The use of linear array pushbroom images presents a new challenge in photogrammetric applications when it comes to transforming object coordinates to image coordinates. To address this issue, the Best Scanline Search/Determination (BSS/BSD) field focuses on obtaining the Exterior Orientation Parameters (EOPs) of each individual scanline. Current solutions are often impractical for real-time tasks due to their high time requirements and complexities. This is because they are based on the Collinearity Equation (CE) in an iterative procedure for each ground point. This study aims to develop a novel BSD framework that does not need repetitive usage of the CE with a lower computational complexity. The Linear Regression Model (LRM) forms the basis of the proposed BSD approach and uses Simulated Control Points (SCOPs) and Simulated Check Points (SCPs). The proposed method is comprised of two main steps: the training phase and the test phase. The SCOPs are used to calculate the unknown parameters of the LR model during the training phase. Then, the SCPs are used to evaluate the accuracy and execution time of the method through the test phase. The evaluation of the proposed method was conducted using ten various pushbroom images, 5 million SCPs, and a limited number of SCOPs. The Root Mean Square Error (RMSE) was found to be in the order of ten to the power of negative nine (pixel), indicating very high accuracy. Furthermore, the proposed approach is more robust than the previous well-known BSS/BSD methods when handling various pushbroom images, making it suitable for practical and real-time applications due to its high speed, which only requires 2–3 s of time. Full article

Earth-imaging satellites commonly acquire multispectral imagery using linear array detectors formatted as a pushbroom scanner. Landsat 8, a well-known example, uses pushbroom scanning and thus has 73,000 individual detectors. These 73,000 detectors are split among 14 different focal plane modules (FPM), and each detector and FPM exhibit unique behavior when monitoring a uniform radiance value. To correct for each detector’s differences in sensor measurement, a novel technique of relative gain estimation that employs an optimized modified signal-to-noise ratio through a 90${}^{\circ }$ yaw maneuver, also known as side slither, is presented that allows for both FPM and detector-level relative gain calculation. A periodic model based on in-scene FPM corrections was designed as a go-to model for all bands aboard Landsat 8. Relative gains derived from the side-slither technique and applied to imagery provide a visual and statistical reduction in detector-level and FPM-level striping and banding in Landsat 8 imagery. Both reflective and thermal wavelengths are corrected to a level that rivals current operational methods. While Landsat 8 is used as an example, the methodology is applicable to all linear array sensors that can perform a 90${}^{\circ }$ yaw maneuver. Full article

The efficient use of nitrogen fertilizer is a crucial problem in modern agriculture. Fertilization has to be minimized to reduce environmental impacts but done so optimally without negatively affecting yield. In June 2017, a controlled experiment with eight different nitrogen treatments was applied to winter wheat plants and investigated with the UAV-based hyperspectral pushbroom camera Resonon Pika-L (400–1000 nm). The system, in combination with an accurate inertial measurement unit (IMU) and precise gimbal, was very stable and capable of acquiring hyperspectral imagery of high spectral and spatial quality. Additionally, in situ measurements of 48 samples (leaf area index (LAI), chlorophyll (CHL), and reflectance spectra) were taken in the field, which were equally distributed across the different nitrogen treatments. These measurements were used to predict grain yield, since the parameter itself had no direct effect on the spectral reflection of plants. Therefore, we present an indirect approach based on LAI and chlorophyll estimations from the acquired hyperspectral image data using partial least-squares regression (PLSR). The resulting models showed a reliable predictability for these parameters (R²_LAI = 0.79, RMSE_{LAI [m²m⁻²]} = 0.18, R²_CHL = 0.77, RMSE_{CHL [µg cm⁻²]} = 7.02). The LAI and CHL predictions were used afterwards to calibrate a multiple linear regression model to estimate grain yield (R²_yield = 0.88, RMSE_{yield [dt ha⁻¹]} = 4.18). With this model, a pixel-wise prediction of the hyperspectral image was performed. The resulting yield estimates were validated and opposed to the different nitrogen treatments, which revealed that, above a certain amount of applied nitrogen, further fertilization does not necessarily lead to larger yield. Full article

