The growth of MAPbBr₃ crystal-faced films is a critical challenge for advancing optoelectronic devices. This study presents a methodology for fabricating a (100) crystal-faced MAPbBr₃ film on a lattice-matched MgO/TiN composite substrate using a localized thermally driven inverse temperature crystallization technique. The metallic TiN buffer layer offers a 0.66% lattice mismatch to MAPbBr₃, minimizing interfacial strain. Furthermore, the orientation enhancement of the film induced by post-annealing was confirmed by X-ray diffraction, with the (200) peak FWHM decreasing from 0.042° to 0.028° and the intensity ratio of the (100) to (110) peaks increasing from 6.89 to 19.00. These structural improvements directly translate into enhanced optical performance. The annealed sample exhibited sharper Raman phonon modes at 49 cm⁻¹ and 151 cm⁻¹, a 1.8-fold photoluminescence intensity enhancement, and a 20.8% narrowing of the PL FWHM at 536 nm. Additionally, UV-Vis spectroscopy confirms the bandgap of MAPbBr₃, displaying a steeper absorption edge with a bandgap of 2.30 eV. These metrics provide compelling evidence of suppressed non-radiative recombination and improved optical homogeneity after annealing. By integrating TiN as an electron-transport and buffer layer to reduce strain and lattice mismatch, the MgO/TiN/MAPbBr₃ architecture offers a scalable, scientifically grounded pathway to improve MAPbBr₃’s optical performance. Full article

This paper presents the concept of a 2D m × n waveguide-based power combiner (PC) that is scalable with respect to the operating frequency band and number of input ports. To our knowledge, this work reports the first planar (2D) power combiner, where the input waveguide ports are distributed in two spatial dimensions to form an array, rather than arranged along a single linear (1D) axis as in conventional corporate or cascaded waveguide combiners. The novelty of the approach relies on using H-plane rectangular waveguide T-junctions and low-loss polarization twisters in between vertically stacked T-junctions to facilitate scalability. The work is motivated by the aim to coherently combine the output power of multiple modified uni-traveling carrier (MUTC) terahertz (THz) waveguide photodiodes (PDs) in a 2D array configuration. In the manuscript, the design of a 2 × 2 planar waveguide power combiner for the WR3 band (220–320 GHz) is reported, and it is also shown that this block can be further extended to m × n input ports. Full-wave numerical analysis of the proposed 2 × 2 power combiner shows a return loss of 11 dB at the output port and an average transmission coefficient of about −6.5 dB, i.e., an overall power combining efficiency of ~90%. Furthermore, to enable 2D photodiode array integration, the manuscript presents a new slot-bow tie antenna integrated MUTC photodiode for radiating the optically generated THz power from each PD vertically into the rectangular waveguide. The simulation results of reflection loss and insertion loss for the slot bow-tie antenna are shown to be better than 10 dB and 1.4 dB over the full WR3 band, respectively. To prove scalability of the power combiner concept w.r.t. the number of input ports, a 2 × 4 power combiner is also analyzed. Results reveal a return loss better than 10 dB from 225 to 318 GHz and a transmission coefficient of approximately −9.7 dB at 300 GHz, i.e., a power combining efficiency of ~85%. Full article

Circularly polarized (CP) organic light-emitting diodes (CP-OLEDs) have attracted considerable attention due to their promising applications in next-generation display systems, optical data transmission, and quantum computing, and their potential roles in medical devices. Achieving efficient and tunable CP emission remains a significant challenge, prompting the development of various strategies that leverage organic semiconductors. Notably, certain classes of materials now consistently deliver CP polarization at levels suitable for technological applications. Among these, conjugated polymers, particularly the copolymer poly(9,9-dialkylfluorene-alt-benzothiadiazole) (PFBT), stand out for their exceptional optoelectronic properties, ease of processing, and adaptability to produce CP emission. PFBT has played diverse roles within CP-OLED devices, enabling innovative architectural solutions. This review explores principal strategies for integrating PFBT into CP-OLED architectures, drawing upon findings from the recent scientific literature. By consolidating current knowledge and identifying unresolved issues, this work aims to inspire further research into the development of solution-processable, high-performance and tunable CP-OLEDs based on PFBT and conjugated polymers in general. Full article

