was found that the maximum equivalent stresses appeared in the bottom section of the centre sill behind the back support; they amounted to about 315 MPa and did not exceed the allowable values. The maximum displacements were detected in the middle section of the centre sill and amounted to 9.6 mm. The maximum deformations were 1.17 × 10⁻². The research also presents the strength calculation for a weld joint in the maximum loaded zones of the bearing structure of an open wagon and gives the results of a modal analysis of the bearing structure of the improved open wagon. It was found that the critical oscillation frequencies did not exceed the allowable values. The results of the research may be useful for those who are concerned about designing innovative rolling stock units and improving the operational efficiency of railway transport. Full article

This research is concerned with the use of double walls filled with foam aluminum for an open wagon to decrease loading during operational modes. The research presents the strength calculation for the frame of a wagon with a consideration of the engineering solutions proposed. It was found that the maximum equivalent stresses appeared in the bottom section of the center sill behind the back support; they amounted to about 290 MPa and did not exceed the allowable values. The maximum displacements were in the middle parts of the main longitudinal beams of a section, and they amounted to 8.8 mm. The research also presents the strength calculation for a weld joint in the maximum loaded zones of the frame of a wagon and reports the results of the modal analysis of the frame of the improved wagon. It was found that the oscillation frequencies did not exceed the allowable values. The results of the research may be useful for those who are concerned about designing innovative rolling stock units and improving the operational efficiency of railway transport. Full article

The development of foreign economic activity of the Eurasian states led to the introduction of rail and ferry transportation. It is important to note that the current normative documentation does not fully cover the issues of transporting combined trains by sea. This can lead to a violation of the traffic safety of both the railway ferry and the transport of containers as part of combined trains by sea. In this connection, we investigated the dynamic loading of a container as part of a combined train when transported by a railway ferry. To ensure the stability of the container relative to the frame, we suggested an improvement of the load-bearing structure of a flat wagon. Additionally, we suggested the use of a viscous linkage between containers with the aim of reducing their dynamic load. To justify the suggested solutions, we carried out a mathematical modelling of the container dynamic load. The calculation was performed in MathCad. Due to the fact that the container has its own degree of freedom when transported by sea, the accelerations were separately determined for the supporting structure of the flat wagon and for the container. We found that the total amount of acceleration that acted on the container was 3.57 m/s² (0.36 g) and on the load-bearing structure of the wagon was 2.47 m/s² (0.25 g) which were, respectively, 38% and 23% less than the acceleration values in the typical scheme of their interaction. To determine the fields of acceleration distribution relative to the load-bearing structure of a flat wagon with containers, we carried out computer modelling of their dynamic load. The maximum percentage of discrepancy between the accelerations obtained by mathematical and computer modelling was 17.7%. The study will contribute to the creation of recommendations for the safe transport of combined trains by sea, as well as to increasing the efficiency of combined transport through international transport corridors. Full article