Mars topographic data, such as digital orthophoto maps (DOMs) and digital elevation models (DEMs) are essential to planetary science and exploration missions. The main objective of our study is to generate a higher resolution DEM using the Mars Express (MEX) High Resolution Stereo Camera (HRSC). This paper presents a novel pixel-level image matching method for HRSC linear pushbroom imagery. We suggest that image matching firstly be carried out on the approximate orthophotos. Then, the matched points are converted to the original images for forward intersection. The proposed method adopts some practical strategies such as hierarchical image matching and normalized cross-correlation (NCC). The characteristic strategies are: (1) the generation of a DEM and a DOM at each pyramid level; (2) the use of the generated DEM at the current pyramid level as reference data to generate approximate orthophotos at the next pyramid level; and (3) the use of the ground point coordinates of orthophotos to estimate the approximate positions of conjugate points. Hence, the refined DEM is used in the image rectification process, and pixel coordinate displacements of conjugate points on the approximate orthophotos will become smaller and smaller. Four experimental datasets acquired by the HRSC were used to verify the proposed method. The generated DEM was compared with the HRSC Level-4 DEM product. Experimental results demonstrate that an accurate and precise Mars DEM can be generated with the proposed method. The approximate positions of the conjugate points can be estimated with an accuracy of three pixels at the original image resolution level. Though slight systematic errors of about two pixels were observed, the generated DEM results show good consistency with the HRSC Level-4 DEM. Full article

Epipolar resampling aims to eliminate the vertical parallax of stereo images. Due to the dynamic nature of the exterior orientation parameters of linear pushbroom satellite imagery and the complexity of reconstructing the epipolar geometry using rigorous sensor models, so far, no epipolar resampling approach has been proposed based on these models. In this paper for the first time it is shown that the orientation of the instantaneous baseline (IB) of conjugate image points (CIPs) in the linear pushbroom satellite imagery can be modeled with high precision in terms of the rows- and the columns-number of CIPs. Taking advantage of this feature, a novel approach is then presented for epipolar resampling of cross-track linear pushbroom satellite imagery. The proposed method is based on the rigorous sensor model. As the instantaneous position of sensors remains fixed, the digital elevation model of the area of interest is not required in the resampling process. Experimental results obtained from two pairs of SPOT and one pair of RapidEye stereo imagery with different terrain conditions shows that the proposed epipolar resampling approach benefits from a superior accuracy, as the remained vertical parallaxes of all CIPs in the normalized images are close to zero. Full article

Landsat-7 Enhanced Thematic Mapper Plus (ETM+) and Landsat-8 Operational Land Imager (OLI) and Thermal Infrared Sensor (TIRS) are currently operational for routine Earth observation. There are substantial differences between instruments onboard both satellites. The enhancements achieved with Landsat-8 refer to the scanning technology (replacing of whisk-broom scanners with two separate push-broom OLI and TIRS scanners), an extended number of spectral bands (two additional bands provided) and narrower bandwidths. Therefore, cross-comparative analysis is very necessary for the combined use of multi-decadal Landsat imagery. In this study, 3,311 independent sample points of four major land cover types (primary forest, unplanted cropland, swidden cultivation and water body) were used to compare the spectral bands of ETM+ and OLI. Eight sample plots with different land cover types were manually selected for comparison with the Normalized Difference Vegetation Index (NDVI), the Modified Normalized Difference Water Index (MNDWI), the Land Surface Water Index (LSWI) and the Normalized Burn Ratio (NBR). These indices were calculated with six pairs of ETM+ and OLI cloud-free images, which were acquired over the border area of Myanmar, Laos and Thailand just two days apart, when Landsat-8 achieved operational obit. Comparative results showed that: (1) the average surface reflectance of each band differed slightly, but with a high degree of similarities between both sensors. In comparison with ETM+, the OLI had higher values for the near-infrared band for vegetative land cover types, but lower values for non-vegetative types. The new sensor had lower values for the shortwave infrared (2.11–2.29 µm) band for all land cover types. In addition, it also basically had higher values for the shortwave infrared (1.57–1.65 µm) band for non-water land cover types. (2) The subtle differences of vegetation indices derived from both sensors and their high linear correlation coefficient (R² > 0.96) demonstrated that ETM+ and OLI imagery can be used as complementary data. (3) LSWI and NBR performed better than NDVI and MNDWI for cross-comparison analysis of satellite sensors, due to the spectral band difference effects. Full article
