As the need for new and advanced space situational awareness systems increases, new technologies for in situ observations are needed. The experimental IoSiS (Imaging of Satellites in Space) system at the German Aerospace Center (DLR) is already capable of high-resolution imaging tasks using inverse synthetic aperture radar technology. As two-dimensional radar images can be difficult to interpret, full three-dimensional imaging is desired. This paper extends the previously published simulation aspects to real ground-based experiments using a single spatially separated receiver, allowing interferometric measurements. However, as interferometry cannot fully resolve a three-dimensional object, more spatially separated receivers are also considered for the use of ISAR tomography to gain experimental insight into true three-dimensional imaging as IoSiS will eventually move toward a tomographic acquisition mode. The results shown here promise a high-resolution imaging method for the future development of IoSiS. Based on the research presented here, additional receivers can be implemented into IoSiS to establish real-world three-dimensional measurements of space objects. Full article

Image registration is essential for applications requiring the joint processing of inverse synthetic aperture radar (ISAR) images, such as interferometric ISAR, image enhancement, and image fusion. Traditional image registration methods, developed for optical images, often perform poorly with ISAR images due to their differing imaging mechanisms. This paper introduces a novel spatial feature-based ISAR image registration method. The method encodes spatial information by utilizing the distances and angles between dominant scatterers to construct translation and rotation-invariant feature descriptors. These feature descriptors are then used for scatterer matching, while the coordinate transformation of matched scatterers is employed to estimate image registration parameters. To mitigate the glint effects of scatterers, the random sample consensus (RANSAC) algorithm is applied for parameter estimation. By extracting global spatial information, the constructed feature curves exhibit greater stability and reliability. Additionally, using multiple dominant scatterers ensures adaptability to low signal-to-noise (SNR) ratio conditions. The effectiveness of the method is validated through both simulated and natural ISAR image sequences. Comparative performance results with traditional image registration methods, such as the SIFT, SURF and SIFT+SURF algorithms, are also included. Full article

An Interferometric Inverse SAR system is able to perform 3D imaging of non-cooperative targets by measuring their responses over time and through several receiving antennas. Phase differences between signals acquired with a spatial diversity in vertical or horizontal directions are used to localize moving scatterers in 3D. The use of several receiving channels generally results into a costly and complex hardware solution, and this paper proposes performing this multichannel acquisition using a single receiver and a hardware compressive device, based on a chaotic cavity which simultaneously multiplexes in the spectral domain signals acquired over different antennas. The radar responses of the scene are encoded in the spectral domain onto the single output of a leaky chaotic cavity, and can be retrieved by solving an inverse problem involving the random transfer matrix of the cavity. The applicability of this compressed sensing approach for the 3D imaging of a non-cooperative target using low-complexity hardware is demonstrated using both simulations and measurements. This study opens up new perspectives to reduce the hardware complexity of high-resolution ISAR systems. Full article

Interferometric inverse synthetic aperture radar (InISAR) has received significant attention in three-dimensional (3D) imaging due to its applications in target classification and recognition. The traditional two-dimensional (2D) ISAR image can be interpreted as a filtered projection of a 3D target’s reflectivity function onto an image plane. Such a plane usually depends on unknown radar-target geometry and dynamics, which results in difficulty interpreting an ISAR image. Using the L-shape InISAR imaging system, this paper proposes a novel 3D target reconstruction algorithm based on Dechirp processing and 2D interferometric ISAR imaging, which can jointly estimate the effective rotation vector and the height of scattering center. In order to consider only the areas of the target with meaningful interferometric phase and mitigate the effects of noise and sidelobes, a special cross-channel coherence-based detector (C3D) is introduced. Compared to the multichannel CLEAN technique, advantages of the C3D include the following: (1) the computational cost is lower without complex iteration and (2) the proposed method, which can avoid propagating errors, is more suitable for a target with multi-scattering points. Moreover, misregistration and its influence on target reconstruction are quantitatively discussed. Theoretical analysis and numerical simulations confirm the suitability of the algorithm for 3D imaging of multi-scattering point targets with high efficiency and demonstrate the reliability and effectiveness of the proposed method in the presence of noise. Full article

The imaging quality of InISAR under squint geometry can be greatly degraded due to the serious interferometric phase ambiguity (InPhaA) and thus result in image distortion problems. Aiming to solve these problems, a three-dimensional InISAR (3D ISAR) imaging method based on reference InPhas construction and coordinate transformation is presented in this paper. First, the target’s 3D coarse location is obtained by the cross-correlation algorithm, and a relatively stronger scatterer is taken as the reference scatterer to construct the reference interferometric phases (InPhas) so as to remove the InPhaA and restore the real InPhas. The selected scatterer needs not to be exactly in the center of the coarsely located target. Then, the image distortion is corrected by coordinate transformation, and finally the 3D coordinates of the target can be accurately estimated. Both simulation and practical experiment results validate the effectiveness of the method. Full article

