Uniformity of water distribution plays an important role in evaluating irrigation quality. As necessities in calculating irrigation uniformity during designing a lateral-move sprinkler irrigation system (LMSIS), the water distribution patterns of individual sprinkler in motion are crucial. Considering the limitation of the experiment platform, dynamic water distribution of an isolated sprinkler is difficult to measure, especially for a fixed spray plate sprinkler (FSPS) which LMSIS has been widely equipped with in China, therefore developing a model to simulate dynamic water distribution of a moving sprinkler is necessary. The objective of this study was to develop and validate the theoretical basis for calculating water distribution characteristics of a single FSPS in translational motion applying a superposition method, and provide an optimized operation management of LMSIS. The theoretical model’s validity was verified in an indoor experiment using a Nelson D3000 FSPS in motion with 36 grooves and blue-plate spray heads. The software was programmed using the Eclipse Platform and the software was capable of simulating water distribution pattern and Christiansen uniformity coefficient (Cu). The results indicated that the water distribution simulated by the software presents three peaks of maximum application under varying conditions, and the value of water application peaks decreased as working pressure and/or mounting height increased. Conversely, the wetted diameter increased as working pressure and/or mounting height increased. Working pressure, mounting height, and sprinkler spacing each had a significant effect on the Cu. The Cu increased as working pressure and/or mounting height increased but decreased as sprinkler spacing increased. As a consequence, the model can be used to predict the relative water distribution pattern; and the Cu can be calculated with the simulated data, thus providing a tool for designing a new LMSIS. Full article

Laterally-moving sprinkler irrigation systems under low pressure experience problems including small spraying range, low uniformity, surface runoff, and low water utilization rate. To solve these problems, experiments were carried out on a laterally-moving sprinkler irrigation system using a Nelson D3000 sprinkler (Nelson Irrigation Co., Walla Walla, WA, USA) under low pressure, sinusoidal oscillating water flow. The sprinkler intensity and impact kinetic energy intensity distribution were investigated for sprinklers both static and in motion. The test data were used to calculate combined sprinkler intensity and impact kinetic energy intensity uniformity for different nozzle spacings, and were compared with constant water pressure test results. It was found that sinusoidal oscillating water flow can effectively increase spraying range, as well as reducing the peak value of the sprinkler intensity and impact kinetic energy intensity. Within an optimal range of amplitude and nozzle spacing, sinusoidal oscillating water flow significantly improves the combined sprinkler intensity, impact kinetic energy intensity uniformity, and the spraying quality of laterally-moving sprinkler irrigation systems under low pressure conditions. When the average water pressure is 100 kPa, the optimal range of amplitude of sinusoidal oscillating flow applied to the laterally-moving sprinkler irrigation system is 50–60 kPa. When the amplitude is 50 kPa, the optimal nozzle spacing is 3.5–4 m; when the amplitude is 60 kPa, the optimal nozzle spacing is 3.5–4.5 m. The related parameters can provide a reference for the application of sinusoidal oscillating water flow in laterally-moving sprinkler irrigation systems. Full article

Due to restrictions and limitations on agricultural water worldwide, one of the most effective ways to conserve water in this sector is to reduce the water losses and improve irrigation uniformity. Nowadays, the low-pressure sprinkler has been widely used to replace the high-pressure impact sprinklers in lateral move sprinkler irrigation systems due to its low operating cost and high efficiency. However, the hazard of surface runoff represents the biggest obstacle for low-pressure sprinkler systems. Most researchers have used the pulsing technique to apply variable-rate irrigation to match the crop water needs within a normal application rate that does not produce runoff. This research introduces a variable pulsed irrigation algorithm (VPIA) based on an ON–OFF pulsing technique to conserve irrigation water through (1) decreasing the runoff losses by considering the soil infiltration rate, surface storage capacity, and sprinkler wetting diameter; and (2) ensuring a high level of water distribution uniformity in the direction of machine movement. From a wide range of pulse numbers and widths tested applying a certain water depth to a sandy loam soil, the best solution that gives the lowest runoff and highest uniformity while delivering an acceptable water depth was selected. A MATLAB code was written to simulate the soil infiltration rate, the sprinkler application rate, and to apply the proposed algorithm. The simulation results showed a runoff reduction of at least 90.7% with a high level of distribution uniformity in the direction of movement while delivering the highest possible irrigation depth using the lowest number of pulses. Full article

Sprinkler irrigation systems are widely used in medium and large scale farms in different forms. However less types are available to apply in small farms due to their high costs. The current study was done according to a novel cost effective design for a semi-permanent sprinkler irrigation system for small farm owners. The new layout known as Corner Pivot Lateral (CPL) was examined in irrigation test center at Lijian Scientific and Technological Demonstration Park, at Nanning city, China. CPL was implemented without a main/sub mainline pipe, by applying a single pivoting lateral at the corner of the plot that directly connected to the resource to convey water from the pump. The lateral moves around the corner using a rotating elbow in a quadrant pattern manually to cover the entire farm. A conventional semi-permanent system was applied for the same farm as reference. A cost analysis on the required components as well as annual operational costs was carried out for comparison and control. Results showed that a lower system component would be needed for the CPL method. Overall, more than a 15% capital cost reduction with 7% annual cost decrement was achieved for CPL in this experiment comparatively. The Catch can technique was applied to examine the CPL system’s efficiency and 79% water distribution uniformity around the sprinkler was obtained. This new method can encourage small estate holders to switch from traditional to pressurized systems which optimizes water application costs. Full article

The experiment was done based on a new layout for a semi-permanent set-move sprinkler irrigation system with a lower capital and annual cost requirement. In this work, a center-pivot system layout was applied to set up a semi-permanent system with a hand-move lateral. The clock hand lateral (CHL) sprinkler irrigation system was implemented using a shorter mainline length with a smaller diameter, lesser number of lateral pipes, minimum number of fittings and a single valve outlet. This combination offers an affordable irrigation system with minimizing the required components. The new irrigation system design was examined at the Agricultural Academy of Science experiment farm at Guangxi, China. The sprinkler system mainline pipe directly extended from the water resource to the center of the plot to feed a single lateral, connected through a pivot elbow. The lateral was rotating around the plot manually, the same way as clock hands do. An ordinary set-move split lateral for the same plot was designed for comparison and control. Based on results, a 37.5% capital cost reduction with an 11.2% annual cost decrement was obtained for CHL compared to the set-move semi-permanent. Water application depth was measured via distribution uniformity coefficient (DU) examination, using a catch can method. The low quarter DU for CHL was counted for 86%. Full article
