In order to provide a theoretical basis for the thermal analysis and management of spacecraft/payload interstellar pointing attitudes, which are used for inter-satellite communication, this paper develops an analytical method for solar heat flux under pointing attitudes. The key to solving solar heat flux is calculating the angle between the sun vector and the normal vector of the object surface. Therefore, a method for calculating the included angle is proposed. Firstly, a coordinate system was constructed based on the pointing attitude. Secondly, the angle between the coordinate axis vector and solar vector variation with a true anomaly was calculated. Finally, the reaching direct solar heat flux was obtained using an analytical method or commercial software. Based on the proposed method, the direct solar heat flux of relay satellites in commonly used lunar orbits, including Halo orbits and highly elliptic orbits, was calculated. Thermal analysis on the payload of interstellar laser communication was also conducted in this paper. The calculated temperatures of each mirror ranged from 16.6 °C to 21.2 °C. The highest temperature of the sensor was 20.9 °C, with a 2.3 °C difference from the in-orbit data. The results indicate that the external heat flux analysis method proposed in this article is realistic and reasonable. Full article

A stable and high-precision autonomous orbit determination scheme for a Low Lunar Orbit (LLO) spacecraft is proposed, leveraging satellite-to-satellite tracking (SST) measurement data and lunar laser ranging data. One satellite orbits around the LLO, while the other satellite orbits around the Distant Retrograde Orbit (DRO). An inter-satellite ranging link is established between the two satellites, while the LLO satellite conducts laser ranging with a Corner Cube Reflector (CCR) on the lunar surface. Both inter-satellite ranging data and lunar laser ranging data are acquired through measurements. By integrating these data with orbital dynamics and employing the Extended Kalman Filter (EKF) method, the position and velocity states of the two formation satellites are estimated. This orbit determination scheme operates independently of ground measurement and control stations, achieving a high degree of autonomy. Simulation results demonstrate that the position accuracy of the LLO satellite can reach 0.1 m, and that of the DRO satellite can reach 10 m. Compared to the autonomous orbit determination scheme relying solely on SST measurement data, this proposed scheme exhibits several advantages, including shorter convergence time, higher convergence accuracy, and enhanced robustness of the navigation system against initial orbit errors and orbital dynamic model errors. It can provide a valuable engineering reference for the autonomous navigation of lunar-orbiting satellites. Full article

Traditional spacecraft orbit determination primarily employs two methodologies: ground station/survey ship-based orbit determination and global navigation satellite system (GNSS)-based orbit determination. The ground tracking measurement system, reliant on multiple tracking stations or ships, presents a less favorable efficiency-to-cost ratio. For high-orbit satellites, GNSS orbit determination is hindered by a limited number of receivable satellites, weak signal strength and suboptimal geometric configurations, thereby failing to meet the demands for the continuous, high-precision orbit measurement of overseas high-orbit satellites. Satellite navigation systems, characterized by global coverage and Ka-band inter-satellite links, offer measurement and communication services to extended users, such as satellites, aircraft, space stations and other spacecraft. With the widespread adoption of navigation satellite systems, particularly in scenarios where ground tracking, telemetry and command (TT&C) stations are out of sight, there is a growing demand among users for Ka-band inter-satellite links for high-precision ranging and orbit determination. This paper introduces an innovative unidirectional orbit-determination technology for extended users, leveraging the navigation Ka-band inter-satellite link. When extended users are constrained by weight and power consumption limitations, preventing the incorporation of high-precision atomic clocks, they utilize their extensive capture capability to conduct distance measurements between navigation satellites. This process involves constructing clock error models, calculating clock error parameters and compensating for these errors, thereby achieving high-precision time–frequency synchronization and bidirectional communication. The technology has enhanced the time and frequency accuracies by three and two orders of magnitude, respectively. Following the establishment of bidirectional communication, unidirectional ranging values are collected daily for one hour. Utilizing these bidirectional ranging values, a mechanical model and state-transfer matrix are established, resulting in orbit-determination calculations with an accuracy of less than 100 m. This approach addresses the challenge of high-precision time–frequency synchronization and orbit determination for users without atomic clocks, utilizing minimal inter-satellite link time slot resources. For the first time in China, extended users can access the navigation inter-satellite link with a minimal allocation of time slot resources, achieving orbit determination at the 100 m level. This advancement significantly enhances the robustness of extended users and provides substantial technical support for various extended users to employ the Ka inter-satellite link for emergency communication and orbit determination. Full article