Terahertz (THz) imaging technology has received increased attention in recent years and has been widely applied, whereas the three-dimensional (3D) imaging for moving targets remains to be solved. In this paper, an adaptive 3D imaging scheme is proposed based on a single input and multi-output (SIMO) interferometric inverse synthetic aperture radar (InISAR) imaging system to achieve 3D images of moving targets in THz band. With a specially designed SIMO antenna array, the angular information of the targets can be determined using the phase response difference in different receiving channels, which then enables accurate tracking by adaptively adjusting the antenna beam direction. On the basis of stable tracking, the high-resolution imaging can be achieved. A combined motion compensation method is proposed to produce well-focused and coherent inverse synthetic aperture radar (ISAR) images from different channels, based on which the interferometric imaging is performed, thus forming the 3D imaging results. Lastly, proof-of-principle experiments were performed with a 0.2 THz SIMO imaging system, verifying the effectiveness of the proposed scheme. Non-cooperative moving targets were accurately tracked and the 3D images obtained clearly identify the targets. Moreover, the dynamic imaging results of the moving targets were achieved. The promising results demonstrate the superiority of the proposed scheme over the existing THz imaging systems in realizing 3D imaging for moving targets. The proposed scheme shows great potential in detecting and monitoring moving targets with non-cooperative movement, including unmanned military vehicles and space debris. Full article

Translational motion of a target will lead to image misregistration in interferometric inverse synthetic aperture radar (InISAR) imaging. In this paper, a strong scattering centers fusion (SSCF) technique is proposed to estimate translational motion parameters of a maneuvering target. Compared to past InISAR image registration methods, the SSCF technique is advantageous in its high computing efficiency, excellent antinoise performance, high registration precision, and simple system structure. With a one-input three-output terahertz InISAR system, translational motion parameters in both the azimuth and height direction are precisely estimated. Firstly, the motion measurement curves are extracted from the spatial spectrums of mutually independent strong scattering centers, which avoids the unfavorable influences of noise and the “angle scintillation” phenomenon. Then, the translational motion parameters are obtained by fitting the motion measurement curves with phase unwrapping and intensity-weighted fusion processing. Finally, ISAR images are registered precisely by compensating the estimated translational motion parameters, and high-quality InISAR imaging results are achieved. Both simulation and experimental results are used to verify the validity of the proposed method. Full article

The all solid-state terahertz (THz) radar has obvious miniaturized integration and high resolution imaging advantages compared with conventional microwave radar. In this paper, a 0.22 THz active frequency-modulated pulse radar system with one transmission channel and four receiving channels is presented, and interferometric inverse synthetic aperture radar (InISAR) imaging experiments, which can acquire altitude information of objects, are carried out. In order to acquire high-quality InISAR images, a calibration method is presented to solve the nonlinearity of wideband signal frequency and phase inconsistency of different receiving channels together. Furthermore, to deal with the phase wrapping in InISAR imaging of objects with large scale, a novel method based on the dominant scatterers to estimate the objects rotation rate is presented. Finally, to show more information of objects in the InISAR images, the imaging results with a large rotation angle by the convolutional back-projection algorithm are obtained. The imaging results verify the superior performance of the multi-channel THz radar system and the imaging processing method, which can provide support for further research on InISAR imaging in the THz band. Full article

This paper proposes a new interferometric near-field 3-D imaging approach based on multi-channel joint sparse reconstruction to solve the problems of conventional methods, i.e., the irrespective correlation of different channels in single-channel independent imaging which may lead to deviated positions of scattering points, and the low accuracy of imaging azimuth angle for real anisotropic targets. Firstly, two full-apertures are divided into several sub-apertures by the same standard; secondly, the joint sparse metric function is constructed based on scattering characteristics of the target in multi-channel status, and the improved Orthogonal Matching Pursuit (OMP) method is used for imaging solving, so as to obtain high-precision 3-D image of each sub-aperture; thirdly, comprehensive sub-aperture processing is performed using all sub-aperture 3-D images to obtain the final 3-D images; finally, validity of the proposed approach is verified by using simulation electromagnetic data and data measured in the anechoic chamber. Experimental results show that, compared with traditional interferometric ISAR imaging approaches, the algorithm proposed in this paper is able to provide a higher accuracy in scattering center reconstruction, and can effectively maintain relative phase information of channels. Full article

Interferometric inverse synthetic aperture radar (InISAR) imaging for sparse-aperture (SA) data is still a challenge, because the similarity and matched degree between ISAR images from different channels are destroyed by the SA data. To deal with this problem, this paper proposes a novel SA–InISAR imaging method, which jointly reconstructs 2-dimensional (2-D) ISAR images from different channels through multiple response sparse Bayesian learning (M-SBL), a modification of sparse Bayesian learning (SBL), to achieve sparse recovery for multiple measurement vectors (MMV). We note that M-SBL suffers a heavy computational burden because it involves large matrix inversion. A computationally efficient M-SBL is proposed, which, proceeding in a sequential manner to avoid the time-consuming large matrix inversion, is denoted as sequential multiple sparse Bayesian learning (SM-SBL). Thereafter, SM-SBL is introduced to InISAR imaging to simultaneously reconstruct the ISAR images from different channels. Numerous experimental results validate that the proposed SM-SBL-based InISAR imaging algorithm performs superiorly against the traditional single-channel sparse-signal recovery (SSR)-based InISAR imaging methods in terms of noise suppression, outlier reduction and 3-dimensional (3-D) geometry estimation. Full article
