Spaceborne inverse synthetic aperture ladar (ISAL) can achieve high-resolution imaging of satellite targets. However, because the amplitudes of satellite microvibration are comparable to the ladar wavelength, the echoes will contain both space-variant and space-invariant phase errors. These errors will lead to azimuthal image defocus and impede target analysis and identification. In this paper, we establish a phase error estimation model based on satellite vibration characteristics. Based on this model, we propose a vibration phase error compensation algorithm using prior information and adaptive windowing. Compared to conventional algorithms, this algorithm utilizes prior information to improve estimation accuracy while significantly reducing computational complexity. Furthermore, high-accuracy phase function estimation can be achieved through maximum likelihood estimation and adaptive window filtering, thereby enabling the compensation of vibration phase errors. Both simulation and real imaging experiments validate the effectiveness and robustness of the proposed algorithm. Full article

Inverse synthetic aperture ladar (ISAL) systems combine laser coherent detection technology with inverse synthetic aperture imaging methods, offering advantages such as compact size, long detection range, and high resolution. The traditional optical delay line technique is widely used in frequency-modulated continuous wave (FMCW) ISAL imaging systems, but its flexibility is limited, posing challenges for high-precision signal processing. Additionally, frequency modulation errors, atmospheric disturbances, and other errors inevitably affect image quality. Therefore, this paper proposes a signal processing method based on digital delay for FMCW ISAL, aiming to achieve the high-resolution imaging of targets across several kilometers. Firstly, the paper introduces the FMCW ISAL system. By introducing digital delay technology, it enables the flexible and real-time adjustment of reference signal delay. Next, to address the frequency offset issue caused by the introduction of digital delay technology, a preprocessing method for unified frequency shift correction is proposed to ensure signal consistency. Then, a set of internal calibration signal datasets is generated based on digital delay technology. Following this, a frequency modulation error iteration estimation method based on gradient descent is introduced. Without the need for target echo signals, the method accurately estimates the frequency modulation phase errors of both the transmitted and reference signals using only the internal calibration signals. Finally, this paper effectively decomposes the motion of the target, derives the echo model for the FMCW ISAL system, and constructs compensation functions to eliminate the intra-pulse Doppler shift and the residual video phase (RVP). Additionally, the Phase Gradient Autofocus (PGA) algorithm is used after two-dimensional imaging to eliminate the impact of atmospheric disturbances. We conducted two sets of experiments on point targets and surface targets to verify the effectiveness of error compensation in improving imaging quality. The results show that the two-dimensional resolution of point targets was optimized to 3 cm (range) × 0.6 cm (azimuth), while the resolution and entropy of the surface targets were both improved by 0.1. These results demonstrate that the proposed method effectively enhances target imaging quality and provides a new technical approach for high-precision signal processing in FMCW ISAL imaging. Full article

In response to the application requirement of wide-range high-resolution imaging of non-cooperative moving real targets by inverse synthetic-aperture ladar (ISAL), experiments were conducted on the depolarization effect of target materials, and the polarization selection of ISAL receiving and transmitting channels was discussed. Considering the impact of target depolarization and the demand for along-track interferometry, combined with beam-broaden and high-gain amplifiers, an ISAL system design method that can stably image multiple non-cooperative real targets has been proposed. Under the condition of broadening the transmitting and receiving beams to 3° in the elevation direction for non-cooperative moving vehicles, echo data with a duration of 1 s is obtained. The spatial correlation algorithm combined with along-track interferometry is used to estimate the vibration phase error. The sub-aperture Range-Doppler algorithm is used for imaging. The ISAL imaging results of the moving vehicle validated the high-resolution imaging ability of ISAL and its potential for stable imaging of non-cooperative moving real targets. Full article

Inverse synthetic aperture ladar (ISAL) can achieve high-resolution images for long-range moving targets, while its performance is affected by atmospheric turbulence. In this paper, the dynamic evolution of atmospheric turbulence is studied by using an infinitely long phase screen (ILPS), and the atmospheric coherent time is defined to describe the variation speed of the phase fluctuation induced by atmospheric turbulence. The simulation results show that the temporal decoherence of the echo induced by turbulence causes phase fluctuation and introduces an extra random phase, which deteriorates the phase stability and makes coherent synthesis impossible. Thus, we evaluated its effects on ISAL imaging and found a method to mitigate the impact of turbulence on ISAL images. The phase compensation algorithm could correct the phase variation in different pulses instead of that within the same pulse. Therefore, the relationship between the atmospheric coherent time and pulse duration time (rather than that between the atmospheric coherent time and ISAL imaging time) ultimately determines the ISAL imaging quality. Furthermore, these adverse effects could be mitigated by increasing the atmospheric coherent time or decreasing the pulse duration time, which results in an improvement in the ISAL imaging quality. Full article

When imaging maneuvering targets with inverse synthetic aperture ladar (ISAL), dispersion and Doppler frequency time-variation exist in the range and cross-range echo signal, respectively. To solve this problem, an ISAL imaging algorithm based on integral cubic phase function-fractional Fourier transform (ICPF-FRFT) is proposed in this paper. The accurate ISAL echo signal model is established for a space maneuvering target that quickly approximates the uniform acceleration motion. On this basis, the chirp rate of the echo signal is quickly estimated by using the ICPF algorithm, which uses the non-uniform fast Fourier transform (NUFFT) method for fast calculations. At the best rotation angle, the range compression is realized by FRFT and the range dispersion is eliminated. After motion compensation, separation imaging of strong and weak scattering points is realized by using ICPF-FRFT and CLEAN technique and the azimuth defocusing problem is solved. The effectiveness of the proposed method is verified by a simulation experiment of an aircraft scattering point model and real data. Full article