High-fidelity star field simulation is paramount for target detection and space situational awareness (SSA) in geostationary and deep-space environments. However, accurately modeling the synergistic effects of ultra-dense stellar backgrounds and complex platform perturbations remains a formidable challenge. This paper proposes an integrated simulation framework that leverages the Gaia catalog to generate high-precision stellar environments. The core methodological novelty lies in the end-to-end coupling of a full optoelectronic imaging chain with dynamic platform disturbances, effectively bridging the gap between theoretical orbital dynamics and realistic sensor responses. Distinguishing itself from conventional models, our approach uniquely integrates radiative transfer and high-fidelity noise suites—including photon shot noise and non-uniform stray light—while utilizing the Gaia catalog to achieve unprecedented precision in simulating dim stars at low magnitudes. The fidelity of the proposed model was quantitatively validated against empirical data from a ground-based wide-field telescope (GTC). Experimental results, derived from multiple simulation realizations, demonstrate high consistency with real-world observations, achieving a Signal-to-Noise Ratio (SNR) error of less than 10% and a sub-pixel centroiding accuracy exceeding 0.01 pixels. This work provides a robust, high-fidelity data synthesis tool that significantly advances the development of target detection algorithms and the performance optimization of space-based optical sensors. Full article

Metal–organic chemical vapor deposition (MOCVD) is a crystal growth technique used to achieve high-purity thin films, especially III–V materials, for fabricating semiconductor devices. It allows for thickness tunability, controlled doping, and composition of epilayers. This review focuses on the principle of MOCVD, its historical background, and its applications in III–V semiconductor devices such as solar cells, high electron mobility transistors (HEMTs), light-emitting diodes (LEDs), laser diodes (LDs), and photonic integrated circuits (PICs). This review highlights the recent developments in MOCVD aimed at improving its efficiency, performance, and sustainability. Finally, we emphasize emerging trends and challenges in MOCVD process innovation, reactor design, and material integration that are poised to drive the development of next-generation optoelectronic, photonic, and quantum technologies. Together, these findings underscore MOCVD’s pivotal role in enabling high-performance devices and sustaining leadership in post-Moore semiconductor technologies. Full article

Organic solar cells require molecular materials with broad absorption and proper energy-level alignment to maximize photon harvesting and charge transport; in this context, this work focuses on the computational design and characterization of π-conjugated push–pull chromophores, providing an integrated evaluation of their electronic, thermodynamic, and optoelectronic properties for photovoltaic applications. The chromophores were optimized using DFT/ b3lyp/6-31g+(d,p) in Gaussian16, incorporating solvation effects through the CPCM model. Electronic, thermodynamic, and optical properties were investigated using DFT and TD-DFT/CAM-B3LYP/6-311+G(d,p), including the calculation of absorption and emission spectra, first hyperpolarizability, and two-photon absorption. The STQ-PP chromophores exhibit differentiated optoelectronic responses, with DTTQ-DPP-1 showing an energy gap of 0.82–0.86 eV, stabilized LUMO levels between −2.50 and −2.61 eV, high electronic polarizability, and optical absorption extended beyond 800 nm, favoring the harvesting of low-energy photons, whereas DTTQ-DPP displays a gap close to 2.70 eV and absorption predominantly localized in the UV region, associated with potentially inferior photovoltaic performance. Compared with commercial donor materials, DTTQ-DPP-1 exhibits a red-shifted absorption into the NIR and a smaller gap, indicating enhanced low-energy photon capture; its structural stability and increased rigidity further support its photovoltaic viability. Full article