In the near future, international space agencies have planned to achieve significant milestones in investigating the utilization of Global Navigation Satellite Systems (GNSS) within and beyond the current space service volume up to their application to lunar missions. These initiatives aim to demonstrate the feasibility of GNSS navigation at lunar altitudes. Based on the outcomes of such demonstrations, dozens of lunar missions will likely be equipped with a GNSS receiver to support autonomous navigation in the lunar proximity. Relying on non-invasive, consolidated differential techniques, GNSS will enable baseline estimation, thus supporting a number of potential applications to lunar orbiters such as collaborative navigation, formation flight, orbital manoeuvers, remote sensing, augmentation systems and beyond. Unfortunately, the large dynamics and the geometry of such differential GNSS scenarios set them apart from current terrestrial and low-earth orbit use cases. These characteristics result in an increased sensitivity to measurements time misalignment among orbiters. Hence, this paper offers a review of baseline estimation methods and characterizes the divergences and limitations w.r.t. to terrestrial applications. The study showcases the estimation of the baseline length between a lunar CubeSat mission, VMMO, and the communication relay Lunar Pathfinder mission. Notably, real GNSS measurements generated by an Engineering Model of the NaviMoon receiver in the European Space Agency (ESA/ESTEC) Radio Navigation Laboratory are utilized. A radio-frequency constellation simulator is used to generate the GNSS signals in these hardware-in-the-loop tests. The performed analyses showed the invalidity of common terrestrial differential GNSS ranging techniques for space scenarios due to the introduction of significant biases. Improved ranging algorithms were proposed and their potential to cancel ranging errors common to both receivers involved was confirmed. Full article

This paper investigates the distributed formation control of a group of leader-following spacecraft with bounded actuation and limited communication ranges. In particular, connectivity-preserving and collision-avoidance controllers are proposed for the leader with constant or time-varying velocity, respectively. The communication graph between the spacecraft is modeled via a distance-induced proximity graph. By designing a virtual proxy for each spacecraft, the spacecraft–proxy couplings address the actuator saturation constraints. The inter-proxy dynamics incorporated with a bounded artificial potential function fulfill the coordination of all proxies. In addition, the bounded potential function can simultaneously tackle connectivity preservation and collision avoidance problems. The distributed formation controllers are proposed for multiple spacecraft with constant or time-varying velocities relative to the leader. A sliding mode control approach and the proxies’ dynamics are used in the design of a distributed cooperative controller for spacecraft to address the cooperative problem between the followers and the leader. Numerical simulations confirm the effectiveness of the anti-saturation distributed connectivity preservation controller. Full article

For space-based gravitational wave detection, a laser interferometric measurement system composed of a three-spacecraft formation offers the most rewarding bandwidth of astrophysical sources. There are no oscillators available that are stable enough so that each spacecraft could use its own reference frequency. The conversion between reference frequencies and their distribution between all spacecrafts for the synchronization of the different metrology systems is the job of the inter-spacecraft frequency setting strategy, which is important for continuously acquiring scientific data and suppressing measurement noise. We propose a hierarchical optimization algorithm to solve the frequency setting strategy. The optimization objectives are minimum total readout displacement noise and maximum beat-note frequency feasible range. Multiple feasible parameter combinations were obtained for the Taiji program. These optimized parameters include lower and upper bounds of the beat note, sampling frequency, pilot tone signal frequency, ultrastable clock frequencies, and modulation depth. Among the 20 Pareto optimal solutions, the minimum total readout displacement noise was 4.12 $\mathrm{pm}/\sqrt{\mathrm{Hz}}$, and the maximum feasible beat-note frequency range was 23 MHz. By adjusting the upper bound of beat-note frequency and laser power transmitted by the telescope, we explored the effects of these parameters on the minimum total readout displacement noise and optimal local laser power in greater depth. Our results may serve as a reference for the optimal design of laser interferometry system instrument parameters and may ultimately improve the detection performance and continuous detection time of the Taiji program. Full article

Autonomous navigation and orbit determination are key problems of asteroid exploration missions. Inter-satellite range link is a type of measurement widely used in the orbit determination of Earth satellites, but not so widely used in missions around small bodies. In our study, we assume that highly accurate inter-satellite range data can be obtained around small bodies between the chief spacecraft and some low-cost deputies, and study the feasibility of simultaneous autonomous orbit determination of the spacecraft and the gravity-field recovery without the support from ground stations. After the feasibility analysis, two modified methods are proposed. Both methods demonstrate obvious improvements in both the convergence region and the accuracy. One remark is that the inter-satellite range data can be also used together with various observation data from ground stations to enhance the accuracy of the determined orbits and the gravity field. Full article