A multiple strong coupling system comprising monolayer MoS₂ and Ag nanodisk (Ag-ND) arrays is investigated using transient absorption (TA) spectroscopy. By tuning the diameter and period of the Ag-NDs arrays, the surface plasmon polariton (SPP) resonances are made to simultaneously overlap with the A (~660 nm) and B (~608 nm) excitons of monolayer MoS₂. As a result, three distinct negative ground-state bleaching (GSB) peaks, corresponding to the upper (UP), middle (MP), and lower (LP) hybrid polariton states, were observed in the TA spectra. This confirms that a multiple strong coupling regime was achieved with both the A and B excitons of monolayer MoS₂ and SPPs modes, which was also highlighted by the anti-crossing behavior across varied Ag-NDs arrays parameters. Finally, by adding an insulating spacer layer of Al₂O₃ film, the coupling strength can be modulated from a strong coupling regime to a weak coupling regime. These results reveal a multi-exciton–plasmon strong coupling system and establish a versatile platform for ultrathin polaritonic devices, including polariton lasers and all-optical switches. Full article

Silicon photonic integrated circuit (Si-PIC) components/devices based on silicon-on-insulator (SOI) waveguides have become critical components in modern optoelectronic information systems. This investigation systematically examines optical propagation losses (OPLs) induced by the sidewall roughness (SWR) of a waveguide through comparative analysis of two scattering-loss theoretical frameworks: the SWR-improved Payne–Lacey (P-L) three-dimensional (3-D) formalism and Hörmann’s 3-D perturbation model. Crucially, our computational results identify SWR = 10 nm as the convergence threshold where both models exhibit consistent OPL predictions across waveguide architectures. Single-mode SOI rib waveguides with 0.5 µm high ribs on 2.0 µm silicon film and a 2.0 μm BOX layer were designed and fabricated using the classic ICP-RIE technique. Furthermore, SWRs of 28 nm were obtained with confocal laser scanning microscopy for SOI waveguides, leading to OPLs of 2.66 and 2.67 dB/cm for TE and TM modes, respectively, from the 2-D SWR-enhanced P-L model, and 1.7 and 1.9 dB/cm, respectively, from the Hörmann 3-D model. Finally, the average experimental result of OPL for the same waveguide was 2.61 dB/cm, showing a strong agreement with the numerical values of the SWR-improved P-L 3-D formalism, providing a robust framework for optimizing industrial-grade SOI waveguide-based PIC devices/components. Full article

Chemical monitoring of pollutants and hazardous materials in water supply systems traditionally depends on centralized laboratories, advanced instrumentation, and trained personnel, limiting accessibility and preventing real-time, on-site analysis. This work presents an alternative cost-effective, field-deployable approach that uses genetically engineered bioluminescent bioreporters, encapsulated in self-sufficient alginate capsules and integrated with an optoelectronic detection circuit, to detect and quantify target materials in water. We have developed a scalable single-channel prototype featuring four sensing tracks—two for sample measurement, one for clean water, and one for a standard reference solution. The latter employs the standard ratio (SR) method to ensure robust quantification, compensating for batch variability and environmental effects. System characterization showed high uniformity across tracks. Validation with nalidixic acid (NA) demonstrated reliable quantitative performance, with a blind test estimation of 5.6 mg/L for a true concentration of 5 mg/L, well within the calibration error range. Additional sensitivity testing confirmed detection of mitomycin C (MMC) at concentrations as low as 50 µg/L. Overall, the results highlight the potential of bacterial chemical sensing as a practical and scalable tool for real-time, in situ water quality monitoring networks. Full article

This study presents a SCAPS-1D-based numerical optimization of an organic ultraviolet (UV) photodetector employing an FTO/PTB7/Spiro-OMeTAD/Au device architecture. The novelty of this work lies in a simulation-guided, UV-specific optimization strategy that combines thickness engineering, controlled doping, and contact work-function tuning to achieve intrinsic spectral selectivity without external optical filters. We systematically optimize material and device parameters, including active layer thicknesses, donor and acceptor densities, and the metal electrode work function, to enhance responsivity, detectivity, and spectral performance. Simulations identify optimal thicknesses of 1200 nm for PTB7 and 1000 nm for Spiro-OMeTAD, with donor concentrations of 1 × 10²⁰ cm⁻³ and 1 × 10¹⁸ cm⁻³, respectively. A comparative contact analysis demonstrates that replacing aluminum with gold (Au) forms a near-ohmic back contact, leading to improved hole extraction and suppressed dark current due to favorable energy-level alignment. The optimized device achieves a peak external quantum efficiency of approximately 80% in the 300–400 nm ultraviolet range, with a responsivity up to 0.4 A/W. The UV selectivity originates from the absorption characteristics of PTB7 combined with suppressed long-wavelength charge collection, resulting in a negligible response in the visible–near-infrared region. These results confirm the device’s strong potential for high-sensitivity, solar-blind UV photodetection. By integrating practical material selection with physically consistent SCAPS-1D optoelectronic modeling, this work provides a robust design framework to guide the development of next-generation organic UV photodetectors for environmental sensing, biomedical diagnostics, and wearable optoelectronics. Full article

Amorphous gallium oxide thin-film transistor photodetectors are promising for ultraviolet detection because of their wide bandgap and low dark current. Magnetron sputtering is compatible with low-temperature processing, but device performance is sensitive to sputtering conditions. Poor parameter choices can introduce oxygen vacancies and interface charges, degrading optoelectronic performance. Here, a three-factor, three-level orthogonal design is used to vary sputtering power, Ar/O₂ flow ratio, and film thickness. Nine device sets are fabricated and compared based on transfer characteristics and transient photocurrent–time (I-t) responses measured at a wavelength of 254 nm, with clear differences observed among process combinations. To identify the origin of these differences, representative samples with significant responsivity variations were modeled using TCAD. By fitting the simulated I-t curves to measured transients, the interface fixed charge density and defect-state densities were extracted, and the photon absorption distribution of different samples was analyzed. This analysis, from both defect and UV absorption perspectives, revealed the reasons for the differences in responsivity. The absorption coefficients at 254 nm measured by ellipsometry for the two samples were also compared, and the absorption trends observed in both the simulation and ellipsometry were consistent, confirming the accuracy of the simulation results. This work presents an integrated experimental and TCAD approach for process optimization and mechanistic analysis of a-GaO_x TFT-PDs. Full article

The significant disparity between the size and electronegativity of N and group-V (P, As, Sb) atoms in dilute III–V-Ns remains a cornerstone for developing the next-generation electronics. Variations in the structural, optical, and phonon properties of the quaternary GaAs_1−x−ySb_yN_x alloys are being used for improving the high-performance photovoltaic energy and optoelectronic technologies. Bandgap ${\mathrm{E}}_{\mathrm{g}}$ tunability has assisted efficient light emission/detection to cover the crucial optical fiber wavelengths for the low-cost integrated chips in data communications and sensing devices. The lattice dynamical properties of these materials are critical for assessing the reliability to evaluate the performance of long-wavelength lasers, photodetectors, and multi-junction solar cells. Our systematic Raman measurements on high-quality MBE grown $\mathrm{G}\mathrm{a}{\mathrm{A}\mathrm{s}}_{0.946}{\mathrm{S}\mathrm{b}}_{0.032}{\mathrm{N}}_{0.022}$/GaAs samples have detected ${\mathsf{\omega }}_{\mathrm{T}\mathrm{O}\left(\mathsf{\Gamma }\right)}^{\mathrm{G}\mathrm{a}\mathrm{A}\mathrm{s}}$ and ${\mathsf{\omega }}_{\mathrm{T}\mathrm{O}\left(\mathsf{\Gamma }\right)}^{\mathrm{G}\mathrm{a}\mathrm{A}\mathrm{s}}$ phonons along with a high frequency N_As local mode near ~476 cm⁻¹. Weak phonon structures on both sides of the broad 476 cm⁻¹ band are interpreted forming a complex N_As–Ga–Sb_As defect center. Using a realistic rigid-ion model in the Green’s function framework, the simulations of impurity modes for isolated and complex defects have provided corroboration to the experimental data. Full article