This paper presents a solution for autonomous orbit determination and time synchronization of spacecraft in Halo orbits around Lagrange points using inter-satellite links. Lagrange points are stable positions in the gravitational field of two large bodies that allow for a sustained presence of a spacecraft in a specific region. However, a challenge in operating at these points is the lack of fixed landmarks for orbit determination. The proposed solution involves using inter-satellite links to perform range and range-rate measurements, allowing for accurate computation of the spacecraft’s orbit parameters without the need for any facilities on Earth. Simulations using a fleet of three satellites in Near Rectilinear Halo Orbits around the Earth–Moon Lagrange point, proposed for the Lunar Gateway stations, were conducted to demonstrate the feasibility of the approach. The results show that inter-satellite links can provide reliable and accurate solutions for orbit determination with a DRMS error lower than one meter (90th percentile) and synchronization errors of around one nanosecond. This solution paves the way for a fully autonomous fleet of spacecraft that can be used for observation, telecommunication, and navigation missions. Full article

The GRACE follow-on satellites carry the very first interspacecraft Laser Ranging Interferometer (LRI). After more than four years in orbit, the LRI outperforms the sensitivity of the conventional Microwave Instrument (MWI). However, in the current data processing scheme, the LRI product still needs the MWI data to determine the unknown absolute laser frequency, representing the “ruler” for converting the raw phase measurements into a physical displacement in meters. In this paper, we derive formulas for precisely performing that conversion from the phase measurement into a range, accounting for a varying carrier frequency. Furthermore, the dominant errors due to knowledge uncertainty of the carrier frequency as well as uncorrected time biases are derived. In the second part, we address the dependency of the LRI on the MWI in the currently employed cross-calibration scheme and present three different models for the LRI laser frequency, two of which are largely independent of the MWI. Furthermore, we analyze the contribution of thermal variations on the scale factor estimates and the LRI-MWI residuals. A linear model called Thermal Coupling (TC) is derived, which significantly reduces the differences between LRI and MWI to a level where the MWI observations limit the comparison. Full article

The spacecraft tracking telemetering and command (TT&C) system plays an essential role in celestial and terrestrial networks, requiring relative ranging and communication, particularly in satellite formation flying networks and distributed spacecraft networks. To achieve precious ranging and high-data-rate communication in a Master/Slave satellite architecture, an integrated communication-ranging system (ICRS) is introduced. ICRS is based on the inter-satellite spread spectrum ranging and spread/non-spread spectrum communication modulated by unbalanced quadrature phase shift keying (UQPSK). In both uplink and downlink, the in-phase (I) branches and the quadrature (Q) branches undertake the tasks of ranging and communication, respectively. In addition, a global navigation satellite system (GNSS) like signal is adopted in I branches for the sake of better ranging accuracy, and binary phase shift keying (BPSK) modulation is employed in Q branches for a higher data rate. Therefore, the key point of the ICRS design is the power resource allocation between two branches via the selection of a suitable power distribution factor (PWDF). Simulation results demonstrate the good performance of the proposed approach in ranging error and bit error rate (BER). In addition, a reasonable PWDF is recommended. Furthermore, the influence of clock offset is also taken into consideration. Full article

Global navigation satellite systems (GNSS) are widely used in low Earth orbit (LEO) satellite navigation; however, their availability is poor for users in medium Earth orbits (MEO), and high Earth orbits (HEO). With the increasing demand for navigation from MEO and HEO users, the inadequate coverage of GNSS has emerged. Inter-satellite links (ISLs) are used for ranging and communication between navigation satellites and can also serve space users that are outside the navigation constellation. This paper aims to summarize their application method and analyze their service performance. The mathematical model of visibility is proposed and then the availability of time division ISLs is analyzed based on global grid points. The BeiDou navigation constellation is used as an example for numerical simulation. Simulation results show that the availability can be enhanced by scheduling more satellites and larger beams, while the presence of more users lowers the availability. The availability of navigation signals will be strengthened when combined with the signals from the ISLs. ISLs can improve the space service volume (SSV) of navigation constellations, and are therefore a promising method for navigation in MEO/HEO spacecraft. Full article