Terahertz (THz) technology is finding increasingly widespread applications in biosensing, high-speed communication, and stealth materials. Meanwhile, graphene, as a quintessential two-dimensional material, has emerged as a core component of THz devices due to its unique optoelectronic properties. However, the precise and non-destructive characterization of the complex conductivity of graphene at the microscopic scale remains a formidable challenge. Conventional measurement methods often suffer from limitations associated with contact resistance or intricate sample preparation processes. In this paper, we propose a non-invasive parameter inversion method based on deep learning. We design a tri-layer graphene-silica-copper metasurface structure featuring a central cavity and establish a high-fidelity scattering model that incorporates physical effects such as edge diffraction and multi-mode resonance. Utilizing the Radar Cross Section (RCS) data generated by this model, we train a Deep Enhanced Conductivity Predictor (DECP) network integrated with a Convolutional Block Attention Module (CBAM). Experimental results demonstrate that the proposed network can accurately reconstruct the complex conductivity of graphene from far-field RCS data. The coefficients of determination (R²) for the prediction of both real and imaginary parts exceed 0.99, with a Root Mean Square Error (RMSE) as low as the order of 10⁻⁵. This study not only validates the effectiveness of data-driven approaches in material characterization but also provides a novel paradigm for the real-time monitoring and intelligent design of terahertz metasurfaces. Full article

Fluorescence remains a foundational optical phenomenon underpinning applications in sensing, imaging, diagnostics, and catalysis. Among the strategies developed to modulate fluorescence, coupling fluorophores with plasmonic metals has emerged as a powerful route for both enhancement and quenching. The collective excitation and decay of surface plasmons can profoundly alter fluorophore excitation rates, radiative pathways, and emission efficiencies. This review provides a mechanistic and historical synthesis of metal–fluorophore interactions, unifying enhancement and quenching phenomena under the term Metal Manipulated Fluorescence (MMF). We summarize the fundamental principles of fluorescence and plasmon resonance, discuss theoretical and computational approaches for predicting metal–fluorophore coupling, and critically examine recent advances in plasmonic nanostructure synthesis that enable precise control over fluorophore behaviour. By integrating experimental observations with theoretical models, we highlight the opportunities and limitations of current MMF strategies and outline future directions in materials design, synthesis methodologies, and predictive modelling for next-generation optical and optoelectronic technologies. Full article

Quantum dots combine advantages such as strong processability via solution methods, wide color gamut coverage, and precise emission color coordinates, making them highly promising for applications in optoelectronic devices. However, they face limitations such as insufficient fluorescence intensity and low far-field extraction efficiency. Plasmonic nanocavities based on metallic nanostructures offer an efficient platform for regulating light–matter interactions. In this study, we constructed a tilted plasmonic nanocavity structure composed of a silver nanocube, CdSe/CdS nanorods, and a single-crystal silver microplate. An Al₂O₃ isolation layer prepared via atomic layer deposition was used to control the nanocavity gap, precisely matching the plasmonic resonance mode with the 620 nm fluorescence emission of the quantum dots. This coupling system significantly enhances the radiative rate in the emission band and the electric field strength in the excitation band, achieving a 187-fold luminescence enhancement of the quantum dot. Additionally, leveraging the nano-antenna effect, the fluorescence exhibits upward directional emission. Experimental and simulation results confirm the high-efficiency enhancement and directional control of quantum dot fluorescence by the tilted nanocavity, providing new insights for the integrated application of quantum dots in displays, quantum communication, and other fields. Full article
